EdgeStar CWR302SZ User manual

ii
V2.0-08062018
Built-In Wine Cooler
CWR302SZ
Owner’s Manual
For more information on other great EdgeStar products on the web, go to http://www.edgestar.com
To use the EdgeStar self-diagnostic tool, go to https://support.edgestar.com

i
Important Safety Information
Improper handling can cause serious damage to the EdgeStar Wine Cooler and / or injury to
the user. This Wine Cooler is designed for domestic indoor use only. Do not use the unit for
industrial or commercial use. Any other use may invalidate the warranty. Please review the
ratings label located on the rear panel of the unit for electrical and other technical data related
to this unit. The unit must be used in a properly grounded wall outlet.
Please read and follow the safety information listed below to reduce the risk of fire,
electric shock, or injury.
Electrical Safety
Do not exceed the power outlet ratings.
It is recommended the Wine Cooler be connected on its own circuit.
The unit must be installed in accordance with state and local electrical codes.
A standard electrical supply (115 V, 60Hz), that is properly grounded in accordance with the
National Electrical Code and local codes and ordinances is required.
Use outlets that cannot be turned off by a switch or pull chain.
Always turn the unit off and unplug it from the outlet when cleaning.
Unplug the unit if it is not going to be used for an extended period of time.
Do not operate the unit with a power plug missing the ground plug, a damaged cord, or a loose
socket.
Be sure the Wine Cooler is properly grounded.
Never plug or unplug the unit with wet hands.
Do not bypass, cut, or remove the grounding plug.
Do not use extension cords or power strips with this unit. You may need to contact your
electrician if it is necessary to use a longer cord or if you do not have a grounded outlet. Do not
modify the power cord’s length or share the outlet with other appliances.
Do not start or stop the unit by switching the circuit’s power on and off.
If the power cord is damaged, it must be replaced by the manufacturer or a qualified technician.
Never repair the unit while it is plugged in.
Immediately unplug the unit if it makes strange sounds, emits smells, or smoke comes out of it,
and contact customer service.
Do not remove any part of the casing unless you are instructed to do so by an authorized
technician.
You should never attempt to repair the unit yourself.
Contact customer service for service options if the unit needs service.

ii
Note: This owner’s manual is provided for reference use only. Specifications may change
without prior notice. Refer to the product label on the back of your Wine Cooler for the latest
technical information.
General Safety
To prevent back and other types of injuries, use at least two people to move and install the wine
cooler.
This appliance is not intended for use by persons, including children, with reduced physical,
sensory or mental capabilities, unless they have been given supervision or instruction concerning
the use of the appliance by the person(s) responsible for their safety.
Install the Wine Cooler in a well-ventilated area where the ambient temperature is above 50° F
and below 95° F.
The temperature range for this cooler is optimized for wine storage. Perishable food items may
require a different storage environment.
Do not place hot or warm items into the cooler before they cool down to room temperature.
This unit is designed to be installed indoors, and protected from rain, sleet, snow, and / or
moisture.
This unit is not intended to be used by children.
Children should be supervised to ensure that they do not play with this product.
Never allow children to crawl inside the Wine Cooler. If you are disposing of the unit, remove the
door.
Do not use this appliance near flammable gas or combustibles, such as gasoline, benzene,
thinner, etc.
Do not place the unit near heat sources such as ovens, grills, or direct sunlight.
Only use in an upright position on a flat, level surface and provide proper ventilation.
Do not pinch or kink the power supply line between the unit and cabinet.
Do not leave any cleaning solutions in the unit.
Do not use solvent-based cleaning agents or abrasive solutions to clean the unit as they may
damage the interior and exterior.
Do not place any other appliances on top of the unit.
Do not turn the unit upside down, on its side, or at an angle off level.
If your model of wine cooler is equipped with a lock, take care to keep the keys away from
children.
Do not move the unit without emptying the contents and securing the door in a closed position.
Note: Flammable Refrigerant Used! When handling, moving, and using the refrigerator, make
sure to avoid either damaging the refrigerant tubing, or increasing the risk of a leak.

