Edvotek Mezzo 533 User manual

Features:
• Touch OLED display: change speed, time and start/stop
• Speed Range: 1000-12000 rpm, 1000 rpm increments
• Timer Range: 10 seconds-20 min, 10 second increments
• Max RCF: 7490 xg
• Power: AC100-240V, 50Hz/60Hz; 30W
• Dimensions: 210 x 180 x 130 mm
• Weight: 1.5 kg
• One Year Warranty
Includes:
• High-speed Mini Centrifuge
• 12 place 1.5/2.0 mL tube + 32 place 0.2 mL tube rotor
(4 x 8 Strip) rotor
• 12 tube adapters 0.2 mL
• 12 tube adapters 0.5 mL
• US, UK, EU adapter
Installation Instructions:
1. UNPACK and PLACE the centrifuge on a solid and at surface (laboratory bench space).
2. ENSURE a good working environment and ambient temperature of 5°C - 35°C.
3. PROTECT the centrifuge from direct sunlight or temperatures higher than 30°C.
4. ALLOW for good ventilation by avoiding crowded areas.
5. KEEP the centrifuge away from heat or liquid chemical spills.
Rotor Installation:
1. ENSURE the centrifuge chamber is clean and dry.
2. ENSURE there is no sign of corrosion, cracks, or damage to the rotor.
3. Firmly PLACE the rotor into position onto the rotor base motor shaft.
4. PRESS the rotor inward onto the motor shaft to secure tightly.

Visit our website at www.edvotek.com
OPERATION MANUAL Mezzo™Microcentrifuge
2
Operating Procedures:
1. CONNECT the power supply and PRESS the power switch located on the back of the main unit so the OLED
screen lights up.
2. PRESS the button to open the lid and PLACE the sample-loaded centrifuge tubes symmetrically on the rotor with-
out spilling any liquid. Take care to LEVEL the tubes in advance (see gure below).
3. CLOSE the centrifuge cover and TOUCH the “Speed” and “Time” indicators on either side of the screen to switch
between speed and time on the main and secondary displays of the OLED screen. TURN the dial knob to set
speed and time respectively.
4. PRESS the OLED screen key to start the centrifuge. PRESS again to stop operation. NOTE: If the “Open” button is
pressed while the centrifuge is running, the top cover opens and the machine stops automatically.
5. REMOVE the centrifuge tubes and SWITCH o the power.
Warnings:
Changes or modications not expressly approved by EDVOTEK® could void the user’s warranty and authority to op-
erate the equipment. NOTE: This centrifuge has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the centrifuge is operated in a commercial environment. The centrifuge generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the user manual, may cause
harmful interference to radio communications. Operation of centrifuge in a residential area is likely to cause harmful
interference in which case the user may be required to correct the interference.
NOTE: Ensure the rotor is ALWAYS balanced with equal weighted tubes on opposite sides of the rotor.
