Ecliptech Shift-i User manual

Install guide for Shift-i in a
1998 to 2002 Ford Falcon

1. Take off the 2 screw covers for the Instrument cluster shown below and undo the 2 Phillips head
screws holding the cluster in. Push down at the base of the cluster near the odometer display then
pull the cluster out using the 2 screw holes at the top.
2. Disconnect the connections at the back of the cluster (Mid and Hi series cluster have 3 connectors
one on the left and 2 on the right)
3. Once disconnected we need to concentrate on the left hand side connector. You need to locate the
following wires
- Pin 1 – Black = Ground
- Pin 4 – Red & Dark Green = Ignition
- Pin 16 – Pink & White or Pink & Blue = Tacho input 0 to +12v pulsed

4. You need to run the wiring depending on where you want the Shift-i to sit. This one is running
down the steering column and into the dash area just below the cluster.
5. Splice into the wires and solder the corresponding wires using the table below.
Wire Cluster Color Shift-i Color
Ground Black Black
Ignition Red & Dark Green Black & Red
Tacho Input Pink & White or Pink & Blue Black & Blue
6. Once you have soldered the wires and have used the electrical insulation tape to stop the wires
touching and shorting out. Then connect the cluster and switch the ignition on and the Shift-i unit
should light up if not refer to the manual troubleshooting.
7. Once everything is working put the cluster back in and then you can mount the Shift-i user some
wax & grease remover to clean the surface before applying the double sided tape.
8. Calibrate the unit according to the manual and to your required driving style

Here is a List of pin outs for the left had side connector for the cluster handy to locate the wires if
unsure.
AUI Falcon Low/Mid/High Series Instrument Cluster
Right Hand Side Instrument Cluster Connector (Common for all models - J2)
Pin 1 Power Ground Ground Black
Pin 2 Signal Ground Ground Black / Light Green
Pin 3 Low Coolant Resistance Yellow / Red
Pin 4 Ignition Power +12V with Ignition On Red / Dark Green
Pin 5 Low Oil Warning (Low Series)
Oil Pressure (Mid/High Series) 0V Low Oil 0V Low Pressure, 12V High Pressure White / Red
Pin 6 Door Ajar (Low / Mid Series)
Front Drivers Door open (High Series) Ground when any door open Ground when Drivers door open Black / Light Blue (Low/Mid) White (Hi)
Pin 7 Fuel Sender Resistance Yellow / Dark Green
Pin 8 Spare (Low and Mid Series)
MDC Tx Data (High Series) Output to Trip/Climate Control Center Orange
Pin 9 Spare (Low and Mid Series)
MDC Rx Data (High Series) Input from Trip/Climate Control Center Yellow
Pin 10 Low Washer Fluid Input Switch to ground for low fluid Pink / Yellow
Pin 11 Spare (Low Series) Traction Control Warning Lamp (Mid/High
Series) Ground to Illuminate Dark Blue
Pin 12 Airbag Audible warning Open Collector Orange / Yellow
Pin 13 EEC V Data (Serial) Open Collector (Sheilded Data Line)
Pin 14 Diagnostic ISO Serial I/O Open Collector Pullup Batt Not Connected
Pin 15 LCD Dimmer Input 2 Stage (Low Series)
LCD Dimmer Input Variable (Mid/High Series) Ground/Resistance Open Collect PWM Output from Bem White
Pin 16 Tacho Input Pulsed from 0V to +12V White / Pink
Pin 17 Speed Input Pulsed from 0V to +12V Light Blue / White (Hi) / White (Low)
Pin 18 Speed Output Pulsed form 0V to +12V White
Pin 19 Speedo Sender power supply +8.2V Red (Hi) / Yellow/Light Green (Low)
Pin 20 Battery Power +12V Black / Orange
