Eco Pure EPWUFF User manual

Manufactured and warranted by
Ecodyne Water Systems
1890 Woodlane Drive
Woodbury, MN 55125
How to install, operate and
maintain your Undersink Full
Flow Water Filtration System
Model EPWUFF
System tested and certified by NSF International
against NSF/ANSI Standards 42 & 53.
See performance data sheet for details.
201-8401220 (Rev. 02 1/2/18)
Ins alla ion and Opera ion Manual
If you have any questions or concerns when
installing, operating or maintaining your water
filtration system, call our toll free number:
1-800-693-1138
or visit www.ecopure.com
When you call, please be prepared to provide
the model number and date code of
your product, found on the filter head.
PR DUCT AND WARRANTY
REGISTRATI N
Register your product
online to validate and
extend your warranty.
See warranty page for
details.
www.ecopure.com

2
TABLE F C NTENTS
Page
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications & Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts & Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Typical Undersink Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Filter Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Filter Cartridge ife . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Filter Cartridge Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Exploded View & Parts ist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
WARRANTY
UNDERSINK FULL FL W WATER FILTRATI N SYSTEM - M DEL EPWUFF
(not including filter cartridges)
Warrantor: Ecodyne Water Systems, 1890 Woodlane Drive, Woodbury, MN 55125
ne Year Warranty:
Warrantor guarantees, to the original owner, that the Undersink Full Flow Water Filtration System (EPWUFF), when
installed and maintained in accordance with the instructions, will be free from defects in materials and workmanship for a
period of one (1) year from the date of purchase.
Lifetime Warranty:
Warrantor guarantees, to the original owner only, that the Undersink Full Flow Water Filtration System (EPWUFF) will be
free from defects in materials and workmanship for the lifetime of the owner, provided that:
● The system is installed and maintained in accordance with the instructions in the same home where it was originally
installed.
● The owner replaces the filter every six (6) months and registers their purchase of the EcoPure EPWURF filter cartridge
on www.ecopure.com. Purchase of no more than two (2) EPWURF filter cartridges in a 12 month period may be
applied toward compliance with this warranty.
Failure to adhere to the above requirements from the date of purchase voids the lifetime warranty.
If, during such respective periods, a part proves, after inspection, to be defective, Warrantor will, at its sole option, either
replace or repair the part without charge except normal shipping and installation charges. abor to maintain the equipment
is not part of the warranty. Filters, which are expendable, are not covered by the warranty.
TO OBTAIN WARRANTY PARTS, SIMP Y CA 1-800-693-1138 for assistance. This warranty applies only while this
product is in use in the United States or Canada.
General Provisions
The above warranties are effective provided the Undersink Full Flow Water Filtration System is operated at water pres-
sures not exceeding 100 psi, and at water temperatures not exceeding 100°F; provided further that the Undersink Full Flow
Water Filtration System is not subject to abuse, misuse, alteration, neglect, freezing, accident or negligence; and provided
further that the Undersink Full Flow Water Filtration System is not damaged as the result of any unusual force of nature
such as, but not limited to, flood, hurricane, tornado or earthquake.
Warrantor is excused if failure to perform its warranty obligations is the result of strikes, government regulation, materials
shortages, or other circumstances beyond its control.
*THERE ARE N WARRANTIES N THE UNDERSINK FULL FL W WATER FILTRATI N SYSTEM BEY ND TH SE
SPECIFICALLY DESCRIBED AB VE. ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY F MER-
CHANTABILITY R F FITNESS F R A PARTICULAR PURP SE, ARE DISCLAIMED T THE EXTENT THEY MIGHT
EXTEND BEY ND THE AB VE PERI DS. THE S LE BLIGATI N F WARRANT R UNDER THESE WAR-
RANTIES IS T REPLACE R REPAIR THE C MP NENT R PART WHICH PR VES T BE DEFECTIVE WITHIN
THE SPECIFIED TIME PERI D, AND WARRANT R IS N T LIABLE F R C NSEQUENTIAL R INCIDENTAL DAM-
AGES. N WARRANT R DEALER, AGENT, REPRESENTATIVE, R THER PERS N IS AUTH RIZED T EXTEND
R EXPAND THE WARRANTIES EXPRESSLY DESCRIBED AB VE.
Some states do not allow limitations on how long an implied warranty lasts or exclusions or limitations of incidental or con-
sequential damage, so the limitations and exclusions in this warranty may not apply to you. This warranty gives you spe-
cific legal rights, and you may have other rights which vary from state to state. This warranty applies to consumer-owned
installations only.
EXTEND Y UR WARRANTY:
Register your EcoPure replacement filter purchases
You can turn your water filtration system’s one year factory warranty into a lifetime warranty by registering your pur-
chases of EcoPure replacement filter cartridges. See “ ifetime Warranty” below for details.

