EINHELL JS SERIES User manual

JS SERIES SAWS
OPERATIONS AND MAINTENANCE MANUAL
SAVE THIS MANUAL AND MAKE AVAILABLE
TO ALL USERS OF THIS TOOL!
WARNING
Read and understand
operator's manual before
using this machine.
Failure to follow operating
instructions could result
in injury or damage to
equipment.

Table of Contents
Sections:
1.0 Instructions for useof manual sections......................................................................................3
2.0 Specifications....................................................................................................................... 3
3.0 Applications...........................................................................................................................4
4.0 Rules for safer operation........................................................................................................ 5
5.0 Pre-operation checklist.......................................................................................................... 9
6.0 Operation.............................................................................................................................17
7.0 Parts list and accessories ......................................................................................................19
8.0 Maintenanceandinspection...................................................................................................29
9.0 Warranty and service............................................................................................................33
List of Figures:
Figure1 -Warningsticker (decal) summary.......................................................................................... 5
Figure3-Warning label - read and understand manual..........................................................................9
Figure 4 - JSSERIES SAWS assembly...............................................................................................10
Figure 5-JS SERIES SAWS bottom view ...........................................................................................10
Figure6 -Warning label - SMI concrete saw safety ..............................................................................11
Figure7-Warning label - engine exhaust contains carbon monoxidegas ...............................................11
Figure 8-Max rpm label - maximum blade speed................................................................................12
Figure9 -Warning label - useonly diamond blades..............................................................................12
Figure 10-Warning label - inspect blades before use...........................................................................13
Figure 11 - Pointer wheel adjustment..................................................................................................13
Figure 12-Alignment of blade and thepointer wheels - JS bottom view.................................................14
Figure13- Shaft collar and bladedepth adjustment..............................................................................15
Figure 14-Warning label -do not operate with guard removed..............................................................16
Figure15-Warning label - do not operate with guard up........................................................................16
Figure16 -Warning label -wear ear and eye protection.........................................................................16
Figure 17-JS SERIES SAWS in cutting operation...............................................................................18
Figure 18-JS SERIES SAWS top front right view................................................................................21
Figure 19-JS SERIES SAWS top rear left view...................................................................................22
Figure 20-JS SERIES SAWS top view...............................................................................................23
Figure21 -JS SERIES SAWS with flangedetail...................................................................................24
Figure 22 - JS SERIES SAWS with belt and flangedetails ....................................................................25
Figure23-JS SERIES SAWS rear viewwith switch detail.....................................................................26
Figure24- Jack assembly exploded view............................................................................................27
Figure 25-Warning sticker (decal) locations........................................................................................28
Figure26-Warning label - inspect blades before use............................................................................29
Figure 27-JS in blade change position with engine off.........................................................................30
Figure28- Maxrpm label - maximum bladespeed...............................................................................30
Figure29 -Warning label - useonly diamond blades............................................................................31
Figure30 - Bladenut facemust beflat against outer flange...................................................................31
Figure31 - Blade, spacers, and flanges set up.....................................................................................31
Figure 32 - Bladeguard caster wheel adjustment.................................................................................32
List of Tables:
Table 1 -Approximateblade depth chart in inches............................................................................... 14
Table 2 - Handleturns and affect on approximate blade depth ininches..................................................14
Table 3 - JS SERIES SAWS parts list................................................................................................19
Table 4-JS SERIES SAWS parts list................................................................................................20
Table 5-Jack assembly parts list.......................................................................................................27
Table 6- Dry cut diamond blade list....................................................................................................28

1.0 Instructions for use of manual sections
Read this entire operations and maintenance manual before using your new tool. Pay close attention to the
Rules for safer operation, Dangers, Warnings and Cautions.
The purpose of safety symbols and explanations are to attract your attention to possible hazards and how to
avoid them. The safety symbols and explanations do not by themselves eliminate any danger. The
instructionsor warnings they givearenot substitutes for proper accident preventionmeasures.
DANGER: Indicates an imminently hazardous situation that if not avoided, will result in death or serious
injury. This signal wordislimited to themost extreme situations.
WARNING
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death or serious
injury.
CAUTION
CAUTION: Indicates a potentially hazardous situation that, if not avoided may result inminor or moderate
injury. Itmay alsobeused to alert against unsafepractices that may cause property damage.
2.0 Specifications
JS SERIES SAWS engine:
JS SERIES SAWS engine:
Fuel type:
Oiltype&capacity:
JSSERIESSAWSWeight:
JS SERIES SAWS weight:
Bladespeed:
Bladediameter sizes:
Bladedepth cut:
Bladetype:
Overall size:
Bladenut wrenchsize:
Shaft diameter:
Flanged bearing grease:
Assembly part numbers:
Recommended dust
collector system:
Vacuum hose size:
Operating &
maintenancemanual
revisionnumber:
Honda 13 HPGas Powered
5HP 230v 1P, 5HP 208/480v 3P
Unleaded gasoline, 86 octane or higher
SAE10W-30, 1.16qt
160 pounds Gas
180 pounds Electric
5850 rpm maximum
8" and 10"
3" with 10" blade, 2" with 8" blade
Dry diamond, 1" arbor hole, & single drive pinhole
28.3" WX 35.5" LX 37.5" H
1-1/2"
1"
ALVANIA®Grease3 every 100hours
JS SERIES SAWS 13 hp GAS SX77130
230v 1P Electric SX77100
208/480v 3P Electric SX77104
U.S. SAWS Mega-Vac Electric SX24550
4"
JSSeriesRevised1/1/2011
U.S.SAWSMega-Vac Gas SX24555
SX24555

