Ecotron EPX Series User manual

EPX-SERISE USER MANUAL Rev. G
1
EPX-Series
Diagnostic X-ray System
User Manual
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu, Seoul, Korea
D/N: EPX-SERISE, Rev. G

EPX-SERISE USER MANUAL Rev. G
2
(This page intentionally left blank)

EPX-SERISE USER MANUAL Rev. G
3
CONTENTS
1. INTRODUCTION----------------------------------------------------------------------------------------- 6
2. NOTICE OF THE SAFE OPERATION ------------------------------------------------------------- 8
3. RADIATION SAFETY ----------------------------------------------------------------------------------- 9
4. SAFETY AND SPECIFICATIONS ------------------------------------------------------------------ 10
5. SYSTEM CONFIGURATION------------------------------------------------------------------------- 47
6. OPERATION MODE ----------------------------------------------------------------------------------- 50
7. MAINTENANCE PROCEDURE -------------------------------------------------------------------- 58
8. DISPOSAL OF WASTE ------------------------------------------------------------------------------ 61
9. QUALITY WARRANTY ------------------------------------------------------------------------------- 62
10. INTENDED OPERATOR AND SERVICE PERSONAL PROFILE ------------------------ 63
11. EMC DECLARATION --------------------------------------------------------------------------------- 64
12. APPENDIX A: TECHNICAL CHART ------------------------------------------------------------- 68
13. APPENDIX B: PEDIATRICS AND SMALL PATIENTS -------------------------------------- 74

EPX-SERISE USER MANUAL Rev. G
4
REVISON HISTORY
Revision Number
Date
Description
A
SEP 11, 2013
First Edition
B
SEP 30, 2014
European Authorized Representative Change
C
JAN 12, 2015
Manual Updates
D
Mar 23, 2015
Manual Updates
E
JUN 11, 2015
Manual Updates
F
G
SEP 01, 2015
JUN 21, 2016
Manual Updates
Manual Updates
ADVISORY SYMBLOS
The following advisory symbols are used throughout this manual.
Their application and meaning are described below.
WARNING
Warning symbol used to indicate a potential hazard lead operators, service personnel to serious injury, death or
radiation exposure.
CAUTION
Caution symbol used to indicate a potential hazard lead operators, service personnel to injury or damage of
equipment.
NOTE
Note symbol used to indicate important information need to proper use and right operation of equipment.
Keep this service manual with the equipment at all times, and review the important information whenever
required.

EPX-SERISE USER MANUAL Rev. G
5
(This page intentionally left blank)

EPX-SERISE USER MANUAL Rev. G
6
1.INTRODUCTION
The EPX Series Innovation diagnostic X-ray system features excellent x-ray Image, quality, accuracy,
reproducibility and long-term stability. Fast kV rising time minimize unnecessary patient dose and supply
superior Image quality, fast Image response.
The operator control console is designed to be simple and user-friendly and one can select or change x-
ray parameters easily using a large soft membrane switch.
Indications for use / Intended use
This product, diagnostic X-ray system, is radiation medical equipment used by a qualified / trained
physician or technician on both adult and pediatric subjects for taking diagnostic X-rays.
This product is used on hand (wrist), foot (ankle), shoulder, elbow, knee, and other body parts.
Available the patient population for use
Gender: no gender restrictions
Age: no age restrictions
The patient population for use
- Adults
- Pediatric patients
NOTE
Federal law restricts this device to sale by or on the order of physician or with the
descriptive designation of any other practitioner licensed by the law of the State
in which he practices to use of order the use of the device.

