Assembly Instruction
EHC HT10
Page 1
Hauptsitz
Schweden Benelux Deutschland England
EHC Teknik ab EHC Teknik bvba EHC Teknik GmbH EHC Teknik Ltd
Ögärdesvägen 8a Karel Soetelaan 37 Eiserfelder Str.316 10 Hollow Rise
S‐433 30 Partille B-2150 Borsbeek D-57080 Siegen High Wycombe
Tel.: [phone] Tel.: [phone] Tel.: [phone] Bucks HP13 5NU
Fax.:[phone] Fax .:[phone] Fax .:[phone] Tel.: [phone]
E‐Mail, [email protected] E‐Mail, [email protected] E‐Mail, [email protected] Fax .:[phone]
www.ehcteknik.com www.ehcteknik.be www.ehcteknik.de E‐Mail. [email protected]
www.ehcteknik.nl www.ehcteknik.co.uk
www.ehcteknik.fr
Page 1

www.ehcteknik.com
Description EHC HT10 filter
EHC HT filter for diesel engines
The HT filter is rust protected by zinc. Coating
The unit can be mounted horizontal or vertically.
And condensate is drained through the hose.
1.
2
3
Page 2
Mounting:
1. The unit is mounted using the two
clamping rings (1), to the intended
machine.
2. The lowest point, determines the hole
for the outlet of the condensate (2)
3. Companion flange (3) appropriate to the
size of the vehicle.
For the measurements of the filter unit and
connections, see technical data
2
Important! Mount the unit with
condensate hose (2) as the
lowest point.
Important! Mount the device
vibration‐free
Page 2

www.ehcteknik.com
Connection Instructions:
1. Determine the size of the exhaust tail
pipe O/D.
2. Using one of the blank flanges provided,
weld a connecting pipe to the center of
the flange. The same size as your exhaust.
Open up the centre of the flange to th
e
same size as the pipe.
3. Using the bolts and gasket supplied, Fit
the flange to the inlet of the filter.
4. Make up a tail pipe using the second
flange ensuring that the outlet hole is n
o
smaller than the I/D of the machine tailpipe.
Warning: Do not use the second flange to blank
off the outlet if no tailpipe is required
Filter replacemen
t
1.
Page 3
1. Loosen eccentric locks (1) on the filte
r
housing.
2. Remove the filter container (2).
3. Remove the filter element (3) from the
filter container (2) and insert the ne
w
filter cartridge.
4. Insert the filter canister with silicon
gasket (4) first.
The used filter can be dispsed of as
combustible waste.
Warning:! Filter may be hot at filter
change.
2.
3
4.
Page 3

www.ehcteknik.com
Electrical pressure switch 12/24
V
The electrical pressure switch has a buzzer that
sounds and a lamp that lights up when filte
r
change is necessary. Pressure switch (4) is
screwed into the existing socket on the unit as
image.
Electrical connection + linked to the ignition
switch, and ‐to the battery.
Mount the coupling device according to IP5
4
¹.
1. Delay relay, ~2min.
2. Buzzer
3. Lamp
4 P it h
4
2
3
1Important! Beware of not breaking
the moisture blocking seal-
ing on the guard at the
Important! Mount the delay relay
protected in the cabin IP54)
5
Page 4
4. Pressure switch
5. Fuse, 2A
Mechanical pressure guard (Optional
)
The mechanical pressure guard (1) vents when
filter replacement is necessary. Replace the
membrane of the pressure guard when the filte
r
cartridge replacement is made.
[1] IP54=Dust cover and withstand water spray from all angles
1
Page 4

www.ehcteknik.com
Technical data:
EHC HT Filter separates >95% (>0,4μ) of the
particles in the exhaust.
Maximum temperature, exhaust: 250°C
K‐Value recommended: 1.3
Weight: 23kg
Life expectancy depends on engine size, engine
type, the engine used and engine condition.
EHC HT Filter meet the exhaust requirements:
• TÜV Fahrzeug GmbH, S‐129.99.001.00
• TRGS 554 (D)
• VERT Filter List: B135/10.03 (CH)
• COSHH (GB)
2
3
4
Page 5
1
2
Page 5