3.0 Applications
Typical applications for the U.S. SAWS JSSERIES SAWS would bejoint cleanout and trenchcutting. The
saw uses dry cut diamond blades in either 8" diameters or 10" diameters with an allowablemaximum depth
cut of 3". The blade rotates in an upward direction allowing for easy dust collection when connected to an
appropriate vacuum system. The machine should always be operated with a dust collection system and in a
well-ventilated area due to carbonmonoxide fumes emitted from the gasoline engine.

4.0 Rules for safer operation
WARNING
Read and understand
operator's manual before
using this machine.
Failure to follow operating
Instructions could result
in injury or damage to
equipment.
WARNING
Use only diamond blades (steel
centered diamond cutting-off
wheels) with this machine. RPM
rating on blade mustexceed
machine max rpm rating. The use
of any other bladecould result in
death or serious injury.
2001 Hazard Communication Systems. LLC
800.7^-0241 No. Heiei-TUWrPL ©2002 Hsard Communication Syatema, LLC
800-748-0241 Reorder No. H6014-369W HPL
5850 MAX. RPM
C1 hazard Communication Sywems. LLC MO-746-0241
WARNING
Avoid injury.
Do NOToperate with
guard removed.
Replaceguard before
operating machine.
WARNING
To avoid injury:
Always inspect saw
blades before use.
Replaceallcrackedor
damagedblades.
WARNING
Rotating blade
hazard.
Do NOT operate with
guard up.
Keep hands and feet
away.
WARNING
Engine exhaust
contains poisonous
carbon monoxide gas.
Breathing it could cause
death.
Operate machine in well
ventilated area.
SS20C2HCS.LLC 800-74W>!41 BT No 11 50-557WHPL O2002 Hazonl Cor m Systcml, LLC
8QO-74g-Oi41
N
WARNING

4.1 KNOW YOUR EQUIPMENT.
Do not operate this machine unless you have read the operations and maintenance manual
carefully. Read any additional instructions included from other manufacturers and organizations
such as Honda® and the Masonry and Concrete Saw Manufacturers Institute. Learn the
applications and limitations as well as thespecificpotential hazards related to this tool.
4.2 RECEIVE PROPER TRAINING.
Do not operate this machine unless you have received operational and maintenance training from a
U.S. SAWS representative or from anauthorized distributor for U.S. SAWS.
4.3 PROTECT YOUR FEET.
Observe all applicable local, state and federal safety regulations. Wear OSHA approved foot
protection.
4.4 PROTECT YOUR EYES.
Observe all applicable local, state and federal safety regulations. Wear OSHA approved safety
glasses.
4.5 PROTECT YOUR LUNGS.
Breathable silica may be generated by use of this product. Silica can cause severe and permanent
lung damage, cancer, andother seriousdiseases. Do not breaththe dust. Donotrely onyoursight or
smell to determineif the dust is in theair. Silica may be in the air without a visible dust cloud. If air
monitoring equipment for silica is not provided by your employer at your worksite, you MUST wear
appropriate respiratory protection when using or servicing the machine. Consult your employer
and OSHA regarding the appropriate respiratory protection.

