3G-6408n
User Manual
05-2012 / v1.0

1
COPYRIGHT
Copyright Edimax Technology Co., Ltd. all rights reserved. No part of this publication may
be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language or computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior written permission
from Edimax Technology Co., Ltd.
Edimax Technology Co., Ltd. makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any warranties,
merchantability, or fitness for any particular purpose. Any software described in this
manual is sold or licensed as is. Should the programs prove defective following their
purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire
cost of all necessary servicing, repair, and any incidental or consequential damages
resulting from any defect in the software. Edimax Technology Co., Ltd. reserves the right to
revise this publication and to make changes from time to time in the contents hereof
without the obligation to notify any person of such revision or changes.
The product you have purchased and the setup screen may appear slightly different from
those shown in this QIG. For more information about this product, please refer to the user
manual on the CD-ROM. The software and specifications are subject to change without
notice. Please visit our website www.edimax.com for updates. All brand and product names
mentioned in this manual are trademarks and/or registered trademarks of their respective
holders.
Edimax Technology Co., Ltd.
Add: No. 3, Wu-Chuan 3rd Rd., Wu-Ku Industrial Park, New Taipei City, Taiwan
Tel: [phone]
Email: [e-mail]
Notice According to GNU General Public License Version 2
This product includes software that is subject to the GNU General Public License version 2.
The program is free software and distributed without any warranty of the author. We offer,
valid for at least three years, to give you, for a charge no more than the costs of physically
performing source distribution, a complete machine-readable copy of the corresponding
source code.

2
CONTENTS
CHAPTER I: PRODUCT INFORMATION ...............................................................................................................4
1-1 Package Contents ................................................................................................................................4
1-2 Hardware .............................................................................................................................................4
CHAPTER II: SYSTEM AND NETWORK SETUP .....................................................................................................6
2-1 Establishing a network connection......................................................................................................6
2-2 Setting client computers to obtain IP addresses automatically..........................................................7
2-2-1 Windows 95/98/Me IP address setup......................................................................................8
2-2-2 Windows 2000 IP address setup ............................................................................................10
2-2-3 Windows XP IP address setup ................................................................................................12
2-2-4 Windows Vista IP address setup ............................................................................................14
2-3 Connecting to broadband router via web browser ...........................................................................16
2- U Q “...........................................................................................................................21
2-4- U GG    .................................................................23
2-4- U D IP     ..............................................................25
2-4- U “ IP     ...................................................................26
2-4- U PPPE     ......................................................................27
2-4- U PPTP     ........................................................................29
2-4- U LTP    .........................................................................32
2-4- U WI“P     ........................................................................35
2- U Q“ ......................................................................................................................................37
CHAPTER III: GENERAL SETUP ..........................................................................................................................40
3-1 System................................................................................................................................................41
3-1-1 Time Zone ...............................................................................................................................42
3-1-2 Password Settings...................................................................................................................43
3-1-3 Remote Management.............................................................................................................44
3-2 WAN...................................................................................................................................................45
3-2-1 3G/3.75G ................................................................................................................................46
3-2-2 Dynamic IP ..............................................................................................................................48
3-2-3 Static IP ...................................................................................................................................49
3-2-4 PPPoE......................................................................................................................................50
3-2-5 PPTP........................................................................................................................................52
3-2-6 L2TP ........................................................................................................................................55
3-2-7 WISP........................................................................................................................................58
3-3 LAN.....................................................................................................................................................60
3-3-1 LAN IP......................................................................................................................................60
3-3-2 DHCP Server............................................................................................................................62
3-3-3 Static DHCP Leases .................................................................................................................63
3-4 Wireless .............................................................................................................................................65
3-4-1 Wireless Settings ....................................................................................................................65
3-4-2 Security Settings .....................................................................................................................67

3
3-4-2-1 Disabled.......................................................................................................................67
3-4-2-2 WEP .............................................................................................................................67
3-4-2-3 WPA Pre-Shared Key ...................................................................................................69
3-4-2-4 WPA RADIUS................................................................................................................70
3-4-3 MAC Address Filtering ............................................................................................................71
3-4-4 WPS (Wi-Fi Protected Setup) Settings....................................................................................73
3-5 Advance Settings................................................................................................................................74
3-5-1 QoS .........................................................................................................................................75
3-5-1-1 Basic QoS Settings .......................................................................................................75
3-5-2 DDNS.......................................................................................................................................78
3-5-3 Port Forwarding......................................................................................................................81
3-5-4 DMZ ........................................................................................................................................83
3-5-5 Fail Over..................................................................................................................................84
3-5-6 3G Limit Control......................................................................................................................85
3-6 NAT ....................................................................................................................................................87
3-6-1 Virtual Server..........................................................................................................................87
3-6-2 Special Applications................................................................................................................89
3-6-3 UPnP Settings .........................................................................................................................91
3-6-4 ALG Settings............................................................................................................................92
3-6-5 Static Routing..........................................................................................................................93
3-7 Firewall...............................................................................................................................................95
3-7-1 Access Control ........................................................................................................................95
3-7-2 URL Blocking ...........................................................................................................................99
3-7-3 DoS........................................................................................................................................101
CHAPTER IV: STATUS, TOOLS & LANGUAGE ..................................................................................................104
4-1 Status ...............................................................................................................................................104
4-1-1 Internet Connection .............................................................................................................104
4-1-2 Device Status ........................................................................................................................105
4-1-3 System Log............................................................................................................................105
4-1-4 Security Log ..........................................................................................................................106
4-1-5 Active DHCP Client................................................................................................................106
4-1-6 Statistics................................................................................................................................107
4-1-7 Modem Info..........................................................................................................................107
4-2 Tools.................................................................................................................................................108
4-2-1 Configuration Tools ..............................................................................................................109
4-2-2 Firmware Upgrade................................................................................................................110
4-2-3 Restart ..................................................................................................................................110
4-3 Language..........................................................................................................................................111