EPX-SERISE USER MANUAL Rev. G
7
1.1 COMPOSITION
This product is composed of the X-ray component part, accessories part. Detail information of each component
follows below.
(1) X-ray component part
Main Power board
SMPS
Mono block X-ray tank
OP control board
FET drive board
Collimator
(2) Accessories
Hand switch
Foot switch(Option)
Operator’s Manual
Mobile Stand
NOTE
This manual contains important safety information. An understanding of this
information is critical to the safe operation of your equipment.
Please ensure that you read the warning notices before using the equipment

EPX-SERISE USER MANUAL Rev. G
8
CAUTION
No protection against the ingress of the liquids
2. NOTICE OF THE SAFE OPERATION
This user’s guide is designed to ensure correct use and operation of EPX series. Please read all the
lines thoroughly before you use this equipment.
Incorrect use and operation exceeding described conditions in this manual may occur damage of the
machine and shorten its life. Particular attention must be paid to all the warnings, cautions and notes
incorporated herein.
This equipment should be used only by the legally qualified persons and practitioners.
EPX series is designed with the due consideration for users’ safety and product reliability. It, however, is
advisable to follow under mentioned rules to keep your additional safety and health.
1. This product should be operated only by or under the supervision of legally qualified persons.
2. EPX series is designed for the radiographic uses and not for fluoroscopy or other associated
applications.
3. EPX series should be used for the diagnosis, not for the therapy.
4. Do not modify the equipment at your discretion and in case any modification is required unavoidably,
ask the help of Ecotron or its authorized dealer for the service.
5. This system has been calibrated for optimal operations.
6. The outside temperature of the device is not as high as burns, but there watch out for a low-
temperature burns if the operator contacts with a certain part(control panel, collimator knob, metal
enclosure etc.) for a long time.
7. EPX series should be used to plug the power cord into the wall socket.

EPX-SERISE USER MANUAL Rev. G
9
CAUTION
The ionizing radiation could be dangerous for patients and operators
unless following safety regulations are strictly observed.
3. RADIATION SAFETY
1. Users and operators should wear appropriate protecting devices and clothes.
2. Stay distance from the radiant sources and all the possible secondary radiation zones.
3. Eliminate all unnecessary objects near the exposure zones.
4. The distance from the focus to skin should be kept at least 8 inch (20cm).
5. For the experimental uses, apply the lowest possible values of kV, mAs and exposure time.
6. Be careful not to exceed the limited radiograms in the exposure area.
7. The contraindications for pregnant patient or children to avoid unnecessary ionizing radiation
exposure.

EPX-SERISE USER MANUAL Rev. G
10
X-RAY EQUIPMENT IS DANGEROUS TO BOTH PATIENT AND OPERATOR
UNLESS MEASURES OF PROTECTION ARE STRICTLY OBSERVED
4. SAFETY AND SPECIFICATIONS
4.1 SAFETY AND WARNING SYMBOLS
Never allow unqualified personnel to operate the X-ray
system.
High voltage symbol used to indicate the presence of
high voltage.
Warning symbol used to indicate a potential hazard to
operators, service personnel or to the equipment.. It
indicates a requirement to refer to the accompanying
documentation for details.
Radiation symbol used to indicate the presence of
radiation.
Laser radiation symbol used to indicate the presence of
laser beam.
HV 3 MINUTES WARNING LABEL
This label is attached on the main power board.
The DC link capacitor(approximately 325 VDC with line voltage
at 230VAC) will remain charged for up to 3 minutes after the AC
mains is disconnected or the AC switch is switched off.

EPX-SERISE USER MANUAL Rev. G
11
WARNING
This X-ray unit may be dangerous to patient and
operator unless safe exposure factors, operating
instructions and maintenance schedules are
observed.
DANGER HIGH VOLTAGE LABEL
This label attached to the main fuse cover, main noise filter
cover and FET driver board. Main voltage is present inside the x-
ray system whenever the main disconnect is switched on.
Additionally, the DC link capacitors will remain charged for up to
3 minutes after the AC mains is disconnected or the AC switch is
switched off.
LASER STARE CAUTION LABEL
This label attached to side of the collimator case. Laser pointer is
present inside the collimator part of X-ray system. When X-ray system
shoot a laser beam, there do not stare into beam because the eyes
may be damaged from laser beam.
SAFE USE WARNING LABEL
This label attached to a control panel. This X-ray unit may be
dangerous to patient and operator unless safe exposure factors,
operating instructions and maintenance schedules are observed.