4.6 PROTECT YOUR HEARING.
Observe all applicable local, state and federal safety regulations. Wear OSHA approved hearing
protection.
4.7 DRESS PROPERLY.
Do not wear loose clothing or jewelry that can be caught in moving parts. Wear protective hair
covering to contain long hair. Keep hair away from motor air vent. Rubber gloves and non-skid
footwear are recommended when workingoutdoors.
4.8 AVOID A DANGEROUS ENVIRONMENT.
Do not expose machine to rain. Do not use machine in wet conditions. Keep work area well lit.
When working at an elevated location, pay attentionto articles and persons below.
4.9 BEWARE OF HIDDEN DANGERS IN CONCRETE.
Rebar or utility lines may be buried in concrete. Disconnect the power to any utility lines. If these
items are to be missed, clearly mark the area. If these items are to be cut, check the blade
manufacturer's guidelines onmaterial to be cut.
4.10 AVOID ANY AREAS OR ACTIONS THAT EXPOSE YOU TO CARBON MONOXIDE.
Exhaust gas from gasoline engines contains dangerous carbon monoxide. Breathing it can cause
unconsciousness and even kill you. Always operate gasoline engine machines in a well-ventilated
area. Do not operate in areas where exhaust fumes could accumulate without wearing appropriate
respiratory protection. Consult your employer and OSHA regarding use of appropriate respirator for
dangerouscarbonmonoxidegases.
4.11 KEEP WORK AREA CLEAN. DO NOT RUN OVER ANYTHING.
Loose objects could be thrown from crack. Make sure area to be cut is clear from people and any
looseobjects, nuts, bolts, etc. Never run over any looseobjects.
4.12 KEEP CHILDREN AND VISITORS AWAY.
Do not allow anyone to stand inline with the blade path. Do not let children or visitors contact
machine or extension cord. Keep children and visitors awayfrom thework area.
4.13 AVOID FLAMMABLE LIQUIDS OR GASES.
Engines and diamond blades produce heat and sparks during operation. Never use machines in
dangerous sites containing flammable, combustible or explosive materials such as lacquer, paint,
benzene, thinner, gasoline, gases, and adhesiveagents.
4.14 AVOID CONTACT WITH HOT MUFFLER.
Themuffler becomes hot during operation and remains hot after stopping theengine. Do not touch
the muffler while it is hot. Let the engine cool before storing indoors. Do not place flammable
objectsclosetothe engine.
4.15 AVOID CONTACT WITH HOT BLADE AND BLADE GUARD.
The blade and blade guard become hot during operation and remain hot after stopping the engine.
Do not touch thebladeand bladeguard without proper hand protection.
4.16 KEEP FIRM GRIP ON MACHINE.
During normal operation as instructed in Section 6.0, keep a firm hold on the handle grips and
maintain control of themachineuntil the blade completely stops.
4.17 SHUT OFF ENGINE.
When not in use, before servicing and when changing accessories shut off engine. Release the
deadman lever switch and move the on/off switch to the OFF position. Move the fuel valve lever to
theOFFposition.
4.18 REFUEL WITH CARE.
Gasoline is extremely flammable. Gasoline vapor can explode. Refuel outdoors, in a well ventilated
area, with the engine in the OFF position. Never smoke near gasoline and keep other flames and
sparks away. Always store gasoline in an approved container. If any gasoline is spilled, make sure
thearea is dry beforestartingtheengine.

4.19 CHECK BLADE AND MACHINE ROTATION DIRECTION.
Never operate a blade in the wrong rotation direction. Check the machine rotation direction and
bladedirection when mounting a blade.
4.20 CHECK BLADE MAXIMUM ALLOWABLE SPEED.
Check the maximum operating speed of the machine and blade. Never use a blade rated less than
themachine'smaximum speed rating.
4.21 CHECK BLADE FOR CRACKS, DAMAGE, AND MISALIGNMENT.
Never usea cracked,damaged,ormisaligned blade. Aftermountingblade, rotatebyhandtocheckfor
proper alignment.
4.22 CHECK DIAMOND BLADE FOR WARNINGS.
Many diamond blades contain a chemical known to the state of California to cause cancer and/or
birth defectsor other reproductiveharm.
4.23 DO NOT FORCE WRONG SIZE OR TYPE BLADE ONTO MACHINE.
Do not force a blade onto the machine shaft or alter the size of the arbor-mounting hole. Be certain
that the drive pin is in place through the blade when tightening the blade nut. Never add a drive pin
hole or modify ablade.
4.24 USE CORRECT SAW AND ACCESORIES.
Do not force a small saw to do the job of a heavy-duty saw. Do not use the saw for improper
applications. Never cut material for which the blade was not designed. Check blade manufacturer's
guidelines onmaterial tobe cut.
4.25 STORE IDLE EQUIPMENT.
Themachine, blades and tools should bestored in a dry and secure location when not in use. Keep
equipment out of reach of children.
4.26 DO NOT FORCE SAW.
Thesaw will dothejob better and safer at the ratefor whichit was designed.
4.27 OBTAIN MATERIAL SAFETY DATA SHEET (MSDS) FOR ALL WORK SURFACE MATERIALS.
This includes primers, all coatings, adhesives, tile and crack filling materials, etc. Do not attempt to
cut, clean out or remove material without MSDS information. Consult MSDS sheet for hazards
information. Beaware that somematerials are explosiveas a dust.
4.28 DO NOT OVERREACH.
Keep proper footing and balanceat all times.
4.29 MAINTAIN MACHINE WITH CARE.
Keep machine clean and follow maintenance procedures for better and safer performance. Keep
handles dry, clean, and free from oil and grease. Follow instructions for lubricating and changing
accessories.
4.30 REMOVE AJUSTING TOOLS.
Form a habit of checking to see that tools such as adjusting wrenches are removed from the
machine and properlystored beforestarting theengine.
4.31 STAY ALERT.
Watch what you are doing. Use common sense. Do not operate machine when you are tired or
fatigued.
4.32 DO NOT USE DRUGS, ALCOHOL, MEDICATION.
Do not operatemachinewhileunder the influenceof drugs, alcohol, or anymedication.
4.33 KEEP THE RIGHT PARTS IN THE RIGHT POSITIONS.
Do not operatemachine withpartsmissing or improperly mounted.

