Eiki LC-XWP2000 User manual

Key Features
▼
Extremely Short Throw Lens: as close as a 1:1 Throw-to-Width Ratio.
▼
2000 ANSI Lumens, 85% uniformity, and 400:1 contrast ratio.
▼
Weighs less than 8 lbs! Compact, low-profile design!
▼
3panel LCD imaging delivers a rich, color saturated picture.
▼
XGA resolution. SXGA~VGA compatible.
▼
Smart data compression/expansion, and video scaling.
▼
Two HD15 computer inputs, plus one HD15 computer monitor output.
▼
Preset image offset. Automatic vertical digital keystone correction.
▼
Auto Ceiling adjustment. Auto Brightness adjustment.
▼
Accepts Composite, S, and Component Video in all major standards.
▼
Displays both 4:3 and 16:9 formats. Supports most HDTV resolutions.
▼
Wireless remote control w/Laser.4X digital zoom. Auto input search.
▼
3Year* Projector Warranty!
Projectors... and more!
2345
Ultrawide XGA LCD Projector
2345
An extremely short throw lens... as close as a
1:1 Throw-to-Width Ratio... makes it perfect for
interactive applications.
LC-XWP2000
2000 ANSI Lumens
LC-XWP2000
2000 ANSI Lumens

Specifications subject to change without notice.
©2007 EIKI International, Inc. Printed in the USA. 09/01/07
Brightness......................................... upto2000ANSILumens
IlluminationUniformity............................................... 85%
SizeofColorPalette .......................................... 16.7Million
ContrastRatio ........................................ 400:1(FullON/OFF)
ProjectionLamp............................................ 205WattNSH
Estimated Lamp Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . up to 2000 Hours of Use
Imaging System . . . . . . . . . . . . . . . . . . . . . . 0.63” PolySilicon active matrix TFT Panels x 3
Screen Pixels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1024 x 768 in stripe configuration
TotalPixels.................................... 2,359,296((1024x768)x3)
LensType......................................... ManualZoomandFocus
Lens Specs . . . . . . . . . . . . . . . . . Speed: f:1.6~1.88; FL: 0.51~0.61 in. (13.0~15.62 mm)
Lens Ratios . . . . . . . . . . . . . . . . . . . . . . . Zoom Max:Min: 1.2:1; Throw:Width: 1.0~1.2:1
Image Diagonal: Normal Projection . . . . . . . . . . . . . . . . . . . . 40~300 in. (101.6~762 cm)
Image Width: Normal Projection . . . . . . . . . . . . . . . . . . . . . . . . . 2.7~20 ft. (0.81~6.1 m)
Throw Distance (tele~wide) . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6~19.8 ft. (0.79~6.04 m)
FrontElevation.............................................. Upto14°Up
Anti Keystone . . . . . . . . . . . . . . . . . . . . . . . . . Fixed Image Offset, Ratio (Top:Bottom) 6.5:1
Vertical Keystone Correction . . . . . . . . . . . . . . . . . . . . . . . . . Digital: up to 30° up or down
Scanning Frequency . . . . . . . . . . . . . . . . . . . . . Auto: H Sync. 15-69kHz; V Sync. 43-85Hz
DotClock.................................................... 110MHz
Image Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Normal, Reversed, Inverted
Remote Projector Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Wireless (Infra Red) x 1
RS-232C ControlPort..................................... MiniDIN8Pinx1
Computer Native Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1024 x 768 (XGA)
Computer: Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SXGA, XGA, SVGA, VGA
Computer: Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1280 x 1024 through 640 x 480
Computer: Higher Resolutions . . . . . . . . . . . . . . . . . Displayed panned or Smart Compressed
Computer: Lower Resolutions . . . . . . . . . . . . . . . . . . . Displayed normal or Smart Expanded
Video Compatibility ..................... NTSC/PAL/SECAM/NTSC 4.43/PAL-M&N
Video HD Compatibility . . . . . . . . . . . . . . . . . . . . . . 480i/p, 575i/p, 720p, 1035i, 1080i