iii
Table of Contents
IMPORTANT SAFETY INFORMATION.......................................................................................................................I
TABLE OF CONTENTS .............................................................................................................................................III
FIRST TIME OPERATING INSTRUCTIONS ...........................................................................................................................4
INTRODUCTION..........................................................................................................................................................4
PARTS IDENTIFICATION ...........................................................................................................................................5
FRONT VIEW ..................................................................................................................................................................5
BACK VIEW ....................................................................................................................................................................5
Carbon Filter ................................................................................................................................................................6
Internal Fan..................................................................................................................................................................6
INSTALLING THE WINE COOLER ............................................................................................................................7
UNPACKING THE WINE COOLER......................................................................................................................................7
TYPES OF INSTALLATION.................................................................................................................................................7
Free-standing Installation:............................................................................................................................................7
Built-in Installation:.......................................................................................................................................................7
INSTALLATION CLEARANCE REQUIREMENTS.....................................................................................................................8
ELECTRICAL REQUIREMENTS ........................................................................................................................................10
Recommended Grounding Method............................................................................................................................10
LEVELING THE WINE COOLER........................................................................................................................................10
INSTALLING THE DOOR HANDLE.....................................................................................................................................11
INSTALLING AND REMOVING THE SHELVES.....................................................................................................................11
To Install the Shelves:................................................................................................................................................11
To Remove the Shelves.............................................................................................................................................11
REVERSING THE DOOR SWING......................................................................................................................................12
To Reverse the Door from Right Swing to Left Swing ...............................................................................................12
REMOVING AND INSTALLING DECORATIVE PLUGS...........................................................................................................13
OPERATION..............................................................................................................................................................14
INSTALLATION CHECK LIST BEFORE OPERATION............................................................................................................14
USING THE TEMPERATURE CONTROL PANEL..................................................................................................................15
NORMAL SOUNDS.........................................................................................................................................................16
Temperature Alarm ....................................................................................................................................................16
Door Ajar Alarm..........................................................................................................................................................16
DEFROSTING................................................................................................................................................................16
PREPARING THE WINE COOLER FOR STORAGE ..............................................................................................................17
CLEANING AND MAINTENANCE............................................................................................................................17
EXTERIOR CLEANING....................................................................................................................................................17
INTERIOR CLEANING .....................................................................................................................................................17
TROUBLESHOOTING...............................................................................................................................................18
SPECIFICATIONS.....................................................................................................................................................20
EDGESTAR LIMITED WARRANTY..........................................................................................................................21

4
First Time Operating Instructions
Before use, make sure all packaging labels and materials are removed from the unit. Be sure
to keep track of all included parts and pieces before discarding the packaging materials. It is
advised that you keep the original box and packaging materials in case you ever need to move
or ship the appliance in the future.
Let the unit stand for at least 24 hours before you use it; this allows the cooling components
time to settle from transit. The instruction manual should be read before use.
Introduction
Thank you for purchasing this EdgeStar Wine Cooler. We hope that this purchase will be the
beginning of a lasting and rewarding relationship between you and EdgeStar. We will provide
the customer support and exemplary products necessary to nurture that relationship.
This manual contains important information regarding the proper installation, use, and
maintenance of your Wine Cooler. Following this manual will ensure that your product will work at
its peak performance and efficiency.
Please save the original product packaging in case you need to safely transport your Wine Cooler.
For Your Records:
Please write down the model number and serial number below for future reference.
Both numbers are located on the ratings label on the back of your unit and are needed
to obtain warranty service. You may also want to staple your receipt to this manual as it
is the proof of your purchase, and is also needed for service under your warranty.
Model Number:
Serial Number:
Date of Purchase:
For a more efficient experience, please do the following before contacting customer service:
If you received a damaged product, immediately contact the retailer or dealer that sold you
the product.
Read and follow this instruction manual carefully to help you install, use, and maintain your
Wine Cooler.
Read the troubleshooting section of this manual as it will help you diagnose and solve
common issues.
Visit us on the web at http:/www.edgestar.com to register your product, download product
guides, and access additional troubleshooting resources and up-to-date information. You
can also find an interactive self-diagnostic tool at https://support.edgestar.com
If you need warranty service, our friendly customer service representatives are available
via email at serv[email protected] or by telephone at 1 [phone].

