EDIFIER W360BT User manual

W360BT
Wearable Bluetooth Earbuds, Headphones, Earphones, Earbuds
Operating instructions

1
Section 1
Product introduction
Before using the headphone, please read this manual carefully and keep it safe for future reference.
■Productfeatures:
Modernergonomicdesignstreamlinedforcomfortandoptimalfit
13mmmovingcoilensuresoutstandingperformancenotablyinmid‐rangeandlowfrequencies
HighqualityCSRchipwithBluetoothV4.1supportsupto10metersindistance
Upto20hoursofcontinuousplay
Wiredcontrollersupportsvoicecalls,makesvolumeadjustmentandswitchesbetweenmusic
SupportsCVCvoicenoisereductionandHSP/HFP/A2DP/AVRCPprotocols
Voicecontrolwakeupsignalenabled
Abletoconnecttwodevicessimultaneously
Comeswithcompleteaccessorieskit

Specifications
Bluetoothversion:BluetoothV4.1
Bluetoothprotocol:HSP/HFP/A2DP/AVRCP
Effectivedistance:10m
Workingtime:20hours
Standbytime:About500hours
Charginginput:DC5.0V300mA
Chargetime:about2hrs
Batterycapacity：300mAh
Frequencyresponse：20Hz‐20KHz
Soundpressurelevel（SPL）：106dB
Impedance：32Ω

Note: Any changes about design and specification, we will be without notice.
Section 2
■Package list
Product and attachments illustration
Headphones*1 pcs Portable bag*1 PCS Manual*Warranty card 1 PCS each
USB charging cable*1 pcs 

Big size silicon eartips*1 pairs Middle size silicon eartips*1 pairs Little size silicon eartips*1 pairs

2
■How to wear
1. Put the cable downward, wear the neck hook from the back of neck;
2. Insert the eartips into the ears and adjust them to a comfortable position.
Section 3
■Operation instructions
1. Charging
Whentheheadphoneisinuse,ifblueindicatorchangetoredcolor,itshowsthebatterylevelisinlow,andyouneedto
charge.
1.1 Connect the USB charging cable to USB pocket with standard power source.
1.2 Connect the other port of the USB charging cable to micro USB charging port on the headphone.
Red light is steady light means it is charging, red light off and blue light is steady light means it is fully charged.
It takes about 2 hours for fully charging
Fully charged Battery is in low level
Tips: In order to avoid shorten the battery life, recommence to be fully charged the battery before the first time use;
please charge the battery at least once per 3 months when un-use the headphone for a long time.
Warning: the rechargeable battery on the headphone must be properly disposed for recycling use. Do not put the
battery into fire to avoid explosion.
2. Power ON/OFF
Function operation indicator
ON Slide the switch to ON position Blue light steady light for 1 seconds
OFF Slide the switch to OFF position Red light steady light for 2 seconds
Tips: the headphone is design with toggle switch, please note that it can’t automatically be off when without any
connection after power on.
Section 4
3. Pairing
3.1. Follow the below operation to make the headphone enter pairing mode
Function Operation Indicator
Enter pairing mode Press and hold multi-function key for about 5 seconds Red/blue light flash alternatively

3
3.2 The distance between your Bluetooth device and the headphones should be kept within 1 m. The closer, the
better.
3.3 Enable your mobile’s Bluetooth function and search the headphone.
3.4 Select ‘EDIFIER W360BT’ to pair up. After being connected successfully, the headphones’ blue light is flashing
slowly.
Tips:
● In pairing process, if it needs pairing password, please input ”0000”
●After completing paired, When used in next time, the headphones shall automatically connect the device that was
connected last time.
●Over the effective distance, if you return within 10 minutes, it can automatically re-connect, at this time, the blue
indicator flashes once per 8 seconds, and has prompt.
Connect two Bluetooth devices simultaneously
1.PairheadphonewiththefirstBluetoothdevice
2.Re‐starttheheadphonetoenterpairingstatusandpairwiththesecondBluetoothdevice.
3.OperatethefirstBluetoothdevicetoconnecttheheadphone,thenfinishtoconnecttwoBluetoothdevice.


4. Calling
4.1 Basic call operation
Function Headphone status Operation
Answer incoming call Incoming call ringing Press the multi-function key
Reject incoming call Incoming call ringing Press and hold multi-function key for about 2
seconds
Cancel call Calling Press the multi-function key
End call Talking Press the multi-function key
Increase volume Talking Press the volume increasing key
Decrease volume Talking Press the volume decreasing key
Mute Talking Press and hold the volume decreasing key for
about 2 seconds
Cancel mute Talking(mute) Press and hold the volume increasing key for
about 2 seconds
Talking transferred to mobile Talking (headphone) Press and hold multi-function key for about 2
seconds

