EdgeStar PUR700W User manual

Air Purifier
Owner’s Manual
For more information on other great EdgeStar products on the web, go to http://www.edgestar.com
PUR700W

i
Important Safety Information
Improper handling can cause serious damage to the appliance and/or to the
user. Please read the following safety information.
Electrical products should not be disposed of with household waste.
Please contact your local recycling center for more information on how
to recycle electronic waste.
Electrical Safety
This unit is designed for indoor use only.
Do not use the unit in extremely humid or wet environments.
Do not spray water and wet the housing or control panel.
Do not pull the unit by the cord.
Always turn the unit off and unplug it from the outlet when cleaning.
Unplug the unit if it is not going to be used for a long period of time.
Do not operate the unit with a damaged plug or a loose socket.
Use only the correct power supply with appropriate amperage.
If the power cord is damaged, it must be replaced by the manufacturer,
a service agent, or qualified technician.
Do not remove any part of the casing unless instructed by an
authorized technician.
General Safety
This air purifier is not intended to be used by children.
Children should be supervised to ensure that they do not play with this
product.
Do not allow children to play with the controls or drop any objects into
the air outlets or vents.
Do not place objects or let any person sit on top of the unit.
Only use in the upright position on a flat, level surface and provide at
least 20 inches of clearance from any walls or objects.
Route the power cord carefully to avoid a tripping hazard.
This unit is intended for domestic use only. Do not use the air purifier
for industrial or commercial use. Any other use may invalidate the
warranty.

EdgeStar Air Purifier ii
Table of Contents
IMPORTANT SAFETY INFORMATION.................................................................I
INTRODUCTION ...................................................................................................1
PARTS IDENTIFICATION.....................................................................................2
FRONT VIEW........................................................................................................2
BACK VIEW..........................................................................................................2
PREPARATIONS ..................................................................................................3
INCLUDED FILTERS ............................................................................................4
CONTROL PANEL OVERVIEW............................................................................5
REMOTE CONTROL OVERVIEW ........................................................................6
MAINTENANCE ....................................................................................................7
CLEANING THE UNIT .............................................................................................7
CLEANING THE PRE-FILTER...................................................................................7
CLEANING THE SENSOR .......................................................................................7
PREPARATION FOR STORAGE ...............................................................................7
TROUBLESHOOTING ..........................................................................................8
SPECIFICATIONS.................................................................................................9
EDGESTAR LIMITED WARRANTY ...................................................................10

1
Introduction
Thank you for purchasing this EdgeStar air purifier. We are glad you chose us.
We believe that your purchase of this product opens a relationship between you
and EdgeStar. We will provide the customer support needed to nurture that
relationship.
This manual contains important information regarding the proper installation, use
and maintenance of your air purifier. Following this manual will ensure that your
product will work at its peak performance and efficiency.
Please save the original product packaging in case you need to safely transport
your air purifier.
For Your Records:
Please write down the model number and serial number
below for future reference. Both numbers are located on the
ratings label on the back of your unit and are needed to
obtain warranty service. You may also want to staple your
receipt to this manual as it is the proof of your purchase, and
is also needed for service under your warranty.
Model Number:
Serial Number:
Date of Purchase:
To better serve you, please do the following before contacting customer service:
f you received a damaged product, immediately contact the dealer that
sold you the product.
Read and follow this instruction manual carefully to help you install, use
and maintain your air purifier.
Read the troubleshooting section of this manual as it will help you
diagnose and solve common issues.
Visit us on the web at http://www.edgestar.com to register your
product, download product guides, additional troubleshooting resources
and up-to-date information.
If you need warranty service, our friendly customer service
representatives are available via email at [e-mail] or by
telephone at 1 [phone].

EdgeStar Air Purifier 2
Parts Identification
Front View
Back View
Control Panel
Dust Sensor
Air Intake
Front Panel
Power Cable
Handle
Air Outlet

3
Preparations
1. Take off the front panel in the
direction shown in the figure.
2. Take off the pre-filter by pushing
down the two levers connecting it to
the unit.
3. Take out the multi-filter and anti-virus
filter, both packed in plastic film.
Tear off the plastic film.
4. Re-install the filters, pre-filter and the
front panel of the unit in the opposite
order as shown above.

EdgeStar Air Purifier 4
Included Filters
This unit comes equipped with three (3) separate filters with unique
functionalities.
1. Multi-filter: Combined 3M HEPA filter with Activated Carbon is
designed to remove at least 99.9% of all airborne particles larger
than 0.3 microns effectively. The carbon removes odors, chemical
vapors, volatile organic compounds, and other gasses.
2. Anti-Virus Filter: This filter combats airborne bacteria and viruses
in order to reduce the inhalation of harmful contaminates in the air
that lead to sickness.
3. Pre-filter: Created to block large elements in the air, such as dirt
and dust. The grid filter can be washed and replaced after cleaning
when needed.