5
Parts Identification
Front View
Back View
Note: The carbon filter
should be replaced
every 3-6 months
depending on the
unit’s exposure level
to odor. If the unit is
placed in the kitchen
regular replacement
every 3 months is
ideal.

6
Carbon Filter
A built-in carbon filter protects your beverages by acting as a natural barrier against harmful
odors.
Internal Fan
This is an air-cooled unit equipped with an internal fan that maintains a consistent internal
temperature.
Note: The Carbon filter should be replaced every 3 - 6 months depending on the unit’s
exposure level to odor. If the unit is placed in the kitchen, regular replacement every 3 months
is ideal.
Tip: Gather the model and serial number from the product label and write them down before
installing the Wine Cooler.

7
Warning: Use two or more people to move and install the Wine Cooler. Failure to do so can
result in back or other injury. Carefully remove the packaging materials. Remove any shipping
tape and glue from your Wine Cooler before use. Do not use sharp instruments, rubbing
alcohol, flammable fluids, or abrasive cleaners to remove tape or glue. These products can
damage the surface of your Wine Cooler.
Important: Do not remove any safety, warning, or product information labels from your Wine
Cooler.
Installing the Wine Cooler
The Wine Cooler should be installed in accordance with local electrical code requirements.
The Wine Cooler should also be placed in a location that is strong enough to support its total
weight, keeping in mind that it will weigh substantially more when fully loaded than when empty.
Before you plug the Wine Cooler into a power supply, be sure to let it stand upright for
at least 24 hours to allow the compressor’s oils to settle.
Unpacking the Wine Cooler
Types of Installation
This Wine Cooler has been designed for free-standing or built-in installation. In each case,
there must be adequate ventilation and access for service.
Free-standing Installation:
A free-standing installation will allow you to install the Wine Cooler in almost any place you
desire. You must follow the stated instructions for electrical requirements and leveling the
Wine Cooler.
Built-in Installation:
A recessed installation will allow you to install the wine cooler under a counter or in a
kitchen cabinet as long as the required clearance space around the wine cooler is
provided. It is necessary to allow adequate ventilation space around the unit, including at
the back of the unit. The following additional items must be observed:
1. Place the Wine Cooler in front of the installation location. Adjust the feet and place the
unit flat on the floor or on a platform depending on your installation requirements.
2. If the electrical outlet for the Wine Cooler is behind the cabinet, plug in the Wine
Cooler.
3. Push the Wine Cooler into position.
Tip: Gather the model
and serial number
from the product label
and write them down
before installing the
Wine Cooler.
Warning: DO NOT install the Wine Cooler behind a closed cabinet door.

8
Important Notes:
Choose a location that has ambient temperatures above 50° F and below 95° F. Operation outside
these temperatures may result in lowered efficiency or cause other adverse effects.
This unit MUST be installed in an area protected from the elements, e.g. wind, rain, water spray or
drips.
The Wine Cooler should not be located next to ovens, grills, or other high heat sources.
Do not kink or pinch the power supply cord between the Wine Cooler and the wall or cabinet.
Installation Clearance Requirements
When installing the Wine Cooler under a counter, follow the recommended spacing dimensions
shown.
To ensure proper service access and ventilation, allow at least 1-2” of clearance at the
back, 1/4” at the top, and 1/4” at the sides. If the door side is against a wall, allow at least
2 3/8”of clearance. The installation should allow the unit to be pulled forward for servicing,
if necessary.
Important Notes:
• Choose a location that has
ambient temperatures above
50°F and below 95°F.
Operation outside these
temperatures may result in
lowered efficiency or cause

9
The Wine Cooler should be installed on a firm and level surface that will be able to support
the entire weight of a fully loaded unit. It is important for the Wine Cooler to be level in
order to work properly. If needed, you can adjust the height of the Wine Cooler by rotating
the feet. See the “Leveling the Wine Cooler” section.
A standard electrical supply (115 VAC only, 60 Hz), properly grounded in accordance with
National Electrical Code and local codes and ordinances, is required.

