EDIFIER HECATE EDF700006 User manual

TRUE WIRELESS GAMING EARBUDS
EDF700006

■Product description and accessories
There are different size of ear tips attached in the package, please select the suitable ones to wear.
Note: Images are for illustrative purposes only and may differ from the actual product.
Earbuds
Charging case
Silicone ear tips
Strap
Charging cable
User manual

■Take earbuds out
Take the earbuds out of the charging case and tear insulating films off.
■Charge
For initial use, place the earbuds in the charging case and close the case, then connect the case to power source
with the included Type-C charging cable for charging.
Charge the earbuds
•You may hear a warning tone when at low battery level, please place the earbuds in the case for charging.
•Ice blue indicator steady lit = charging Ice blue indicator off = fully charged
Charge the charging case
•Open the charging case to show its battery level; if red light of the charging case flashes rapidly, it indicates
the charging case has a low battery capacity, please charge it in time.
•LED light flashing = charging Three LED lights steady lit = fully charged
Input: 5V 50mA(earbuds) 5V 500mA(charging case)
Warning: The rechargeable batteries that provide power for this product must be disposed properly for recycling.
Do not dispose of batteries in fire to prevent an explosion.
If not used for long periods of time, please charge the product with lithium battery every three months.
Label

■Power on/off
Automatically
•Power on automatically when taken out of the charging case.
•Power off automatically while placed in the charging case.
Manually
•When powered off, respectively press and hold the touch zones of the left and right earbuds for around 3
seconds to power on;
•When powered on, respectively press and hold the touch zones of the left and right earbuds for around 5
seconds to power off.
■Bluetooth connection
Two earbuds mode
•For initial use, take the earbuds out of the charging case and they will automatically power on (white lights
lit for around 2 seconds);
•Then the left and right earbuds will auto-connect to each other, after interconnection is done, the earbuds
will enter Bluetooth pairing state (white and ice blue lights flashing alternately);
•Set Bluetooth device to search for and connect to "HECATE GM5", after pairing is successful, the
indicators of the earbuds will flash once per 4 seconds.
One earbud mode
Please take the left or right earbud out of the charging case, and refer to the procedures mentioned in "Two
earbuds mode"to pair with Bluetooth devices.
Re-connect automatically
•Take the earbuds out of the charging case, they will auto-connect to the Bluetooth device connected last
time.
•When the earbuds are disconnected from Bluetooth device for not in the effective distance, they can
auto-connect to the Bluetooth device if return to the effective distance within 5 minutes.
TWS pairing of the left and right earbuds
The left and right earbuds have finished TWS pairing before leaving factory. If the wireless connection fails to
resume, please follow the steps below to re-pair:
•After powered on, simultaneously double click the left and right earbuds to start TWS pairing, and the
white lights of the earbuds will flash in a breathing pattern;
•After TWS pairing is done, the earbuds will enter Bluetooth paring state (white and ice blue lights of the
earbuds flahsing alternately and rapidly).
•Please refer to the procedures mentioned in "Two earbuds mode"to pair with Bluetooth device again.
■Restore to factory settings (use with caution)
Restoring to factory settings will clear all pairing records of the earbuds.
•When powered off, respectively press and hold the touch zone of the left and right earbuds for 8 seconds;
then double click the touch zone when the indicator is steady lit; the factory settings have been restored
when the light flashes twice.
•Please refer to the procedures mentioned in "TWS pairing of the left and right earbuds" to complete TWS
pairing again.

■Functional operation
Music playback mode
Enter game mode: triple click
Exit game mode: triple click
Answer a call: double click
End a call: double click
Reject a call:
press and hold for around 2 seconds
Voice assistant: four click
Previous track:
press and hold for around 2 seconds
Pause/play: double click
Next track:
press and hold for around 2 seconds
Pause/play: double click
Left earbud
Right earbud
Enable monitor mode: triple click
Disable monitor mode: triple click
Low-latency game mode
Right earbud(music mode)
Enable/disable monitor mode
Left earbud
Call mode
Left/right earbud
Voice Assistant
Except when you are in a conversation, four-click the touch
zone of the left earbud to enable the voice assistant function
(ensure the connected Bluetooth device supports this function).

■FAQs
No sound
•Check if the earbuds are operating.
•Check if the earbuds volume are at an appropriate level.
•Check if the earbuds are correctly connected with Bluetooth device.
•Check if the earbuds are operating within a normal working range.
The call quality of the earbuds are not good.
•Check if Bluetooth device is in an area with strong signal.
•Please ensure the earbuds are within effective distance (10m) and no obstacle between the earbuds and
Bluetooth device.
When playing music, cannot control pause/play/previous track/next track via the earbuds.
•Please ensure the paired Bluetooth device supports AVRCP (Audio/Video Remote Control Profile) profile.

■Maintenance
•Keep the product away from humid places to avoid affecting internal circuit. Do not use the product during
intense exercise or with much sweat to prevent sweat from dropping into the product to make damage.
•Do not put the product in places exposed to sun or with high temperature. High temperature will shorten
service life of electronic components, damage battery and make plastic components deformed.
•Do not put the product in cold places to avoid damaging internal circuit board.
•Do not dismantle the product. Non-professional personnel may damage the product.
•Do not drop, strongly vibrate, strike the product with hard object to avoid damaging internal circuit.
•Do not use drastic chemicals or cleaner to clean the product.
•Do not use sharp objects to scratch product surface to avoid damaging shell and affecting facade.

CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
A warning that batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like.
---------------------------------------------------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------------------------
•"To prevent possible hearing damage, do not listen at high volume levels for long periods."
•"Fully understand user manual before use."
•"Ensure your player at low volume levels or power off before you leaving."
---------------------------------------------------------------------------------------------------------------------------------
Correct Disposal of this product. This marking indicates that this product should not be disposed with other
household disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your
used device, please use the return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.

WARNING!
Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type.
For products with removable battery, the battery must be properly recycled or disposed. For products with
built-in battery, disassembling is prohibited.
Never disassemble, hit with force, squeeze batteries or dispose of batteries in fire. Do not expose batteries in
conductive materials, liquid, fire or heat. Do not let metal object contact two battery poles. If the battery looks
swollen, leaking, discolored, having odor or any abnormal appearance, stop using it. Do not use the battery after
immersed in water.
Improper use of battery may lead to explosion or leakage, causing skin burn or other injuries; in the event of
battery leakage, handle it with care and immediately dispose of the battery in the manner in compliance with
applicable laws and regulations in your locality.
FCC statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
IC statement: CAN ICES-3(B)/NMB-3(B).
FCC Regulatory Compliance
Warning: changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:

RF Exposure Compliance
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Déclaration FCC:
Cet appareil est conforme àla partie 15 des règles FCC. Son utilisation est soumise aux deux conditions
suivantes:
(1) cet appareil ne doit pas causer d'interférences nuisibles, et (2) cet appareil doit accepter toute
interférence reçue, y compris les interférences susceptibles de provoquer un fonctionnement indésirable.
Déclaration IC: CAN ICES-3(B)/NMB-3(B).
ISED Regulatory compliance
This device contains licence-exempt transmitters that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
This device may not cause interference.
This device must accept any interference, including interference that may cause undesired operation of
the device.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment.
L’émetteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
L’appareil ne doit pas produire de brouillage;
L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
Cet équipement est conforme aux limites d'exposition aux radiations IC CNR-102 établies pour un
environnement non contrôlé.
