ECOWITT WFC01 User manual

WFC01 User Manual
Content
⚫Product Overview .................................................1
⚫Product Specifications ..............................................2
1. Size .........................................................2
2. Weight .......................................................2
3. Material and Protection Level.....................................2
4. Power Supply and Power ........................................3
5. Inlet and Outlet Interface ........................................3
6. Flow and Pressure ..............................................3
7. Working Temperature and Humidity ...............................3
8. Accessory List.................................................3
9. Specifications .................................................3
⚫Product Structure ..................................................4
⚫Installation .......................................................5
1. Power on .....................................................5
2. Test .........................................................5
3. Pair with hub..................................................6
3.1 Configuration of GW2000.................................6
3.2 Configuration of WFC01..................................6
4. Mount .......................................................9
⚫Software Functions ...............................................10
1. Watering Methods .............................................10
2. Operation Modes..............................................10
2.1 Timer Button Mode......................................10
2.2 Manual Watering Mode...................................11
2.3 Plan mode..............................................13
3. Alerts.......................................................16
⚫Note ...........................................................17
1. Installation...................................................17
2. Usage environment ............................................18
3. Maintenance .................................................18
4. Precautions during use .........................................18
⚫Help ...........................................................18
⚫Warranty Information..............................................18
⚫Product Certification ..............................................19

1 / 19
⚫Product Overview
1. Welcome to use WFC01, a product that enables intelligent irrigation. This product needs
to be connected to the Ecowitt Cloud System via the WIFI Hub GW2000 to achieve smart
irrigation.
2. The Smart Water Timer is equipped with a flow meter and a built-in temperature sensor,
which not only functions as a water timer but also allows real-time monitoring of water
flow and temperature, providing you with a better understanding of water usage in your
home. WFC01 supports cloud-based control, and all water usage log is stored in the
cloud. Users can check their water usage anytime and manage and optimize it for more
convenient control and achieve more scientific and rational water usage.
3. This product can be set up in the Ecowitt APP and can be linked with Ecowitt Soil
Moisture Sensors to enable automatic irrigation. It can also be linked with Ecowitt Rain
Sensors to automatically terminate irrigation plans, avoiding water waste and
overwatering. Even in case of network issues, the pre-set plans can still operate normally.
4. The Smart Water Timer utilizes radio frequency transmission technology and a gateway
for data transmission, ensuring stable and reliable communication between the timer and
the gateway within a range of 100 meters in an open area. Remote control is possible
through the Ecowitt APP, allowing you to control your water timer anytime and
anywhere.
5. With a design featuring all-copper pipelines and connectors, the Smart Water Timer can
withstand water pressure of up to 0.9 MPa. It is IP66 waterproof and dustproof, durable,
corrosion-resistant, with a long service life.

2 / 19
⚫Product Specifications
1. Size
L159 * W82 * H45mm
2. Weight
520g.
3. Material and Protection Level
Shell Material: ABS+PC.
Inlet Interface Material: Brass (CU).
Outlet Interface Material: Brass with Chrome Plating.
Waterproof / Dustproof Level: IP66.

3 / 19
4. Power Supply and Power
Power Supply: 1.5V AA*2.
Power: 1.5mW (Average power of opening and closing once a day).
Battery Runtime: Over 6 months (Average runtime of opening and closing once a day).
5. Inlet and Outlet Interface
The inlet/outlet interface is G1/2inch thread.
6. Flow and Pressure
Maximum flow rate: 30L/min.
Working pressure: 0.03 ~ 0.9MPa.
Flow rate error: ±10%.
7. Working Temperature and Humidity
Working Temperature: 1~ 60℃ (The equipment can still transfer data during -40 ~ 0℃, but
water freezing may cause damage to the product).
Working Humidity: 1% ~ 99%.
8. Accessory List
1 x Hexagon nut; 1 x 3/4" to 1/2"Adapter; 1 x Retaining bracket; 2 x Nylon cable ties;
3 x Screws.
9. Specifications
Product Name
Smart Water Timer
Product Model
WFC01
Product Size
159×82×45(mm) | L×W×H
Weight
520g
Shell Material
ABS+PC
Inlet Material
Brass

4 / 19
Outlet Material
Brass + Chrome Plating
Waterproof Level
IP66
Power Supply
1.5V AA Battery ×2
Power
1.5mW (Average power of opening and closing once a day)
Battery Runtime
Over 6 months (Average runtime of opening and closing once a day).
Interface Type
G1/2inch thread
Maximum Flow Rate
30L/min
Working Pressure
0.03 ~ 0.9MPa
Flow Rate Error
±10%
Working Temperature
1 ~ 60℃ (The equipment can still transfer data during -40 ~ 0℃, but water
freezing may cause DAMAGE to the product)
Working Humidity
1 ~ 99%
RF Communication
Distance
100 meters
⚫Product Structure

5 / 19
⚫Installation
1. Power on
Unscrew the 4 screws on the battery door on the back, and put in 2 AA batteries. The
blue light on the front indicates that the device is powered on normally, and screw on the
screws.
2. Test
Short press the button to test whether the function of the water timer button is normal.

6 / 19
3. Pair with hub
3.1 Configuration of GW2000
You have to finish the configuration of GW2000 as the video instructs. Please scan the
QR code to the video.
https://s.ecowitt.com/43PBGA
If you’ve already got a GW2000 configured, go to 3.2.
3.2 Configuration of WFC01
3.2.1 Long press the button for more than 5s, the LED will flash quickly and enter the
network configuration mode.
3.2.2 Click as the following pictures indicate to enter the network configuration mode.

