EDAN INSTRUMENTS CADENCE II User manual

EDAN INSTRUMENTS, INC.
ManualVer: V1.1
Release Date:Mar.2005
Part Number: MS1-17567-V1.1
CADENCE
Fetal Monitor

CadenceIIFetalMonitorServiceManual
2
Copyright
CopyrightEDANINSTRUMENTS,INC. 2005. Allrights reserved.
Att
ention
EdanInstruments, Inc. (hereinaftercalled EDAN) makes no warrantyofanykind with
regard tothis material, including,but not limitedto the implied warranties of
merchantabilityand fitness for a particular purpose. EDAN assumesnoresponsibilityfor
anyerrors thatmayappear inthisdocument,orfor incidental or consequential damage
in connectionwith the furnishing, performance or use ofthis material.
No partofthis document maybe photocopied,reproducedortranslated toanother
language without priorwritten consent ofEDAN.
Theinformation containedin this document issubject to change withoutnotice.
Responsibility of the Manufacturer
EDAN onlyconsiders itselfresponsiblefor anyeffectson safety,reliabilityand
performance ofthe equipment if:
Assemblyoperations, extensions,re-adjustments,modificationsor repairs are carried
out bypersons authorized byEDAN, and the electricalinstallation ofthe relevantroom
complies with nationalstandards,and the instrumentis used in accordancewith the
instructions foruse.
Note:This device is notintended for homeuse.
WARNING :This deviceis not intended for treatment.
Ifthereis doubt as tofetalwell-being after using theunit,further investigations should
be undertakenimmediatelyusing alternativetechniques.
TheaccuracyofFHR is controlled bythe equipment andcan not beadjusted byuser.If
theFHR result is distrustful, pleaseuseother methodsuchas stethoscope to verifyor
contact thelocaldistributorormanufacture to gethelp.
Failure on the partof the responsibleindividualhospitalor institution employing the use
ofthis equipment toimplementasatisfactorymaintenanceschedulemaycause undue
equipmentfailure and possible health hazards.
Upon request,EDANmayprovide, withcompensation,necessary circuit diagrams, and
other informationto helpqualified technician to maintain and repairsome parts, which
EDAN maydefine as userserviceable.
Warranty
EDAN warrantsthat theCADENCE FetalMonitor wesellisfreefromdefectsin
materials and workmanship. In thestatusofnormal operation andmaintenance, if
EDAN receives noticeofsuch defects during the warranty period thatbeginson thedate

CadenceIIFetalMonitorServiceManual
3
ofshipment,EDANshall, atitsoption, either repairor replacehardware productswhich
prove to be defective.
EDAN software and firmwareproductswhich aredesignated byEDAN for use with a
hardware product,when properlyinstalledon that hardware product, are warrantednot
tofailto executetheir programming instructions dueto defects in materials and
workmanship.IfEDANreceives noticeofsuch defectsduring the warrantyperiod that
begins on the date ofshipment, EDANshall repair orreplacesoftwaremediaor
firmware whichdo not executetheir programming instructionsduetosuchdefects. But
EDAN doesn’twarrantthat operating ofthehardware, software, or firmware shallbe
uninterruptedor free fromerror.
Thisunit has no parts can be repairedbyusers themselves. The equipment must be
serviced only by authorized and qualified personnel. EDAN can notaccept responsibility
forsafetycompliance,reliabilityandperformance ifmodifications or repairs arecarried
out byunauthorized personnel.
Thewarrantyperiodfor this main unitis two years, and oneyear for transducers,etc.
accessories (from thedate ofpurchasing). EDAN’sobligation under this warrantyis
limitedtorepairing,at EDAN’soption, anypartwhichupon EDAN's examination proves
defective. Iftheproduct doesn’tfunctionas warranted during the warrantyperiod, we
willrepairor replace it withoutcharge.
Notes:
EDAN's obligation or liabilityunder thiswarrantydoes not includeanytransportationor
other charges or liabilityfor direct,indirector consequentialdamages or delayresulting
fromtheimproper useor applicationoftheproduct or the substitution uponit of partsor
accessories not approvedbyEDAN orrepaired byanyone other than EDAN authorized
representative.
Thiswarrantyshall notextend to anyinstrument which has been subjectedtomisuse,
negligenceoraccident; anyinstrument from whichEDAN’soriginalserialnumber tagor
product identification markings havebeenaltered or removed, or anyproductofany
other manufacturer.
Using This Label Guide
Thisguide is designed to givekeyconcepts on safetyprecautions.
WARNING
A WARNING labeladvises against certain actionsor situations thatcouldresultin

