ECS Electronics L4IBAE User manual

L4IBAE V1.0a
i
Preface
Copyright
This publication, including all photographs, illustrations and software, is protected un-
der international copyright laws, with all rights reserved. Neither this manual, nor any
of the material contained herein, may be reproduced without writtenconsent ofthe au-
thor.
Version 1.0a
Disclaimer
The information in this document is subject to change without notice. The manufac-
turer makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any par-
ticular purpose. The manufacturer reserves the right to revise this publication and to
make changes from time to time in the content hereof without obligation of the manu-
facturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digi-
tal device, pursuant to Part 15 of the FCC Rules. These limitsare designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not oc-
cur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
−Reorient or relocate the receiving antenna.
−Increase the separation between the equipment and the receiver.
−Connect the equipment onto an outlet on a circuit different from that to which
the receiver is connected.
−Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing
this device. Changes or modifications not expressly approved by the system's manu-
facturer could void the user's authority to operate the equipment.

L4IBAE V1.0a
ii
Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the follow-
ing conditions:
−This device may not cause harmful interference, and
−This device must accept any interference received, including interference
that may cause undesired operation.
Canadian Department of Communications
This class B digital apparatus meets all requirements of the Canadian Interference-
causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement
sur le matériel brouilieur du Canada.
About the Manual
The manual consists of the following:
Chapter 1
Introducing the Mainboard Describes features of the mainboard,
and provides a shipping checklist.
Go to ⇒page 1
Chapter 2
Installing the Mainboard Describes installation of mainboard
components.
Go to ⇒page 7
Chapter 3
Using BIOS Provides information on using the BIOS
Setup Utility.
Go to ⇒page 29
Chapter 4
Usingthe Mainboard Software Describes the mainboard software.
Go to ⇒page 50

L4IBAE V1.0a
iii
T
TA AB BL LE E O OF F C CO ON NT TE EN NT TS S
Preface i
Features and Packing List Translations 錯誤! 尚未定義書籤。
CHAPTER 1 1
Introducing the Mainboard 1
Introduction............................................................................................................1
Checklist.................................................................................................................1
Standard Items ...................................................................................................1
Features..................................................................................................................2
Choosing a Computer Case................................................................................4
Mainboard Components.......................................................................................5
CHAPTER 2 7
Installing the Mainboard 7
Safety Precautions................................................................................................7
Quick Guide...........................................................................................................7
Installing the Mainboard in a Case.....................................................................8
Checking Jumper Settings...................................................................................8
Setting Jumpers .................................................................................................8
Checking Jumper Settings.................................................................................9
Jumper Settings.................................................................................................9
Connecting Case Components.........................................................................11
Front Panel Connectors...................................................................................13
Installing Hardware.............................................................................................14
Installing the Processor...................................................................................14
InstallingMemoryModules............................................................................17
Installing a Hard Disk Drive/CD-ROM ..........................................................18
Installing a Floppy Diskette Drive ..................................................................20
InstallingAdd-on Cards..................................................................................21
Connecting Optional Devices..........................................................................23
Connecting I/O Devices ..................................................................................27
CHAPTER 3 29
Using BIOS 29
About the Setup Utility........................................................................................29
The Standard Configuration............................................................................29
Entering the Setup Utility................................................................................30
Updating the BIOS..........................................................................................30
Using BIOS..........................................................................................................31
Standard CMOS Features................................................................................32
Advanced BIOS Setup Option........................................................................34
Advanced Chipset Features Option.................................................................36

L4IBAE V1.0a
iv
IntegratedPeripheralsOption..........................................................................38
Power Management Setup Option...................................................................42
PNP/PCI Configuration Option.......................................................................45
PC Health Status Option..................................................................................46
Frequency/Voltage Control..............................................................................47
LoadFail-Safe Defaults Option......................................................................48
Load Optimized Defaults Option....................................................................48
Set Password Option.......................................................................................48
Save & Exit Setup Option...............................................................................49
Exit Without Saving........................................................................................49
CHAPTER 4 50
Using the Mainboard Software 50
About the Software CD-ROM............................................................................50
Auto-installing under Windows 98....................................................................50
Running Setup.................................................................................................51
Manual Installation..............................................................................................53
Utility Software Reference.................................................................................53

