Edgetech STARMUX III User manual

EdgeTech
4 Little Brook Road
West Wareham, MA 02576
Tel: [phone]
Fax: [phone]
www.EdgeTech.com
STARMUX III
U S E R H A R D W A R E M A N U A L
0016903_REV_B July 2016

ii
STARMUX III 0016903_REV_B
The information, figures, and specifications in this manual are proprietary and are issued in strict
confidence on condition that they not be copied, reprinted, or disclosed to a third party, either wholly or
in part, without the prior, written consent of EdgeTech. Any reproduction of EdgeTech supplied software
or file sharing is strictly prohibited.
EdgeTech © 2016. All rights reserved.

iii
ATTENTION –READ THIS FIRST!
All personnel involved with the installation, operation, or maintenance of the equipment described in this
manual should read and understand the warnings and cautions provided below.
CAUTION! This equipment contains devices that are extremely sensitive
to static electricity. Therefore, extreme care should be taken when
handling them. Normal handling precautions involve the use of anti-static
protection materials and grounding straps for personnel.
WARNING! High Voltage may be present in all parts of the system.
Therefore, use caution when the electronics are removed from their
containers for servicing.
CAUTION! Operation with improper line voltage may cause serious
damage to the equipment. Always ensure that the proper line voltage is
used.

iv
STARMUX III 0016903_REV_B
HARDWARE VARIATIONS AND COMPATIBILITY
The STARMUX III contains both standard and proprietary hardware. At times, EdgeTech may change the
standard components due to their availability or performance improvements. Although the component
manufacturers—along with their models and styles—may change from unit to unit, replacement parts will
generally be interchangeable.
EdgeTech will make every effort to see that replacement components are interchangeable and use the
same software drivers (if applicable). At times, however, direct replacements may not exist. When this
happens, EdgeTech will provide the necessary drivers with the replacement part, if applicable.
EdgeTech may also change certain hardware per customer requirements. Therefore, portions of this
manual, such as parts lists and test features, are subject to change. These sections should be used for
reference only. When changes are made that affect system operation, they will be explicitly noted. Also,
some options and features may not be active in the customer’s unit at time of delivery. Upgrades will be
made available when these features are implemented.
Contact EDGETECH CUSTOMER SERVICE with any questions relating to compatibility.

v
ABOUT THIS DOCUMENT
We, the employees at EdgeTech, would like to thank you for purchasing STARMUX III. At EdgeTech, it is
our policy to provide high-quality, cost-effective products and support services that meet or exceed your
requirements. We also strive to deliver them on-time, and to continuously look for ways to improve them.
We take pride in the products we manufacture, and want you to be entirely satisfied with your equipment.
Purpose of this Manual
The purpose of this manual is to provide the user with information on the setup and use of EdgeTech’s
STARMUX III. Although this manual encompasses the latest operational features of the STARMUX III, some
features may be periodically upgraded. Therefore, the information in this manual is subject to change and
should be used for reference only.
Liability
EdgeTech has made every effort to document the STARMUX III in this manual accurately and completely.
However, EdgeTech assumes no liability for errors or for any damages that result from the use of this
manual or the equipment it documents. EdgeTech reserves the right to upgrade features of this
equipment, and to make changes to this manual, without notice at any time.
Warnings, Cautions, and Notes
Where applicable, warnings, cautions, and notes are provided in this manual as follows:
WARNING! Identifies a potential hazard that could cause injury or death.
CAUTION! Identifies a potential hazard that could damage equipment or
data.
NOTE: Recommendations or general information that is particular to the
material being presented.
Revision History
Revision
Notes
Date
Approval
A
Release to Production
04/13/2015
TS
B
Updated images and technical description
07/11/2016
TS

vi
STARMUX III 0016903_REV_B
WARRANTY STATEMENT
All equipment manufactured by EdgeTech is warranted against defective components and workmanship
for a period of one year after shipment. Warranty repair will be done by EdgeTech free of charge.
Shipping costs are to be borne by the customer. Malfunction due to improper use is not covered in the
warranty, and EdgeTech disclaims any liability for consequential damage resulting from defects in the
performance of the equipment. No product is warranted as being fit for a particular purpose, and there is
no warranty of merchantability. This warranty applies only if:
i. The items are used solely under the operating conditions and in the manner recommended in
Seller's instruction manual, specifications, or other literature.
ii. The items have not been misused or abused in any manner, nor have repairs been attempted
thereon without the approval of EdgeTech Customer Service.
iii. Written notice of the failure within the warranty period is forwarded to Seller and the directions
received for properly identifying items returned under warranty are followed.
iv. The return notice authorizes Seller to examine and disassemble returned products to the extent
Seller deems necessary to ascertain the cause for failure.
The warranties expressed herein are exclusive. There are no other warranties, either expressed or implied,
beyond those set forth herein, and Seller does not assume any other obligation or liability in connection
with the sale or use of said products. Any product or service repaired under this warranty shall be
warranted for the remaining portion of the original warranty period only.
Equipment not manufactured by EdgeTech is supported only to the extent of the original manufacturer's
warranties.

