Ednet 84104 User manual

1
Dual Car Charger, USB Type C
(Input 12-24V, 35W)
User Manual
84104

2
1.0 INTRODUCTION
This product is a high-performance and fashionable design car charger. It
allows you to charge USB-C devices as well as other mobile devices
quickly and efficiently in your car. It is equipped with two USB
connectors (one USB-C connector and one USB-A connector) for power.
This product allows two devices to be charged at the same time, and the
product provides the maximum output of 35 watts. The USB-C port is
specially designed for Type-C supported devices. It is helpful and
convenient to use!
2.0 FEATURES
Input voltage (DC): 12-24V
Two ports for charging:
USB-A: 5V/1.0A
USB-C: 5V/3A, 9V/3A, 12V/2A, or 20V/1.5A
Accurate limited current output and over current protection
Overload protection and over voltage protection
Short circuit protection
Over temperature protection and remove the fault condition
auto-recovery
Select precision electrical components, fire line version, and
imported fire plastic
Specially designed for your Type-C devices.

3
3.0 SPECIFICATIONS
Input/Output
Input 12-24VDC
Input Plug Cigarette Lighter
Output USB-A: 5V/1.0A
USB-C: 5V/3A, 9V/3A, 12V/2A,
or 20V/1.5A
Output Port USB-A*1 +USB-C*1
Protection
Over Current Protection Yes
Over Load Protection Yes
Over Temperature Protection Yes
Short Circuit Protection Yes
Performance
Ripple And Noise ≤200mV
Efficiency ≥85%
Mechanical
Color Black
Size 68.3(L)mm*φ30.1mm
Weight about 29g
Environmental
Operating Temperature Range 0~30
°
C
Storage Temperature Range -20 ~ 60
°
C
Operating Relative Humidity 30~ 90% RH
Certification CE
4.0 PACKAGE CONTENT
Before attempting to use this unit, please check the packaging and
make sure the following items are contained in the shipping carton:
Main unit ×1
User Manual ×1

4
5.0 PRODOCT SHOW
1. USB-A charging port: 5V/1.0A
2. USB-C charging port: 5V/3A, 9V/3A, 12V/2A, 20V/1.5A
6.0 OPERATION
Operation Procedures
1. Plug the car charger into the car cigarette lighter, and the LED light
turns blue.
2. Plug one USB connector of the cable into the preferred charging port
of the car charger and plug the other connector of the cable into
your mobile device.
3. Please pull the USB connector out after your device is fully charged.
1
2

5
Operation Notes
1. For optimum performance, please use the power station according to
the user manual.
2. Please plug the power adapter into socket whose voltage range
should be 100~240VAC.
3. Please unplug the power adapter after using.
Note: Our products have protection functions and the two tips above are
suggestions just for safety.
4. Do not use the power station with an electronic product which is not
in conformity with the specifications, so as to avoid any problems
caused by specification mismatching.
5. It’s normal that power adapter and power station will be a little bit
overheated in the use process.
6. When the power station stops working under over-current, over-
temperature or short-circuit protection, please unplug the device
after it automatically returns to work. You need to check whether the
device is compatible with this charger.
7. Do not let the power station close to fire, such as stove or candles… etc.
8. Do not let the power station soak into liquid, such as swimming pool,
bathtub… etc.
9. Do not wash the power station with corrosive cleaner.
10. If the power station cannot work properly, please contact the store
or distributor in your area.
All brand names and logos which mentioned above are trademarks or registered
trademarks of the respective owner.

6
7.0 CONNECTION DIAGRAM
Hereby ASSMANN Electronic GmbH, declares that this device is in compliance with the
requirements of Directive 2014/30/EU and the Directive 2011/65/EU for RoHS compliance.
The complete declaration of conformity can be requested by post under the below
mentioned manufacturer address.
Warning:
This device is a class B product. This equipment may cause some radio interference in living
environment. In this case, the user can be requested to undertake appropriate measures to
prevent interference.
www.assmann.com
Assmann Electronic GmbH
Auf dem Schüffel 3
58513 Lüdenscheid
Germany
