Edimax EW-7317UHg User manual

8
80 02 2. .1 11 1g g H HI I- -G Ga ai in n W Wi ir re el le es ss s L LA AN N
U
US SB B A Ad da ap pt te er r
User Manual
Version: 1.0
(Sep, 2004)

COPYRIGHT
Copyright ©2004/2005 by this company. All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or
by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of this company
This company makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any
warranties, merchantability or fitness for any particular purpose. Any software
described in this manual is sold or licensed "as is". Should the programs
prove defective following their purchase, the buyer (and not this company, its
distributor, or its dealer) assumes the entire cost of all necessary servicing,
repair, and any incidental or consequential damages resulting from any defect
in the software. Further, this company reserves the right to revise this
publication and to make changes from time to time in the contents hereof
without obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered
trademarks of their respective holders.

Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
This equipment must be installed and operated in accordance with provided
instructions and a minimum 5 cm spacing must be provided between
computer mounted antenna and person’s body (excluding extremities of
hands, wrist and feet) during wireless modes of operation.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible
for compliance could void the authority to operate equipment.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an
uncontrolled environment. In order to avoid the possibility of exceeding the
FCC radio frequency exposure limits, human proximity to the antenna shall
not be less than 20cm (8 inches) during normal operation.

R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/CE
OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on
radio equipment and telecommunication terminal Equipment and the mutual
recognition of their conformity (R&TTE)
The R&TTE Directive repeals and replaces in the directive 98/13/EEC
(Telecommunications Terminal Equipment and Satellite Earth Station
Equipment) As of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who
install and use it. However, special attention must be paid to the dangers of
electric shock and static electricity when working with electrical equipment. All
guidelines of this and of the computer manufacture must therefore be allowed
at all times to ensure the safe use of the equipment.
EU Countries Intended for Use
The ETSI version of this device is intended for home and office use in Austria,
Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy,
Luxembourg, the Netherlands, Portugal, Spain, Sweden, and the United
Kingdom.
The ETSI version of this device is also authorized for use in EFTA member
states: Iceland, Liechtenstein, Norway, and Switzerland.
EU Countries Not intended for use
None.

CONTENTS
1INTRODUCTION.............................................................................1
1.1 FEATURES .................................................................................................... 1
1.2 SPECIFICATIONS............................................................................................ 1
1.3 PACKAGE CONTENTS..................................................................................... 2
2INSTALLATION PROCEDURE .....................................................3
3CONFIGURATION UTILITY .........................................................8
3.1 WIRELESS CONNECTION STATUS.................................................................... 8
3.2 GENERAL CONNECTION SETTING ................................................................. 10
3.3 WEP AND WPA ENCRYPTION...................................................................... 13
3.3.1 WEP Setting........................................................................................................... 13
3.3.2 WPA Setting .......................................................................................................... 14
3.4 ADVANCED SETTING ................................................................................... 16
3.5 SOFTWARE AP MODE.................................................................................. 17
3.5.1 AP Connection Status ............................................................................................. 18
3.5.2 AP General Connection Setting............................................................................... 19
3.5.3 MAC Address Filter ............................................................................................... 21
4TROUBLESHOOTING..................................................................23

