User Manual
110W Solar Panel
with Monocrystalline silicon cells
60W Solar Panel
with Monocrystalline silicon cells
SOLAR PANEL

Protective Case and kickstand
only for 110W Solar Panel
MC4 Output Controller
Output
Controller
MC4 to XT60 Cable
for Recharging
EF DELTA/R600
User Manual
& Warranty Card
6.5-13Hours(60w)
(Depends on Weather)
How to Recharge R600
MC4 Output Ports （Sold Separately）
R600
110W/60W
Solar Panel
In The Box
OPTIONAL
How It Works
* This Cable sold separately

How to Recharge Your Devices
* This Cable sold separately
MC4 to TX60
R600
EFDELTA
EF DELTA
(Sold Separately)
R600
(Sold Separately)
(Sold Separately)
(Sold Separately)
INPUT PORT
XT60
MC4 Output Ports
Your Solar Setup
Using Your Kickstand
12
110W/60W SOLAR PANEL

5
34
110W/60W
SOLAR Panel
MC4
Adapter
Cable
90o60o
*Use the solar panel bag as a kickstand to prop your solar panel in a 60-90
degree angle for best efficiency.

* Each 110W/60W Solar charger sold separately
Two Ways to Get More Power!
How It Works
1. Connect two 110W or 60W solar panels to the two Ports
on R600(Series connection not supported)
2. Chain three 110W or 60W solar panels to EFDELTA.
EFDELTA
110W/60W SOLAR PANEL 110W/60W SOLAR PANEL
R600 * Users have to buy the solar panels and other
parallel connection accessories seperately.
Solar MC4 parallel connection cable

1. What can the 110W/60W Solar Panel charge?
Each 110W/60W Solar Panel has a pair of MC4 ports to directly recharge R600
(370/412/500). An XT60 Cable can be used to recharge EF DELTA.
2. Does the 110W/60W Solar Panel give a full 110/60W watts of power?
Under optimal conditions the 110W/60W Solar Charger can deliver up to 110 /60Watts
of power, but the angle of the panels and the weather can impact its
performance.
3. Is the 110W/60W Solar Panel water resistant?
The 110W/60W Solar Panel is made of water resistant material, making it
durable and easy to use in the outdoors.
4. Can I chain multiple 110W/60W Solar Panel together?
The chainable feature enables you to chain a maximum of three 110W/60W
solar panels together with the MC4 cable. Please note that R600 cannot
support more than one solar panel per single port. Our safety system will
prevent the panels from charging R600 should you accidentally chain too
many devices together.
5. How long does it take to recharge R600 with the solar panel?
R600 can be recharged via the 110W solar panel in 5-10 hours and the 60W
solar panel in 6.5-13 hours, depending on the angle of the panels and weather
conditions.
Weight：13.2 lbs (6KG) Solar Panel 8.8lbs (4KG)
Unfolded Dimensions: 20.2*62.5*0.8 in (51.4*158*2.0 cm)
Folded Dimensions: 20.2*16.5*0.8 in (51.4*42*2.0 cm)
Warranty: 12 months
Rated Power: 110W(+/-5W)*
Open Circuit Voltage: 21.7V(Vmp 18.5V)
Short Circuit Current: 6.3A(Imp 6.0A)
Eciency: 21%-22%
Cell Type: Monocrystalline silicon
Tested And Certified
110w Solar Panel
General
MC4 Solar Port to XT60: 80V(max), up to 10A (max)
Chainable: Yes, DELTA up to 400W, R600 up to 200W(Parallel)
Output Ports
Weight：7.7 lbs(3.5KG) Solar Panel 4.4 lbs(2.0KG)
Unfolded Dimensions: 21*32.1*0.8 in(53.7*81.5*2cm)
Folded Dimensions: 21*16.5*0.8 in(53.7*42*2cm)
Warranty: 12 months
Rated Power: 60W(+/-5W)*
Open Circuit Voltage: 21.6V(Vmp 18.2V)
Short Circuit Current: 3.5A(Imp 3.3A)
Eciency: 21-22%
Cell Type: Monocrystalline silicon
Tested And Certified
60w Solar Panel
General
MC4 Solar Port to XT60: 80V(max), up to 10A (max)
Chainable: Yes, DELTA up to 400W, R600 up to 200W(Parallel)
Output Ports
*Standard Test Conditions:1000W/m2, AM1.5, 25oC
FAQs
Technical Specifications
