EdgeStar TBC50BL User manual

Table of Contents
Thank you 2
Accessories 2
Installation 2
Tapping your first mini keg 3
Operation 9
Cleaning 9
Important safeguards 10
Limited warranty 10
1

Thank you
Thank you for purchasing this EdgeStar mini kegerator. Once you get this unit set up,
it will provide you and your family with years of great service.
This mini kegerator is designed to refrigerate and serve most 5 Liter mini kegs- under
optimal conditions, it can refrigerate to the mid to high 30°s Fahrenheit. It ships with a
tap for Heineken brand DraughtKeg 5 Liter mini kegs. An optional accessory kit is
available that fits most other brands of 5 Liter mini keg. A 5 Liter mini keg has about
169 ounces of beer in it, so it should provide about 10 ½ pints of beer or the
equivalent of about 14 12 oz cans.
If you are reading this owner’s manual, you’ve probably already unpacked the unit.
Note that you should save the packaging in case you need to safely transport this
unit in the future.
Accessories
Included accessories:
•Main unit
•AC power cord
•DC power cord
•“Squeeze bottle” cleaning kit
•Heineken-style mini keg tap
•Dispenser handle
•Emblem for dispenser handle
•Drip tray assembly
Optional accessories:
•Regulator
•16g CO2cartridges (3)
•16g CO2adapter
•16g CO2holder
•Non-pressurized mini keg tap
•CO2releaser
•Pressurized cleaning kit
•Rubber ring (2)
If you would like to order the optional accessory kit, or if you need any help with this
unit, please feel free to call EdgeStar at 866.319.5473.
Installation
In order to assemble this appliance, carefully unpack all parts.
Place the unit on a flat and level surface. It will work best in a
room temperature environment, away from the sun and other
heat sources, and with 2”-3” of ventilation room all around it.
2

Install the drip tray by sliding it partially underneath the main unit (align the “tab”
sticking out of the drip tray assembly with the notch in the underside of the main unit).
Install the dispenser handle by screwing it onto the dispenser head.
There is also a circular emblem that magnetically attaches directly to the
top of the dispenser handle. Place this on the dispenser handle.
Now select the appropriate power cord (three prong grounded 115V or
the 12V DC plug [cigarette lighter adapter]). Plug the power cord into the
back of the unit, and then plug the other end into your power source.
Check to make sure the unit is on by looking at the LED in front of the
unit. If the LED is lit, your unit is powered up.
We suggest you clean the lines prior to tapping your first mini keg,
and cleaning them again after every mini keg.
Note that this mini kegerator ships with the connections to tap and
enjoy Heineken brand DraughtKeg 5 Liter mini kegs. This is the most
popular and widely-available 5 Liter mini keg. Heineken brand
DraughtKeg 5 Liter mini kegs are already pressurized and need no
additional CO2 to tap them. With the optional upgrade kit, you can tap and enjoy all
commercially available 5 Liter mini kegs.
Tapping your first mini keg
Cleaning the lines
Before tapping your first mini keg, and after each mini keg, clean the lines.
1. Fill the “Squeeze bottle” cleaning kit half full of water. Add a small amount of
detergent, baking soda, white vinegar, or beer line cleaner. Mix the mixture
thoroughly.
2. Attach the nozzle of the squeeze bottle to the beer line. Place a cup or bowl
underneath the beer dispenser.
3. Squeeze the bottle while opening the dispenser all the way, forcing the
cleaning mixture through the beer line and into the cup/bowl beneath the
nozzle.
4. Once all the mixture has run through the line, rinse out the squeeze bottle.
5. Refill the squeeze bottle with water and repeat the above process with water
until the lines are clear of cleaning solution.
General instructions
Regardless of the brand of 5 Liter mini keg, here are the basic steps for tapping it:
1. Chill your keg- although this mini kegerator has a cooling plate that will cool
your keg, best results will come from a keg that is already cooled to drinking
temperature- this way, the cooling plate only has to keep your keg cool.
2. Follow the instructions on the mini keg to eliminate excess gas or pressure.
3. Connect the beer line to the correct dispenser head and tap the keg (use the
included head for Heineken brand DraughtKeg 5 Liter mini kegs; use the
optional head for all other brands)
4. Connect the gas lines (if using the optional head for non-pressurized 5 Liter
mini kegs)
3