L4IBAE V1.0a
1
C
Ch ha ap pt te er r 1 1
Introducing the Mainboard
I
In nt tr ro od du uc ct ti io on n
Congratulations on purchasing the L4IBAE mainboard. The L4IBAE main-
board is a Full ATX mainboard that uses a 4-layer printed circuit board and
measures 304.8 mm x 244 mm. The mainboard features an mPGA478 Socket
that accommodates Intel/P4 Willamette/Northwood processors supporting
system speeds up to 400/533 MHz and data bus bandwidths up to 3.2GB/s /
4.2GB/s.
The L4IBAE incorporates the Intel i82845E (MCH) and the Intel 82801DB
(ICH4) chipsets, which supports 2.5V DDR DRAM, 2X/4X AGP (1.5V only),
AC’ 97 codec and USB 2.0.
C
Ch he ec ck kl li is st t
Compare the mainboard’s package contents with the following checklist:
Standard Items
•One mainboard
•One diskette drive ribbon cable
•One IDE drive ribbon cable
•One auto-install software support CD
•One Retention module
•One I/O shield
•This user’s manual

L4IBAE V1.0a
2
F
Fe ea at tu ur re es s
Processor The L4IBAE mainboard uses a mPGA478 Socket that has the
following features:
•Accommodates Intel/P4 Willamette/Northwood 478-pins
CPU
•Supports a system bus (FSB) of 400/533 MHz
•Supports 3.2GB/s / 4.2GB/s data bus bandwidth
Chipset Intel’s innovative i82845E (MCH) and 82801DB (ICH4) chip-
sets are based on an innovative and scalable architecture with
proven reliability and performance. A few of the advanced
features of the chipsets are:
•Host interface controller supports 400/533 MHz frontside
(system) bus frequency
•Supports System Bus Dynamic Bus Inversion (DBI).
•Supports 266 MHz DDR SDRAM devices
•Supports a max of 2 Double-Sided DIMMs (4 rows popu-
lated) with unbuffered DDR266 (w/ or w/out ECC)
•Maximum DRAM Address Decode Space of 2GB
•Supports AGP 2.0 Including 1X/2X/4X AGP Data Trans-
fers and 2X/4X Fast Write Protocol
•PCI Rev. 2.2, 3.3V (5V Tolerant), 33 MHzInterface Com-
pliant
•PCI to System Memory Data Streaming Up to 132
MB/sec
•Six USB 2.0 Ports for Serial Transfers at 480Mbits /Sec
Max
•Integrated AC 97 audio that supports full surround sound
with up to six channels
Additional key features include support foran AC 97link foraudio
and modem, hardware monitoring, and ACPI/OnNow power man-
agement.
Memory The mainboard can accommodate 2.5V DDR SDRAM. It ac-
commodates three unbuffered 2.5V 184 pin slots with a total
maximum capacity of 2 GB.
AC’ 97 Audio
Codec The AC’ 97 Audio codec is compliant with the AC’ 97 2.2
specification, and supports 18-bit ADC (Analog Digital Con-
verter) and DAC (Digital Analog Converter) resolution as well
as 18-bit stereo full-duplex codec with independent and vari-
able sampling rates.
ULTRA ATA/100
Controller •Complies with PCI2.2 Spec, and supports up to
133MB/Sec PCI data transfer rates
•Compatible with all ATA devices -including Ultra
DMA/ATA100, 66, 33 and EIDE Fast ATA-2
•Co-exists with a motherboard's standard IDE ports, add-
ing two additional IDE controllers to the system.
Promise 20265
(optional)
•Supports Ultra ATA100 drives and backward compatible
with Ultra ATA66/33 & EIDE drives (identical drives rec-
ommended)
•Supports IDE RAID 1 (mirroring) or 0 (striping)
•Supports UDMA 5/4/3/2/1/0, DMA 2/1/0, PIO 4/3/2/1/0
modes
•Two independent IDE channels support up to four
UDMA/100/66/33 or EIDE drives

L4IBAE V1.0a
3
UDMA/100/66/33 or EIDE drives
IEEE 1394A Con-
troller Interface
(optional)
•Fully supports provisions of IEEE 1394-1995 and P1394A
for high performance serial bus
•Provides two fully compliant cable ports at 100/200/400
Mbits and operates in one, two or three port mode
•Single 24.576 MHZ crystal provide transmit/receive data
at 100/200/400 Mbits/s and LLC clock at 49.152 M
•Separate cable bias (TPBIAS) and driver termination
voltage supply for each port
•Support power-down feature to conserve energy in bat-
tery powered applications
Expansion
Options The mainboard comes with the following expansion options:
•Six 32-bit PCI slots
•One 4xAGP slot (support 1.5V only)
•Two IDE connectors which support four IDE channels and
a floppy disk drive interface
•IDE RAID 1, 0 supported by Promise PDC20265R con-
troller (optional)
•One Onboard LAN (optional) chip and LAN port on top of
the USB port
The L4IBAE supports Ultra DMA bus mastering with transfer
rates of 33/66/100 MB/sec.
Integrated I/O The mainboard has a full set of I/O ports and connectors:
•Two PS/2 ports for mouse and keyboard
•Two serial ports
•One parallel port
•One MIDI/game port
•Two USB ports
•One LAN port (optional)
•Audio jacks for microphone, line-in and line-out
Onboard LAN
(optional) The Realtek RTL8100B is incorporated in the chipset providing the mainboard with integrated Ethernet PCI LAN capabilities.
BIOS
Firmware This mainboard uses Award BIOS that enables users to con- figure many system features including the following:
•Power management
•Wake-up alarms
•CPU parameters and memory timing
•CPU and memory timing
The firmware can also be used to set parameters for different
processor clock speeds.