vii
SOFTWARE SERVICE OVERVIEW
EdgeTech provides software services free of charge. This software agreement does not address customer-
specified modifications or enhancements. These services may be ordered separately. Furthermore,
EdgeTech software upgrades are meant for the sole use of EdgeTech customers. Any reproduction of
EdgeTech-supplied software or file sharing is strictly prohibited.
Software Updates and Enhancements
EdgeTech customers can download new software releases with all modifications and enhancements from
the EdgeTech ftp site. Major software issues, should they occur, will be reported directly to the customer.
New software releases consist of the following:
Software enhancements that are not on the price list
Software fixes and changes
Product integration
Documentation updates to on-line help
Tests for compatibility with other modules
Software patches consist of software that has undergone the following:
Minor software enhancements
Software fixes and changes
Software Telephone, Facsimile, and E-mail Support
EdgeTech customers are entitled to contact EDGETECH CUSTOMER SERVICE by telephone, facsimile, or e-mail
to report a difficulty, to discuss a problem or to receive advice on the best way to perform a task. When
contacted, EdgeTech Customer Service will do the following:
Respond within 24 hours
Immediately attend to serious problems affecting operations
Attempt to find an immediate work-around

viii
STARMUX III 0016903_REV_B
RETURNED MATERIAL AUTHORIZATION
Prior to returning any equipment to EdgeTech, a Returned Material Authorization (RMA) number must be
obtained. The RMA will help us identify your equipment when it arrives at our receiving dock and track
the equipment while it is at our facility. The material should be shipped to the address provided in the
EDGETECH CUSTOMER SERVICE section. Please refer to the RMA number on all documents and
correspondences as well.
All returned materials must be shipped prepaid. Freight collect shipments will not be accepted. EdgeTech
will pay freight charges on materials going back to the customer after they have been evaluated and/or
repaired.
CAUTION! If your product is a portable topside, never attempt to it in its
Storm CaseTM alone. Although rugged, these cases are not intended to be
used as shipping containers, and the delicate internal components could
be damaged if used in this manner.
The following steps apply only to material being returned from outside the Continental United States.
Follow them carefully to prevent delays and additional costs.
1. All shipments must be accompanied by three copies of your proforma invoice, showing the value
of the material and the reason for its return. If the reason is for repair, it must be clearly stated in
order to move through customs quickly and without duties being charged. Whenever possible,
please send copies of original export shipping documents with the consignment.
2. If the value of the equipment is over $1000, the following Shipper's oath must be sent with the
invoice. This oath can be typed on the invoice, or on a separate letterhead:
"I, ______________________________, declare that the articles herein specified are the
growth, produce, or manufacture of the United States; that they were exported from the
United States from the port of _____________________, on or about _______________;
that they are returned without having been advanced in value or improved in condition
by any process of manufacture or any other means; and that no drawback, or allowance
has been paid or admitted hereof."
Signed ______________________________

ix
3. If there is more than one item per consignment, a packing list must accompany the shipment. It
is acceptable to combine the proforma invoice and packing list as long as the contents of each
carton are clearly numbered and identified on the invoice.
4. Small items can be shipped prepaid directly to EdgeTech by FedEx, DHL, UPS, Airborne, etc.
5. If the equipment is the property of EdgeTech (formerly EG&G Marine Instruments Division),
please insure for full value.
6. Fax one invoice, packing list, and a copy of the airway bill to EdgeTech upon shipment.

x
STARMUX III 0016903_REV_B
CUSTOMER SERVICE
Customer service personnel at EdgeTech are always eager to hear from users of our products. Your
feedback is welcome, and is a valuable source of information which we use to continually improve these
products. Therefore we encourage you to contact EdgeTech Customer Service to offer any suggestions or
to request technical support:
NOTE: Please have your system Serial Number available when contacting
Customer Service.
E-mail: [email protected]om
Mail: 4 Little Brook Road
West Wareham, MA 02576
Telephone: [phone]
Facsimile: [phone]
24-Hour Emergency
Technical Support Line: [phone]
For more information please go to www.EdgeTech.com.