5. Do a test-pour to ensure that the beer is flowing freely. If the test pour is good,
start the party!
Note that you may experience a lot of foam shortly after tapping the mini keg.
If you wait 15-20 minutes after tapping, the foam should lessen. Additionally,
pours with the spout fully open should deliver less foam than pours with the
spout only partially open.
To put the mini keg into the mini kegerator:
1. Open the mini kegerator door by depressing the button located on the upper
right-hand side of the door.
2. Gently put the mini keg on the cold plate. You may find it helpful to hook the
line(s) up to the mini keg while it is slightly outside the unit.
Heineken brand DraughtKeg tapping instructions
Heineken brand DraughtKeg mini kegs have an internal CO2 tank. This is the only
type of mini keg that you can tap without the optional accessories.
1. Chill the mini keg
2. Open the door of the mini kegerator.
3. Place the mini keg near the open door.
4. Make sure the top of the mini keg looks like this:
5. Attach the Heineken-style tap to the beer line:
6. Attach the Heineken-style tap and beer line assembly to the mini keg:
4

7. Place the mini keg inside the mini kegerator and shut the door.
8. Pour your first glass of beer!
9. When the keg is floated, remove the Heineken-style tap from the keg by
squeezing the two tabs on top of it and pulling it off.
10.Detach the tap from the beer line by pressing the white/gray button and pulling
the line off.
11.Rinse the tap under running water. You should also clean it with a mild
detergent solution and rinse it thoroughly.
12.Clean the beer lines as noted above.
Note: Heineken says that a tapped Heineken brand DraughtKeg will remain fresh
for up to 30 days after tapping (provided it remains refrigerated).
Non-pressurized mini keg tapping instructions
Note that the following instructions refer to optional accessories. Call 866.319.5473
for more information or to order them.
All 5 Liter mini kegs except the above-mentioned Heineken DraughtKeg are “non-
pressurized”- though the kegs are shipped with minimal pressure inside to ensure the
freshness of the beer, once they are opened, all the pressure escapes and they must
be served with gravity (poured), or by re-pressurizing them (in this case, with CO2).
All non-pressurized mini kegs must use the optional non-pressurized mini keg tap,
shown following:
CO2 line in connects
here (CO2flows in here) Beer line connects here (beer flows out this connector)
Piercing tube (goes into
the mini keg)
A few notes on usage of the above tap:
•Before piercing the plug on the top of the keg, you must always follow the
instructions marked on the keg to eliminate the excess gas and ensure that
5

the keg has remained still long enough to avoid foaming from the ventilation
opening.
•It’s a good idea to wet the “piercing tube” with a little water prior to tapping a
mini keg. This will lubricate the tube.
•Drive the piercing tube soundly into the mini keg when tapping it, and then
secure the tap assembly onto the top of the mini keg with the spring-loaded
catch.
Tapping the different types of kegs:
There are several different types of non-pressurized 5 Liter kegs available. The mini
kegs mainly differ in the type of “bung” (plug) sealing the top of the mini keg. It is into
this bung that the mini kegs are tapped.
a) Mini keg with rubber plug:
This type of plug allows you to tap the keg with the piercing tube
by screwing the piercing tube into the rubber bung- simply drive
the tube down the center of the bung- the center piece will fall
harmlessly into the beer.
b) Mini keg with combined plug:
This type of plug requires the pressurized air to be expelled from the keg before tapping it.
Read and comply with the instructions on the mini keg. Then pull vigorously on the below-
pictured part, revealing the second part of the plug. Next drive the piercing tube down the
center of the bung- the center piece will fall harmlessly into the beer.
c) Mini keg with vent plug:
It is difficult to tell the difference between this type of bung and the above type (combined
plug).
This type of plug requires the pressurized air to be expelled from the keg before tapping it.
Read and comply with the instructions on the mini keg. Then pull vigorously on the below-
pictured part, revealing the second part of the plug. Now use a tool (not included) the
cut/remove the remaining part of the bung. If part of the bung falls into the beer, this will not
cause any health risks or affect the flavor of the beer. Now fit the yellow-orange all-purpose
plug (received with the optional spare parts) into the hole in the mini keg. Finally, drive the
piercing tube down the center of this plug. (Note: make sure to retrieve, wash, and save this
plug for future use when you are done with this mini keg.)
6