4.34 CHECK DAMAGED PARTS.
Verify all machine guards are in good condition and will function properly before using the machine.
Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting, and
any other conditions that may affect machine operation. A guard, power switch or other part that is
damaged should be properly repaired or replaced by an authorized service center unless indicated
elsewhere in this instruction manual. Do not operate machine if deadman lever or engine on/off
switch does not function properly.
4.35 SECURELY MOUNT ACCESSORIES AND BLADES TO THE MACHINE.
Extra caremust betaken when usingsaws on an elevated location toprevent injurytosomeone on a
lower level in the event the tool or accessory should drop. Do not operatewithout fall protection for
operator and debris protection for public.
4.36 NEVER TOUCH THE MOVING PARTS.
Never touchmoving parts suchas blades, belts and others.
4.37 STOP OPERATION IMMEDIATELY IF ANY ABNORMALITY IS DETECTED.
Stop using machine immediately if any abnormalities are observed during operation. Examples of
abnormalities include unusual noise and vibration.
4.38 WHEN REPLACING A PART, USE THE SAME TYPE AND QUALITY.
When replacing a component part with a new one, use only the same type and quality of new part.
Never attempt to repair a machine if you are unfamiliar with proper procedures and techniques
required.
4.39 DO NOT MODIFY MACHINE.
Do not modify machine from its original design without written permission from the manufacturer.
Non-authorized modifications could lead to seriousinjury ordeath and voidwarranty.
4.40 NEVER DISABLE THE DEADMAN LEVER.
Do not modify, disable, or attempt to permanently engage the deadman lever. Do not operate a
machine if deadmanlever is not functioning. This couldlead to serious injury or death.
4.41 SAVE THESE INSTRUCTIONS.
Refer to this operations and maintenance manual as well as any additional instructions included
from other manufacturers and organizations such as Honda® and the Masonry and Concrete Saw
Manufacturers Institute®. Never permitanyoneto operatethe machine without proper instructions.
5.0 Pre-operation checklist
WARNING
Read and understand
operator's manual before
using this machine.
Failure to follow operating
instructions could result
in injury or damage to
equipment.
2001 Ha»'dCommunfctttofi Syacmt. U.C
aop.74B.Oi41 No. H616I.TUWHPI
Figure 3 - Warning label - read and understandmanual
5.1 Start by reading the entire Honda Engines Owner's Manual, Rx for Diamond Blade Safety, and Rx
for Concrete Saws by the Masonry and Concrete Saw Manufacturers Institute. Then, read the
entire JS operations and maintenance manual. Get familiar with the machine's parts. See Figure 1
throughFigure32.

WARNING
TO PREVENT SERIOUS INJURY
DO NOT OPERATE SAW
WITHOUTPROPERTRAINING
AND. UNDERSTANDING
OFTHE OWNERS MANUAL
WHEN OPERATING THIS MACHINE
ALWAYSWEARSAFETYAPPROVED
HEARING
PROTECTION
EYE OR FACE
PROTECTION
HEAD
PROTECTION
WARNING
WARNING: Improperly maintainingthe JS including the Honda engine or failing to correct a problem before
operation could cause a malfunction resulting in a serious injury. Always perform a pre-operation inspection
before each operation and correct any problem. See Honda Engines Owner's Manual.
5.2 Check thecondition of the Honda engine. Seethesection titled "Before operation - is your
engine ready to go?" in the Honda Engines Owner's Manual.
WARNING
WARNING: Exhaust gas from gasoline engines contains dangerous carbon monoxide. Breathing it can
cause unconsciousness and even kill you. Always operate gasoline engine machines in a well-ventilated
area. Do not operate in areas where exhaust fumes could accumulate without wearing appropriate
respiratory protection. Consult your employer and OSHA regarding use of appropriate respirator for
dangerouscarbonmonoxidegases. See Figure 7.
WARNING
Engine exhaust
contains poisonous
carbon monoxide gas.
Breathing it could cause
death.
Operate machine in well
ventilated area.
©2002 Hazard Communication Sy«t*m«, LLC Na. 4006.ES6WHPL
Figure 7 - Warning label - engineexhaust contains carbonmonoxide gas
11
RESPERATOR

