EGO HT2400E User manual
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
OPERATING MANUAL
56-VOLT
LITHIUM-ION
CORDLESS
HEDGE TRIMMER
MODEL NUMBER HT2400E
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E2
TABLE OF CONTENTS
Read All Instructions ......................................3
Safety Symbols ..........................................4
Safety Instructions.....................................5-12
Introduction ............................................13
Specications ..........................................13
Assembly ..............................................14
Packing List ............................................15
Description .........................................15-16
Operation ...........................................17-22
Maintenance ........................................23-25
Troubleshooting ......................................26-27
Warranty ...........................................28-29
Parts List ..............................................30
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 3
READ ALL INSTRUCTIONS!
This Hedge Trimmer has many features for making its use more pleasant and
enjoyable. Safety, performance, and dependability have been given top priority in the
design of this product making it easy to maintain and operate.
DANGER! People with electronic devices, such as pacemakers, should consult
their physician(s) before using this product. Operation of electrical equipment in close
proximity to a heart pacemaker could cause interference or failure of the pacemaker.
WARNING: To ensure safety and reliability, all repairs and replacements should
be performed by a qualied service technician.
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E4
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to following all instructions listed below
may result in electric shock, re, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
WARNING! The operation of any power tools can result in foreign objects being
thrown into your eyes, which can result in severe eye damage.
Before beginning power tool operation, always wear safety goggles
or safety glasses with side shields and a full face shield when
needed. We recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side shields. Always use
eye protection complying with Australian Standards AS1337.1 2010.
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 5
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read,
understand, and follow all instructions on the machine before attempting to assemble
and operate.
Safety Alert Indicates a potential personal injury hazard.
Read the Operator’s
Manual
To reduce the risk of injury, user must read
operator’s manual.
Do not expose to
rain
WARNING: Do not use in the rain or leave
outdoors while it is raining.
VVolt Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
WWatt Power
min Minutes Time
Alternating Current Type of current
Direct Current Type or a characteristic of current
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E6
n0No-Load Speed Rotational speed, at no load
... /min Per Minute Revolutions per minute
SPM Strokes Per Minute Stroke speed, at no load
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 7
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings and instructions. Fail to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodied plugs and
matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E8
PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the inuence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or energizing power tools that
have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench
or a key left attached to a rotating part of the power tool may result in personal
injury.
Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust devices can
reduce dust-related hazards.
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 9
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and more safely at the rate for
which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the power
tool accidentally.
Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tools
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control;
Use the power tool, accessories, tool bits, etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E10
BATTERY TOOL USE AND CARE
Recharge only with the charger specied by the manufacturer. A charger that
is suitable for one type of battery pack may create a risk of re when used with
another battery pack.
Use power tools only with specically designated battery packs. Use of any
other battery packs may create a risk of injury and re.
When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects that can
make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a re.
Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, ush with water. If liquid contact
eyes, additionally seek medical help. Liquid ejected from the battery may cause
irritation or burns.
SERVICE
Have your power tool serviced by a qualied repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
HEDGE TRIMMER SAFETY WARNINGS
Keep all parts of the body away from the cutter blade. Do not remove cut material
or hold material to be cut when blades are moving. Make sure the switch is off
when clearing jammed material.
A moment of inattention while operating the hedge trimmer may result in serious
personal injury.
Carry the hedge trimmer by the handle with the cutter blade stopped. When
transporting or storing the hedge trimmer always t the cutting device cover. Proper
handling of the hedge trimmer will reduce possible personal injury from the cutter
blades.
Hold the power tool by insulated gripping surfaces only, because the cutter blade may
contact hidden wiring. Cutter blades contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an electric shock.
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 11
Use both hands when operating the hedge trimmer. Using one hand could cause
loss of control and result in serious personal injury.
WARNING: Check the hedge for foreign objects before operating, e.g. wire
fences Only use the hedge trimmer with the guard properly assembled. The use of
the hedge trimmer without the proper guard may result in serious personal injury!
IMPORTANT SAFETY INSTRUCTIONS
Do not use the battery-operated hedge trimmer in rain.
Do not charge the battery pack in rain or in wet locations.
Use only with the battery packs and chargers listed below:
BATTERY CHARGER
BA2240E
BA1120E
CH5500E
CH2100E
Do not grasp the exposed cutting blades or cutting edges when picking up or holding
the hedge trimmer.
Do not use on a ladder, rooftop, tree, or other unstable support. Stable footing on a
solid surface enables better control of the hedge trimmer in unexpected situations.
Never allow children to operate the hedge trimmer.
Never remove or tamper with safety devices. Check their proper operation regularly.
