eCoaster WLEC15 User manual

User Manual
eCoaster Bluetooth Smart Scales
Model No.: WLEC15
FCC ID: 2AJS9WLL

I. Product
Introduction
Thank you for choosing eCoaster Bluetooth Smart Scale. To ensure proper
operation and to maintain the lifespan and the utmost accuracy of the scale,
please read this manual carefully before use.
Read this Instruction Manual carefully and keep it for future reference.
Warnings:
This product is suitable for adults use only.
Improper operation or disassembling may result in irreversible damage to this
product or may cause injury to user.
Damage caused by improper operation or disassembling is not covered by
warranty.
We do NOT accept any liability for damages caused by improper operation or
disassembling.
II. Constraints of Use
Working temperature: 0℃-50℃Avoid Water
Avoid Magnetization Load limit: 5Kg
III. Parts included in this package:
Name Quantity
eCoaster Bluetooth Smart Scale 1
USB Cable 1
User Manual 1

IV. Specifications
Load Limit 5000 g 11 lb 175 oz
Degree of Accuracy 1g 0.1 lb 0.1 oz
Temperature Range 0℃~50℃
Product sizes 105mm X105mm X 12mm
Length * Width * Height
Battery type Lithium-ion rechargeable 3.7V 600mAh
Display Screen LED displays
Button Type Capacitive touch buttons
Bluetooth Connection Bluetooth 4.0
Stand-by time 7 days in the default mode
V. Product View

VI. LED readout and lights description
[UNIT]
LED Display
[g] Gram
[lb] Pound
[oz] Ounce
Blue Light
ON Scale On
Flash Weighing in progress /low temperature alarm
OFF Sleep Mode
[BLUE]－
LED Display
ON Bluetooth Connected
Flash Waiting for Bluetooth pairing
OFF Bluetooth Disconnected
Green Light
ON Pre-tare function is on and it turns off in 3
seconds after weighing
Flash Alarm Ringing
OFF Pre-tare function off
Yellow Light
ON Post-tare function is on and it turns off in 3
seconds after weighing
Flash Alarm Ringing
OFF Post-tare function off
Red Light ON Low battery
Flash Alarm ringing／high temperature alarm

VII. Operating Instruction
Operating Instructions
Function Button
name Procedures
Weigh the
tare first Tare Button
1 Place the container on the scale
2 Press the button once to turn on the green light
3 Wait until the reading returns to zero
4Put the food in the container and the blue light is
flashing
5 When the blue light is static, the reading is shown.
Weigh the
tare after Tare Button
1Place the container and food on and the blue light
begins to flash
2When the blue light stops flashing, the reading is
shown
3Remove the food and the container
The reading returns to zero
4Put the container on and the blue light begins to
flash
5Wait until the blue light stops flashing and the
reading is shown
6Press the function button twice to turn on the
orange light
7The weight of the container flashes 3 times and
then the food weight reading is shown on screen.
VIII. Other functions：
A. Digital Room Thermometer function:
This Bluetooth scale can be used as room Thermometer to measure and
display room temperature (working range 0℃-50℃). User can also set alarm
to alert if the room temperature goes beyond their pre-set temperature range.
(Please refer to APPs help for more details)
B. LED Alarm Clock function:
This scale can be used for LED clock display via Bluetooth. When
connected to a mobile device via Bluetooth, clock time can be set manually or
will be automatically updated. User can set up to 3 alarms which flashes in 3
different colours. (Please refer to APPs help for more details)

C. Saving mode and Stand-by mode:
User can set the scale in Saving mode or Stand-by mode from apps.
D. The scale has 3 levels of brightness to choose from.
E. Thescalehas3displayoptions:
Clock only, Digital Thermometer only, or Clock and Digital
Thermometers (displays switch every 2 seconds between two functions).
IX. Error Info
Display info Error info
Overload
Low battery
X. More functions and App downloads:
Please check our website www.wlinks.uk for details.
XI. FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
XII. RF warning statement:
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