d) Other types of mini kegs:
For most other types of mini kegs, you can remove the bung and replace it with the
yellow-orange all-purpose plug (received with the optional spare parts). Then drive the
piercing tube down the center of this plug. (Note: make sure to retrieve, wash, and save
this plug for future use when you are done with this mini keg.)
Installing the beer line and running the CO2to the mini keg
Now that you have tapped your non-pressurized mini keg, you need to run the beer
line and CO2 supply.
Running the beer line is simple- insert the “male” end of the beer line in the mini
kegerator to the “female” receptacle on the tap.
Running the CO2is a bit more complicated:
•Open the compartment located on the right-hand side of the mini kegerator.
•Make sure that the pressure gauge valve is closed (to close the valve, turn it counter-
clockwise).
•Attach the pressure gauge on the end piece of the 16g adapter.
•Insert the 16g CO2cartridge in the long part of the adapter.
•Screw the two parts of the adapter together.
Note : once you screw this
assembly together with a 16g
CO2 cartridge, do not unscrew it
until the cartridge is empty- or all
remaining CO2 will rush out
•Screw the gas cartridge fully home on the pressure gauge.
•Connect the hose by driving it home into the regulator (To check that the hose is
correctly connected, try to remove it by gently tugging on it. Resistance indicates that
7

the hose is correctly connected. If you really want to disconnect the hose, push down
the metallic end-piece while pulling the hose).
•Place the assembly on its support and place the entire assembly into the
compartment located on the right-hand side of the mini kegerator.
•Connect the
CO2 line to the tapped mini keg (the “female” end of the line coming from
the mini kegerator connects to the “male” connector on the mini keg tap)
•Turn the dial on the regulator clockwise to begin the flow of CO2. Check the chart
under “Operation” for pressure suggestions.
Notes:
You can use a larger CO2tank if you wish. Please seek informed assistance if you wish to
pursue this option.
Do not use BB gun/paintball CO2 cartridges- these often have some oil mixed in with the
CO2.
Make sure to close the regulator if you want to remove the tap from the mini-keg.
To replace the CO2 cartridge, close the regulator, unscrew the current cartridge, and reinstall
a new cartridge as detailed above.
Removing the CO2line and mini keg
Once your mini keg is floated, you need to shut off the CO2 and remove the keg.
•Open the compartment located on the right-hand side of the mini kegerator.
•Shut off the regulator (turn the knob counter-clockwise).
•Put a container under the dispenser and pour off any remaining beer (this will also
relieve some of the pressure in the mini keg).
•Open the mini kegerator main door and disconnect the CO2 line and beer line.
•Empty the remaining CO2from the mini keg with the CO2 releaser as shown
following:
•Undo the tap from the mini keg by releasing the catch (on the top of the tap)
and pulling it up and out of the mini keg):
8

•Rinse the tap out under running water. You should also clean it with a mild
detergent solution and rinse it thoroughly.
•Clean the lines as directed above under “Tapping your first mini keg”
Note that the optional accessories include a cleaning kit that uses CO2 pressure to
force the cleaning solution through the lines. To use this system, fill the cleaning kit
half full with your choice of cleaning solution (water mixed with a bit of beer line
cleaner, baking soda, or white vinegar), connect it to the unit as if it were a non-
pressurized mini keg, and pour out all of the solution. Make sure to rinse the lines
again!
Operation
1. For best results, use clean glasses. Rinsing the glasses with cold water prior to
pouring can deliver better results (less foam).
2. Hold the glass at an angle under the dispenser. Do not touch the nozzle of the
dispenser to the glass.
3. Pull the dispenser handle towards you to start the flow of beer. Open the dispenser
up all the way to get the maximum flow rate (this will decrease foam).
4. Slowly tip the glass upright as it fills.
5. Gently ease the dispenser handle back to the “closed” position as the foam nears the
lip of the glass.
6. Enjoy your beer!
Note: If you are enjoying a non-pressurized mini keg, you may adjust the pressure for
maximum enjoyment. Here are our suggestions:
Beer type CO2 content in % Pressure (@ approx. 41°F)
German beers +/- 0.5 +/- 0.4 - 0.5 bars
French beers +/- 0.6 - 0.8 +/- 0.8 bars
Very fermented brown ales +/- 0.6 - 0.8 +/- 0.8 - 1 bars
Cleaning
You should clean the lines after every keg. The instructions for this are under the
heading “Tapping your first mini keg”.
For cleaning the other parts of the unit, a damp cloth with a mild detergent solution is
best.
9

