EcoBurner ECOSERVE GN User manual

ECOSERVE GN
INSTRUCTIONS FOR USE
FOLDING LEGS:
The legs fold neatly so that the EcoServe GN can be stacked and stored away conveniently.
1. Lay the EcoServe GN upside down on a so surface to prevent scratching.
2. To unfold the legs, firstly move and hold
the locking levers (1) in the direction shown
by the arrow cut-outs. Then fold the legs (2)
to the upright position in the direction of the
green arrows.
1. Locking Levers
2. Folding Legs
3. Outer Spring Clips
4. Central Spring Clip
5. Knurled Nuts
6. Locking Screws
7. Hot Air Cover
1
2
3
4
5/6
7
Thank you for purchasing this EcoServe GN. It is a
waterless replacement for chafing dishes that keeps
food warm using the EcoBurner, or cool using the
EcoServe Cool Pack. Please follow the use and care
instructions to ensure it retains its high quality finish.
WARNING: The EcoServe GN is only to be used with
the EcoBurner and EcoBurner fuel. Any other heat
source will cause damage that can not be repaired.
3. To fold the legs for stacking and storing
away, move and hold the locking levers (1) in
the direction shown by the arrow cut-outs.
Then fold the legs to the stowed position as
shown by the green arrows.
5/6
1
Scan here
for video
instructions

FITTING & LIGHTING THE ECOBURNER:
The EcoServe GN may be powered by one or two EcoBurners. Powering with one EcoBurner
is suitable for most indoor uses. Powering with two is best suited to outdoor use.
1. For even heat distribution when powering
with just one EcoBurner, the EcoBurner
should be fitted in the Central Spring Clip
position (4) as shown in the diagram above.
1. The legs should be in the unfolded position before
beginning.
2. Lay the EcoServe GN upside down on a so surface to
prevent scratching.
3. Unscrew both Knurled Nuts(5) and li the cover away
from the Locking Screws(6). When refitting, be careful to
align the cover holes with the Locking Screws(6).
4. All parts of the EcoServe GN should be wiped clean with
a damp cloth to retain the best quality finish. Do not use
abrasive cleaners as these will damage the product.
2. When powering with two EcoBurners, it is
only possible to fit them in the Outer Spring
Clip positions (3) as shown in the diagram
above.
3. To fit the EcoBurner, first light the EcoBurner
as normal. The burner head should be glowing
orange before the EcoBurner is positioned.
Align the EcoBurner with the Spring Clip cradle
and push firmly into place.
4. The EcoBurner Reflector Plate should be
gripped by the spring clip as shown above.
MAINTENANCE & CLEANING
The Hot Air Cover (7) may be removed for cleaning.
(5)
(5)
Please retain this leaflet for future reference.
EcoBurner Ltd., Unit 5, Gulfstream Ave., Airside Business Park, Waterford X91RF20 Ireland