CadenceIIFetalMonitorServiceManual
4
personalinjury ordeath.
CAUTION
A CAUTION labeladvises againstactionsor situationsthat coulddamageequipment,
produce inaccuratedata,or invalidate a procedure.
Note:ANOTE provides useful information regarding a function or procedure.

CadenceIIFetalMonitorServiceManual
5
Table of Contents
CHAPTER 1 OVERVIEW.....................................................................................................................7
1.1 PRODUCT INFORMATION................................................................................................................7
1.2TECHNICAL SPECIFICATIONS..........................................................................................................7
1.3 FETAL MONITOR OPERATION PRINCIPLE.......................................................................................10
1.4 FUNCTION MODULES...................................................................................................................11
1.3.1 Power SupplyBoard......................................................................................12
1.3.2 Mainboard.....................................................................................................13
1.3.3 fetal monitor Board........................................................................................17
1.3.4 PrintControl Board........................................................................................19
1.3.5 the interface board.........................................................................................19
CHAPTER 2 INSPECTION OF THEMONITOR................................................................................23
2.1 SYSTEM INSPECTION...................................................................................................................23
2.1.1 Appearance, and Packing Inspection............................................................23
2.1.2 Power OnInspection.....................................................................................23
2.1.3 Control Panel.................................................................................................25
2.1.4 Indicator.........................................................................................................29
2.1.5 Recorder........................................................................................................30
2.1.6 Networking Function......................................................................................33
2.1.7 Connecting withPersonal Computer (PC).....................................................34
CHAPTER 3 INSTALLING THE MONITOR......................................................................................34
3.1 INSTALLING POWER SUPPLY BOARD.............................................................................................35
3.2 INSTALLING MAIN BOARD..............................................................................................................36
3.3 INSTALLING FETALMONITOR BOARD.............................................................................................37
3.4 INSTALLING BATTERY.................................................................................................................38
3.5 INSTALLING THE PRINT BOARD......................................................................................................38
3.7TROUBLESHOOTING.....................................................................................................................41
3.6.1 Monitor Failure..............................................................................................41
3.6.2 Operation, Recorder,or Networking Failure..................................................41
3.6.3 DisplayFailure...............................................................................................42
3.6.4 Power SupplyBoardFailure..........................................................................42
3.6.5 Monitoring ParameterFailure........................................................................42
CHAPTER 4 PACKING OF THE MONITOR.....................................................................................43
4.1 CHECKING BEFORE PACKING.......................................................................................................43
4.2 PREPARATION BEFORE POWER ON..............................................................................................43
4.3 POWER ON.................................................................................................................................43
4.4 NOTES........................................................................................................................................43
CHAPTER 5 MONITORING...............................................................................................................44
5.1 ULTRASOUND MONITORINGOF FHR............................................................................................44
5.2 FETAL ECG ELECTRODE MONITORINGOF FHR...........................................................................45
5.3 DUAL HEART RATE MONITORING..................................................................................................48
5.4 MONITORING UTERINE ACTIVITY..................................................................................................49
5.3.1 Monitoring Contractions (External)................................................................49
5.3.2 Monitoring Contractions (Internal).................................................................50
5.5 REMOTE PATIENT MARKER RECORDING OF FETAL MOVEMENT .....................................................53
5.6AFTER MONITORING....................................................................................................................53
CHAPTER 6 MAINTENANCE, CARE AND CLEANING..................................................................54
6.1 PREVENTIVE MAINTENANCE.........................................................................................................54