10
ELECTRIC SHOCK HAZARD!
Plug into a grounded 3-prong outlet.
Never remove the grounding prong from the plug.
Never use an adapter to bypass the grounding prong.
DO NOT use an extension cord.
Failure to follow these instructions can result in fire, electrical shock, or death.
Important: Once you are ready to install the unit in a cabinet or directly on the floor, you must
adjust the feet to level the Wine Cooler.
Electrical Requirements
Before you move your Wine Cooler into its final location, it is important to make sure you have
the proper electrical connection:
A standard electrical supply (115 V, 60Hz), properly grounded in accordance with the National
Electrical Code and local codes and ordinances, is required.
It is recommended that a separate circuit, serving only your Wine Cooler, be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
The fuse (or circuit breaker) size should be 3 Amps.
Recommended Grounding Method
For your personal safety, this appliance must be grounded. It is equipped with a power
supply cord that has a 3-pronged grounding plug. To minimize possible shock hazard, the
cord must be plugged into a mating 3-pronged wall socket, and grounded in accordance
with the National Electrical Code and local codes and ordinances. If a mating wall socket is
not available, it is the personal responsibility of the customer to have a properly grounded,
3-prong wall receptacle installed by a qualified electrician.
Leveling the Wine Cooler
It is important for the Wine Cooler to be level in order to work properly. It
can be raised or lowered by rotating the plastic sheaths around each of
the feet on the bottom of the machine. If you find that the surface is
not level, rotate the feet until the Wine Cooler becomes level .You may
need to make several adjustments to level it. We recommend using a
carpenter’s level to check the machine.
1. Place a carpenter’s level on top of the product to see if the Wine Cooler
is level from front to back and side to side.
2. Adjust the height of the feet as follows:
Turn the leveling feet to the right to lower that side of the
refrigerator.
Turn the leveling feet to the left to raise that side of the
refrigerator.

11
Installing the Door Handle
To install the door handle:
1. Open the door and carefully pull the door gasket around the area where the handle is to
be installed.
2. Carefully remove the two pre-installed decorative plugs from the front of the door.
3. Insert each Phillips head screw through the gasket side of the door until the screw passes
through the door.
4. Align the handle with the screws and tighten using a Phillips head screwdriver until the
handle is flush against the door frame.
5. Carefully press the door gasket into its original position.
Installing and Removing the Shelves
To prevent damaging a door gasket, make sure to open the door all the way before pulling the
shelves out of their track.
To Install the Shelves:
1. Open the door completely.
2. Slide the shelf onto the shelf track and slowly push it back until it stops.
3. Push down on the front of the shelf to allow the back of the shelf to lift over the plastic
post. (Imagine a seesaw movement.) Continue to push the shelf back until both
notches pass through the plastic posts on each side of the shelf track.
4. Continue to push the shelf back.
To Remove the Shelves
1. Open the door completely.
2. If necessary, make sure you remove all the contents sitting on the shelf.
3. Pull the shelf forward until the notch aligns with the plastic post on each side of the
shelf track.
4. Lift the shelf until both notches pass through the posts.
5. Continue to pull the shelf forward until it is completely removed from the inner
compartment.
Note: some wine coolers do not have decorative plugs installed.
Caution: Do not over-tighten the screws as this may cause damage to the handle or to the
stainless steel door.

12
Reversing the Door Swing
Follow the instructions below to reverse the door swing.
To Reverse the Door from Right Swing to Left Swing
1. Open the door and use a Philips Screwdriver to remove the bottom screws from the
lower hinge.
2. Carefully slide the bottom of the door forward and down, and place it on a padded
surface to prevent damaging it.
3. Remove the screws from the upper right hinge. Place the upper right hinge in a safe
place in case you need to reverse the door in the future. Remove the plastic caps
from the upper left hinge corner. Install the upper left hinge by fastening the screws
through the left hinge to the cabinet. Insert the plastic caps into the upper right corner.
4. Remove the lower hinge and bushing from the bottom right support bracket. Remove
the decorative screws from the left corner of the door and install and tighten them to
the right corner holes. Remove the plastic cap from the top left corner of the door and
insert it into the top right corner.
Important: Before you begin, unplug the refrigerator.