1
1 Introduction
Thank you for purchasing the 802.11g Hi-Gain Wireless LAN USB Adapter. This USB
Adapter is designed to comply with IEEE 802.11g Wireless LAN standard and easy to carry.
It is suitable for any Laptop or Desktop computers.
This adapter supports 64/128/256-bit WEP data encryption that protects your wireless
network from eavesdropping. It also supports WPA (Wi-Fi Protected Access) feature that
combines IEEE 802.1x and TKIP (Temporal Key Integrity Protocol) technologies. Client
users are required to authorize before accessing to APs or AP Routers, and the data
transmitted in the network is encrypted/decrypted by a dynamically changed secret key.
This adapter has built-in AES engine which ensure the highest degree of security and
authenticity for digital information and it is the most advanced solution defined by IEEE
802.11i for the security in the wireless network.
This adapter is cost-effective, together with the versatile features; it is the best solution for
you to build your wireless network.
1.1 Features
•Complies with the IEEE 802.11b and IEEE 802.11g 2.4GHz standards.
•Up to 54Mbps high data transfer rate.
•Support 64/128/256-bit WEP, WPA (TKIP, IEEE 802.1x) and AES functions for high level of
security.
•Supports Software AP function, which turns the wireless station into a wireless AP.
•Complies with IEEE 802.11d country roaming standard.
•Support the most popular operating system: Windows 98SE/Me/2000/XP.
•Supports USB 2.0/1.1/1.0 interface.
•Portable and mini-size design.
•Suitable for Any Notebook or Desktop PC.
1.2 Specifications
•Standard: IEEE 802.11g/b
•Bus Type: Mini-USB
•Frequency Band: 2.4000~2.4835GHz (Industrial Scientific Medical Band)
•Modulation: OFDM with BPSK, QPSK, 16QAM, 64QAM (11g)
BPSK, QPSK, CCK (11b)
•Data Rate: 54/48/36/24/18/12/11/9/6/5.5/2/1Mbps auto fallback
•Security: 64/128/256-bit WEP Data Encryption, WPA (IEEE 802.1x with TKIP) and AES
•Antenna: Internal Antenna
•Drivers: Windows 98SE/Me/2000/XP/2003 Server
•LEDs: Power, Link

2
•Transmit Power: 20dBm (Typical)
•Signal Range: Indoors: Up to 500 ft (150 meters), Outdoors: Up to 2100 ft (650 meters)
•Dimension: 120(H) x 75(W) x 87(D) mm
•Temperature: 32~131°F (0 ~55°C)
•Humidity: Max. 95% (NonCondensing)
•Certification: FCC, CE
1.3 Package Contents
Before you begin the installation, please check the items of your package. The package
should include the following items:
•One USB Adapter
•One USB 2.0 Extension Cable (150 cm)
•One Quick Guide
•One CD (Driver/Utility/User Manual)
If any of the above items is missing, contact your supplier as soon as possible.

3
2 Installation Procedure
Before you proceed with the installation, please notice following descriptions.
Note1: Please do not install the USB adapter into your computer before installing the software
program from the CD.
Note2: The following installation was operated in Windows XP. (Procedures are similar for
Windows 98SE/Me/2000/2003 Server.)
Note3: If you have installed the Wireless PC Card driver & utility before, please uninstall the
old version first.
Please follow below instructions to install the USB Adapter.
I. Install the Configuration Utility
A. Insert the Installation CD to your CD-ROM Drive. Execute the “setup” program.
B. If you want to install the software program in another location, click “Browser” and select
an alternative destination. Then, click “Next”.

4
C. Click “Continue Anyway” to finish the installation.

5
II. Install the USB Adapter
A. Plug the USB Adapter into the USB port of your computer.
B. The “Found New Hardware Wizard” is displayed, select “Install the software automatically
(Recommended)” and click “Next”.
C. Click “Continue Anyway” and the system will start to install the USB adapter.

6
D. Click “Finish” to complete the installation.
III. Using the Configuration Utility
To setup the USB adapter, double-click the icon in the system tray.
For Windows XP, there is a “Windows Zero Configuration Tool” by default for you to setup
wireless clients. If you want to use the Utility of the USB adapter, please follow one of the
ways as below.

7
First Way
A. Double-click the utility
icon in the system tray.
B. Click “Yes” to use the
utility of the USB adapter.
Second Way
A. Double-click the icon.
B. Click “Advance”.
C. Uncheck “Use Windows to
configure my wireless
network settings”.