5
Control Panel Overview
POWER BUTTON
Pressing the Power Button once will turn the unit on. By
default, the unit will begin to operate in AUTO Mode and
the indicator light will illuminate. Pressing this button a
second time enables SLEEP Mode. The unit will continue
to operate in the previous settings, but will turn off all but
the Power Button’s indicator light. Pressing this button a
third time turns the unit off.
FILTER BUTTON
This air purifier has an internal timer to alert when the
filters should be replaced. The indicator light to the left of
this button will illuminate after 6 months of run time. Once
the new filters are installed hold this button for 5 seconds
to reset the timer. This will also turn the indicator light off.
TIMER BUTTON
Pressing the Timer Button enables an automatic shutoff for
time frames of four, eight, and twelve hours. The unit will
stay on for the allotted time. The indicator lights above this
button will indicate the respective set time frame. The
Timer can be turned off by pressing this button until no
indicator lights are illuminated.
SPEED BUTTON
There are four fans speeds to choose from –Low,
Medium, High, and Turbo. Pressing the Speed Button will
alternate through these settings. If the unit is in AUTO
Mode pressing the Speed Button once will set it to the Low
fan speed and turn off AUTO Mode. The indicator lights
above this button will indicate the respective fan speed.
AUTO BUTTON
Pressing the Auto Button enables AUTO Mode. The air
purifier will select the appropriate fan speed based on the
air quality level. Press again to turn off AUTO Mode.
AIR QUALITY INDICATOR LIGHTS
RED - High level of contaminants.
BLUE - Moderate level of contaminants.
GREEN –Low level of contaminants
Remote Control Sensor
NOTE: Environments with
higher pollutant levels may
cause users to replace their
filters sooner than 6 months.
To order replacement filters
visit www.allergyandair.com
or call 1-855-302-6628.
Top View

EdgeStar Air Purifier 6
Remote Control Overview
The remote control is used to operate most of your air purifier’s
functions.
Note: This remote comes equipped with battery. To replace the
battery, the user must slide off the backing, and insert a
Lithium 3V Battery, size CR2025.
Button
Function
Powers the unit on or off. Press once to turn unit
on. Press again to turn the indicator lights off for
SLEEP Mode. Press again to turn the unit off.
Speed
Selects fan speed which ranges from Low to Turbo.
Timer
Used to enable the Timer.
Auto
Allows the user to initiate AUTO Mode. The air
purifier will select the proper fan speed based on
the air quality level.
NOTE: Be careful not to drop
the remote control. Do not
place the remote control in a
location exposed to direct
sunlight.

7
Maintenance
Use a soft dry cloth to wipe the body clean. If necessary, use
rubbing alcohol to dampen a cloth to clean the unit.
Use a soft bristle brush to clean between the vents. Do not wash
the filters in this unit. The pre-filter can be cleaned with water. See
below.
Never use abrasive chemicals, volatile substances, gasoline,
detergents, chemically treated cloths, or other cleaning solvents
that may damage the cabinet exterior.
Never spray water directly on the unit.
To clean the pre-filter, follow the steps below:
1) Power off the unit and remove the pre-filter.
2) Use a vacuum cleaner or tap the filter lightly to remove loose
dust and dirt, then rinse thoroughly under lukewarm running water
(below 104°F). You may use a mild soap and water solution if
needed. Allow the pre-filter to air dry in a cool and shaded place.
Dry thoroughly before reinstalling.
Clean the pre-filter periodically. If the unit is used in a dusty
environment you may need to clean it on a weekly basis.
Please see the pictures to the left to better depict the following
instructions:
1) Slightly brush the hatch of the sensor and its surroundings.
2) Take off the hatch and wipe the sensor with a cotton stick,
shown in the figure below. The cotton stick may be dampened with
water, however be sure not to use alcohol. The sensor should be
cleaned every two (2) to four (4) weeks to ensure that dust is being
detected accurately.
If you are not going to be using the unit for an extended period of
time, follow the instructions below before storing your unit:
1) Power off the unit, and clean or change the filters.
2) Unplug and carefully wind the power cord.
3) Store in a cool, dry place.
Cleaning the unit
Cleaning the pre-filter
Cleaning the Sensor
Preparation for Storage
Warning: Never operate
the unit without the pre-
filter.
Warning: The filters for
this unit are not designed to
be cleaned or washed.
New filters should always
be switched for old filters
that need to be replaced.

EdgeStar Air Purifier 8
Troubleshooting
Follow the troubleshooting guide below to resolve common issues.
Issue
Possible Cause
Solution
My air purifier is not
functioning at all.
Unit is not receiving
power.
Make sure the unit is
plugged in to a
grounded outlet.
Insufficient power.
Move the unit to
another outlet. Check
your circuit breaker.
(Refer to the rating
label on the back of
the unit to determine
the Amperage draw).
The panel is not
locked into place.
Try to refit the panel
into the designated
slots.
Control panel is
disconnected.
If no indicator lights
turn on, contact
customer service.
My remote control
does not work and the
indicator light on
remote does not turn
on.
Batteries not installed.
Install new batteries.
Bad batteries.
Replace the batteries.
Batteries installed
incorrectly.
Reinstall the batteries
correctly.
A defective remote
control.
Contact customer
service.
My air purifier is
making a loud noise.
The unit is not level.
Make sure the unit is
on a level surface.
A foreign object has
jammed the fan.
Remove the object
from the fan.
The packaging on the
filter has not been
removed.
Remove the filter
packaging.
The pre-filter or multi-
filter is very dirty.
Clean the problem
filter.
The floor below the
unit is uneven.
Move the unit to a
level surface.
My air purifier is
making a continuous
metallic knocking or
pinging sound.
Unit may have been
shipped on its side.
Shut off the unit. Let
the unit sit on a level
surface for at least 24
hours and restart.
Damaged motor.
Contact customer
service.
My air purifier runs for
a little while and then it
trips the power cord or
the circuit breaker.
The air purifier may be
plugged into an outlet
that cannot supply the
correct amount of
current.
Contact an electrician
if the unit works in a
different room or
circuit.
The control panel
lights blink randomly.
Unit may have a faulty
control panel.
Contact customer
service.
Speed button does not
work.
Unit may be in AUTO
mode.
Press AUTO to disable
this mode.