CadenceIIFetalMonitorServiceManual
6
6.2 CAREAND CLEANING OF MONITOR ..............................................................................................54
6.2.1 Cleaner..........................................................................................................55
6.3 CAREAND CLEANING OF TRANSDUCER........................................................................................55
6.3.1 CleaningofTOCO Transducer......................................................................56
6.3.2 CleaningofUltrasoundTransducer...............................................................56
6.3.3 CleaningofFetalECG Cable........................................................................57
6.4 CLEANING OF RECORDER............................................................................................................57
6.5 CLEANING OF BELT......................................................................................................................57
6.6 STERILIZATION ............................................................................................................................58
6.7 DISINFECTION .............................................................................................................................58
6.8 CARE OF RECORD PAPER............................................................................................................59

CadenceIIFetalMonitorServiceManual
7
Chapter1 Overview
1.1 Product Information
CADENCE providesaccurate and reliable monitoringinformation,usingnon-invasive
ultrasound Doppler,external TOCOtechnique.
RS-485/RS-232 communication portisbuilt,themonitorcan beconnected with
MFM-CNScentral monitoring systemviathis port.The monitorcanbe connected to
wireless network module via aDB9interface, and the wireless network module will
complete the data switch ofthe monitor andthe MFM-CNS central monitoring system.
Thedatacollectedand stored bytheCADENCE Fetal Monitor canbe analyzed and
printed bythe CADENCEInsightsoftware running on PC or MFM-CNS Obstetrical
CentralMonitoring System (CareVista) (Refer to MFM-CNSObstetricalCentral
Monitoring System (CareVista) User Manual andtherelevant informationofwireless
network module).
CADENCE adopts 5.7＂LCD, andthe collected data,trends,and monitoring
parametersare displayed at thesame screen.Abuilt-in thermalrecorderisused to
record the monitoring information.
1.2 Technical Specifications
(1) Safety
The CADENCE FetalMonitor is designed to complywith the international safety
requirements IEC60601-1 for medical electricalequipment. It is class I equipment.
(2) Size and Weight
Size (Monitor) 330 (L) x 270 (W)x 100 (H) mm
Weight (Monitor) About3.5 kg
(3) Environment
Working Temperature: 5℃-40℃
Humidity:< 80%
Atmospheric Pressure:86kPa-106kPa
Transport andStorage Temperature: -20℃-55℃
Humidity:< 93%
Atmospheric Pressure:86kPa-106kPa
Power Supply: 100-240VAC, 50/60Hz
Pmax =60VA

CadenceIIFetalMonitorServiceManual
8
Fuse T1.6AL
BATTERY16.8V 6000mAh3X4 encapsulation
(4) Display
Backlight: Cold cathodefluorescent
Active Area: 103.0(W)x 79.0(H)mm (320 x 240 dots)
Resolution: 85dots per inch
(5) Recorder
PaperWidth: 112mm
Effective Printing Width104mm
Printing Speed 1cm/min, 2cm/min, 3cm/min optional
FHR Printout Width 7cm
FHR Scaling 30bpm/cm
TOCO Printout Width 3.4cm
TOCO Scaling 25%/0.85cm
AccuracyofData±5% (X axis)
AccuracyofData ±1% (Yaxis)
RecordMessage Data,time,TOCO type, paper speed,FHR type,bed NO.,ect
PaperZ-fold,thermal
(6) Ultrasound Channel
TechniquePeak-peak detection techniqueandautocorrelation
Pulse Repetition Rate3.2KHz
Pulse Duration 114us
Nominal Frequency2.0MHz
UltrasoundFrequency 2.0MHz±10%
Acoustic pressure P- <1MPa
Output beam intensity Iob<20 mW/cm2
IntensityIspta<100mW/cm2
FHR Range 50-210 bpm
Resolution 1 bpm
Accuracy
Leakage
Dielectric Strength
FHR Range
±2 bpm
<10uA@264VACappliedto transducer
>4KV RMS
50-210bpm(internationalstandard)
30-240bpm(USA standard)