8
3 Configuration Utility
The Configuration Utility is a powerful application that helps you configure the 802.11g HI-
Gain Wireless LAN USB Adapter and monitor the link status during the communication
process.
The Configuration Utility appears as an icon on the system tray of Windows while the card is
running. You can open it by double-click on the icon.
Right click the icon, there are some items for you to operate the configuration utility.
zOpen Utility Window
Select “Open Utility Window” to open the Configuration Utility tool.
zExit ZDWlan
Select “Exit ZDWlan” to close the Configuration Utility tool.
Before using the utility, you have to know some restrictions of the utility.
1. If you want to connect to 11g (up to 54Mbps) network, please ensure to install the
adapter to PC or laptop with USB 2.0 interface. This adapter runs at lower performance
while you connect it to the USB 1.1/1.0 port of your computer instead.
2. This adapter will work in 11b mode when the network type is in Ad Hoc mode. It is
defines by Wi-Fi organization. If you want to enable the data rate up to 54Mbps (11g),
please follow steps listed below.
A. Go to “Network Connections”.
B. Right Click the “Wireless Network Connection” and select “Properties”.
C. From the pop-up screen, click “Configure”.
D. Enter into “Advanced” page of the “Properties” screen.
E. Enable the setting of “IBSS_G_Mode”.
3.1 Wireless Connection Status
When you open the Configuration Utility, the system will scan all the channels to find all the
access points/stations within the accessible range of your card and automatically connect to
the wireless device with the highest signal strength. From the screen, you may know all the
infomration about the wireless connection.

9
Parameter Description
Mode Station – Set the USB adapter a wireless client.
Access Point – Turns the USB adapter to function as a wireless
AP. Please refer to Section 3.5 for the AP settings.
Network Adapter Display the product information of the USB Adapter.
Available Network Display all the SSID and Signal Strength of wireless stations
nearby. To re-survey the available wireless devices please click
“Refresh”.
There are two ways to automatically make the connection
between the USB Adapter and the wireless station on the list.
1. Double-click the wireless station on the list directly.
2. Select the station you intend to connect and then click
“Connect this site“.
Current Network Information Display the information about the wireless network this adapter is
connecting to. The information includes Channel, Type, SSID, TX
Rate and Encrypt settings. Note: Please refer to Section 3.2 for
the description of each item.
More Setting For setting more functions including disable/enable WEP and
Power Saving Mode, etc. Please refer to Section 3.2, 3.3 and 3.4.
Link Status Display the status of the wireless connection.
BSSID Display the MAC Address of the network the adapter is
connecting to.

10
Parameter Description
Signal Strength This bar shows the signal strength level. The higher percentage
shown in the bar, the more radio signal been received by the
adapter. This indicator helps to find the proper position of the
wireless station for quality network operation.
Link Quality This bar indicates the quality of the link. The higher the
percentage, the better the quality.
TX Frame It shows the number of data frames which are transmitted by the
adapter successfully.
RX Frame It shows the number of data frames which are received by the
adapter successfully.
3.2 General Connection Setting
Click “More Setting”, users are allowed to setup the wireless connection setting, Encryption
Setting of the USB adapter and other advanced functions.
Parameter Description
General Connection Setting
Channel Select the number of the radio channel used for the networking.
The channel setting of the wireless stations within a network
should be the same.

11
Parameter Description
Tx Rate There are several options including
Auto/1/2/5.5/11/6/9/12/18/24/36/48/54Mbps for you to select.
When the “Auto” is selected, the device will choose the most
suitable transmission rate automatically. The higher data rate you
designated in the network, the shorter distance is allowed
between the adapter and the wireless stations.
When the adapter works in 11b mode, the maximum data rate is
11Mbps so that there are only “Auto/1/2/5.5/11Mbps” options you
can select.
SSID The SSID (up to 32 printable ASCII characters) is the unique
name identified in a WLAN. The ID prevents the unintentional
merging of two co-located WLANs.
You may specify a SSID for the adapter and then only the device
with the same SSID can interconnect to the adapter.
Any If “Any“ check box is enabled, the adapter will survey and connect
to one of the available wireless stations without checking the
consistency of channel and SSID with the wireless station.
Network Type Ad-Hoc – This mode enables wireless network adapters
interconnecting without through AP or Router. Select this mode if
there is no AP or Router in the network.
Infrastructure – This operation mode requires the presence of an
802.11 Access Point. All communication is done via the Access
Point or Router.
Change/Apply Clcik “Change“ will enable you to setup the parameters of
“General Connection Setting“. In the meantime, the button will
change to “Apply“ for you to confirm your settings.
Encryption Setting In the block, users may enable/disable WEP and WPA encryption
within the network. Please refer to Section 3.3 for more
description.