Formats Supported . . . . . . . . . . . . . . . . . . . . . . . . . . . Normal 4:3 and Wide Screen 16:9
Video: Image Sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Video Scaling Technology
Signal Inputs
Computer 1 ................................................ HD15 x 1
Computer 2/Component Video (w/optional adapter): . . . . . . . . . . . . . . . . . . . HD15 x 1
S-Video...................................................S-Videox1
Composite Video .............................................. RCA x 1
Audio: ................................................ MiniStereo x 1
Outputs
ComputerMonitor:............................................HD15x1
Audio(Stereo)–Line:...................................... MiniStereox1
SoundSystem–Amplifier:.................................... 2Watts(Mono)
Sound System – Speaker: . . . . . . . . . . . . . . . . . . . . . . . . 1.6 x 1.2 in. (4x3 cm) x 1(Ellipse)
FanNoise..............................................aslowas41dBA
Cabinet Size (HxWxD) . . . . . . . . . . . . . . . . . . 3.8 x 12.3 x 10.6 in. (96 x 310 x 270 mm)
Including lens and feet . . . . . . . . . . . . . . . 5.3 x 12.3 x 13.2 in. (135 x 311 x 334 mm)
Weight .................................................. 7.7 lb (3.5 kg)
Packaged Size (HxWxD) ............... 9.9 x 17.7 x 13.8 in ( 250 x 450 x 350 mm)
PackagedWeight.......................................... 13.7lb(6.2kg)
Power Requirements................................. 100-240VAC,50/60Hz
Power Consumption ........................................ Up to 250 Watts
Heat............................................. upto853BTU(215KC)
PowerCord.................................... 6’(1.8M)Type3,Detachable
SafetyCompliance............................................ UL,cUL,IEC
SecurityFacilities.................................... Kensington
®Security Slot
OperatingTemperature.................................... 41~95°F(5~35°C)
User Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Clean Air Filter, Replace Lamp
Warranty: (to the original end-use customer)
Projector: . . . . . . . . . . . . . . . . 3 Years/6000 Hour Use*(Parts & Labor to Correct Defects)
Lamp ................................ 90 Days (Failed Lamp Replaced Pro-Rata)
*Whichever occurs first
SPECIFICATIONS: LC-XWP2000
Eiki International, Inc.
30251 Esperanza, Rancho Santa Margarita, CA 92688-2130
Tel: [phone]; Fax: [phone], E-mail: [email protected]
In Canada, 310 First St.- Unit 2, P.O. Box 156, Midland, ON L4R 4K8
Phone: [phone], Fax: [phone] E-mail: [email protected]
http://www.eiki.com
Talk to your EIKI Dealer... the"pro" in projectors.
Projectors... and more!
2345
INCLUDED ACCESSORIES:
Quick Start Guide. Owner’s Manual on CD-ROM. AC Power Cord.
Computer Input Cable (HD15~HD15). S-Video Input Cable
(S-Video~S-Video) Composite Video Input Cable (RCA~RCA) Audio
Input Cable (2RCA~Mini Stereo) USB Mouse Cable (USB-A~USB-B)
Wireless Remote Control w/Laser Pointer & Batteries (AAA x 2).
OPTIONAL ACCESSORIES:
Replacement Lamp. Carry Bag. Component Video Input Cable
(HD15~3-RCA). RS-232C Input Cable (DB9~Mini DIN-8).
Ceiling Mount. Ceiling Post and Plate. EZ-250 Local Control.
NPC-1 Network Control.
Noteworthy Features:
1. An extremely short throw lens... as close as a 1:1 Throw-to-Width
Ratio... makes it perfect for interactive applications.
2. A 1.2X manual zoom permits image size adjustment.
3. Automatic vertical digital keystone correction.
4. Automatic ceiling mounting image inversion.
5. Automatic brightness adjustment prolongs lamp life.
5.3"
12.3" 13.2"
Input Panel
LC-XWP2000 2000 ANSI lumens
LC-XWP2000 2000 ANSI lumens
Wireless Remote Control
Lamp Contains
Mercury. Do not
put in trash.
Dispose-of-as Hazardous
Waste, according to the
laws in your jurisdiction.