CadenceIIFetalMonitorServiceManual
9
(7) Contraction
Internal IUP (optional)
Pressure Range (IUP):0-100mmHg
Sensitivity: 5uV/V/mmHg
Non-linear Error:±1mmHg
Resolution: 1%
Zero Mode:Automatic/Manual
External TOCO
TOCO Range: 0-100(%),135g strengthcorresponding to 100%
Sensitivity: 3.7uV/V/mmHg
Non-linearError:±10%
Resolution: 1%
Zero Mode: Automatic/Manual
Leakage: <10uA@264 VAC applied totransducer
DielectricStrength:>4 kV RMS
(8) DECG (optional)
Technique: Peak-peak detectiontechnique
FHR Range: 50-210bpm (international standard)
30-240bpm (USA standard)
ArtifactElimination > ±25bpmchanges are ignored
Resolution: 1bpm
Accuracy: ±1bpm
Input Impedance: >10M(differential, dcto 50/60Hz)
Input Impedance: >20M(Commonmode)
CMRR:>110dB
Noise:<4uVp
Skin Voltage Tolerance:±500mV
FetalInput Voltage Range:20uVp to 3mVp
Earth LeakageCurrent: <10uA@264 VAC applied to transducer
PatientLeakage Current:<10uArms@220V/50Hz
PatientAuxiliaryCurrent: <0.1uA(dc)
Dielectric Strength: 4000Vrms
Calibration SignalInput:1mv

CadenceIIFetalMonitorServiceManual
10
(9) FetalMovement Marker
Manual fetal movement mark
(10) AFM
Technique: Pulsed Doppler ultrasound
Range: 0-100 (%)
Resolution: 1%
Gain Control: Manual/ Automatic
1.3 Fetal Monitor Operation Principle
Thefirstandthesecondgenerationfetalmonitors used previouslydetect FHRwith high
frequencycontinuous ultrasonicwaves. Continuous ultrasonic waves can’tcontrol
distancegate, and easyto beinterferedby other movementorgan and adult trunk blood
vessel movementsignal. Thefetus suffers moreultrasonic radiationthanpulsed wave.
Thethird generationfetal monitoradoptslowfrequencypulsedwave ultrasound,The
ultrasonic signal controlled byDoppler gatetransmitspulsed waves withspecific
frequencyto fetal heart,and it’s hardto beinterfered.
Thefirstandthe second generation fetalmonitors calculateFHRbymeasuring the
interval time ofDoppler signal peak values. Whilemodern fetal monitor calculatesFHR
using digital signal processing auto-correlationarithmetic. Auto-correlation operation
creates characteristic parameterviaprocessing Dopplerechosignal. Comparingnew
characteristicparameter createdbynewsignalwiththe former one, andobtainthedata
ofFHRdisplayandrecorder updating. Auto-correlation operation decreases additional
artificialsignal effectively,and onlyextractseffectiveecho signalthatcandeduce FHR.
Thedetection ofexternal TOCO is obtained byindirectmeasurement viadisplacement
transducer (TOCO) bindingatmaternal abdominalwall.
Operation Principleof Ultrasound Doppler FHR Monitoring
Ultrasoundtransducer is madeupofagroup ofquincunx multi-wafer piezoelectricity
transducers. TheCADENCE IIultrasound transduceris made upofninepiecesof
piezoelectric crystals withuniform distributed eight pieces constituting acircle, andone
lying atthe centerofacircle. Transducer transmits / receives switchunder thecontrol of
transmitting/receiving timingpulsegivenbysystemtimer.Receiver willbeclosed
during transmitting.Itcan receive Doppler frequency shiftinformation offetalheart when