Never do anything to interfere with the intended function of a safety device or to
reduce the protection provided by a safety device.
Never operate the hedge trimmer without proper guards, plates, or other safety
protective devices in place.
Check damaged parts before further use of the hedge trimmer. A guard or other
part that is damaged should be carefully checked to determine that it will operate
properly and perform its intended function. Check for alignment of moving parts,
binding of moving parts, breakage of parts, mounting, and any other condition that
may affect its operation. A guard or other part that is damaged should be properly
repaired or replaced by an authorized service center unless indicated elsewhere in
this manual.
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E12
Check the blade and motor mounting bolts at frequent intervals for proper tightness.
Also, visually inspect blade for damage (e.g., bent, cracked, and worn). Replace the
blade only with a blade from the original equipment manufacturer (OEM).
Replace the blade if it is bent or cracked. An unbalanced blade causes vibration that
could damage the motor drive unit or cause personal injury.
If the equipment should start to vibrate abnormally, stop the motor and check
immediately for the cause. Vibration is generally a warning of trouble.
The trimmer shall be used to cut stems less than (22mm) thick.
Trim only in daylight or in good articial light.
Remove or disconnect battery before servicing, cleaning, or removing material from
the hedge trimmer.
Do not wash with a hose; avoid getting water in motor and electrical connections.
When servicing use only identical replacement parts listed in this manual. Use of
parts which do not meet the original equipment specications may lead to improper
performance and compromised safety.
Follow instructions for lubricating and changing accessories.
Keep handles dry, clean and free from oil and grease.
Save these instructions. Refer to them frequently and use them to instruct others
who may use this tool. If you loan this tool to someone else, also loan these
instructions to them to prevent misuse of the product and possible injury.
SAVE THESE INSTRUCTIONS!
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 13
INTRODUCTION
Congratulations on your selection of a new generation of 56V Lithium-ion powered
hedge trimmer. It has been designed, engineered and manufactured to give you the
best possible dependability and performance.
Should you experience any problem you cannot easily remedy, please contact EGO
customer service center 1300 000 EGO (1300 000 346).
This manual contains important information on to the safe assembly, operation and
maintenance of your hedge trimmer. Read it carefully before using the hedge trimmer.
Keep this manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE
SPECIFICATIONS
Voltage 56V
No-Load Speed 1300/min
Cutting Length 61cm
Cutting capacity 22mm
Weight (Without battery pack, blade guard) 2.79 kg
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E14
ASSEMBLY
WARNING: If any parts are damaged or missing do not operate this product until
the parts are replaced. Use of this product with damaged or missing parts could result
in serious personal injury.
WARNING: Do not attempt to modify this product or create accessories not
recommended for use with this hedge trimmer. Any such alteration or modication is
misuse and could result in a hazardous condition leading to possible serious personal
injury.
WARNING: To prevent accidental starting that could cause serious personal
injury, always remove the battery pack from the tool when assembling parts.
UNPACKING
This product has been shipped completely assembled.
Carefully remove the product and any accessories from the box. Make sure that
all items listed in the packing list are included.
Inspect the tool carefully to make sure no breakage or damage occurred during
shipping.
Do not discard the packing material until you have carefully inspected and
satisfactorily operated the tool.
If any parts are damaged or missing, please return the product to the place of
purchase.
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 15
PACKING LIST
PART NAME QUANTITY
Hedge Trimmer 1
Blade Guard 1
Operating manual 1
DESCRIPTION
KNOW YOUR HEDGE TRIMMER (Fig. 1)
WARNING: The safe use of this product requires an understanding of the
information on the tool and in this operator’s manual, as well as knowledge of the
project you are attempting. Before use of this product, familiarize yourself with all
operating features and safety rules.
Hand Guard
Helps protect hand from cutting and deect chips or other debris away from the
operator’s hands.
1
Blade
Blade Guard
Hand Guard
Front Handle
Front
Switch
Lever
Rear Handle
Battery-Release
Button
Electric
Contacts
Latch
Ejection Mechanism
Rear Switch
Lever
Mounting Slot
Tip Protector
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E16
Front Handle
For easy control of the tool during cutting work.
Rear Handle
Ergonomic handle with overmold improves comfort and grip.
Front Switch Lever/Rear Switch Lever
The hedge trimmer can be started only if both of the switch levers (in rear and
front of the handle) are depressed simultaneously.
Blades
Steel blades for cutting hedges and shrubs.
Blade Guard
The blade guard keeps the operator from coming in contact with the sharp blades
when the tool is not in use. It also helps keep the blades from being nicked or
damaged when the tool is in storage.
Tip protector
Protecting the blade and protecting the special cutters from damage when cutting near
the ground or along walls.