L4IBAE V1.0a
4
C
Ch ho oo os si in ng g a a C Co om mp pu ut te er r C Ca as se e
There are many types of computer cases on the market. The mainboard com-
plies with the specifications for the Full-ATX system case. Some features on
the mainboard are implemented by cabling connectors on the mainboard to
indicators and switches on the system case. Ensure that your case supports
all the features required. The mainboard can support one or two floppy disk-
ette drives and four enhanced IDE drives. Ensure that your case has sufficient
power and space for all the drives that you intend to install.
Most cases have a choice of I/O templates in the rear panel. Make sure that
the I/O template in the case matches the I/O ports installed on the rear edge
of the mainboard.
This mainboard has a Full-ATX form factor of304.8 mm x 244 mm. Choose a
case that accommodates this form factor.

L4IBAE V1.0a
5
M
Ma ai in nb bo oa ar rd d C Co om mp po on ne en nt ts s

L4IBAE V1.0a
6
Table of Mainboard Components
Label Component
1394A-J1 / 1394A-J2 IEEE 1394A header
AGP1 Accelerated Graphics Port
ATX12V Power connector
ATX1 Standard 20-pin ATX power connector
AUDIO1 Front panel MIC/Speaker Out header
BT1 Three volt realtime clock battery
CASFAN1 Case fan connector
CDIN1 Primary CD-in connector
CDN2 Secondary CD-in connector
CNR1 Communications and Networking Riser slot
CPUFAN1 Cooling fan for CPU
CPU Socket CPU socket (mPGA478)
DDR1 ~ DDR3 Three 184-pin DDR sockets
FLOPPY1 Floppy disk drive connector
IDE 1 Primary IDE channel
IDE 2 Secondary IDE channel
IDE 3 Third IDE channel for ATA 66/100
IDE 4 Fourth IDE channel for ATA 66/100
JP1 Clear CMOS jumper
JP3 BIOS flash protect jumper
JP4 LAN select onboard LAN
JP5 1394A jumper
JP6 RAID jumper
LED1 Memory module LED
LPANEL1* Connector for case front panel switches and LED indica-
tors
LSJ1* Single-color LED header
LUSB1* Front panel USB headers
PANEL1 Panel connector for case switches and LEDs
PCI1 ~ PCI6 Six 32-bit add-on card slots
SJ1 Single color LED header
SPEAKER1 Speaker connector
USB2 / USB3 Connector for front panel USB ports
WOL1 Wake On LAN wakeup connector
WOM1 Wake On Modem wakeup connector
* Reserved for OEM use only
Note: LED1 is usually connected to a light that indicates that the computer is
powered on. Do not install hardware or disconnect power cables while the
LED is on.
This concludes Chapter 1. The next chapter explains how to install the main-
board.

L4IBAE V1.0a
7
C
Ch ha ap pt te er r 2 2
Installing the Mainboard
S
Sa af fe et ty y P Pr re ec ca au ut ti io on ns s
Follow these safety precautions when installing the mainboard:
•Wear a grounding strap attached to a grounded device to avoid
damage from static electricity.
•Discharge static electricity by touching the metal case of a safely
grounded object before working on the mainboard.
•Leave components in the static-proof bags they came in.
•Hold all circuit boards by the edges. Do not bend circuit boards.
Q
Qu ui ic ck k G Gu ui id de e
This Quick Guide suggests the steps you can take to assemble your system
with the mainboards.
The following table provides a reference for installing specific components:
Locating Mainboard Components Go to page 5
Installing the Mainboard in a Case Go to page 8
Setting Jumpers Go to page 8
Installing Case Components Go to page 11
Installing the CPU Go to page 14
Installing Memory Go to page 17
Installing an HDD and CD-ROM Drive Go to page 18
Installing an FDD Go to page 20
Installing Add-on Cards Go to page 21
Connecting Options Go to page 23
Connecting Peripheral (I/O) Devices Go to page 27