CadenceIIFetalMonitorServiceManual
11
transducer is inthe properplace. Magnifyand filter f0±fdDopplerfrequencyshift
ultrasound echoreceived byhardware system, thendemodulateit,the(f0±fd)- f0＝±fd
signal is obtained.After thesignal is filtered by Doppler frequencyshiftfilter,it is rectified
in full wave, and low-pass filtered. The envelope signalofDopplerfrequencyshiftis
extracted, and sentto multi-channel strobe.Itwill become digitalsignal via A/D
transform. FHRisobtained byDSPauto-correlation operation. The Doppleraudio is not
real sound, but an imitative soundcausedbyDoppler frequency shift change brought by
movementobject.TheFHRsignal range is 50-210BPM.
FHR signal processing flowis as follows.
TOCO Measurement Operation Principle
External TOCOmeasurementsub system uses thestraingauge bridge. Whenstrain
gauge suffers pressure,the bridge connection willlose balance, and produces an output
signal. Thepressurechanges veryslowly,so a low-pass filterissetto filter noise signal.
Itwillchangeintodigitalsignal viaA/D,and itsrelevantvalue iscomputed byDSP.We
take 100 gramforcesas 100 units, pressure measured byTOCO is contactforcesensor
processing.
1.4 Function Modules
CADENCE IIMonitor obtains accurateandreliableparameters, e.g. FHRandmaternal
uterine activity,etc.by usingpulsed Dopplerultrasound, external TOCO,etc.invasive
detection technologyand device. The structure ofCADENCE Series maybedifferent
ExamineSignals
Begin
End
Auto-correlation
Arithmetic
Connect Auto-correlation
Results
Analyze Auto-correlation
Results
CalculatePeriods

CadenceIIFetalMonitorServiceManual
12
accordingto different configuration. The basic partsofthemonitor include: pulsed wave
ultrasound transducer,externalTOCO transducer, Manual fetal movement mark, Fetal
monitor board, mainboard,built-inthermalprinter module,power supplymodule, and
Structure Diagram
1.3.1 Power SupplyBoard
power moduleis designedaccording withIEC 60601-1,which canoffer DCpower as
+12V@1.5A,[email protected], and +5V@1.5A;The definitions ofitspower input, and output
jacks are asfollows:
P4 is power switch ；P8isBatterysupplyinput jack.
Definitions for power supplyinput jack pins:
PIN No. Function Description
PIN1 (brown), PIN3 (blue) A.C. supplyinput pin
PIN2 Null

CadenceIIFetalMonitorServiceManual
13
Definitions for power supplyoutput jack pins:
PINNo. Function Description
PIN1(yellow)D.C. supplyoutputpin: VDD (+12V)
PIN2 (red) D.C. supplyoutputpin:Vcc (+5V)
PIN3Null
PIN4、PIN5 (black) Earth: 0V
PIN6 (blue) D.C. supplyoutputpin: VEE (-12V)
1.3.2 Mainboard
Mainboard includes keyinput control, LCDdisplay,processprint, audioalarm and led
indicatelight alarm, datamemorize andrecall,time and datemanagement,
communication with the internal modules ,ect.
Interface function is as follows:
Defineinterface:
ParallelInterface1: sendout command (ESC protocol)to thermalprinter for printingvia
print interface.
Serial Interface2: sendout command to LCDdisplay modulefor datadisplay,and
receivekeyboard command.
Serial Interface 3:communicatewith central station. Transmit data andreceive
commandfromcentral station.
Definitions for each jack pinon the mainboard areasfollows:
Definitions for power supplyjack J2 pins:
PIN No.Function Description
PIN1VCC
PIN2Earth: 0V
PIN3Earth: 0V
ATMEGA128 MainControl
Process datakeyboard command,
display/printresults, system
management
DSP
TMS320F206
Audio Drive
FHR Ultrasound
TOCOPressure
RS-232C/RS-485
CNS
communication interfac
e
POWER control unit
Parallel interface
Printcontrol
Keyboard
LCD display