5.3 Observethecondition of your work environment. Walk over area work area and look for hazards.
Makesure thework environment is safe andmeets allsafe-working conditionsdiscussed in section
4, Rules for safer operation.
5.4 Obtain MATERIAL SAFETY DATA SHEET (MSDS) for all work surface materials. This includes
primers,all coatings, adhesives, tile and crackfillingmaterials,etc. Do not attempt tocut, clean out,
or removematerial without MSDS information. Consult MSDS sheet for healthhazards information.
Be aware that somematerials areexplosive as a dust
WARNING
WARNING: The JS SERIES SAWS maximum blade operating speed is 5850 rpm as labeled on theblade
guard. Use only dry cut diamond blades rated higher than 5850 rpm safe operating speed. Do not use a
bladerated for lessthan 5850 rpm. Do notusea bladethat isnota drycut diamond blade. Using anon dry cut
diamond bladeor a bladerated below5850rpm could result in severe bladefailure, personal injury or death.
See Figure 8 and Figure 9. Never cut material for which the blade was not designed. Check blade
manufacturer's guidelines on material to be cut. Never operate a blade in the wrong rotation direction. Verify
blade direction when changing blades. The JS is designed to cut in a straight line. Never attempt to cut any
pattern or follow any joint that is not a straight line.
5850 MAX. RPM
€2001 Hazard Communication System*. LLC 30<i-748-0241
5.5 Figure 8 - Max rpm label - maximum blade speed
Choose the proper dry cut diamond blade for the application, speed and material to be cut. See
Figure9.
WARNING
Use only diamond blades (steel
centered diamond cutting-off
wheels) with this machine. RPM
rating on blade must exceed
machine max rpm rating. The use
of any other bladecould result in
death or serious injury.
©2002 Hazard Communication Systems, LLC
800*740-0241 Reorder No. H60-U-369WHPL
5.6
5.7
Figure 9 - Warning label - use only diamond blades
Clearly mark all intended cut areas with straight paint or chalk lines.
Verify that the deadman lever is disengaged or released and the Honda engine switch and fuel
valvelever are in theOFFposition. Make sureblade is completely stopped.
CAUTION
CAUTION: Running the JS generates heat in the engine, blade and blade guard. Do not touch these
components without wearing proper heat protecting work gloves.
12

5.8
5.9
Remove bolt in the blade guard holding bracket. Hold the blade guard firmly and raise guard up into
theholding bracket. Reinsert bolt inthe blade guard holding bracket and tighten nut.
Remove both blade change wrenches from the JS handle. Install dry cut diamond blade. See
section 8.1 for detailed instructions on removing and installing blades. Inspect diamond blades for
damage at least twice daily and before each use. Damaged diamond blades are hazardous and
should never beused on a JS. SeeFigure 10.
WARNING
To avoid injury:
Always inspect saw
blades before use.
Replace all cracked
or damaged blades.
B2001 HCS, LLC No. H6110-M1WVPK
5.10
5.11
5.12
5.13
Figure 10 - Warning label - inspect blades before use
Replace thewrenches in the holding bracket on thehandle. Tighten the wrench-clamping knob.
Check thebelt tension each day beforestartingwork. Check after thefirst hour of operation if theJS
or belt is new. See section 8.3for detailed instructions onchecking and adjustingthe belt tension.
Move the front and rear pointer arms down towards the ground. Turn the height adjustment handle
clockwise until the blade touches the ground. Now turn the adjustment handle counter-clockwise
onecomplete360° turn. This will raisethe blade slightly off the ground.
Using themarked chalk line or any straight line on the ground, align the blade with the line. On the
pointer wheels, loosen the adjustment nuts and align the wheels with the same chalk line. Push the
JSalongthe lineto verify the alignmentis straight. SeeFigure 11 and Figure 12.
Figure 11 - Pointer wheel adjustment
13
..POINTER WHEEL
ADJUSTMENT NUTS
INTENDED CUT LINE