EPX-SERISE USER MANUAL Rev. G
12
Protection earth symbol
Live line among the single phase line powers.
Neutral line among the single phase line powers.
First phase line power among the three phase line
powers.
Second phase line power among the three phase line
powers.
Third phase line power among the three phase line
powers.
Single phase AC line voltage.
X-ray radiation exposure may be damaging to health, with some effects being cumulative and extending
over periods of many months or even years. X-ray operators should avoid any exposure to the
primary beam and take protective measures to safeguard against scatter radiation. Scatter radiation is
caused by any object in the path of the primary beam and may be of equal or less intensity than the
primary beam that exposes the film.
No practical design can incorporate complete protection for operators or service personnel who do not
take adequate safety precautions. Service and operating personnel only authorized and properly
trained by ECOTRON should be allowed to work with this X-ray system equipment. The
appropriate personnel must be made aware of the inherent dangers associated with the servicing of high
voltage equipment and the danger of excessive exposure to X-ray radiation during system operation.
●Wear protective clothing. Protective aprons and gloves with an equivalent of a minimum of
1/64”(0.35mm) of lead are recommended.
● To protect the patient against radiation, always use radiation protection accessories in addition to
devices which are fitted to the X-ray system
● Keep as large a distance as possible away from the object being exposed and the X-ray tube
assembly.
L
N
L1
L2
L3
V~

EPX-SERISE USER MANUAL Rev. G
13
●Never operate this X-ray system in areas where there is a risk of explosion. Detergents and
disinfectants, including those used on patients, may create explosive mixtures of gases. Please
observe the relevant regulations.
●The operator console or anything electrically connected to it, must never be used within 6ft(1.8m) of
the patient environment.
● Do not place liquids(coffee, beverages, flowers, etc) on the X-ray system.
● Do not operate the x-ray system in direct sunlight or near any heat sources.
● Do not operate the x-ray system near strong magnetic fields(microwave ovens, speakers, etc), and
avoid routing the x-ray system near these devices.
● The x-ray system must be operated in locations that are clean(free of excess dust, dirt, debris, etc),
stable(free of vibration).
● Only trained maintenance staff may remove the covers of the x-ray system.
●Contain an instruction not to position the ME EQUIPMENT so that it is difficult to operate the
disconnection device.

EPX-SERISE USER MANUAL Rev. G
14
4.2 COMPOSITION LABEL
4.2.1 EPX-F1600
IDENTIFICATION LABEL-HIGH TENSION TANK
This is label is attached on side of the HV mono block tank inside of the diagnostic x-ray system.
(Example)
Output power: 1.6kW , KVP range: 40-90kVp
mA range: 12-30mA,
Line Power: 200-240V , 50/60Hz
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
HV Mono Block Tank
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu,
Seoul, Korea
EMB-F1600 Series
Inserted X-ray Tube
Focal spot: 1.2mm x 1.2mm, Target angle: 16 degrees
Anode Heat Storage: 50kHU
Inherent Filtration: At least 0.8mmAl
D-125
Certification Statement
▪This product complies with 21 CFR 1020.30 –1020.31
▪This product complies with 21 CFR Subchapter J.
REPRESENTATIVE IDENTIFICATION LABEL X-RAY SYSTEM
This label is attached to rear cover of the diagnostic x-ray system. (Example)
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
Diagnostic X-ray System
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu, Seoul, Korea
EPX-F1600 (S/W: Ver )
Inserted X-ray Tube
▪Focal Spot: 1.2mm x 1.2mm, Inherent Filtration: At least 0.8mmAl
Target Angle: 16 degrees, Anode Heat Storage: 50kHU
D-125
Input Power: 200~240V, 50/60Hz
Output power: 1.6kW @ 50kV, 30mA
KVP range: 40-90kVp, mA range: 12-30mA, mAs Range: 0.4-32mAs
▪Total Filtration: 3.3mmAl
(Tube: 0.8mmAl, Fixed Added Filter: 2.0mmAl, Collimator: 0.5mmAl)
▪Time interval between Max kV and Max mAs exposure: rest time 5min
2015.03
Certification Statement
▪This product complies with 21 CFR Subchapter J.
CAUTION
▪Only an experienced expert should operate the unit.
▪Do not use with wet hands.