Battery Release Button
Press to release the battery pack from the tool.
Latch
Locks the battery pack in place when installed on the tool.
Ejection Mechanism
Aids in removing the battery.
Mounting Slot
Guides the battery pack.
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 17
OPERATION
WARNING: Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufcient to inict serious injury.
WARNING: Always wear eye protection with side shields marked to comply with
AS1337.1 2010, along with hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious injuries.
WARNING: Do not use any attachments or accessories not recommended by the
manufacturer of this product. The use of attachments or accessories not recommended
can result in serious personal injury.
Before each use, inspect the entire product for damaged, missing, or loose parts, such
as screws, nuts, bolts, caps, etc. Tighten securely all fasteners and caps and do not
operate this product until all missing or damaged parts are replaced.
APPLICATION
You may use this product for the purposes listed below:
Trimming and the forming of hedges, shrubs, and bushes with a branch diameter
of less than 22mm
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E18
TO INSTALL/REMOVE BATTERY PACK (Fig. 2 & 3)
WARNING: Always remove the battery pack from the product when you are
assembling parts, making adjustments, cleaning, or when not in use. Removing the
battery pack will prevent accidental starting that could cause serious personal injury.
NOTE: Fully charge the battery pack before rst use.
TO INSTALL (Fig. 2)
Align the ribs of the battery pack
with the mounting slots in the hedge
trimmer’s battery port.
Press the battery pack down until it
snaps into position.
NOTE: Make sure that the latch on the
hedge trimmer snaps into place and the
battery pack is secured to the tool before
beginning operation.
TO REMOVE (Fig. 3)
WARNING: Always be aware for
the location of your feet, children, or pets
when pressing the battery-release button.
Serious injury could result if the battery
pack falls. NEVER remove the battery
pack at a high location.
Press the battery-release button,
the battery pack will disengage
from the latch.
Grasp the battery pack and remove
it from the hedge trimmer.
2
Press to Release
3
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 19
HOLDING THE HEDGE TRIMMER
The unit has both a front and rear handle. With the blade directed away from you, hold
the unit by both handles.
The switch lever in the front handle
can be activated on any of the three
sides, giving you many choices for a
comfortable grip when performing cutting
operations (Fig. 4, 5 & 6).
WARNING: Always keep both
hands on the hedge trimmer handles.
Never hold shrubs with one hand and
operate the hedge trimmer with the other.
Failure to heed this warning may result in
serious injury.
STARTING/STOPPING
THE HEDGE TRIMMER
Before starting the hedge trimmer:
Make sure you have a secure and
balance footing.
Stand upright and hold the hedge
trimmer in a relaxed position.
Remove the blade guard.
Make sure the cutting blade is not
touching the ground or any other
objects.
Hold the unit with both hands: one
hand on the rear handle and one
hand on the front handle.
4
5
6
56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E20
TO START THE HEDGE TRIMMER
Your hedge trimmer is equipped with two switch levers. Both switch levers need to be
pressed for the hedge trimmer to start. Depress and hold the switch lever in the front
handle and press the switch lever in the rear handle to start the hedge trimmer.
TO STOP THE HEDGE TRIMMER
Move hedge trimmer away from cutting area, release one of the switch levers to stop
the hedge trimmer.
WARNING: Always remove the battery pack from the hedge trimmer during
work breaks and after nishing work.
USING THE HEDGE TRIMMER
WARNING: If the blade jams on any electrical cord or line, DO NOT TOUCH THE
BLADE! IT CAN BECOME ELECTRICALLY LIVE AND VERY DANGEROUS. Continue to hold
the hedge trimmer by the insulated rear handle or lay it down and away from you in
a safe manner. Disconnect the electrical service to the damaged line or cord before
attempting to free the blade from the line or cord. Failure to heed this warning will
result in serious personal injury or possible death.
WARNING: If any parts are missing, damaged or broken, do not operate your
trimmer until they have been replaced. Failure to do so could result in possibly serious
personal injury.
WARNING: To prevent serious personal injury, always use both the front handle
and the rear handle to hold the hedge trimmer during operation.
WARNING: To prevent serious personal injury, keep hands away from blades.
Do not attempt to remove cut material or hold material to be cut when the blades
are moving. Make sure that the blades have totally stopped and the battery pack is
removed before clearing jammed material from blades. Do not grasp the exposed
cutting blades or cutting edges when picking up or holding the unit.
WARNING: Clear the area to be cut before each use. Remove all objects, such
as cords, lights, wire, or string which can become entangled in the cutting blade and
create a risk of serious personal injury.
Other manuals for HT2400E
3
Table of contents
Other EGO Trimmer manuals
