EGi DOMOS2 User manual

40100
Remote control
www.egiaudio.com
Avda. Almozara, 79  50003 ZARAGOZA - Spain  Phone [phone]  Fax [phone]  http//: www.egiaudio.com  e-mail: [e-mail]
Users Manual
English
005180

Thank you for choosing the
EGi DOMOS2 Universal
Remote Control. It will allow
you to control your home
appliances, as well as your
EGi Audio & Domotic System.
Please read carefully before
using the system and save this
manual for future reference.
EGi DOMOS2 Universal
Remote Control can program
codes from other remote
controls (TV, VCR, DVD, audio
equipment, etc.) by the
learning process or selecting
them on a code list.
EGi DOMOS2 Universal
Remote Control has a LCD
backlight touch-screen with
56 buttons to control each
device.
The advanced functions
allow you to program up to
60 commands at the touch
of a button.

CHAPTER 1
Getting started 4
40100 Remote control 4
CHAPTER 2
Before use 6
Code/Learn button 6
Manual code selection 6
Automatic code selection 7
CHAPTER 3
Code learning function 9
Code learning process 9
LCD Edit mode: Device buttons 10
Delete codes and devices 11
MACRO Function 12
Reset to initial codes 14
CHAPTER 4
EGi - Audio 15
EGi - Domotics 17
CHAPTER 5
Option settings 19
APPENDIX A
Technical specifications 23
APPENDIX B
Problem-solving chart 24

1
2
3
4
5
7
6
www.egiaudio.com
4
Getting started
Before using the 40100 Remote Control, please make sure that the package contains the following components:
•1 x 40100 Remote Control.
•1 x User’s Manual.
•1 x Pre-Programmed Code List.
•3 x AAA 1.5 V Alkaline Batteries.
If the package does not include any of these components, please contact your installer or the EGi
Customer Service.
BATTERY ORIENTATION
Open the battery lid that is on the backside of the remote control.
Chapter 1
1IR Emitter to transmit the signals to the device to be
controlled.
2Ambient light sensor to detect the light in the room
and turn the backlight on, if necessary.
3LCD Touch-screen to display all control buttons of
the device to be controlled.
4Backlight. If there is not enough ambient light, the
remote control will be illuminated during use and 90
seconds after pressing a button.
5Device buttons to select the device to be controlled.
6Connector to transfer settings between two remote
controls using a wire (not included).
7IR Receiver to use during the learning mode.
•Inside the battery compartment there are symbols showing in which direction
the batteries should be placed. Carefully follow these directions.
•Do not mix new and old batteries.
•Replace all batteries at the same time.
40100 Remote control

1 2 3 4
5 6 7 8
www.egiaudio.com
5
40100 Remote Control will allow you to control your EGi Audio & Domotic System. You will also be
able to control all home appliances, as well as your TV, DVD, audio equipment, and radio receiver with
your 40100 Remote Control.
To select the device or system that you want to control, press the icon on the lower part of your remote
control display.
1Select the TV device.
2Select the satellite receiver/cable.
3Select the video device (VCR).
4Select the DVD device.
5Select the audio equipment.
6Select other audio sources.
7Select the EGi domotic system.
8Select the EGi audio system.

www.egiaudio.com
6
Before use
Before using the 40100 Remote Control, you must set it to ensure the correct transmission to the devices
that are going to be controlled.
The setting can be done by introducing the CODES:
•Manual: Introducing the number (from the code list) assigned to the device to be controlled.
•Automatic: Allowing the remote control to interact with the device to be controlled.
You may also set the device through the LEARNING process.
Code Learn button
Press the CODE button for 3 seconds to access to the confirmation screen. Then press each number
in any order to access to the next screen. Press the and buttons to select one of the following
options:
•CODE: Automatic setting. Your remote control must be included on the code list.
•LEARN: If your remote control is not included on the code list, you must prerecord the codes
manually. To do so, put the remotes in front of the other.
Manual code selection
This function allows you to set your 40100 Remote Control and make it work as one of the remotes
included on the attached list.
Chapter 2
1Select the device to be programmed for instance, TV.
2Press and hold the CODE button for 3 seconds to access to
the confirmation screen.
3Press each number (2, 4, 6, 8) in any order. Start to use the
PRE-CODE function.