EPX-SERISE USER MANUAL Rev. G
15
4.2.2 EPX-F2400
IDENTIFICATION LABEL-HIGH TENSION TANK
This is label is attached on side of the HV mono block tank inside of the diagnostic x-ray system.
(Example)
Output power: 2.4kW , KVP range: 40-100kVp
mA range: 16-40mA,
Line Power: 200-240V , 50/60Hz
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
HV Mono Block Tank
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu,
Seoul, Korea
EMB-F2400 Series
Inserted X-ray Tube
Focal spot: 1.2mm x 1.2mm, Target angle: 16 degrees
Anode Heat Storage: 50kHU
Inherent Filtration: At least 0.8mmAl
D-125
Certification Statement
▪This product complies with 21 CFR 1020.30 –1020.31
▪This product complies with 21 CFR Subchapter J.
REPRESENTATIVE IDENTIFICATION LABEL X-RAY SYSTEM
This label is attached to rear cover of the diagnostic x-ray system. (Example)
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[e-mail]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
Digital X-ray System
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu, Seoul, Korea
EPX-F2400 (S/W: Ver )
Inserted X-ray Tube
?Focal Spot: 1.2mm x 1.2mm, Inherent Filtration: At least 0.8mmAl
Target Angle: 16 degrees, Anode Heat Storage: 50kHU
D-125
Input Power: 200~240V , 50/60Hz, 5.7kVA, Standby 150VA
Output power: 2.4kW @ 60kV, 40mA
KVP range: 40-100kVp, mA range: 16-40mA, mAs Range: 0.4-100mAs
?Total Filtration: 3.3mmAl
(Tube: 0.8mmAl, Fixed Added Filter: 2.0mmAl, Collimator: 0.5mmAl)
?Time interval between Max kV and Max mAs exposure: rest time 5min
2015.03
Certification Statement
?This product complies with 21 CFR Subchapter J.
CAUTION
?Only an experienced expert should operate the unit.
?Do not use with wet hands.

EPX-SERISE USER MANUAL Rev. G
16
4.2.3 EPX-F2800
IDENTIFICATION LABEL-HIGH TENSION TANK
This is label is attached on side of the HV mono block tank inside of the diagnostic x-ray system.
(Example)
Output power: 2.8kW , KVP range: 40-120kVp
mA range: 14-40mA,
Line Power: 200-240V , 50/60Hz
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
HV Mono Block Tank
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu,
Seoul, Korea
EMB-F2800 Series
Inserted X-ray Tube
Focal spot: 1.2mm x 1.2mm, Target angle: 16 degrees
Anode Heat Storage: 50kHU
Inherent Filtration: At least 0.8mmAl
D-125
Certification Statement
▪This product complies with 21 CFR 1020.30 –1020.31
▪This product complies with 21 CFR Subchapter J.
REPRESENTATIVE IDENTIFICATION LABEL X-RAY SYSTEM
This label is attached to rear cover of the diagnostic x-ray system. (Example)
Input Power: 200-240V , 50/60Hz, 5.7kVA, Standby 150VA
Output power: 2.8kW @ 80kV, 35mA
KVP range: 40-120kVp, mA range: 14-35mA, mAs Range: 0.4-100mAs
▪Total Filtration: 3.3mmAl
(Tube: 0.8mmAl, Fixed Added Filter: 2.0mmAl, Collimator: 0.5mmAl)
▪Time interval between Max kV and Max mAs exposure: rest time 5min
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
Diagnostic X-ray System
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu, Seoul, Korea
EPX-F2800 (S/W: Ver )
Inserted X-ray Tube
▪Focal Spot: 1.2mm x 1.2mm, Inherent Filtration: At least 0.8mmAl
Target Angle: 16 degrees, Anode Heat Storage: 50kHU
D-125
2015.03
Certification Statement
▪This product complies with 21 CFR Subchapter J.
CAUTION
▪Only an experienced expert should operate the unit.
▪Do not use with wet hands.