14-1/2"
4" 3"
1"
3
Before You S ar
Specifica ions & Dimensions
qRead all steps and guides carefully before installing and using your undersink full flow water filtration
system. Follow all steps exactly to correctly install. Reading this manual will also help you to get all
the benefits from the filtration system.
qDo not use with water that is microbiologically unsafe or of unknown quality without adequate disinfec-
tion before or after the system. This system is certified for cyst reduction and may be used on disin-
fected waters that may contain filterable cysts.
qAll plumbing should be done in accordance with local codes and requirements. In Massachusetts,
plumbing code 248 CMR 3.00 and 10.00 shall be adhered to. Consult with your licensed plumber.
qThe undersink full flow water filtration system works on water pressures of 30 psi (minimum) to 100 psi
(maximum). If your house water pressure is over the maximum, install a pressure reducing valve in
the water supply pipe to the filtration system.
qDo not install the filtration system outside, or in extreme hot or cold temperatures. Temperature of the
water supply to the filtration system must be between 40°F and 100°F. Do not install on hot water.
4” FIG. 1
14-1/2”
3”
Supply Water Pressure Min. - Max. 30 - 100 psi (207 - 689 kPa)
Supply Water Temperature Min. - Max. 40 - 100 °F (4 - 38 °C)
Rated Service Flow 2.0 gallons per minute (7.57 liters per minute)
Inlet - Outlet 3/8" quick connect fittings and tubing included
1”
Questions? Call Toll Free 1-800-693-1138 or visit www.ecopure.com
When you call, please be prepared to provide the model number and date code, found on the filter head.

1"
4
Par s & Tools
Typical Undersink Ins alla ion
ocate the water filter housing on the cold water supply pipe, under the kitchen and/or bathroom sink, to
filter the cold water. Refer to the following drawing.
=Filter head, bracket & mounting screws
=Filter cartridge
=Tubing
=Faucet adaptor
=Slotted and Phillips screwdrivers
=Pliers and adjustable jaw wrench
=Tubing cutter
=Electric drill
=Teflon tape
FIG. 2
N TE: Be sure to allow a minimum space of 1-1/2” under the
system for removing the filter cartridge to change it.
1”
mounting
screws (2)
3/8” tubing
to faucet
UTLET
blue collar on
push-in fitting
INLET
yellow collar on
push-in fitting
3/8” tubing
from cold
water supply
SINK
HOT C LD
shutoff valve
filtered water
faucet
OUT ET
IN ET
Included:
Not Included:

5
Ins alla ion Ins ruc ions
Step B - Make Tubing Connections
N TE: Remove protective foam plugs before connecting tubes (See Fig. 4). Discard foam plugs.
1. ocate the piece of supplied 3/8" tubing not used previously. Route it between the union connector
and the filter system outlet (See Figures 2 & 3). Allowing some slack, measure and cut to length. Cut
the ends of the tubing square.
2. Insert tubing all the way into the union connector and filter system outlet. Pull on the tubing to be
sure that it's held firmly in the fittings.
3. Repeat steps 1 and 2 to connect the tube installed on the cold water shutoff to the filter system inlet.
Tubing Connection (all push-in fitting locations):
This system includes push-in fittings for quick tubing connections. When working with the fittings, do the
following.
continued on the next page
Step A - Install Water Supply Fittings
Check and comply with local plumbing codes as you plan, then install the fittings to connect the
undersink filter into the sink’s cold water supply line. Fittings (9/16-24 thread) and 3/8” O.D. tubing are
included to provide connections to and from the undersink filter’s inlet and outlet. A typical connection
using the included water supply fittings is shown in Figure 3.
1. Close the sink’s water shut off valve(s), or another shut off valve upstream from where you will
install the filter, and open faucets to relieve pressure from the sink’s cold water supply line.
2. ocate the line connecting the cold water shutoff to the sink faucet. Typically this line will be a flexible
hose. Disconnect the nut that connects this line to the cold water shutoff. Use a bucket to catch water
that drains from this line.
3. ocate one piece of the supplied 3/8” tubing, plus the supplied compression nut, ferrule and tubing
insert (See Fig. 3). Assemble the parts onto the tube, as shown in Figure 3, and thread the compres-
sion nut onto the cold water shutoff. Tighten to provide a leak-tight connection.
4. ocate the water supply adaptor (supplied) and, using thread sealing tape, install it into the nut on the
supply line which you disconnected in Step 2. Refer to Figure 3.
5. Press the stem of the water supply adaptor into one end of the supplied union connector (See Figure
3). Be sure to push the stem all the way in.
insert
ferrule
compression
nut
3/8" tubing to
water filter
IN ET
use thread
sealing tape
on threads
cold water shutoff filter system assembly
cold water
shutoff
SINK
filtered water faucet
OUT ET
IN ET
water supply
adaptor
flexible connection
to faucet use thread sealing
tape on threads
3/8" tubing from
water filter
OUT ET
union
connector
FIG. 3

