Edimax EK-PAK2 User manual

10~60"
(with an increment of 5”)
5, 10~99" (with an increment of 10”)Scan Intervals
Hot Keys / Push Buttons
/ Switching Software
Hot Keys / Push ButtonsPC Selection
2
2 x HDB 15-pin female
(integrated with USB)
2 x USB Type Mini B
(for audio & mic)
2 x HDB 15-pin female
(integrated with PS/2)
2 x USB Type Mini B
(for audio & mic)
2 x HDB 15-pin female
(integrated with PS/2)
PC Side Connection
1 x PS/2 Keyboard
(6-pin Mini Din female)
1 x PS/2 Mouse
(6 pin Mini Din female)
1 x HDB-15 VGA female
1 x 3.5mm audio jack
1 x 3.5mm mic jack
2 x Audio / Mic Cables
(USB Mini B-3.5 mm jack)
2 x detachable slim USB
KVM Combo Cable
2 x detachable slim PS2 KVM Combo CableConnection Cables
2 x USB Type A
(Keyboard & Mouse)
1 x HDB 15-pin female
1 x Audio 3.5mm jack
1 x Mic 3.5mm jack
1 x PS/2 Keyboard
(6-pin Mini Din female)
1 x PS/2 Mouse
(6 pin Mini Din female)
1 x HDB-15 VGA female
Console Side
Connection
96 x 61 x 24mmDimension
95.6g100.2g95.4gWeight (g)
Temperature : 0~50 °C / Humidity : 0~90%, Non-CondensingOperation info
350MHzMax. Bandwidth
2048 x 1536Max. Resolution
2 x Audio / Mic Cables
(USB Mini B-3.5 mm jack)
N/AAudio Cables
PC Ports LED
2Max PC Connections
EK-UAK2EK-PAK2EK-PSK2
USB with Audio & MicPS2 with Audio & MicPS2 KVM
Model NO. / Type
2 Ports KVM Switches
2 Ports KVM Switches

10~60"
(with an increment of 5”)
5, 10~99" (with an increment of 10”)Scan Intervals
Hot Keys / Push Buttons
/ Switching Software
Hot Keys / Push ButtonsPC Selection
4
4 x HDB 15-pin female
(integrated with USB)
4 x 3.5mm audio jack
4 x 3.5mm mic jack
4 x HDB 15-pin female
(integrated with PS/2)
4 x 3.5mm audio jack
4 x 3.5mm mic jack
4 x HDB 15-pin female
(integrated with PS/2)
PC Side Connection
1 x PS/2 Keyboard
(6-pin Mini Din female)
1 x PS/2 Mouse
(6 pin Mini Din female)
1 x HDB-15 VGA female
1 x 3.5mm audio jack
1 x 3.5mm mic jack
4 x Audio / Mic Combo
Cables
4 x detachable slim USB
KVM Combo Cables
4 x detachable slim PS2 KVM Combo CablesConnection Cables
2 x USB Type A
(Keyboard & Mouse)
1 x HDB 15-pin female
1 x Audio 3.5mm jack
1 x Mic 3.5mm jack
1 x PS/2 Keyboard
(6-pin Mini Din female)
1 x PS/2 Mouse
(6 pin Mini Din female)
1 x HDB-15 VGA female
Console Side
Connection
164 x 72 x 26mmDimension
191.6g194.6g185.0gWeight (g)
Temperature : 0~50 °C / Humidity : 0~90%, Non-CondensingOperation info
350MHzMax. Bandwidth
2048 x 1536Max. Resolution
4 x Audio / Mic Combo
Cables
N/AAudio Cables
PC Ports LED
4Max PC Connections
EK-UAK4EK-PAK4EK-PSK4
USB with Audio & MicPS2 with Audio & MicPS2 KVM
Model NO. / Type
4 Ports KVM Switches
4 Ports KVM Switches
