EGAN ESSH361 User manual

Comments
or
Questions?
CALL US!
WARRANTY
Egan Visual Inc. warrants the construction and finish
of this product for normal and reasonable use for the
period of five (5) years from the date of invoice. This
warranty does not apply to defects resulting from lack
of normal maintenance, improper cleaning or
negligence.
Egan
Shelving Unit
INSTALLATION
INCLUDED HARDWARE:
Minifix bolts
Rafix bolts
4
4
6
Minifix housings
CANADA: 1-800-263-2316
USA EAST: 1-800-263-2387
USA WEST: 1-800-826-1778
email: [email protected]
www.egan.com
Reference #024H001 12/99:10M
36” Track Shelf - 1
ESSH361
024H001 Qrk 10/18/00 4:01 PM Page 1

Philips
Screwdriver
TOOLS REQUIRED:
ASSEMBLY
1. Locate the two gables and insert Minifix
bolts on the gable edge, then insert
Minifix housings in the rear side. Now
attach gables to back and lock as shown
in picture
2. Insert the Rafix screws at the bottom
of the gables. Place adjustable shelf
onto Rafix bolts as shown in
3. Lock shelf in place as shown in C
A
B
B
A
MINIFIX
BOLT
C
GABLE
SHELF
BACK
REAR
ADJUSTABLE
SHELF
MINIFIX
HOUSING
RAFIX
BOLT
MINIFIX
HOUSING
024H001 Qrk 10/18/00 4:01 PM Page 2

Comments
or
Questions?
CALL US!
WARRANTY
Egan Visual Inc. warrants the construction and finish
of this product for normal and reasonable use for the
period of five (5) years from the date of invoice. This
warranty does not apply to defects resulting from lack
of normal maintenance, improper cleaning or
negligence.
Egan
Shelving Unit
INSTALLATION
INCLUDED HARDWARE:
Minifix bolts
Rafix bolts
6
6
12
Minifix housings
CANADA: 1-800-263-2316
USA EAST: 1-800-263-2387
USA WEST: 1-800-826-1778
email: [email protected]
www.egan.com
Reference #024H002 12/99:10M
36” Track Shelf - 2
ESSH362
024H002 Qrk 10/18/00 4:00 PM Page 1

Philips
Screwdriver
TOOLS REQUIRED:
ASSEMBLY
1. Locate the two gables and insert Minifix
bolts on the gable edge, then insert
Minifix housings in the rear side. Now
attach gables to back and lock as shown
in picture
2. Insert the Rafix screws at the bottom
of the gables. Place adjustable shelf
onto Rafix bolts as shown in
3. Lock shelf in place as shown in
4. Repeat steps 2 + 3 for the remaining
shelf.
C
A
B
B
A
MINIFIX
BOLT
C
GABLE
SHELF
BACK
REAR
ADJUSTABLE
SHELF
MINIFIX
HOUSING
RAFIX
BOLT
MINIFIX
HOUSING
024H002 Qrk 10/18/00 4:00 PM Page 2

Comments
or
Questions?
CALL US!
WARRANTY
Egan Visual Inc. warrants the construction and finish
of this product for normal and reasonable use for the
period of five (5) years from the date of invoice. This
warranty does not apply to defects resulting from lack
of normal maintenance, improper cleaning or
negligence.
Egan
Shelving Unit
INSTALLATION
INCLUDED HARDWARE:
Minifix bolts
Rafix bolts
8
8
18
Minifix housings
CANADA: 1-800-263-2316
USA EAST: 1-800-263-2387
USA WEST: 1-800-826-1778
email: [email protected]
www.egan.com
Reference #024H003 12/99:10M
36” Track Shelf - 3
ESSH363
024H003 Qrk 10/18/00 4:00 PM Page 1

ASSEMBLY
1. Locate the two gables and insert Minifix
bolts on the gable edge, then insert
Minifix housings in the rear side. Now
attach gables to back and lock as shown
in picture
2. Insert the Rafix screws at the bottom
of the gables. Place adjustable shelf
onto Rafix bolts as shown in
3. Lock shelf in place as shown in
4. Repeat step 2 + 3 for the remaining
shelves.
C
A
B
Philips
Screwdriver
TOOLS REQUIRED:
B
A
MINIFIX
BOLT
C
GABLE
SHELF
BACK
REAR
ADJUSTABLE
SHELF
MINIFIX
HOUSING
RAFIX
BOLT
MINIFIX
HOUSING
024H003 Qrk 10/18/00 4:00 PM Page 2