L4IBAE V1.0a
8
I
In ns st ta al ll li in ng g t th he e M Ma ai in nb bo oa ar rd d i in n a a C Ca as se e
Refer to the following illustration and instructions for installing the mainboard
in a case:
This illustration shows an ex-
ample of a mainboard being
installed in a tower-type case:
Note: Do not overtighten
the screws as this
can stress the main-
board.
Most system cases have
mounting brackets installed in
the case, which correspond to
the holes in the mainboard.
Place the mainboard over the
mounting brackets and secure
the mainboard onto the mount-
ing brackets with screws.
2. Secure the mainboard with
screwswhereappropriate.
1. Place the mainboard
over the mounting brackets.
Ensure that your case has an I/O template that supports the I/O ports and
expansion slots on your mainboard.
C
Ch he ec ck ki in ng g J Ju um mp pe er r S Se et tt ti in ng gs s
This section explains how to set jumpers for correct configuration of the main-
board.
Setting Jumpers
Use the mainboard jumpers to set system configuration options. Jumpers with
more than one pin are numbered. When setting the jumpers, ensure that the
jumper caps are placed on the correct pins.
The illustrations below show a 2-pin jumper.
When the jumper cap is placed on both pins,
the jumper is SHORT. If you remove the
jumper cap, or place the jumper cap on just
one pin, the jumper is OPEN.
This illustration shows a 3-pin
jumper. Pins 1 and 2 are SHORT.
Short Open 123

L4IBAE V1.0a
9
Checking Jumper Settings
The following illustration shows the location of the mainboard jumpers. Pin 1 is
labeled.
Jumper Settings
Jumper Type Description Setting
JP1 3-pinClear CMOS 1-2: Normal (default)
2-3: Clear CMOS
JP1
1
JP3 2-pin Flash Protect Open: Flash (Default)
Short: Flash Protect
JP3

L4IBAE V1.0a
10
JP4 3-pin LAN Select
On Board LAN 2-3: Disabled 1-2: Enabled JP4
1
JP5 3-pin 1394A jumper 1-2: Enabled
2-3: Disabled JP5
1
JP6 3-pin RAID jumper 1-2: Enabled
2-3: Disabled JP6
1
JP1 –This jumper is use to clear all the current data stored in the
CMOS memory. Refer to the following instructions:
1. Turn the system off.
2. Remove all ATX power connectors (including ATX12V
and ATX1).
3. Short pins 2 and 3 on JP1.
4. Return the jumper to the normal setting.
Plug in all ATX power connectors.
JP3 –Enables you to prevent the BIOS from being updated
(flashed). Open the jumper if you are going to update your
BIOS. After updating the BIOS, short the jumper to protect
the BIOS from being flashed.
JP4 –Use this jumper to enable or disable built-in LAN network
adapter.
JP5 –Use this jumper to enable or disable the built-in1394A
controller
JP6 –Use this jumper to enable or disable the built-in RAID con-
troller.

L4IBAE V1.0a
11
C
Co on nn ne ec ct ti in ng g C Ca as se e C Co om mp po on ne en nt ts s
After you have installed the mainboard into a case, you can begin connecting
the mainboard components. Refer to the following:
1. Connect the Pentium 4
processor auxiliary case
power supply connector
to ATX12V.
2. Connect the standard
power supply connector
to ATX1.
3. Connect the CPU cool-
ing fan cable to
CPUFAN1.
4. Connect the case cool-
ing fan connector to
either CASFAN1.
5. Connect the case
speaker cable to
SPEAKER1.
6. Connect the case LED
cable to SJ1/LSJ1.
7. Connect the case
switches and indicator to
PANEL1/LPANEL1.
Note:When the system is heavily loaded,
you should install, at a minimum, an
ATX12V powersupply with a 300W
capacity.
ATX12V: ATX 12V Power Connector
Pin Signal Name Pin Signal Name
1
2+12V +12V 3 4Ground Ground
ATX1: ATX 20-pin Power Connector
Pin Signal Name Pin Signal Name
1
2
3
4
5
6
7
8
9
10
+3.3V
+3.3V
Ground
+5V
Ground
+5V
Ground
PWRGD
+5VSB
+12V
11
12
13
14
15
16
17
18
19
20
+3.3V
-12V
Ground
PS ON#
Ground
Ground
Ground
-5V
+5V
+5V

