ecoey FJ100A-H14 User manual

User Manual
Model: FJ100A-H14
Motion Detector
• Power Supply: DC3V(AA×2)
• Standby Current: ≤15uA
• Trigger Average Current: 250mA
• The Carrier Frequency: 2.4GHz
• Communication Distance: ≥100m @ open environment
• Detection Range: 5~10 meters
• Detection Angle: 90°
• Detection Speed: 0.3~3 m/s
• Warm up Time: 20 s
• The Work Environment: -10~33℃, ≤95%RH (No dew)
• Environmental Protection Standard: RoHS
PRODUCT FEATURES
INSTALLATION INSTRUCTIONS
• Automatic digital temperature compensation for both summer and winter
• Equipped with universal mounting bracket, the detection Angle is adjusted at will
• Support anti-white light function, reduce the probability of error trigger
• Standby current as low as 15uA, long battery life
• The use of Tuya Wi-Fi wireless communication protocol, safe, reliable, convenient
• Press the button 3 times to join the Tuya smart APP, easy to network
Installation Position
• It is recommended to be installed on the wall parallel to the human body
movement, as shown in figure 1 or figure 2
• It is not recommended to be installed on the wall perpendicular to the human
body movement, as shown in figure 3
• Do not install in a position facing Windows or direct sunlight
• Do not install in a position facing the air conditioner or fan
• No large obstructions are allowed in the detection area
• The detection distance between winter and summer is different. It is
recommended that the direct distance between the installation location and the
detection area is less than 5 meters
• The distance between the detector and the ground is between 1.5 meters and 2
meters
Figure 1 correct installation method 1 Figure 2 correct installation mode 2
Figure 3 wrong installation
Human
Movement
Human
Movement
Human Movement

DIRECTIONS FOR USE
DIRECTIONS FOR USE
Installation Method
1) Choose the right place to install and make sure there are no hidden objects such
as wires or water pipes in the wall.
2) See figure 4. According to the spacing of screw holes on the bracket, drill 2 holes
with diameter of 5mm in the installation position.
3) Insert 2 expansion gels from accessory bag into the hole.
4)
Fix the bracket on the expansion adhesive with 2 screws in the accessory package,
and tighten the screws to ensure that they do not become loose.
5) Hang the detector on the bracket.
•
Status of people: the indicator light flashes for 3 times to report the status of people
to the APP and push it in the APP; The indicator light flashes 1, no upload status
• Normal state: every 10 minutes or so (the test mode is 30 seconds), when no human
movement is detected, report the normal status to the APP and push it from the APP
There are 2 ways to connect internet, you can choose the one you like. Smart
mode internet connection is recommended as it’s easier.
If you have any problem in wifi connection, please contact us, we will help you.•
• Smart mode networking: when the APP is waiting for networking, press the
detector button 3 times quickly (within 1.5 seconds), the indicator flashes 2 times in
1 second, and the indicator flashes 10 times in a row for networking success
• AP mode networking status: press the detector button 3 times quickly (within 1.5
seconds), and the indicator light flashes once in 3 seconds. In the APP, choose the
hot spot distribution network of other methods for networking
Warm tip: when the detector is just loaded with battery, it needs to be preheated
for about 20 seconds. At this time, the red indicator light flashes, during which no
operation can be conducted. When one of the two networking modes fails, it will
automatically switch to the other mode for networking
Join the Tuya smart APP
2) Quickly press the detector button 3 times, and the APP will click the "confirm"
button to add. After success, you can enter the device page
Number The fault phenomenon Cause analysis Elimination method
1
2
3
4
When a human body passes
through the detection area, the
detector light will flash, but the
APP state will not change
When a human body passes
through the detection area, the
detector light will not flash, and
the APP state will not change
The wireless communication
distance between the detector
and the router is too short
After the preheating of the
detector is completed, the red
indicator light is always on
The router is not
connected to a Wi-Fi
wireless network
The detector is too
far from the router
The detector is installed
at an incorrect position
or Angle
Dead battery
Low battery
Product failure
Check the Wi-Fi
Adjust installation
position
Adjust installation
position or Angle
Replace the battery
Contact the seller to
repair or replace the
product
1) Click the button on the APP device page and select the human body
sensor (Wi-Fi).
Status description (test mode is 5 minutes before power on)