Important Safeguards
•Do not use the appliance if the power supply cord is damaged. If the power
supply cord is damaged, it must be replaced by a qualified technician.
•This unit is designed to function on 115 Volts/ 60 Hz (110/115/120 Volts
acceptable) electrical circuits.
•This appliance is not designed for children. Never allow unattended children to
use this appliance.
•Unplug the appliance if it will not be used for an extended period of time.
•Unplug the appliance prior to cleaning.
•Set the appliance on a flat surface away from direct sunlight and other heat
sources.
•This appliance is designed to function optimally in room temperature
environments (mid 70°s Fahrenheit).
•Do not move the unit while it is full.
•The power supply cord must be grounded.
•Never pull the cord directly to disconnect the appliance. Always pull the plug
out of the socket.
•Never lift the appliance by the power supply cord or the dispensing tap.
•Keep the power supply cord away from heating surfaces.
•Do not try to repair, adjust this appliance or replace its components by
yourself. Should it not operate correctly, contact customer support.
•This appliance is designed for household use only and not for commercial use.
Do not use the appliance for other uses than that for which it is designed.
•Do not immerse the appliance or its power supply cord in water or any other
liquid.
•Do not cover the appliance or place anything on it.
•Do not insert any objects into the ventilation holes.
•Only use approved CO2cartridges
•Cartridges contain pressurised CO2. Keep them away from heat, in a dry and
cool place.
•Do not dispose of empty CO2 cartridges in a fire.
•Clean this appliance prior to use, and after every keg
Limited Warranty
This EdgeStar product is warranted to be free from defective workmanship and
materials for the first year following the date of original purchase. Replacement parts
will be supplied free of charge for the first year following the date of original purchase.
Labor will be performed free of charge for the first 90 days following the date of
original purchase.
WHAT IS COVERED:
This warranty applies to the original purchaser only, and only covers defects in
workmanship experienced during operation of the product under normal service,
maintenance, and usage conditions. This warranty applies to the purchase and use
of this product in residential settings within the United States of America.
WHAT IS NOT COVERED:
The following limitations apply to the coverage of this warranty:
10

Optional accessories, attachments, and appearance items are excluded from
warranty coverage, as is shipping damage, and any damage caused by improper
voltage or any other misuse, including abnormal service, handling, or usage.
This warranty does not cover normal wear and tear on parts or replacement of parts
designed to be replaced, e.g. filters, etc.
This warranty does not cover service trips to deliver, pick-up, repair, or install the
product, or to instruct in proper usage of the product.
Damages or operating problems resulting from abuse, operation outside
environmental specifications, uses contrary to instructions provided in the owner’s
manual, accidents, vermin, fire, flood, improper installation, unauthorized service,
acts of God, unauthorized installation or modification, or commercial use are
excluded from warranty coverage.
This warranty does not cover labor incurred 91 days or more after the date of original
purchase.
This warranty does not cover use of EdgeStar products in commercial settings.
DESCRIPTION OF WARRANTY SERVICE:
All defective product components covered by this warranty will be repaired or
replaced, at EdgeStar’s option, free of charge on a mail-in basis to EdgeStar’s
authorized repair facility during the first 90 days from the date of original purchase.
All defective product components covered by this warranty will be repaired or
replaced, at EdgeStar’s option, on a mail-in basis to EdgeStar’s authorized repair
facility during the time period beginning on the 91st day from the date of original
purchase and ending one year from the date of original purchase. During this time
period, parts will be supplied free of charge, but labor charges will apply.
All replacement parts and units will be new, remanufacturered, or refurbished.
All products and components replaced by EdgeStar under warranty service become
the property of EdgeStar.
OBTAINING WARRANTY SERVICE:
Contact EdgeStar for troubleshooting assistance and warranty service authorization
at 1-866-319-5473. Please have your order receipt available to confirm the date of
purchase.
Once an EdgeStar authorized representative has confirmed that your product is
eligible for warranty service, the product must be returned to an EdgeStar authorized
repair facility.
The purchaser is solely responsible for prepaying all shipping related costs to and
from the repair facility.
EdgeStar is not responsible for damage resulting from shipper mishandling or
improper packaging.
Do not return defective product to the place of purchase.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR
IMPLIED, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE
EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN
DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. NEITHER THE
MANUFACTURER NOR ITS DISTRIBUTORS SHALL BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES
11

OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR
PROFITS, OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT, TORT,
OR OTHERWISE. SOME STATES DO NOT ALLOW THE EXCLUSION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION
MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO
STATE.
12