xi
COMPANY BACKGROUND
EdgeTech (formerly EG&G Marine Instruments) traces its history in underwater data acquisition and
processing back to 1966. EdgeTech has designed, developed, and manufactured products, instruments,
and systems—for the acquisition of underwater data, including marine, estuarine, and coastal
applications—for over 45 years.
The company has responded to the needs of the scientific, Naval, and offshore communities by providing
equipment—such as sub-bottom profilers, side scan sonar, acoustic releases, USBL positioning systems,
and bathymetric systems—that have become standards in the industry.
EdgeTech has also consistently anticipated and responded to future needs through an active research and
development program. Current efforts are focused on the application of cutting-edge CHIRP and acoustic
technology.

xii
STARMUX III 0016903_REV_B
TABLE OF CONTENTS
ATTENTION –READ THIS FIRST! .........................................................................................................iii
HARDWARE VARIATIONS AND COMPATIBILITY..................................................................................iv
ABOUT THIS DOCUMENT....................................................................................................................v
Purpose of this Manual............................................................................................................................. v
Liability...................................................................................................................................................... v
Warnings, Cautions, and Notes................................................................................................................. v
Revision History ........................................................................................................................................ v
WARRANTY STATEMENT ...................................................................................................................vi
SOFTWARE SERVICE OVERVIEW........................................................................................................vii
Software Updates and Enhancements.................................................................................................... vii
RETURNED MATERIAL AUTHORIZATION .......................................................................................... viii
CUSTOMER SERVICE...........................................................................................................................x
COMPANY BACKGROUND .................................................................................................................xi
TABLE OF CONTENTS........................................................................................................................xii
LIST OF FIGURES.............................................................................................................................. xiv
LIST OF TABLES ................................................................................................................................ xv
1.0: OVERVIEW ...............................................................................................................................1-1
1.1 Applications ..................................................................................................................................1-1
2.0: SPECIFICATIONS .......................................................................................................................2-1
3.0: SETUP AND ACTIVATION...........................................................................................................3-1
3.1 Unpacking and Inspecting.............................................................................................................3-1
3.2 Installing the Digital Link...............................................................................................................3-1
3.2.1 Controls, Indicators, and Connections ...................................................................................3-1
3.2.2 Connecting the STARMUX III ..................................................................................................3-2
3.3 Activating the Unit ........................................................................................................................3-2
3.4 Post-Recovery ...............................................................................................................................3-3
4.0: TECHNICAL DESCRIPTION..........................................................................................................4-1
4.1 Internal Components ....................................................................................................................4-1
5.0: MAINTENANCE.........................................................................................................................5-1

xiii
6.0: TROUBLESHOOTING .................................................................................................................6-1

xiv
STARMUX III 0016903_REV_B
LIST OF FIGURES
Figure 3-1: Front and Back Panels of STARMUX III ....................................................................................3-3
Figure 4-1: STARMUX III—Internal Components .......................................................................................4-3
Figure 4-2: STARMUX III—Block Diagram ..................................................................................................4-4
Figure 4-3: STARMUX III—Wiring Diagram ................................................................................................4-5

xv
LIST OF TABLES
Table 2-1: STARMUX III Specifications .......................................................................................................2-1
Table 6-1: STARMUX III Troubleshooting Guide ........................................................................................6-2

1-1
1.0: OVERVIEW
The STARMUX III Digital Link provides power for the towfish, while acting as an interface between an
external topside processor and an EdgeTech tow vehicle such as a 4200, 2000-DSS, or 2000-TVD towfish.
1.1 Applications
The STARMUX III unit can be used in conjunction with the systems above for the following applications:
Fisheries research
Mine countermeasures
Hydrographic surveys
Cable and pipeline surveys
Channel conditioning/clearance surveys
Geo-hazard surveys
Geological/geophysical surveys
Route surveys
Archaeological surveys
Search and recovery

2-1
2.0: SPECIFICATIONS
The specifications for the STARMUX III are shown in TABLE 2-1:
SPECIFICATION
VALUE
Size:
8.3 cm (3.25 in) high
48.5 cm (19.0 in) wide
43.2 cm (17.0 in) deep
Weight:
6.4 kg (14 lb)
Case Type:
EIA RS-310C 19-inch rack mount
Case Construction:
Aluminum 19-inch rack mount
Case Finish:
Anodized
Mounting:
Standard 19-inch rack with provisions for mounting rack slides (not
provided)
Input Power:
90-260 VAC, 50/60 Hz, 1200 watts max, auto sensing
Power to ROTC and
Side Scan Sonar:
375 VDC
External Trigger INPUT:
5 VDC TTL positive or negative leading edge triggered, selectable in
DISCOVER
I/O Ports:
(1) Ethernet
(1) Trigger
Table 2-1: STARMUX III Specifications