EPX-SERISE USER MANUAL Rev. G
17
4.2.4 EPX-F3200
IDENTIFICATION LABEL-HIGH TENSION TANK
This is label is attached on side of the HV mono block tank inside of the diagnostic x-ray system.
(Example)
Output power: 3.2kW , KVP range: 40-100kVp
mA range: 25-60mA,
Line Power: 200-240V , 50/60Hz
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
HV Mono Block Tank
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu,
Seoul, Korea
EMB-F3200 Series
Inserted X-ray Tube
Focal spot: 2.0mm x 2.0mm, Target angle: 20 degrees
Anode Heat Storage: 40kHU
Inherent Filtration: At least 0.8mmAl
D-205B
Certification Statement
▪This product complies with 21 CFR 1020.30 –1020.31
▪This product complies with 21 CFR Subchapter J.
REPRESENTATIVE IDENTIFICATION LABEL X-RAY SYSTEM
This label is attached to rear cover of the diagnostic x-ray system. (Example)
Input Power: 200-240V , 50/60Hz, 4.5kVA, Standby 150VA
Output power: 3.2kW @ 80kV, 40mA
KVP range: 40-100kVp, mA range: 25-60mA, mAs Range: 0.4-100mAs
▪Total Filtration: 3.3mmAl
(Tube: 0.8mmAl, Fixed Added Filter: 2.0mmAl, Collimator: 0.5mmAl)
▪Time interval between Max kV and Max mAs exposure: rest time 5min
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
Diagnostic X-ray System
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu, Seoul, Korea
EPX-F3200 (S/W: Ver )
Inserted X-ray Tube
▪Focal Spot: 2.0mm x 2.0mm, Inherent Filtration: At least 0.8mmAl
Target Angle: 20 degrees, Anode Heat Storage: 40kHU
D-205B
2015.03
Certification Statement
▪This product complies with 21 CFR Subchapter J.
CAUTION
▪Only an experienced expert should operate the unit.
▪Do not use with wet hands.

EPX-SERISE USER MANUAL Rev. G
18
4.2.5 EPX-F4000
IDENTIFICATION LABEL-HIGH TENSION TANK
This is label is attached on side of the HV mono block tank inside of the diagnostic x-ray system.
(Example)
Output power: 4.0kW , KVP range: 50-110kVp
mA range: 20-80mA,
Line Power: 200-240V , 50/60Hz
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
HV Mono Block Tank
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu,
Seoul, Korea
EMB-F4000 Series
Inserted X-ray Tube
Focal spot: 1.8mm x 1.8mm, Target angle: 15 degrees
Anode Heat Storage: 42kHU
Inherent Filtration: At least 0.5mmAl
OX/110-15
Certification Statement
▪This product complies with 21 CFR 1020.30 –1020.31
▪This product complies with 21 CFR Subchapter J.
REPRESENTATIVE IDENTIFICATION LABEL X-RAY SYSTEM
This label is attached to rear cover of the diagnostic x-ray system. (Example)
Input Power: 200-240V , 50/60Hz, 11kVA, Standby 150VA
Output power: 4.0kW @ 50kV, 80mA
KVP range: 50-110kVp, mA range: 20-80mA, mAs Range: 0.4-100mAs
▪Total Filtration: 3.0mmAl
(Tube: 0.5mmAl, Fixed Added Filter: 2.0mmAl, Collimator: 0.5mmAl)
▪Time interval between Max kV and Max mAs exposure: rest time 5min
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
Diagnostic X-ray System
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu, Seoul, Korea
EPX-F4000 (S/W: Ver )
Inserted X-ray Tube
▪Focal Spot: 1.8mm x 1.8mm, Inherent Filtration: At least 0.5mmAl
Target Angle: 15 degrees, Anode Heat Storage: 42kHU
OX/110-15
2015.03
Certification Statement
▪This product complies with 21 CFR Subchapter J.
CAUTION
▪Only an experienced expert should operate the unit.
▪Do not use with wet hands.