4
Talking transferred to
headphones
Talking (mobile phone) Press and hold multi-function key for about 2
seconds
Redial last call Connected device Double press multi-function key
Voice dial Connected device Press volume increasing/decreasing key /at
the same time
Section 5
Tips:
1. When adjust the volume to the maximum or mute, you will hear a prompt.
2. When use the voice dial, please ensure that your mobile phone supports this function and enable this status.
4.2 Make three way call
Function Headphone status Operation
End the current call to answer the
new incoming call
There is the second incoming call Press the multi-function key
Remain the current call to answer
the new incoming call
There is the second incoming call Double press the multi-function key
Remain the current call to reject the
new incoming call
There is the second incoming call Press and hold the multi-function
key for about 2 seconds
Call switch Talking Double press multi-function key
End current call and switch to
remain call
Talking Press the multi-function key
4.3 Connect call between two mobiles
Function Headphone status Operation
End the first mobile’s call, connect
the second mobile’s incoming call
The first mobile is talking, another
mobile is having incoming call
Press the multi-function key
Remain the first mobile’s call,
connect the second mobile’s
incoming call
The first mobile is talking, another
mobile is having incoming call
Double press the multi-function key
Switch calls and end the current
call
Talking, a call is remained Double press multi-function key
Get back to the remained mobile Talking, a call is remained Press the multi-function key

5
5. Play music
Function Headphone status Operation
Increase volume Play music Press volume increasing key
Decrease volume Play music Press volume decreasing key
Previous track Play music Press and hold volume decreasing
key
Next track Play music Press and hold volume increasing key
Pause play Play music Press the multi-function key
Restore play Pause play Press the multi-function key
Section 6
6. Restore factory settings
Under Bluetooth searching status (red/blue light quickly flashes alternatively), press and hold the volume increasing
key and volume decreasing key at the same time and wait for 5 seconds, it will clear the device list that
headphone paired before, after successful clear with it, turn on the headphone, it will automatically enter into
pairing status.
■Maintenance
●Do not place the product at the damp places so as not to affect the product’s internal circuit.
●Do not place the product at the places exposed to sun or in high temperature. High temperature would shorten the
service life of electronic components, damage battery and make some plastic components deformed.
●Do not place the product at very cold places to prevent damaging the internal circuit board.
●Do not try to dismantle the product. If non-professional personnel operates, they may damage the product.
●Do not fall, vibrate strongly, strike the product with hard object to prevent damaging the internal circuit.
●Please do not use drastic chemical products and cleaner to clean the headphones.
●Do not use sharp objects to scratch on the product surface to prevent damaging the outer case and affecting
looking.
If the product cannot work properly, please send it to your qualified repair units, the personnel shall help you solve
your problem with their whole heart.
■FAQs
1. The red light flashes instead of the blue light.
Answer: It means that the headphones battery is low. You need to recharge your headphones again.
2. The red light is off during charging.
Answer: a. Please ensure the charging device is properly connected with the headphones.
b. When the headphones are not used for a long time, the battery will enter the hibernate status. Now it

6
needs to charge about 30 minutes and then the red light shall be on.
3. The headphones hear nothing.
Answer: a. Ensure the volume of headphone is in an available level.
b. Ensure if the headphones are connected with mobile properly.
c. Ensure the headphones and mobile phone is in an effective distance and no other obstacle.
4. Headphone is not good for talking.
Answer: a. Please ensure if your mobile phone is in the area with strong signal.
b. The effective operational distance of the headphones is 10m. Please ensure the headphones are in
effective operational distance and there is no obstacle between the headphones and your mobile.
5. Why can the headphones not pause, restore, last song and next song when playing music?
Answer: The function requires the device paired up with the headphones to support AVRCP (Audio/Video Remote
Control Profile) protocol.
■Warning!
Toguaranteeyourpersonalsafety,pleasedonotwearorkeepheadphonesinthevicinity(closerthan10cm)ofapacemaker.

Donotinsertplugintoelectricsockets.

Supervisechildrenwhenusingtheequipment,theproductisnotatoy.

Headphonelisteningathighvolumelevels–particularly,overextendedperiodsoftime–maydamageyourhearing.

Theoperationofswitchesonyourhi‐fisystemorpluggingintheheadphonesmaycauseclickswhichathighvolumesetting
mayaffectyourhearing.Therefore,alwayssetthevolumecontroltominimumbeforeswitchingbetweendifferentsources
(tuner,turntable,CDplayer,etc.)orpluggingintheheadphones.

Fortrafficsafety,donotuseheadphoneswhiledrivingorcycling.

7

8
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
A warning that batteries (battery pack or batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
Correct Disposal of this product. This marking indicates that this product should not be
disposed with other household disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the
return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
To prevent possible hearing damage, do not listen at high volume levels for long
periods.
Fully understand user manual before use.
Ensure your player at low volume levels or power off before you leaving.


Scan by WeChat for more information
Product of Beijing Edifier Technology Co., Ltd
Address: No. 68, the West Road of the 4th Northern Ring, Haidian District, Beijing
Manufacturer: Dongguan Edifier Technology Co., Ltd
Address: No. 2, Gongye Dong Lu, Dongguan Songshan Lake Hi-tech Industrial Development Zone
Trademark: EDIFIER○
R, Walker○
Rboth are the registered trademark of Beijing Edifier Technology Co., Ltd.
Counterfeiting is not allowed.
Version No. Ver1.0 IB-100-W0830B-00