13
5. Install the lower hinge and bushing on the bottom left support bracket.
6. Carefully insert the door into the upper right corner hinge, then slide the door on top
of the lower hinge and secure the door by installing the lower screws.
Removing and Installing Decorative Plugs
Follow the instructions below to remove the decorative plugs from the door.
1. Open the door and carefully pull the door gasket from the top left corner until you have
exposed the two holes which correspond with the decorative plugs.
2. Insert a Flathead screwdriver through the gasket side of the door into the decorative plug
slot. You may need to use a flashlight to help guide you through this process.
Important: Before you begin, unplug the refrigerator.

14
3. Carefully turn the screwdriver clockwise to remove the two pre-installed decorative plugs
from the front of the door. Reinsert the decorative plugs into the right side of the door
using this same procedure.
4. Remove the decorative plastic cap from the top left corner of the door and insert it into the
top right corner.
5. After the cap is inserted, carefully press the door gasket into its original position.
Operation
Installation Check List Before Operation
1. Have all packing materials and tape been removed from the interior and exterior of the
Wine Cooler?
2. Have the installation instructions been followed, including connecting the machine to
electricity? And has proper grounding been installed for the Wine Cooler?
3. Has the machine been leveled?
4. Is the Wine Cooler in a site where the ambient temperature is between 50° F and 95° F
all year round?
5. Is there a clearance of at least 1- 2” at the rear, 1/4” at the top, and 1/4” at the sides for
proper air circulation?

15
Using the Temperature Control Panel
The single zone of this Wine Cooler has a temperature range from 40°F to 65°F and
will display the set temperature.
Up Button : Press the button on the control panel to increase the temperature by 1
degree increments.
Down Button : Press the button on the control panel to lower the temperature by 1
degree increments.
RUN LIGHT: When lit, the unit is in cooling mode
Light Button : Press the button to turn the inner light on or off.
Power Button : Turns the unit on and off. ( press and hold this button for approximately 3
seconds)
The Celsius or Fahrenheit light will be lit depending on which temperature type is being
displayed. To switch between C and F. press and hold both buttons (▲/ ▼) simultaneously
for approximately 3 seconds. A beep will occur and the indicator light will illuminate next to
desired temperature setting.
Note:
The Wine Cooler is equipped with a temperature memory function. If power is suddenly
lost, the previously set temperature will be saved and the refrigerator will return to this
setting once power is restored.
Allow at least 24 hours before storing your wines to allow the setting temperature to be
reached.
Caution: If you powered the unit off, please wait at least 5 minutes before powering it back on.

16
Warning: Never attempt to remove frost with a sharp object!
Normal Sounds
Your new Wine Cooler may make sounds that are not familiar to you. Most of the new sounds
are normal. Hard surfaces like the floor and walls can make the sounds seem louder than they
actually are. The following describes the kinds of sounds that might be new to you and what
may be making them.
Rattling noises may come from the flow of the refrigerant or the water line. Items stored on
top of the Wine Cooler can also make noises.
The high efficiency compressor may make a pulsating or high-pitched sound.
Water running from the evaporator to the water bin may make a splashing sound.
As each cycle ends, you may hear a gurgling sound due to the refrigerant flowing in your
Wine Cooler.
You may hear air being forced over the condenser by the condenser fan.
Temperature Alarm
If the interior temperature is higher than 73°F (23°C), “HI” is shown on the temperature
control panel and the temperature alarm will sound continuously after one hour.
This indicates that the inner temperature is too high. If the inner temperature is lower
than 32°F (0°C), “LO” is shown on the temperature display panel and the temperature
alarm will sound continuously after one hour. If one of these situations occurs please
reference the troubleshooting section found in this manual or contact EdgeStar for support.
Door Ajar Alarm
This Wine Cooler includes a door ajar alarm, which will sound if one of the doors is
open for more than five (5) minutes. Leaving the door open for extended periods of time
will cause poor cooling performance and may shorten the life of the refrigerator. Keep
the doors closed as frequently as possible.
Defrosting
Note that under most refrigerating settings, the unit will automatically defrost under most
ambient conditions. However, on colder settings, some frost may build up. Additionally, the
more humid the ambient conditions, the more frost may build up. Keep the door closed as
much as possible and avoid opening the door unnecessarily to minimize frost build-up.
If frost is preventing the door from closing properly, you may need to power the unit off until the
frost melts. Use a soft absorbent towel to dry the unit.