www.egiaudio.com
7
Automatic code selection
4Press and buttons to select the desired options until
you find CODE. Press and access to the code page.
5Press the 4-digit code manually.
NOTES:
•Some codes included on the list are not specific to one remote control model. You must select the
one that best adapt for your model.
•If a code is not included on the Manufacturer’s Code List, the screen will display ERROR when
introducing that code.
EXAMPLE:
Should you wish to control the two televisions that you have at home (TV1 and TV2) with your 40100
Remote Control, follow these steps:
1Assign the TV1 to the TV device button. Please see “LCD Edit Mode: Device buttons” to introduce
the 4 codes, and follow the steps.
2Assign the TV2 to any of the device buttons except DOMOTICS and EGi AUDIO; for instance,
SAT/CBL. Follow the same steps as in TV1.
Press the TV button any time you want to control the TV1. Press the SAT/CBL button any time you
want to control the TV2.
Please note that your remote control may not be listed as there are many manufacturers
and remote control models available on the market. If so, please see “Manual code
selection” & “Code learning process”.
1Manually turn on the device to be controlled.
2Select the device to be controlled (TV, SAT, AUDIO) on your
40100 Remote Control.
3Press CODE for 3 seconds.

www.egiaudio.com
8
4Press each number (2, 4, 6, 8) only once in any order.
5Press the button to select CODE.
6Press AUTO. You will listen to a beep while AUTO and OK
blink.
7When the device (that is being controlled) turns off, press
any key of the remote control.
8Press or until the device you want to control turns on.
9Press the button to ensure the correct operation.
10 Press DISPLAY to see the code of your device.
11 Press the OK button to confirm the selection.

www.egiaudio.com
9
Chapter 3
Code learning process
If we assume that you want to program the TV remote control on the EGi 40100 Remote Control, then
put both remotes together as shown in Figure 6 and proceed as follows:
1Keep the CODE button pressed for 3 seconds to access to
the confirmation screen.
2Press each number (2, 4, 6, 8) only once in any order.
3Navigate through the menu options using the and
buttons until you find the LEARN option.
4Press the button to confirm this option.
5Press the button of the device to be controlled (TV, SAT/CBL,
VCR, DVD, Audio, etc.) for instance, DVD.
Code learning function
EGi 40100 Remote Control allows you to learn the codes from your existing remote control, for instance
TV, without using the Manufacturer’s Code List.
Before learning the codes from your existing remote control, please read carefully the following:
1Before learning the new codes, delete the existing ones from the remote control. For instance, if
you want to control your living room TV instead of your kitchen TV, delete first the commands of
your kitchen TV.
2This learning process does not work with all remote controls on the market.
3Not all of the EGi 40100 Remote Control keys can be programmed: CODE SETUP KEY, DELETE
KEY, MACRO KEY and SYSTEM SETUP.

www.egiaudio.com
10
1Keep the remote control button pressed for at least 3 seconds
to access to the confirmation screen.
2Press each number (2, 4, 6, 8) only once in any order to
access to the selection screen.
3Press the button that you want to change on the remote control
page. Press repeatly to select any of the available options.
4Press KEY to display all the available icons on the LCD screen.
Repeat step 3 until all changes are made.
5Once you have defined the screen, press OK to confirm
changes. If you do not want to save changes, press EXIT.
LCD Edit mode: Device buttons
The edit mode allows you to define the touch screen so as to match it with your existing remote controls.
6The button on the 40100 Remote Control blinks. Press
the same button on the remote control until it stops blinking.
Repeat the process with every blinking button and finish the
copy operation.
NOTE:
If a code of your TV remote control already exists on the 40100
Remote Control, CODE will be displayed on the screen during
the learning process.
Should you wish to learn a code on any of the device buttons,
for instance the TV button; press the TV button for at least 3
seconds. The TV button will start blinking.
Then press the start button on the TV remote control. If it has
been learnt correctly, the 40100 Remote Control screen will
display OK .
5-10 cm.

www.egiaudio.com
11
Delete codes and devices
To delete one or all 40100 Remote Control codes, follow these steps:
1Keep the DELETE button pressed for 3 seconds to access
to the confirmation screen.
2Press each number (2, 4, 6, 8) only once in any order.
3Navigate through the menu options using the and
buttons until you find the device you want to delete, then
press KEY to delete the codes. Should you wish to delete
the TV codes from the 40100 Remote Control, select first
the TV button and then press KEY.
The second option is BANK. If you press this button, you
will delete all remote control codes. Then press the OK button.
4Press the button to confirm this option.