CadenceIIFetalMonitorServiceManual
14
PIN4Earth: 0V
PIN5VDD
PIN6VEE
Definitions for 50Pin jack J10 pins:
PIN No. Function Description
PIN1 VO
PIN2 AA0
PIN3 WR
PIN4 RD
PIN5 LCDAD0
PIN6 LCDAD1
PIN7 LCDAD2
PIN8 LCDAD3
PIN9 LCDAD4
PIN10LCDAD5
PIN11LCDAD6
PIN12LCDAD7
PIN13LCDCS
PIN14LCDRST
PIN15LCDVEE
PIN16Earth: 0V
PIN17PD0
PIN18PD1
PIN19PD2
PIN20PD3
PIN21PD4
PIN22PD5
PIN23PD6
PIN24PD7
PIN25/ACK
PIN26PE
PIN27/STB
PIN28/ERR
PIN29BUSY
PIN30VCC
PIN31Earth: 0V
PIN32VCC
PIN33ALARM_G
PIN34VCC
PIN35ALARM_R
PIN36Earth: 0V
PIN37POWER_LED
PIN38Earth: 0V
PIN39VDD
PIN40Earth: 0V
PIN41K0
PIN42K5
PIN43K1
PIN44K6
PIN45K2

CadenceIIFetalMonitorServiceManual
15
PIN46K7
PIN47K3
PIN48K8
PIN49K4
PIN50K9
Definitions for J1 JTAG
Definitionsfor J3 RJ-45
Definitions for J5 RS-232
PIN No.Function Description
PIN1TCK
PIN2Earth:0V
PIN3TDO
PIN4VCC
PIN5TMS
PIN6NRESET
PIN7VCC
PIN8NULL
PIN9TDI
PIN10Earth:0V
PIN No.Function Description
PIN1T1OUT
PIN2R1IN
PIN3Earth
PIN4TA
PIN5TB
PIN6RA
PIN7RB
PIN8485EN
PIN No.Function Description
PIN1Earth
PIN2T1OUT
PIN3R1IN
PIN4Earth
PIN5Earth
PIN6TA
PIN7TB
PIN8RA
PIN9RB

CadenceIIFetalMonitorServiceManual
16
Definitions for J4 FSPO2
Definitions for J6 POWERCOM
Definitions for J8 FM
Definitions for J9DECG
Definitions for J7 CON6
PIN No.Function Description
PIN1FSPO2RXD
PIN2FSPO2TXD
PIN3VCC
PIN4Earth:0V
PIN5VDD
PIN6Earth:0V
PIN7VEE
PIN No.Function Description
PIN1BATTXD
PIN2BATRXD
PIN3Earth:0V
PIN4POWER_LED
PIN5NULL
PIN6NULL
PIN No.Function Description
PIN1VCC
PIN2VCC
PIN3Earth:0V
PIN4VDD
PIN5Earth:0V
PIN6VEE
PIN7FHRTXD
PIN8FHRRXD
PIN9Earth:0V
PIN No.Function Description
PIN1DECGRXD
PIN2DECGTXD
PIN3VEE
PIN4Earth:0V
PIN5VDD
PIN6VDD
PIN7Earth:0V
PIN8VCC
PIN No.Function Description
PIN1VCC
PIN2Earth:0V
PIN3CTCK
PIN4CTDO
PIN5CTDI
PIN6TMS

CadenceIIFetalMonitorServiceManual
17
1.3.3 fetal monitor Board
Fetalmonitor board includes ultrasound channelsignalprocessing,AFMchannelsignal
processing,pressure channel signal processing,Doppler audiosignal processing, DSP
ultrasound and pressuredataprocessing, generalalarm audiosignal,communication
with mainboard.
Definitions for each jack pinon the fetal monitor Boardare as follows:
Definitions for J1 CON4PINS
Definitions for J4 CON4PINS
Definitions for P1 POWER
PIN No. Function Description
PIN1 FHR1
PIN2 FHR1P
PIN3 FHR1P
PIN4 VDD2
PIN No.Function Description
PIN1FHR2
PIN2FHR2P
PIN3FHR2P
PIN4VDD2
PIN No.Function Description
PIN1+5V
PIN2+5V
PIN3Earth: 0V
PIN4+12V
PIN5Earth: 0V
PIN6-12V
PIN7RXD
PIN8TXD
PIN9Earth: 0V

