Roav F2 User manual

Roav Smart Car Charger F2

Model: R5111-JP

51005000972 V01

Safety

Instructions

Please read and understand all instructions before using this

product. If damage is caused by failure to follow the instructions,

the warranty does not apply.

• Keep these instructions.

• Do not drop, puncture or disassemble this product.

• This product shall not be exposed to dripping or splashing.

• Avoid long exposure to direct sunlight, which may cause

damage.

• Exposing this product to open ﬂames may cause explosion.

• Do not use the product in strong magnetic ﬁeld.

• Use clean, soft cloth to clean. Do not use any corrosive

cleaner/oil to clean.

• Keep your attention on the road. Do not operate the controls

of this product while driving.

Introduction

Features

• Hands-free call

• Stream music to car audio via FM transmitter

• AUX line out

• Dual USB charging ports

• PowerIQ with quick charge technology

• Companion Roav App with FM frequency modulation and car

locator

What’s Included

Owner’s Manual

Roav Smart Car Charger F2

Roav Smart Car

Charger F2

Manual

At a Glance

USB charging port USB charging port/

USB ﬂash drive port

Microphone LED display

Multifunction button

AUX line out

/ Car charger adapter

LED indicators Status

/ FM frequency

ﬂashes alternately

No Bluetooth connected and no ﬂash

drive detected

FM frequency is

displayed

Bluetooth connected or ﬂash drive

detected

FM frequency ﬂashes

Enter FM mode

Incoming call

In a call with hands-free

In a call through smartphone

Get Started

Plug Roav smart car charger into your vehicle’s cigarette

lighter socket.

Start your vehicle’s engine and the LED display will light

on. / FM frequency will ﬂash alternatively. In case you

have completed step , you would hear a voice prompt

“waiting to pair”.

Enable Bluetooth on your smartphone and search for Bluetooth

devices available. Select “Roav F2_xxxx” and connect. Once

successfully connected, FM frequency will be displayed and a

voice prompt “successfully paired” will be heard.

Roav F2_XXXX

Turn on the FM radio on your car audio deck and tune to

an unoccupied frequency (white noise). Press and hold

the multifunction button on Roav smart car charger until

FM frequency ﬂashes. Press or hold / until the

transmitting frequency matches the frequency selected on

your car audio.

Roav Charger

App

With the Roav Charger app, you can set FM frequencies, locate

your car, upgrade software, and learn more about Roav smart car

charger.

To download Roav Charger app, search “Roav Charger” in App

Store or Google Play.

ROAV Charger

Apple and the Apple logo are trademarks of Apple Inc.,

registered in the U.S. and other countries. App Store is a service

mark of Apple Inc., registered in the U.S. and other countries.

Google Play and the Google Play logo are trademarks of Google

Inc.

Play Music

When the Roav smart car charger is successfully connected with

your smartphone, you can play music from your phone. Music can

then be streamed to your car audio via FM transmitter.

You can

also enjoy music that are stored on a USB ﬂash drive.

USB

Play / Pause Press

Previous / Next track Press /

To further reduce echo and cabin noise on your calls, you can

connect a 3.5 mm AUX cable (not provided) to AUX line out

socket of the Roav smart car charger and AUX IN socket of your

car audio system.

FM AUX IN

Hands-free Call

When the Roav smart car charger is successfully connected with

your smartphone, you can enjoy convenient hands-free call.

Answer / End a call Press

Reject a call Press and hold for 1 second

Charge Your

Devices

The Roav smart car charger contains dual USB

charging ports. You can charge two devices at the

same time with maximum output of 5V/3.9A.

2.4A

1.5A

1 2 3 4 5

Specifications

Speciﬁcations are subject to change without notice.

DC input: 12V - 24V

Power output: 5V 3.9A Max

Bluetooth version: V4.2

Bluetooth transmission distance: 10 m / 393.7 in

Audio format: .mp3 .wma .ﬂac .wav

FM frequency range: 87.5-108 MHz

FM transmission range: 2 m / 78.7 in

USB ﬁle system: FAT, FAT32, exFAT

Operating temperature range: -4°F to 104°F / -20°C to 40°C

Storage temperature range: -40°F to 185°F / -40°C to 85°C

Notice

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Warning:

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the

equipment.

Note:

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates uses and can radiate radio frequency

energy

and, if not installed and used in accordance with the instructions, may

cause harmful interference to radi

o communications. However, there is

no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures: (1) Reorient or relocate the receiving

antenna. (2) Increase the separation between the equipment and

receiver. (3) Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected. (4) Consult the dealer or

an experienced radio/TV technician for help.

FCC Radio Frequency Exposure Statement

The device has been evaluated to meet general RF exposure

requirements. The device can be used in ﬁxed/mobile exposure

condition. The min separation distance is 20cm.