FRONT POINTER WHEEL —
BLADE
INTENDED CUT
LINE
Figure 12 - Alignment
of blade and the
pointer wheels - JS
bottom view
5.14 There are seven slots 1/4"
apart in the jack assembly lower
arm. As the bottom of the jack
assembly upper arm moves past
each 1/4" slot, this represents
approximately 3/4" in blade depth
travel. Counting the number of turns
on the handle can also control the
blade depth. See Table 1, Table 2, and Figure13.
Slot*
Number
of Turns
UpperArm
Travel
Depth for 010" Blade
Depth for 08" Blade
1(lowest)
0.0
0.00
3.00
2.00
2
1.5
0.25
2.25
1.25
3
3.0
0.50
1.50
0.50
4
4.5
0.75
0.75
-0.25
5
6.0
1.00
0.00
-1.00
6
7.5
1.25
-0.75
-1.75
7
9.0
1.50
-1.50
-2.50
Table 1 - Approximate blade depth chart in inches
(Positivenumbersrepresent bladedepth into concrete, negative
numbersrepresent clearance of blade out of concrete)
Number
of Turns
BladeDepth
0.5
0.25
1.00
0.50
1.50
0.75
2.00
1.00
2.50
1.25
3.00
1.50
Table 2 - Handle turns andaffect on approximate blade depth in inches
14

CAUTION
CAUTION: The blade depth is approximate and not exact. Many variables affect the exact blade depth such
as the exact diameter of a worn diamond blade. If an accurate depth must be cut, install the blade to be
used with the engine in the OFF position. Place the JS in a secure position that allows the blade to overhang
and be visibly measured at full blade depth. An example would be blocking the wheels withthe engine inthe
OFF position and lowering the JS blade along side a street curb. This will allow a measurement from the
bottom of the blade to the topof the curb.
JACK
ASSEMBLY
UPPER
ARM
Figure 13 - Shaft collar and blade depth
adjustment
Figure 13 shows the JS in themaximum blade depth
cutting positionwith the top of the shaft collar
set at thelowest slot. Tocut less thanmaximum
depths, loosen the socket head cap screws and
tap the collar with a hammer to loosen it. Then slide
theshaft collar up on the jack assembly lower
arm to the desired depth setting. The jack assembly upper arm will now stop on the shaft collar
controlling theblade depth. This shaft collar setting will also allow the JS to be quickly raised from
cutting positionand then lowered back intocutting position at the same depth.
5.15 Hold the blade guard firmly and remove the bolt in the blade guard holding bracket. Lower the
blade guard down until the 2" caster wheel touches work surface. Reinsert bolt in the blade guard
holding bracket for future use.
5.16 Makesure the blade guard caster wheel and white dust brush at the bladeguard base arefirmly
touchingthe work surface. See section 8.2 for detailed instructions on adjustingthe dust brush and
brushguard caster wheel.
WARNING
WARNING: Breathable silica may be generated by use of this product. Silica can cause severe
and permanent lung damage, cancer, and other serious diseases. Do not breath the dust. Do not
rely on your sight or smell to determine if the dust is in the air. Silica may be in the air without a
visible dust cloud. If air monitoring equipment for silica is not provided by your employer at your
worksite, you MUST wear appropriate respiratory protection when using or servicing the machine.
Consult your employer and OSHAregardingthe appropriate respiratory protection.
15
1/4"-28UNF HEX SOCKET
HEAD CAP SCREW
(REQUIRES 3/16" HEX KEY)
DEPTH ADJUSTMENT
SHAFT COLLAR
SLOT#1
(LOWEST)
JACK ASSEMBLY
LOWER ARM

5.18 Slidethe4" diameter vacuum hoseover the connector and tighten the worm drive hose clamp. Pull
firmlyon thehoseto verifytheconnection will not slide off.
5.19 Check for missing or loose bolts. Tighten loose bolts and replace missing bolts before operating
machine. Verify that belt and blade guards are in place. Never operate a JS without guards in
place. See Figure14andFigure 15.
WARNING
5.20 WARNING: If you can see the drive belt or diamond blade, the guards are not in place. Never
operatea JS without guards inplace. The proper positionforthebelt guard isbolted with four bolts to
the chassis. The proper position for the blade guard is down with the white guard dust brush
touchingthe horizontal surface. SeeFigure14 and Figure 15.
WARNING
Avoid injury.
Do NOT operate with
guard removed.
Replace guard before
operating machine.
E2001 HCS 800^4*0241 No.H6060-H5WVPK
Figure 14 - Warning label - do not operate with guard removed
WARNING
Rotating blade
hazard.
Do NOT operate with
guard up.
Keep hands and feet
away.
&200J HCS. LLC aOO-748-0241 No. 11SO-557WHPL
5.21
Figure 15 - Warning label - do not operate with guard up
Dress properly.Wear ear and eyeprotection. See sections 4.3 through 4.7. See Figure 16.
Figure 16 - Warning label - wear ear and eye protection
16
WARNING