12
Parameter Description
Authentication Mode This setting has to be consistent with the wireless networks that
the adapter intends to connect.
Open System – No authentication is needed among the wireless
network.
Shared Key – Only wireless stations using a shared key (WEP
Key identified) are allowed to connecting each other.
Auto – Auto switch the authentication algorithm depending on the
wireless networks that the adapter is connecting to.
WEP Encryption Key Setting Click this button to setup the WEP key. Please refer to Section
3.3 for the details.
WPA Encryption Setting Click this button to setup the WPA function. Please refer to
Section 3.3 for the details.
Profile
Profile Name You can save the network setting as a profile. To connect to the
network without making additional configuration, you can load the
profile.
Load Load the setting values from the file in the “Profile Name“ list. The
new settings will be activated immediately.
Save Current Input a file name and click “Save Current“ to write the current
setting values to be a profile in the “Profile Name“ list.
Delete Delete the profile you select.
Other
Advanced Setting... For more advanced setting, please click it. To know more of the
setting, please refer to Section 3.4.
Information To view the version of the driver, firmware and the MAC Address
of the adapter, click the button.

13
3.3 WEP and WPA Encryption
WEP is an data encryption algorithm, which protects Wireless LAN data in the network
against eavesdropping. WEP has been found that it has some security problems. The
adapter supports WPA (Wi-Fi Protected Access) that combines IEEE 802.1x and TKIP
(Temporal Key Integrity Protocol) technologies. Client users are required to authorize before
accessing to Aps or AP Routers, and the data transmitted in the network is
encrypted/decrypted by a dynamically changed secret key. This adapter is also built-in AES
engine which ensure the highest degree of security and authenticity for digital information
and it is the most advanced solution defined by IEEE 802.11i for the security in the wireless
network.
3.3.1 WEP Setting
Parameter Description
Key Length You may select the 64-bit, 128-bit or 256-bit to encrypt
transmitted data. Larger key length will provide higher level of
security, but the throughput will be lower.
Default Key ID Select one of the keys (1~4) as the encryption key.
Key Format Hexdecimal – Only “A-F“, “a-f“ and “0-9“ are allowed to be set as
WEP key.
ASCII –Numerical values, characters or signs are allowed to be
the WEP key. It is more recognizable for user.

14
Parameter Description
Key1 ~ Key4 The keys are used to encrypt data transmitted in the wireless
network. Fill the text box by following the rules below.
64-bit – Input 10-digit Hex values or 5-digit ASCII values as the
encryption keys. For example: “0123456aef“ or “Guest“.
128-bit – Input 26-digit Hex values or 13-digit ASCII values as the
encryption keys. For example:
“01234567890123456789abcdef“ or “administrator“.
256-bit – Input 58-digit Hex values or 29-digit ASCII values as the
encryption keys.
Change/Apply Clcik “Change“ will enable you to setup the WEP key. In the
meantime, the button will change to “Apply“ for you to confirm
your settings.
3.3.2 WPA Setting
The adapter can automatically detect the WPA setting of the AP which the adapter intends
to connect to. To connect to the AP, you should setup the same setting with the AP.
There are two kinds of WPA mode: WPA and WPA-PSK. WPA is designed for enterprise
which requires a RADIUS Server and Certificate Server for the authentication. WPA-PSK is
a special mode designed for home and small business users who do not have access to
network authentication servers. In this mode, the user manually enters the starting
password in their access point or gateway, as well as in each wireless stations in the
network. WPA takes over automatically from that point, keeping unauthorized users that
don't have the matching password from joining the network, while encrypting the data
traveling between authorized devices.

15
Parameter Description
Connect Information It is the setting for WPA mode.
Protocol This adapter supports two kind of protocol for authentication
including TLS and PEAP. TLS and PEAP requires a certificate
which is provided by the Certificate Server. PEAP requires a set
of user name and password in addition. To get the certificate and
the personal user name and password, please contact with your
administrator.
TLS – Select a certificate from the “Certificate“ list.
PEAP – Input the “User Name“ and “Password“ and also select a
certificate from the “Certificate“ list.
User Name It is the setting for PEAP protocol.
Password It is the setting for PEAP protocol.
Pre-shared Key It is the setting for WPA-PSK mode. Input a 8 to 63 digits of ASCII
format to be the password for the authentication within the
network.
Certificate All the available certificates for TLS or PEAP will display in the
list. Please select a proper certificate for the wireless
authentication.