17
Preparing the Wine Cooler for Storage
If the Wine Cooler will not be used for a long time, or is to be moved to another place, it will be
necessary to defrost the unit and dry the interior.
1. Disconnect the wine cooler from the power supply by removing the power plug from the
wall socket.
2. Leave the door open to allow for air circulation and to prevent mold, mildew, and
unpleasant smells.
Cleaning and Maintenance
Periodic cleaning and proper maintenance will ensure efficiency, top performance, and long life.
Exterior Cleaning
The door and cabinet may be cleaned with a mild detergent and lukewarm water solution such
as 2 tablespoons of baking soda to 1 quart of water.
Do not use solvent based or abrasive cleaners. Use a soft sponge and rinse with clean water.
Wipe with a soft clean towel to prevent water spotting. If the door panel is stainless steel, it can
discolor when exposed to chlorine gas and moisture. Clean stainless steel using a cloth
dampened with a mild detergent and warm water solution. Never use an abrasive or caustic
cleaning agent.
Interior Cleaning
The Wine Cooler’s interior should be cleaned occasionally.
1. Disconnect power to the unit.
2. Open the door and remove the contents and shelves.
3. Wait until the unit defrosts.
4. With a clean cloth, wipe down the interior of the unit.
5. Reinsert the shelves and wine.
6. Reconnect power to the unit.
IMPORTANT:
• Do not touch the power plug
when your hands are wet.
• Never unplug the unit by
pulling on the plug.
Caution: Store the unit out of reach from children. If you have children, you may want to take
additional precautions such as removing the door to prevent a child from being trapped inside
the cooler!
Important:
Do not touch the power plug when your hands are wet.
Never unplug the unit by pulling on the plug.

18
Troubleshooting
Before Calling for Help
If the unit appears to be malfunctioning, read through the “Operation” section of this manual
first. If the problem persists, check the Troubleshooting Guide below and on the following page.
The problem may be something that can easily be solved or explained.
Symptoms
Possible Causes
Solutions
The wine cooler turns on and
off frequently.
The room temperature is
higher than the recommended
ambient environment.
Run the cooler at the
appropriate ambient
temperature.
The door is being opened too
often.
Minimize the number of times
the door is opened.
The door is not completely
closed.
Make sure the door is
completely closed.
The door gasket is not sealing
properly.
Make sure the door gasket is
sealing properly.
The cooler does not have the
suggested ventilation.
Read and follow the
“Installation Clearance
Requirements” section.
The wine cooler does not turn
on.
There is a power failure.
Ensure that the cooler is
plugged in and the power
outlet has power.
The cooler is not plugged in.
Plug the unit in to a power
outlet that has sufficient
amperage.
A house fuse has blown or
the circuit breaker is tripped.
Replace the broken fuse in
your fuse box or reset the
breaker.
The wine cooler will not reach
the desired temperature.
The cooler is placed too close
to a heat source.
Keep the cooler away from
direct sunlight or other heat
sources.
The cooler does not have
sufficient ventilation.
Read and follow the
“Installation Clearance
Requirements” section.
The door is opened too
frequently or for a long period
of time.
Close the door tightly and do
not open the door too
frequently or for a long period
of time.
The wine cooler is making
strange noises.
Certain sounds are normal.
Read the “Normal Sounds”
section.
The unit is not level or is
touching another appliance.
Check to make sure that the
cooler is level, and that it is
not in contact with another
appliance or furniture.

19
Symptoms
Possible Causes
Solutions
The body of the Wine Cooler
is electrified.
The unit is not grounded
properly.
Contact your local electrician
to test your electrical
grounding system.
Frost is forming in the wine
cooler.
The environment is humid.
Though the unit uses an
“auto-defrost” system, under
certain conditions, manual
defrosting may be required. If
frost builds up, you can try
running the cooler on a
warmer temperature setting,
minimizing the number of
times you open the door, or
unplugging the unit to allow
the frost to melt.
The ambient temperature is
too low.
The door is being opened too
frequently.
The door will not shut
properly.
The cooler is not level.
Make sure the cooler is on a
level surface.
The door gasket is dirty.
Clean the door gasket.
The door gasket is not
installed correctly.
Make sure the door gasket is
correctly installed.
The shelves are incorrectly
installed.
Install the shelves correctly.