6
Ins alla ion Ins ruc ions
To Disconnect Tubing:
1. Push the collet inward and hold with a finger while pulling the tubing out.
tubing
collet (depress to remove tubing)
end of tubing round and smooth,
with no cuts, nicks or flat spots
correct full 3/4" engagement
Tubing correctly cut and connected
Incorrect partial engagement
Remove and discard foam plugs
foam plug
push in fitting
continued from the previous page
Connect Tubing:
1. Use a tube cutter to cut the end of tubing square.
2. Inspect the end (about 1") of the tubing to be sure there are no nicks, scratches or other rough spots.
If needed cut the tubing again.
3. Push tubing through the collet and all the way into fitting. Full engagement is 3/4" length of tube into
the fitting.
FIG. 4
FIG. 5
Step D - Turn On Water, Check for eaks and Rinse Carbon Fines
1. Open the shutoff valve(s) that you closed at the beginning of this installation.
2. Open the filtered water faucet to purge air from the system. When the water runs smooth, with no
bubbles or spurting, close faucet and check installation for leaks.
3. Open the filtered water faucet and let water run for 10 minutes to rinse out carbon fines.
Step C - Install the Filter Cartridge
1. Remove the small plastic shipping cap from the open end of the filter cartridge.
2. Install the cartridge onto the water filter head assembly, as shown in Figure 6. Turn cartridge to the
right to tighten.

7
Fil er Car ridges
Filter Cartridge ife
Taste and dor Cartridges: A taste and odor cartridge contains activated carbon. When new, open the
filtered water faucet and allow fine, carbon particles to purge from the cartridge. Flush for 10 minutes. It
is recommended to replace filter cartridge every six months of use. There are several variables that
determine how long a cartridge will last. These include:
1. How much water you use, and
2. How much sediment, taste and/or odor, or other unwanted substance, is in the water.
Use the following information as a guide. However, no matter which type of cartridge you are using, you
will know it is time to replace them when you first notice the return of the unwanted sediment, taste
and/or odor in your water, or when the flow diminishes or stops.
EcoPure Undersink Full Flow Water Filtration System model EPWUFF with replacement element
EPWURF conforms to NSF/ANSI 42 and 53 for the specific performance claims as verified and substan-
tiated by test data. The rated capacity for this system is 2000 gallons (7570 liters) at a rated service flow
of 2.0 gallons per minute (7.57 liters per minute).
Filter Cartridge Replacement
N TE: There is no need to shut off the water supply when replacing the filter cartridge.
1. Turn filter cartridge to the left to remove cartridge from the filter head.
2. Dispose of the cartridge in a proper manner.
3. Install new cartridge. Turn cartridge to the right to re-attach to the filter head.
Taste and dor Cartridges: Taste and odor cartridges contain activated carbon, a black powder.
When new, open the filtered water faucet and allow fine, carbon particles to purge from the cartridge.
Flush for 10 minutes.
FIG. 6
head
filter cartridge
Turn filter cartridge to the left
to remove from head
Turn filter cartridge to the right
to attach to head
Questions? Call Toll Free 1-800-693-1138 or visit www.ecopure.com
When you call, please be prepared to provide the model number and date code, found on the filter head.

8
Troubleshoo ing he Sys em
Problem: Taste and/or Odor.
Cause: Filter cartridge exhausted. Correction: Replace filter cartridge.
Cause: System contaminated. Correction: Sanitize system. Call 1-800-693-1138 for instructions.
Problem: Water leaks at push connect fittings.
Cause: Tubing not pushed in all the way. Correction: Push tubing in all the way into fittings.
Cause: Tubing not cut square. Correction: Cut tubing square.
Cause: Tubing nicked. Correction: Remove nicked portion, reinsert tubing into fitting.
Cause: Outer tubing surface not smooth. Correction: Remove rough portion, reinsert tubing into fitting.
Par s Lis
2
1
3
7
4
5
9
6
8
Parts Bag
To order repair parts call toll free 1-800-693-1138.
ÙPlease purchase replacement cartridges from the retailer where you
bought your water filtration system.
¢Not illustrated.
Key No. Part No. Description
1 1042-45-HA Head Assembly with Quick Connect Fittings
– 1042-45-AC Parts Bag (includes Key Nos. 2-7)
2áMounting Screws (2)
3áWater Supply Adaptor
4áUnion Connector, 3/8” to 3/8”
5áCompression Nut, 3/8”
6áFerrule, Plastic, 3/8”
7áTubing Insert, 3/8”
8 EPWURF Repl. Filter Cartridge, Taste & Odor Ù
9 7168435 Tubing, 3/8” OD x 72” long, White
¢201-8401220 Owner’s Manual
Manufactured and warranted by
Ecodyne Water Systems
1890 Woodlane Drive
Woodbury, MN 55125