EPX-SERISE USER MANUAL Rev. G
19
4.2.6 EPX-F5000
IDENTIFICATION LABEL-HIGH TENSION TANK
This is label is attached on side of the HV mono block tank inside of the diagnostic x-ray system.
(Example)
Output power: 5.0kW , KVP range: 50-110kVp
mA range: 20-100mA,
Line Power: 200-240V , 50/60Hz
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
HV Mono Block Tank
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu,
Seoul, Korea
EMB-F5000 Series
Inserted X-ray Tube
Focal spot: 1.8mm x 1.8mm, Target angle: 15 degrees
Anode Heat Storage: 42kHU
Inherent Filtration: At least 0.5mmAl
OX/110-15
Certification Statement
▪This product complies with 21 CFR 1020.30 –1020.31
▪This product complies with 21 CFR Subchapter J.
REPRESENTATIVE IDENTIFICATION LABEL X-RAY SYSTEM
This label is attached to rear cover of the diagnostic x-ray system. (Example)
Input Power: 200-240V , 50/60Hz, 11kVA, Standby 150VA
Output power: 5.0kW @ 50kV, 100mA
KVP range: 50-110kVp, mA range: 20-100mA, mAs Range: 0.4-100mAs
▪Total Filtration: 3.0mmAl
(Tube: 0.5mmAl, Fixed Added Filter: 2.0mmAl, Collimator: 0.5mmAl)
▪Time interval between Max kV and Max mAs exposure: rest time 5min
Obelis S.A
Avenue de Tervuren, 34, bte 44 1040 Brussels, Belgium / E-mail:[email protected]
Representative: Mr.Gideon ELKAYAM / TEL:[phone], FAX:[phone]
Ecotron Co., Ltd
Made by Korea
Diagnostic X-ray System
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu, Seoul, Korea
EPX-F5000 (S/W: Ver )
Inserted X-ray Tube
▪Focal Spot: 1.8mm x 1.8mm, Inherent Filtration: At least 0.5mmAl
Target Angle: 15 degrees, Anode Heat Storage: 42kHU
OX/110-15
2015.03
Certification Statement
▪This product complies with 21 CFR Subchapter J.
CAUTION
▪Only an experienced expert should operate the unit.
▪Do not use with wet hands.

EPX-SERISE USER MANUAL Rev. G
20
4.2.7 EPX-SERIES COLLIMATOR
COMMON LABEL TO ALL MODELS- COLLIMATOR
This is label is attached on side of collimator of the diagnostic x-ray system. (Example)
▪Input Power: 24V(Lamp) / 5V(Laser)
▪Min. X-ray field size: 0cm x 0cm at 100cm SID
Max. X-ray field size: 36cm x 36cm at 100cm SID
▪Inherent Filtration: 0.5mmAl
Ecotron Co., Ltd
Made by Korea
Beam Limiting Device(Collimator)
#504~505Ho, Hanshin IT Tower II, 47, Digital-ro 9-gil, Geumcheon-Gu,
Seoul, Korea
EPX-Collimator
Certification Statement
▪This product complies with 21 CFR 1020.30 –1020.31
▪This product complies with 21 CFR Subchapter J.