6.0 Operation
6.1 Follow all pre-operating instructionsin section5.0.
6.2 Turn handle counterclockwise until jack assembly upper arm isabove thehighest depth slot. See
Figure 13. This will allow proper clearance between the work surface and theblade tip.
WARNING
WARNING: Never attempt to start theengine with the diamond blade inserted in a joint or previous cut. The
blade will turn as soon as the JS is started. This could damage the blade or cause the JS to jump
backwards.
6.3 Turn on the vacuum system.
6.4 Move theHonda engine fuel valve lever to the ON position.
6.5 To start a cold engine, movethe chokelever to the CLOSED position. To restart a warm engine,
leave thechokelever in the OPEN position.
6.6 Move the throttle lever away from theSLOW position, about 1/3of theway toward the fast position.
6.7 Turn the engineswitch tothe ON position.
6.8 Stand on the side of the JS oppositethe blade guard. Engage or squeeze the deadman lever with
the right hand.
6.9 With theleft hand, pull the starter cord grip lightly until you feel resistance, then pull briskly. Return
the starter grip gently. Repeat until engine starts. If engine does not start, see section 8.5 for
maintenance.
6.10 If thechoke lever has been moved to the CLOSED position to start the engine, gradually move it to
the OPEN position asthe enginewarms up.
6.11 Verify that the deadman device is functioning properly. Release or disengage the deadman lever
whilefirmly holding on to both handlegrips. This will stop the Honda engine. Maintain control of the
machine until the bladecompletely stops.Go backto 6.5 and restart theengine.
WARNING
WARNING: Do not operatea JS if thedeadman lever is not functioning. This could lead to serious injury or
death.
6.12 While continuing to squeeze the deadman lever, switch the right hand with the left hand. In other
words, your left hand will now beon the left handle grip and squeezing thedeadman lever. This will
free your right hand.
6.13 With your right hand, gently turn the handle clockwise to lower the blade into the work surface. Do
not force the blade into thework surface.
6.14 Nowplaceyour right handon theright handlegrip. Slowly walk in a straight lineforward. Do not pull
themachine in a backwards direction. See Figure17.
WARNING
WARNING: Donot twist the blade in thecut. Never attempt to cut any pattern or follow any joint that isnot a
straight line. Do not forcethe blade forward. Theseactions could damage the bladeand JS unit.
17

-ALL WARNING STICKERS IN
PLACE
/---- BLADE GUARD IN
/ DOWN POSITION
/-----DUST BRUSH FIRMLY
/ TOUCHING CONCRETE
POINTER WHEEL DOWN
-AREA IN FRONT IS CLEAR FROM
PEOPLE. TOOLS OR ANY LOOSE
OBJECTS. ETC
Figure 17-JS SERIES SAWS in
cutting operation
(Operator wearing personal protective
equipment and dust collector are not shown)
6.15
6.16
When through cutting, turn handle counterclockwise with your right hand to raise the blade out of the
work surface. Continue until the jack assembly upper arm is above the sixth depth slot. This will
allow proper clearance between the work surface and the blade tip. The JS may now be pushed to
another work area.
To stop the JS in an emergency, release or disengage the deadman lever. During normal operation as
instructed in Section 6.0, keep a firm hold on both handle grips and maintain control of the machine
until the blade completely stops. To remove the blade from the work surface after an emergency stop,
follow directions in step 6.1
WARNING
WARNING: The deadman lever is designed to stop the Honda engine during either normal use or in an
emergency. It may be released at any time during operation regardless of the blade position. If any unsafe
operating condition arises, immediately release the deadman lever. Beware that after releasing the lever, the
blade will continue spinning for several seconds. Keep a firm hold on the handle grips and maintain control of
the machine until the blade completely stops.
6.17 To stop the JS under normal conditions, turn the handle counterclockwise with your right hand until
the jack assembly upper arm is above the sixth depth slot. This will allow clearance between the
work surface and the blade tip. Release or disengage the deadman lever. Keep a firm hold on the
handle grips and maintain control of the machine until the blade completely stops.
6.18 Turn the Honda engine switch to the OFF position.
6.19 Turn the Honda fuel valve lever to the OFF position.
18
—DEADMAN LEVER ENGAGED
BY LEFT HAND
DEPTH ADJUSTMENT
SHAFT COLLAR IN PLACE
/—HONDA ENGINE SWITCH
TURNED TO "ON" POSITION
BELT GUARD IN PLACE
—4" HOSE CONNECTED
TO DUST COLLECTOR
(HOSE NOT SHOWN)
WRENCH CLAMPING^
KNOB SECURE
CASTER WHEEL
ON GROUND
POINTER WHEEL
DOWN