Comments
or
Questions?
CALL US!
WARRANTY
Egan Visual Inc. warrants the construction and finish
of this product for normal and reasonable use for the
period of five (5) years from the date of invoice. This
warranty does not apply to defects resulting from lack
of normal maintenance, improper cleaning or
negligence.
Egan
Shelving Unit
INSTALLATION
INCLUDED HARDWARE:
Minifix bolts
Minifix housing
Rafix bolts
4
4
6
CANADA: 1-800-263-2316
USA EAST: 1-800-263-2387
USA WEST: 1-800-826-1778
email: [email protected]
www.egan.com
Reference #024H004 12/99:10M
42” Track Shelf - 1
ESSH421
024H004 Qrk 10/18/00 4:00 PM Page 1

1. Locate the two gables and insert Minifix
bolts on the gable edge, then insert
Minifix housings in the rear side. Now
attach gables to back and lock as shown
in picture
2. Insert the Rafix screws at the bottom
of the gables. Place adjustable shelf
onto Rafix bolts as shown in
3. Lock shelf in place as shown in
Philips
Screwdriver
TOOLS REQUIRED:
ASSEMBLY
B
A
C
GABLE
C
SHELF
BACK
REAR
ADJUSTABLE
SHELF
A
B
MINIFIX
HOUSING
RAFIX
BOLT
MINIFIX
HOUSING MINIFIX
BOLT
024H004 Qrk 10/18/00 4:00 PM Page 2

Comments
or
Questions?
CALL US!
WARRANTY
Egan Visual Inc. warrants the construction and finish
of this product for normal and reasonable use for the
period of five (5) years from the date of invoice. This
warranty does not apply to defects resulting from lack
of normal maintenance, improper cleaning or
negligence.
Egan
Shelving Unit
INSTALLATION
INCLUDED HARDWARE:
Minifix bolts
Minifix housing
Rafix bolts
6
6
12
CANADA: 1-800-263-2316
USA EAST: 1-800-263-2387
USA WEST: 1-800-826-1778
email: [email protected]
www.egan.com
Reference #024H005 12/99:10M
42” Track Shelf - 2
ESSH422
024H005 Qrk 10/18/00 3:59 PM Page 1

1. Locate the two gables and insert Minifix
bolts on the gable edge, then insert
Minifix housings in the rear side. Now
attach gables to back and lock as shown
in picture
2. Insert the Rafix screws at the bottom
of the gables. Place adjustable shelf
onto Rafix bolts as shown in
3. Lock shelf in place as shown in
4. Repeat steps 2 + 3 for the remaining
shelf.
Philips
Screwdriver
TOOLS REQUIRED:
ASSEMBLY
B
A
MINIFIX
BOLT
C
GABLE
C
SHELF
BACK
REAR
ADJUSTABLE
SHELF
A
B
MINIFIX
HOUSING
RAFIX
BOLT
MINIFIX
HOUSING
024H005 Qrk 10/18/00 3:59 PM Page 2

Comments
or
Questions?
CALL US!
WARRANTY
Egan Visual Inc. warrants the construction and finish
of this product for normal and reasonable use for the
period of five (5) years from the date of invoice. This
warranty does not apply to defects resulting from lack
of normal maintenance, improper cleaning or
negligence.
Egan
Shelving Unit
INSTALLATION
INCLUDED HARDWARE:
Minifix bolts
Rafix bolts
8
8
18
Minifix housings
CANADA: 1-800-263-2316
USA EAST: 1-800-263-2387
USA WEST: 1-800-826-1778
email: [email protected]
www.egan.com
Reference #024H006 12/99:10M
42” Track Shelf - 3
ESSH423
024H006 Qrk 10/18/00 3:59 PM Page 1

ASSEMBLY
1. Locate the two gables and insert Minifix
bolts on the gable edge, then insert
Minifix housings in the rear side. Now
attach gables to back and lock as shown
in picture
2. Insert the Rafix screws at the bottom
of the gables. Place adjustable shelf
onto Rafix bolts as shown in
3. Lock shelf in place as shown in
4. Repeat step 2 + 3 for the remaining
shelves.
C
A
B
Philips
Screwdriver
TOOLS REQUIRED:
B
A
MINIFIX
BOLT
C
GABLE
SHELF
BACK
REAR
ADJUSTABLE
SHELF
MINIFIX
HOUSING
RAFIX
BOLT
MINIFIX
HOUSING
024H006 Qrk 10/18/00 3:59 PM Page 2