7 / 19
3.2.3 There will be a countdown icon showing on the interface. Click Device is in pairing
mode.
3.2.4 Wait for about 20 seconds and the pair will be success.
3.2.5 Click Confirm and you will see the operation interface of WFC01.

8 / 19

9 / 19
4. Mount
Connect the water inlet and outlet pipes according to the direction of the arrow on the
back of the product and fix them.

10 / 19
⚫Software Functions
1. Watering Methods
1.1 By duration
Set a duration. Open the timer and it will automatically be closed after running for the set
opening duration.
1.2 By quantity
Set the amount of water. Open the timer and it will automatically be closed when the set
quantity is reached.
1.3 Always on
Keep the timer always on.
1.4 Off
Keep the timer off.
2. Operation Modes
The operation modes include Timer Button mode, Manual Watering mode, Plan mode and
Smart mode (not in Beta test period).
Each mode trigger will interrupt the others, and the operation mode generated by the most
recent trigger will take effect.
For example, if the watering is currently in progress based on a scheduled plan and a certain
condition is met to close the timer, the timer will be immediately closed. When the next
scheduled time arrives, the watering will resume and the timer will be opened again.
2.1 Timer Button Mode
2.1.1 Short Press
Execute Manual Watering or terminate the current program.。
2.1.2 Long Press for 5s
Enter the network configuration mode.
2.1.3 Long Press for 10s
Restore factory settings.
2.1.4 Anti-misoperation state
The app supports disabling the short press function of the button.

11 / 19
2.2 Manual Watering Mode
2.2.1 Timer open state
Click the RUN button to directly close the timer.
2.2.2 Timer closed state
Will execute immediately after setting the watering method on the APP.
Click the RUN button. Dialog box will pop up: By duration/volume/Always on.
2.2.2.1 By duration
Duration Range:10 ~ 43200 seconds or 1 ~
720 minutes.
Cycle Mode
Can be set as on/off;
On/off time range:5 ~ 3600 seconds.
Click Confirm to execute current setting.

12 / 19
2.2.2.2 By quantity
Volume Range: 1 ~ 6500 L.
Cycle Mode
Can be set as on/off;
On/off time range:5 ~ 3600 seconds.
Click Confirm to execute current setting.
2.2.3.3 Always On
Click Confirm to execute Always On
setting.

13 / 19
2.3 Plan mode
You can set a plan to start, and the plan can be set up to 24 start times.
2.3.1 Click plan to enter the Plan mode.
2.3.2 Click the right button to activate or deactivate a plan.

14 / 19
2.3.3 Click the left icon to enter the plan editing interface.
2.3.4 Adjust the details of the plan on the editing interface.
2.3.4.1 Add or delete a beginning time.

15 / 19
2.3.4.2 Set the method of watering. By Duration or by volume.
2.3.4.3 Select the Cycle Mode.
Cycle Mode
Can be set as on/off;
On/off time range:5 ~ 3600 seconds.

16 / 19
2.3.4.4 Set the repeat mode of watering. By weekly or by daily.
3. Alerts
There are 5 kinds of alerts. The details of the alerts can be inquired below.

17 / 19
3.1 No Water!
No water detected a while after the Water Timer has been open. Please check if the water sour
ce is sufficient.
3.2 Water Leakage!
Water detected a while after the Water Timer has been closed. Please check the equipment im
mediately for leaks.
3.3 Ice Alert!
Current temperature below 5℃. Ice formation may be caused.
3.4 Overheating!
Current temperature above 60℃. Safety threat may be caused.
3.5 Communication Unstable!
Communication is unstable. Plan skip function will be disabled. Please adjust the position of t
he Water Timer or WiFi hub.
⚫Note
1. Installation
The smart water timer should be installed in a dry and well-ventilated location, avoiding
prolonged exposure to humid, high or low temperature, or harmful gas environments. The
installation position should be as close as possible to the water source or the water pipe that
needs to be controlled, and avoid excessive bending or twisting of the water pipe.

18 / 19
2. Usage environment
The smart water timer is suitable for both residential and commercial use. Do not install the
smart water timer in areas prone to moisture or high temperatures. Additionally, it is
prohibited to use chemical or corrosive substances to clean the smart water timer.
3. Maintenance
To ensure the normal operation of the smart water timer, regular maintenance is required.
During daily use, please pay attention to cleaning the water timer and its surrounding area to
prevent the accumulation of dust and dirt. Also, remember to replace the batteries promptly.
4. Precautions during use
When using the smart water timer, do not use it for substances other than liquids. Avoid
hitting, impacting, or forcefully pulling the smart water timer during use to prevent damage to
its mechanical components. Additionally, keep children and pets away from the smart water
timer to prevent accidents.
Please read this user manual carefully and install and use the smart water timer correctly
according to the instructions. If you have any questions, please contact our customer service
team, we will be happy to assist you.
⚫Help
Our product is continuously changing and improving, particularly online services and
associated applications. To download the latest manual and additional help, please contact our
technical support team:
[e-mail]
⚫Warranty Information
We disclaim any responsibility for any technical error or printing error, or the consequences
thereof.

19 / 19
All trademarks and patents are recognized.
We provide a 1-year limited warranty on this product against manufacturing defects, or
defects in materials and workmanship.
This limited warranty begins on the original date of purchase, is valid only on products
purchased, and only to the original purchaser of this product. To receive warranty service, the
purchaser must contact us for problem determination and service procedures.
This limited warranty covers only actual defects within the product itself and does not cover
the cost of installation or removal from a fixed installation, normal set-up or adjustments, or
claims based on misrepresentation by the seller, or performance variations resulting from
installation-related circumstances.
⚫Product Certification
TBA