www.egiaudio.com
12
MACRO function
The MACRO function (a sequence of commands of max. 60 seconds) allows you to have the control of
your TV and DVD at the same time by pressing only one button on the 40100 Remote Control. You must
create a sequence of commands specifying preference and time of execution of DVD, video and TV.
HOW TO CREATE A MACRO
1Keep the MACRO button pressed for 3 seconds to access
to the confirmation screen.
2Press each number (2, 4, 6, 8) only once in any order.
The MACRO icon starts to blink.
3For instance, select the TV to use it as our MACRO function.
Then press any of the numbers to assign this function to it.
Listen to 3 beep tones generated by the creation of the macro.
If the selected number already has a MACRO function assigned
to it, the new function will overwrite the existing one.
4You can establish when the command is executed. Press any
of the buttons with a command assigned to it. Press DELAY
and then press the seconds (up to 9) to delay the execution
between the commands.
5Press OK to confirm or EXIT to cancel.

www.egiaudio.com
13
MACRO BUTTONS
The screen can display the macro function buttons assigned to
a particular device. To do this with the TV button, follow these
steps:
1Press the TV device button.
2Keep the MACRO button pressed in order to display the
remote control macros.
For example, if you select number 9 as macro button on
PAGE 1of the TV, then every time you press the MACRO
button, the screen will display the 9macro function.
3Press the TV button again to check the macro buttons on
PAGE 2. Go back to step 2.
EXAMPLE:
If we assume that you want to turn on your TV in order to watch a film on DVD in 5 seconds, then follow
these steps to set the macro:
1Press the TV button on the 40100 Remote Control. (This will bring you to your TV remote control menu).
2Press . (This will turn on your TV).
3Activate the TV/VIDEO button. (This will put the channel to watch the DVD on your TV).
4Press the DVD button on the 40100 Remote Control.
5Press the button. (This will turn on your DVD device).
6Press the DELAY button, and then press number 5. (The remote control will activate the next
command in 5 seconds).
7Press DVD Play on your remote. (Your DVD will start to play).
8Press OK to confirm this macro.
NOTE:
Should you wish to stop the sequence of macro commands, press the EXIT button.

www.egiaudio.com
14
STOP MACRO COMMANDS
To stop the sequence of macro commands, press first the MACRO button, and then press the EXIT
button. If ERROR is displayed on the screen, the sequence is stopped.
Reset to initial codes
This option allows you to reset to initial codes and macros. The codes and macros that you programmed
will be deleted.
Should you wish to reset your 40100 Remote Control to its initial state, follow these steps:
1Keep the DELETE button pressed for 3 seconds to access
to the confirmation screen.
2Press each number (2, 4, 6, 8) only once in any order.
3Navigate through the menu options using the and
buttons until you find the KEY BANK mode.
4Press the button to confirm this option.
The confirmation screen will be displayed again, then confirm
it once again.
5Press each number (2, 4, 6, 8) in any order once again for
a definitive confirmation.
Check that the OK icon is displayed. It indicates that
the codes are reset to their initial state.

www.egiaudio.com
15
Chapter 4
EGi - Audio
40100 Remote Control will allow you to control some audio and domotic functions of your DOMOS2
system at the touch of a button.
GENERAL
DOMOS2 Audio Menu.
DOMOS2 Domotics Menu.
AUDIO CONTROLS
Turn on/off the audio of the in-wall control unit.
Press the key once to turn off the audio of the control unit of the room. If you press the
key again, the control unit will be turned on and you will continue listening to the program
that you left.
NOTE: This key only turns on/off the audio of the control unit. The other functions will not
be affected.
Volume regulation.
This key turns up/down the volume of the EGi sound system. Keep the up/down key pressed
to control the volume of the audio source (radio, music, TV, etc.).
Program selector (3 General audio programs and 1 local audio program).
It allows you to select any of the general or local audio programs that are available.
NOTE: Your EGi sound system has 3 general audio programs (for the whole system) and 1
local program (but only for the room in which the control unit with built-in tuner has been
installed). You are able to select different audio sources (FM tuner, audio equipment, TV, etc.)
for each audio program.
Press the key to select any of the 3 general audio programs and the local FM radio
program, provided that your control unit has a built-in tuner.
Select a preset radio station in the central unit (General/Local prog.).
It allows you to select any of the preset radio stations of the central unit or in-wall control
unit (local). Please see “FM Radio station scan”.
Pressing the key, the preset radio stations of each audio program will consecutively
change 1.. 9.
Should you wish to listen to a particular preset radio station; first select the program (general or
local) in the unit with the FM tuner, and then press the key to find the desired radio station.