CadenceIIFetalMonitorServiceManual
18
Definitions for J19TOCO
Definitions for J7 HEADER3
Definitions for J8 HEADER3
Definitions for J22 EVENT_MARKER
Definitions for J21 FETAL_MARKER
Definitions for J16CPLD_JTAG
Definitions for J13 AUDIO OUTPUT
PIN No.Function Description
PIN1E3
PIN2E2
PIN3E4
PIN4E1
PIN5TOCOP
PIN6Earth:0V
PIN No.Function Description
PIN1TDI1
PIN2TDI
PIN3TDI2
PIN No.Function Description
PIN1TDO1
PIN2TDO
PIN3TDO2
PIN No.Function Description
PIN1Earth:0V
PIN2EVENT_MARKER
PIN No.Function Description
PIN1Earth:0V
PIN2FETAL_MARKER
PIN No.Function Description
PIN1VCC
PIN2Earth:0V
PIN3CTCK
PIN4CTDO
PIN5CTDI
PIN6CTMS
PIN No.Function Description
PIN1OUT+
PIN2OUT-

CadenceIIFetalMonitorServiceManual
19
1.3.4 Print Control Board
RecordPaperWidth:112mm
Effective Printing Width: 104mm
Dot/Line: 832/mm
Resolution: 8dots/mm
Working Voltage: 5V
Working Circuit: Printhead: 3.4A(Max), 0.9A(Ave)
Electrical Machine:2.4A(Max),0.5A(Ave)
Life: MTBF 5*10EXP(7)
50Km
Connect withmainboard byCENTRONIXinterface to finish detectionofdriving, paper
emptyor not, and the status of printhead.
Definitions for print board20Pinterface jack J5 pins:
PIN No. Function Description
PIN1 STROBE
PIN2 DATA0
PIN3 DATA1
PIN4 DATA2
PIN5 DATA3
PIN6 DATA4
PIN7 DATA5
PIN8 DATA6
PIN9 DATA7
PIN10ACK
PIN11BUSY
PIN12PE
PIN13ERROR
PIN14Powersupply:+12V
PIN15GND
PIN16Vp
PIN17GND
PIN18Vp
PIN19GND
PIN20Vp
1.3.5 the interface board
Theinterface board implement communicationbetweenthemainboard andtheprint
control boardand the displayscreen.The DC-AC inverter for2-coldcathode fluorescent
lamps supportwiderangeofCCFL devices andare characterized byhighlystable
output current.
Definitions for each jack pinon the interface board are as follows:

CadenceIIFetalMonitorServiceManual
20
Definitions for J1 2005S30P
Definitions for J2 LCM
PINNo. Function Description
PIN1VO
PIN2AA0
PIN3WR
PIN4RD
PIN5AD0
PIN6AD1
PIN7AD2
PIN8AD3
PIN9AD4
PIN10AD5
PIN11AD6
PIN12AD7
PIN13LCDCS
PIN14LCDRST
PIN15LCDVEE
PIN16Earth: 0V
PIN17PD0
PIN18PD1
PIN19PD2
PIN20PD3
PIN21PD4
PIN22PD5
PIN23PD6
PIN24PD7
PIN25/ACK
PIN26PE
PIN27/STB
PIN28/ERR
PIN29BUSY
PIN30VCC
PINNo. Function Description
PIN1Earth: 0V
PIN2VCC
PIN3VO
PIN4AA0
PIN5WR
PIN6RD
PIN7AD0
PIN8AD1
PIN9AD2
PIN10AD3
PIN11AD4
PIN12AD5
PIN13AD6
PIN14AD7
PIN15LCDCS
PIN16LCDRST
PIN17LCDVEE
PIN18
Earth:
0
V
