Edimax Wake-On LAN Adapter User manual

L
A
N
P
R
O
F
E
S
S
I
O
N
A
L
Wake-On LAN Adapter
Wake-On LAN Adapter
Installation Guide

FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply
with the limits of a Class B computing devices,
pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
If you suspect this product is causing interference, turn
your computer on and off while your radio or TV is
showing interference. If the interference disappears
then when you turn the computer off and reappears
then you turn the computer on, something in the
computer is causing interference.
You can try to correct the interference by one or more
of the following measures :
1. Reorient/Relocate the receiving antenna.
2. Increase the separation between the equipment and
receiver.
3. Connect the equipment into an outlet on a circuit
difference from that to which the receiver is
connected.
4. Ensure that all expansion slots (on the back or side
of the computer) are covered. Also ensure that all
metal retaining brackets are tightly attached to the
computer.

1
1Introduction
The Wake On LAN (WOL) feature allows users to
configure network adapters that are capable of
“listening to” network packets even when the computer
is turned off.
In order for the Wake On LAN feature to work
correctly, this network adapter must be connected to a
power source even when the PC is turned off. So that
this adapter operates as a wake up NIC in a PC with a
3-pin header connector on the PC motherboard.
Wake On LAN adapters have a special low power
standby mode that is active when the rest of the
computer is without power.
This WOL adapter uses Magic Packet and Wake Up
Frame technology that will respond to a special
“wake-up” packet sent by abother computer or network
device. Typically this wake-up packet causes the
adapter to signal the computer to power up and run a
pre-defined program.
1

2
2Specifications
(1) Hardware requirement
ŸMotherboard with 3-pin WOL connector.
(Some computers may require you to change a setting
in your computer’s BIOS or setup program to enable
the WOL feature.)
ŸATX 2.01 power supply.
Note : Install only one active WOL adapter per
computer. You can install additional,
non-WOL adapters.
(2) 3-pin auxiliary power cable pin assignment
2
PIN Color
Power
Ground
LAN Wake Up*
Red
Black
Green
* Default setting is Active High, can be configured as
Active Low by setup program.

3
3Installation
1. Unplug the PC, remove the cover, and disconnect the
cables.
2. Unpack the NIC and 3-pin auxiliary power cable.
3. Choose an available bus master PCI slot.
4. Remove the backplate and insert the adapter into the
empty PCI slot.
5. Secure the adapter with the screw.
6. Insert the 3-pin auxiliary power cable into the
connector on the adapter.
7. Attach the 3-pin auxiliary power cable to the
connector on the PC motherboard.
8. Reconnect all cables and replace the PC cover.
9. Run configure program of this adapter, please refer
to “User’s Manual”.
3

4
4Trouble-shooting
nThe PC can not boot up after installing the
adapter.
1. Remove the 3-pin cable from the PC connector.
2. Boot up the PC, run setup program to configure the
adapter as “Active Low”(Default setting is “Active
High”)
3. Turn off the PC and reconnect the 3-pin cable to the
PC.
4. Boot up the PC again.
nThe PC does not boot up when a Magic
Packet or Wake Up Frame is sent.
1. Check the specification of this PC meets the
hardware requirement in chapter 2.
2. Verify the BIOS setting of Wake On LAN is
configured properly. (Please check your computer
owner’s manual or contact your dealer for more
information.)
3. Remove the PC cover and check the 3-pin cable
connection.
4. Run configure program to check the setting of this
adapter.
5. If the adapter still does not wake up, install a known
good working Wake On LAN adapter and 3-pin
auxiliary power cable in the PC and recheck the PC.
[!] Contact your dealer if problem persist.
4