9
Specifications
Description of product
Air Purifier
Model
PUR700W
Voltage/Frequency
AC 120V~60Hz
Input Power
95W
Current
0.8A
Color
White
Timer
4, 8, and 12 hour settings
Dimensions
W x H x D
17.75”x 26.75” x 10”
Weight
21 lbs.

EdgeStar Air Purifier 10
EdgeStar Limited Warranty
One (1) Year Parts & Ninety (90) Days Labor
This product is warranted by EdgeStar to be free from defective workmanship and materials, subject to any conditions
set forth as follows:
WHAT IS COVERED:
LABOR: For a period of NINETY (90) DAYS from the date of original purchase, labor will be performed free of charge at
an authorized EdgeStar repair facility. At its option, EdgeStar will repair the product with new or remanufactured parts,
or exchange the defective product with a new, refurbished, or remanufactured product. If a product is replaced, it will
carry the remaining warranty of the original product. After the ninety (90) day period, EdgeStar will no longer be
responsible for labor charges incurred. All defective products and parts covered by this warranty will be repaired or
replaced on a mail-in basis to an EdgeStar authorized repair facility.
PARTS: For a period of ONE (1) YEAR from the date of original purchase, EdgeStar will supply new, rebuilt, or
refurbished parts free of charge. EdgeStar may request a defective part be returned in exchange for the replacement
part. All replacement parts or products will be new, remanufactured, or refurbished. All products and parts replaced by
EdgeStar under warranty service become the property of EdgeStar.
This warranty applies to the original purchaser only, and only covers defects in workmanship experienced during
operation of the product under normal service, maintenance, and usage conditions. This warranty applies to the
purchase and use of this product in residential settings within the United States of America.
WHAT IS NOT COVERED:
The following limitations apply to the coverage of this warranty. This warranty does not cover:
Labor charges for installation, setup or training to use the product.
Shipping damage, and any damage caused by improper packaging for shipment to an authorized service center, and any
damaged caused by improper voltage or any other misuse, including abnormal service, handling, or usage.
Cosmetic damage such as scratches and dents.
Normal wear and tear on parts or replacement of parts designed to be replaced, e.g. filters, cartridges, batteries.
Service trips to deliver, pick-up, or repair, install the product, or to instruct in proper usage of the product.
Damages or operating problems resulting from misuse, abuse, operation outside environmental specifications, uses
contrary to instructions provided in the owner’s manual, accidents, acts of God, vermin, fire, flood, improper installation,
unauthorized service, maintenance negligence, unauthorized installation or modification, or commercial use.
Labor charges incurred 91 days or more after the date of original purchase.
The use of EdgeStar products in commercial settings.
Optional accessories, attachments, and appearance items.
Products that have been modified to perform outside of specifications without the prior written permission of EdgeStar.
Products lost in shipment, or theft.
Products sold AS IS or from an unauthorized reseller.
Products that have had their serial numbers removed or defaced. Products with serial numbers that have been invalidated.
OBTAINING WARRANTY SERVICE:
If you believe your product is defective, contact EdgeStar Customer Support for troubleshooting assistance and
warranty service at 1-866-319-5473. Please have your serial number and proof of purchase available. Once an
EdgeStar authorized representative has confirmed that your product is defective and eligible for warranty service, the
product must be returned to an EdgeStar repair facility. The purchaser is solely responsible for prepaying all shipping
related costs to and from the repair facility. EdgeStar is not responsible for damage resulting from shipper mishandling
or improper packaging. Do not return a defective product to the place of purchase. Products received without a return
authorization number will be refused.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED
WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. NEITHER
THE MANUFACTURER NOR ITS DISTRIBUTORS SHALL BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT,
SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR PROFITS,
OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. SOME STATES DO NOT ALLOW THE
EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO
STATE.

EdgeStar Products
500 N. Capital of TX Hwy, Bldg 5
Austin, TX 78746
Toll Free: 1-866-319-5473
Web: http://www.edgestar.com
E-mail: [e-mail]
Register your product, download owner’s manuals, access additional troubleshooting
resources, and obtain more information on other great EdgeStar products on the web at:
http://www.edgestar.com
Product contents and specifications may change without notice.
Copyright © 2014 Living Direct, Inc. All rights reserved.