Table 3 - JS SERIES SAWS parts list
(Note: UseFigure18 to Figure 24 tolocateitem numbers. See section7.4 for item #53 breakdown. JS SERIES
SAWS parts are thesame except for item #22.)
ITEM
QUANTITY
PART NUMBER
DESCRIPTION
1
1
FOAM GRIP
2
1
SX77144
DEADMAN SWITCH LEVER
3
2
SX78119
POINTER WHEEL
4
1
SX77141
HANDLE
5
1
SX77155
COVER/DEADMAN SWITCH
6
2
SX78117
3/8"-16X4" HEX HEAD BOLT, FULL THREAD
7
3
SX73722
3/8"-16X2" HEX HEAD BOLT
8
2
SX84200
6"X2" M/O WHEEL BEARING
9
1
SX77116
ARM/POINTER 7"
10
11
SX73723
NUT/HEX LOCK 3/8"
11
2
SX75208
1-1/2" OPEN END WRENCH
12
2
SX71520
#10-32X3/8" PHIL PAN HEAD
13
8
SX60474
WASHER/FLAT 3/4"
14
1
SX77120
CHASSIS
15
12
SX92019
WASHER/FLAT 3/8"
16
1
SX77125
BLADE GUARD
17
1
SX98020
3/8" LOCK WASHER
18
1
SX77167
LOWER JACK ASSEMBLY ARM
19
1
SX60184
2"HR 3/8"-16 STEM CASTER
20
1
SX77135
BELT GUARD
21
7
SX92011
NUT/HEX 3/8"-16UNC
22
1
VARIES
MOTOR
23
1
SX92013
DUST BRUSH/BLADE GUARD
24
1
SX78116
POINTER ARM 24"
25
12
SX63730
5/16" FLAT/WASHER
26
4
SX63722
5/16"-18X1" HEX HEAD BOLT
27
2
SX91529
3/8"-16X3" HEX HEAD BOLT
28
2
SX91024
3/8"-16X1-1/2" HEX HEAD BOLT
29
2
SX80207
3/8"-16X1" HEX HEAD BOLT
30
1
SX77024
BLADE SHAFT 1"
31
6
SX63723
1/8"X1" COTTER PIN
32
1
SX77127
FRAME/FRONT AXLE
33
2
SX90177
BEARING/FLANGE 2 BOLT 1" BORE
34
1
SX80501
JS OUTER FLANGE W/PIN
35
1
SX80503
JS DRIVE FLANGE
36
1
SX92000
2" V-RIB BELT SHEAVE, 10 RIBS, J CROSS
SECT.
37
1
SX92017
POLY V BELT -280J10
38
1
SX73706
KNOB/CLAMPING 3/8"-16 STUD
39
1
SX90210
3"X3" RUBBER COUPLER
40
4
SX80502
JS 1/4" SPACER
41
4
SX78108
1/2" NYLOCK NUT

42
2
SX77021
WHEEL/3"X1-13/16"
43
8
SX96507
5/16" NYLOCK NUT
44
1
SX60472
3/8"-16 X 3-1/2" HEX HEAD BOLT
45
1
SX98045
3/8"-16 X 3" TURNED EYE BOLT
46
4
SX98052
1/2" FLAT WASHER
47
4
SX91025
1/2"-13 X 1-1/2" HEX HEAD BOLT
48
1
SX80504
1"-14 BLADE NUT
49
1
SX77148
ADAPTER/3"
50
4
SX98085
3/8-16 X 1-3/4" CARRIAGE BOLT
51
1
SX98026
3/16" X 3" ROLL PIN
52
4
SX72300
#10-32 FLAT WASHER
53
1
SX77162
JACK ASSEMBLY
54
2
SX72200
#10-32 X 1-1/2" PHIL PAN HEAD
55
1
SX77145
RUBBER FLAP
57
1
SX50250
1/4"-20 X 3/8" SOCKET SET SCREW
69
1
SX77032
3" V-RIB BELT SHEAVE, 10 RIBS, J CROSS
SECT.
70
1
SX77033
BUSHING/TAPERLOCK 1210 1" BORE
71
1
SX63738
3/8"-16 X 2 1/2" HEX HEAD BOLT
72
1
SX77163
COLLAR/SHAFT 1-1/4" BORE 2 PIECE CLAMP
73
1
4861100
SWITCH/PIN TYPE LIMIT
74
2
SX71510
#10-32 NYLOCK NUT
75
1
SX77159
KNOB
76
1
SX77154
GROMMET 1" DIA X 1/8" GROOVE

7.3 Figure 18 to Figure 23 of JS SERIES SAWS
Figure 18-JS SERIES SAWS top front right view
21