Comments
or
Questions?
CALL US!
WARRANTY
Egan Visual Inc. warrants the construction and finish
of this product for normal and reasonable use for the
period of five (5) years from the date of invoice. This
warranty does not apply to defects resulting from lack
of normal maintenance, improper cleaning or
negligence.
Egan
Shelving Unit
INSTALLATION
INCLUDED HARDWARE:
Minifix bolts
Minifix housing
Rafix bolts
6
6
10
CANADA: 1-800-263-2316
USA EAST: 1-800-263-2387
USA WEST: 1-800-826-1778
email: [email protected]
www.egan.com
Reference #024H007 12/99:10M
48” Track Shelf - 1
ESSH481
024H007 Qrk 10/18/00 3:58 PM Page 1

Philips
Screwdriver
TOOLS REQUIRED:
B
A
MINIFIX
BOLT
C
PARTITION
BACK
GABLE
D
RAFIX
BOLT
ADJUSTABLE
SHELVES
ASSEMBLY
1. Locate the partition and the back. Insert
Minifix bolts in the back and Minifix
housings in partition and assemble as
shown in picture
2. Insert Minifix bolts into the gables
and attach to the back as shown
in picture
3. Insert Rafix bolts into the gables
and partition, then place adjustable
shelves onto bolts as shown in picture
4. Lock shelves in place as shown in
C
D
A
B
MINIFIX
HOUSING
024H007 Qrk 10/18/00 3:58 PM Page 2

Comments
or
Questions?
CALL US!
WARRANTY
Egan Visual Inc. warrants the construction and finish
of this product for normal and reasonable use for the
period of five (5) years from the date of invoice. This
warranty does not apply to defects resulting from lack
of normal maintenance, improper cleaning or
negligence.
Egan
Shelving Unit
INSTALLATION
Minifix bolts
INCLUDED HARDWARE:
Minifix housing
Rafix bolts
9
9
20
CANADA: 1-800-263-2316
USA EAST: 1-800-263-2387
USA WEST: 1-800-826-1778
email: [email protected]
www.egan.com
Reference #024H008 12/99:10M
48” Track Shelf - 2
ESSH482
024H008 Qrk 10/18/00 3:58 PM Page 1

1. Locate the partition and the back. Insert
Minifix bolts in the back and Minifix
housings in partition and assemble as
shown in picture
2. Insert Minifix bolts into the gables
and attach to the back as shown
in picture
3. Insert Rafix bolts into the gables and
partition, then place adjustable shelves
onto bolts as shown in picture
4. Lock shelves in place shown in
5. Complete the assembly by installing
remaining shelves following steps 3+4.
Philips
Screwdriver
TOOLS REQUIRED:
ASSEMBLY
B
A
MINIFIX
BOLT
C
C
PARTITION
RAFIX
BOLT
A
B
BACK BACK
D
ADJUSTABLE
SHELF
GABLE
MINIFIX
BOLT
MINIFIX
HOUSING
D
024H008 Qrk 10/18/00 3:58 PM Page 2

Comments
or
Questions?
CALL US!
WARRANTY
Egan Visual Inc. warrants the construction and finish
of this product for normal and reasonable use for the
period of five (5) years from the date of invoice. This
warranty does not apply to defects resulting from lack
of normal maintenance, improper cleaning or
negligence.
Egan
Shelving Unit
INSTALLATION
INCLUDED HARDWARE:
12
12
30
Minifix bolts
Minifix housing
Rafix bolts
CANADA: 1-800-263-2316
USA EAST: 1-800-263-2387
USA WEST: 1-800-826-1778
email: [email protected]
www.egan.com
Reference #024H009 12/99:10M
48” Track Shelf - 3
ESSH483
024H009 Qrk 10/18/00 3:52 PM Page 1

Philips
Screwdriver
TOOLS REQUIRED:
ASSEMBLY
B
A
1. Locate the partition and the back. Insert
Minifix bolts in the back and Minifix
housings in partition and assemble as
shown in picture
2. Insert Minifix bolts into the gables
and attach to the back as shown in
3. Insert Rafix bolts into the gables and
partition, then place adjustable shelves
onto bolts as shown in picture
4. Lock shelves in place as shown in
5. Complete the assembly by installing
remaining shelves following steps 3+4.
C
D
A
B
MINIFIX
BOLT
C
PARTITION
RAFIX
BOLT
BACK BACK
D
ADJUSTABLE
SHELF
GABLE
MINIFIX
BOLT
MINIFIX
HOUSING
024H009 Qrk 10/18/00 3:52 PM Page 2