L4IBAE V1.0a
12
CPUFAN1/CASFAN1: FAN Power Connectors
Pin Signal Name Description
1
2
3
GND
+12V
Sense
System Ground
Power +12V
Sensor
SPEAKER1: Internal speaker
Pin Signal Name
1
2
3
4
SIGNAL
KEY
Ground
VCC
SJ1: Single color LED header
Pin Signal Name
1
2
3
ACPI LED
ACPI LED
SB5V
ACPI LED function:
S0 S1 S3 S4/S5
SJ1
1
Light Blinking Blinking Dark
LSJ1: Single color LED header
Pin Signal Name
1
25 VSB SUSLED-Y
ACPI LED function:
S0 S1 S3 S4/S5
LSJ1
Dark Dark Light Dark

L4IBAE V1.0a
13
Front Panel Connectors
The front panel connector (PANEL1 and LPANEL1) provides a standard set of
switch and LED connectors commonly found on ATX or micro-ATX cases. The
LPANEL1 is specially designed for OEM customers that comply with the OEM
specifications. Refer to the table below for information:
PANEL1
Device Pins
Empty 10
N/C 9
Power ON/OFF 6, 8
Reset Switch 5, 7
Green LED
Indicator 2, 4
HDD LED +1, -3
HDD LED
(Pins 1, 3)
2 1
Reset Switch
(Pins 5, 7)
Power Switch
(Pins 6, 8)
Green LED
(Pins 2, 4)
Empty
(Pin 10)
10 9
N/C
(Pin 9)
LPANEL1
Device Pins
Reset Switch 12, 14
Case Speaker 4, 6, 8, 10
Power Switch 9, 11
Power LED +7
Green Power
LED -5
Yellow Power
LED -3
HDD LED +1, -2
HDD LED
(Pins 1, 2)
2 1
Reset Switch
(Pins 12, 14)
Case Speaker
(Pins 4, 6, 8, 10)
Yellow Power LED
(Pin 3)
Empty
(Pin 13)
14 13
Power Switch
(Pin 9, 11)
Green Power LED
(Pin 5)
Power LED
(Pin 7)
Note:The plus sign (+) indicates a pin which must be connected to a positive
voltage.

L4IBAE V1.0a
14
I
In ns st ta al ll li in ng g H Ha ar rd dw wa ar re e
Installing the Processor
Caution: When installing a CPU heatsink and cooling fan make sure that
you DO NOT scratch the mainboard or any of thesurface-mount resistors
with the clip of the cooling fan. If the clip of the cooling fan scrapes
across the mainboard, you may cause serious damage to the mainboard
or its components.
On most mainboards, there are small surface-mount resistors near the
processor socket, which may be damaged if the cooling fan is carelessly
installed.
Avoid using cooling fans with sharp edges on the fan casing and the
clips. Also, install the cooling fan in a well-lit work area so that you can
clearly see the mainboard and processor socket.
Before installing the Processor
This mainboard automatically determines the CPU clock frequency and sys-
tem bus frequency for the processor. You may be able to change these
settings by making changes to jumpers on the mainboard, or changing the
settings in the system Setup Utility. We strongly recommend that you do not
overclock processors or other components to run faster than their rated speed.
Warning: Overclocking components can adversely affect the reliability of
the system and introduce errors into your system. Overclocking can per-
manently damage the mainboard by generating excess heat in
components that are run beyond the rated limits.
This mainboard has a mPGA478 socket. When choosing a processor, con-
sider the performance requirements of the system. Performance is based on
the processor design, the clock speed and system bus frequency of the proc-
essor, and the quantity of internal cache memory and external cache memory.

L4IBAE V1.0a
15
CPU Installation Procedure
The following illustration shows CPU installation components:
Note: The pin-1 corner is marked with an arrow
Follow these instructions to install the CPU:
1. Install and secure the Retention Module on the mainboard.
2. Pull the CPU socket-locking lever away fromthe socket to unhook it and raise
the locking lever to the upright position.
3. Match the corner on the
CPU marked with an arrow
with pin-1 on the CPU
socket (the corner with the
pinhole noticeably missing).
Insert the processor into the
socket. Do not use force.
4. Swing the locking lever down and hook it under the latch on the edge of the
socket.
5. Apply thermal grease to the top of the CPU.
6. Lower the heatsink over the CPU.

L4IBAE V1.0a
16
7. Lower the CPU cooling fan onto
the heatsink.
8. Snap the four retention legs of
the cooling fan into place.
Cooling Fan
Retention Module
Heatsink
9. Swing both lock levers on top of the cooling fan to their opposite sides to
secure the cooling fan on top of the heatsink.
10. Connect the CPU Cooling Fan
power cable to the CPUFAN1
connector.
Note:CPU fan and heatsink installation procedures may vary with the type of
CPU fan/heatsink supplied. The form and size of fan/heatsink may also
vary.