www.egiaudio.com
16
FM Radio station scan.
If your control unit has a FM tuner, you will be able to scan and set FM radio stations by pressing
the button.
Press the key to scan FM radio stations. The unit will scan upward through the FM frequency.
The in-wall control unit will display the FM radio stations that are being saved. The system select
automatically the radio stations.
Activate/Deactivate the timer.
It activates/deactivates the TIMER function. This function allows you to defer the turn off of the
system for a specifc time.
Press this key once to activate/deactivate the TIMER function.
NOTE: This function must be activated in the central unit.
Activate/Deactivate the alarm clock.
It activates/deactivates the ALARM CLOCK function. This function allows you to connect the
system at a specific time.
Press the key once to activate/deactivate the ALARM CLOK function.
NOTE: This function must be activated in the central unit.
INTERCOM FUNCTIONS
• Intercom and baby-phone
1...9 Local intercom.
Local intercom with one zone of the installation. Should you wish to talk to other zone, press the
key with the number of that zone once. Get close to the in-wall DOMOS2 control unit to talk to
the selected zone. You will be able to talk to the other zone for a maximum of 90” before receiving
an answer.
General call.
The general call function allows you to talk to all zones of the house. If you press this key once,
you will be able to talk to all zones for no longer than 90”. Once you receive an answer from other
zone(s), you will be able to keep the conversation for 90” more and so on for conversations
between 2 zones or more.
Activate/Deactivate the baby-phone/monitor function.
Press this key once to activate/deactivate the baby-phone/monitor function of the selected zone.
NOTE: This function must be activated in the central unit. To activate this function, press the key
of the in-wall control unit of the room to be monitored.

www.egiaudio.com
17
Activate/Deactivate the listening function.
Press this key once to activate/deactivate the LISTENING function of the selected zone.
NOTE: This function must be activated in the central unit. To activate this function, press the
key of the in-wall control unit of the room to be monitored.
Activate/Deactivate the “Do not disturb” function.
Press this key once to activate/deactivate the DO NOT DISTRUB function of the selected zone.
NOTE: This function must be activated in the central unit. If this function is activated, you will not
be able to listen to the intercom or any other system call in the room.
• Door entry system
Press to open the door.
If your system has this function activated, the intercom will be activated when receiving a call.
Press this key once to open the door when you receive a call.
Press to cancel the communication through the door entry system.
Press the key once to finish the communication through the door entry system.
Answer the door when you receive a call.
Press this key once to answer the door after receiving a call and talk to the visitor.
EGi - Domotics
DOMOTIC FUNCTIONS
SOS SOS Alarm function.
Keep this key pressed to activate the SOS Alarm.
Pull up the blind.
Keep this key pressed to pull up the blind of the selected zone.
Pull down the blind.
Keep this key pressed to pull down the blind of the selected zone.

www.egiaudio.com
18
Domotic service (1, 2, 3, 4) for one zone.
This icon indicates the domotic services for a specfic zone of the house. It activates/deactivates the
domotic service associated with the number by pressing 1...4.
Domotic service (7, 8, 9, 0) for the whole installation.
This icon indicates the domotic services for the whole installation. It activates/deactivates the domotic
service associated with the number by pressing 7...0.
Roll up the awning.
Keep this key pressed to roll up the awning.
Roll down the awning.
Keep this key pressed to roll down the awning.

www.egiaudio.com
19
Chapter 5
1Keep the SETUP button pressed for 3 seconds to access to
the confirmation screen.
2Press each number (2, 4, 6, 8) only once in any order.
3Navigate through the menu options using the and
buttons until you find the CODE mode.
4Press the button to confirm the transmission. During the
transmission, the screen displays the following:
5Once the transmisson has correctly finished, the OK icon
will be displayed.
If the transmission has not finished, ERROR will be displayed.
Then go back to step 3.
6Press the EXIT button to cancel the transmission.
Option settings
This chapter describes the transmission function, backlight setting, and acoustic signal activation.
TRANSMISSION FUNCTION
You will be able to use the EGi 40100 Remote control to transmit data to other remote control of the same
model. You must first connect both remote controls using a connection wire. Please see “Appendix B” for
further details and follow these steps:
NOTE:
Before you start the transmission process, ensure that both remote cotrols are connected to the auxiliary
wire. Make sure that the batteries supply the necessary energy to run the remote control.

www.egiaudio.com
20
BACKLIGHT SETTING
Learn how to activate the backlight and set the light sensor sensitivity. To activate the backlight, follow
these steps:
1Keep the SETUP button pressed for 3 seconds to access to
the confirmation screen.
2Press each number (2, 4, 6, 8) only once in any order.
3Navigate through the menu options using the and
buttons until you find the BACKLIGHT mode.
4Press the button to confirm the process.
5Press a number button 1-6. “1” indicates a temporal value
of 10 seconds and “60” indicates a temporal value of 60
seconds. It sets the time you want to have the remote control
turned on, after pressing a button.
6Press the OK button to confirm.