4
CHAPTER I: PRODUCT INFORMATION
1-1 Package Contents
Before you start using this router, please check if there is anything missing in the
package, and contact your dealer to claim the missing item(s):
3G router (1 pcs)
Quick installation guide (1 pcs)
CD with setup wizard, multi-language QIG & user manual (1 pcs)
Power adapter (1 pcs)
Ethernet cable (1 pcs)
Hardwire USB cable (1 pcs)
Holding base (1 pcs)
Accessory kit
1-2 Hardware
Front Panel
LED Name
Light Status
Description
PWR
On
Router switched on and correctly powered
Off
Router not powered or not correctly powered
Wi-Fi
On
Wi-Fi activated (or WPS mode activated)
Off
Wi-Fi not activated
Flashing
Wi-Fi activity (transferring data)
WAN
On
Connected to the Internet
Off
Not connected to the Internet
Flashing
Internet activity (transferring data)
3G
On
Connected to the 3G/3.75G network
Off
Not connected to the 3G/3.75G network
Flashing
3G/3.75G activity (transferring data)
1-4
(LAN)
On
LAN port connected
Off
LAN port not connected
Flashing
LAN activity (transferring data)

5
Back Panel
Item Name
Description
USB Port
Connects to 3G/3.75G USB Modem Cards
Power
Connector
Connects to the supplied power adapter
WAN Port
Connects to cable/xDSL modems
1-4
(LAN Ports)
Connects to computer or other web devices
WPS/Reset
Button
Resets the router to factory default settings or starts WPS
function (press this button and hold for 20 seconds to clear all
settings or press this button for 2-5 seconds to activate WPS
function)
Wi-Fi ON/OFF
Switch
Switches the Wi-Fi network on and off

6
CHAPTER II: SYSTEM AND NETWORK SETUP
2-1 Establishing a network connection
Please follow the following instructions to build a network connection between your
new broadband router, computers, and other network devices:
1. Plug your 3G/3.75G USB modem card into the USB port on this router.
2. C        LAN 
3. Power on the router and insert the installation CD into your computer. Select your
preferred language in the setup wizard and start configuring your router.

7
2-2 Setting client computers to obtain IP addresses automatically
Before you start configuration procedures, your computer must be able to get an IP
address automatically (set to use dynamic IP addresses). If your computer is set to use a
static IP address, or if you are unsure, please follow the following instructions to configure
your computer to use dynamic IP addresses:
Windows 95/98/Me (see section 2-2-1)
Windows 2000 (see section 2-2-2)
Windows XP (see section 2-2-3)
Windows Vista (see section 2-2-4)

8
2-2-1 Windows 95/98/Me IP address setup
1. C  “        -left corner of your
   C P Duble-  N   
N    “ TCPIP    P

9
2. “ O  IP    DHCP    OK

10
2-2-2 Windows 2000 IP address setup
1. Click th “        -left corner of your
   C P D-  N  D-up
C    - L A C When the
L A C P    I P
TCPIP    P

11
2. “ O  IP    O DN“  
   OK

12
2-2-3 Windows XP IP address setup
1. C  “        -left corner of your
   C P D-  N  I
C   N C  - L A
C W  L A C P   
P

13
2. “ O  IP    O DN“  
   OK

14
2-2-4 Windows Vista IP address setup
1. Click the “        -left corner of your
   C P C V N “  T 
  M N C ‘- L A N 
 P W  L A C P  
 I P V  TCPIP    P

15
2. “ O  IP    O DN“  
   OK

16
2-3 Connecting to broadband router via web browser
Y      -based configuration interface via any
connected computer with a web browser (Internet Explorer 5.x or above, Firefox, Opera, or
Safari).
1. Please input          E
2. You should see the following authentication window:
NOTE I       -based configuration
interface, the IP address you have inputted may be incorrect. If you have previously
   IP        
3. P     U       P 
C  OK       

17
4. Th         H Y     
settings and other system information here.
System
Model
Displays this broadband router   seful when
you need technical service)
Up Time
Displays the amount of time this router has been switched on
Hardware Version
Displays this broadband router hardware version (useful
when you need technical service)
Boot Code
Version
Displays this broadband router boot code version (useful
when you need technical service)
Runtime Code
Version
Displays this broadband router runtime code version (useful
when you need technical service)
Internet Connection
IP Address Mode
Displays how this broadband router currently obtains IP
addresses
IP Address
Displays the IP address of the WAN connection
Subnet Mask
Displays the subnet mask of the WAN connection
Default Gateway
Displays the IP address of the WAN connection default
gateway
MAC Address
Displays the physical address of the WAN port
Primary DNS
Displays the IP address of the first DNS server
Secondary DNS
Displays the IP address of the second (backup) DNS server

18
3G/3.75G
WWAN Status
Displays the status of the 3G/3.75G connection
IP Address
Displays the IP address of the 3G/3.75G connection
Subnet Mask
Displays the subnet mask of the 3G/3.75G connection
Default Gateway
Displays the IP address of the 3G/3.75G connection default
gateway
Wireless Configuration
Mode
Displays the operation mode of the wireless access point
ESSID
Displays the name of the access point
Channel Number
Displays the channel number of the wireless network
Security
Displays the security authentication mode of the access point
LAN Connection
IP Address
Displays the IP address of the LAN connection
Subnet Mask
Displays the subnet mask of the LAN connection
DHCP Server
Displays the status of the internal DHCP server
MAC Address
Displays the physical address of the LAN port
The SSID, the up time, the IP address of the LAN connection, and the runtime code is
always displayed on the top of the webpage.
