Eizo FP-2401W User manual

NoteNote
• Please be careful not to scratch the LCD panel or the cabinet with the panel protector during installation. Also please do not
remove the panel protector often. It may scratch or result in damage to the LCD panel.
• The panel protector has an anti-glare treatment side and a glossy side. Use preferable side.
• When using LCD monitor with optional panel protector, it is preferable to avoid using downwards. In this condition, the panel
protector might become bend or slip out from the monitor.
Installation
Before installation, please remove dust and stains from the LCD panel.
1.
(1)
(2)
2.
Lever
1.Setthepanelprotectorintothegroovesofthepanelframe;thelowerrst(1),thentheupper(2).
2.Withtheenclosedtool(Lever)setthetabsofthepanelprotectorintothesidegrooves(4tabs).
Put the lever on the tabs of the panel protector and move it toward the LCD panel to install. Position the protector into the
LCD panel tightly without leaving an opening.
Fortherecommendation,pleaseusethestopperstopreventthepanelprotectorfrombendingor
slippingoutfromthemonitor.2typesofstoppersareincluded.Check“ApplicableModels”printedon
thebagofthestopperstousetheappropriatetypedependingonthemonitor.
Beforeinstallationthestoppers,pleaseremovedustandstainsfromthecabinetofthemonitor.Follow
these steps to install the stoppers.
1. Remove the protection paper from the stoppers.
2. Install the stoppers on the cabinet of the monitor.
Removing
Releasethestoppersfromthecabinet.Puttheleveronthetabsofpanelprotectorandmoveittowardthe
cabinettoremove.
Cleaning
NoteNote
• Please be sure to keep the panel protector immobilized while cleaning it. Otherwise it may scratch the surface of the LCD
panel. To hold the panel protector by hand, use a soft cloth to avoid dust or nger prints.
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel,
and also quality deterioration of the image.
• Never use any solvents or chemicals, such as thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or
panel.
Ifnecessary,thestainsonthecabinetandpanelsurfacecanberemovedbymoisteningpartofasoftcloth
with water.
Tips
• The optional ScreenCleaner is recommended for cleaning the cabinet and panel surface.
Specication
Surface treatment Anti-glare side: anti-glare hard coating / Glossy side: hard coating
Coating strength 2H
Reectivity Less than 6.8 % Light transmission More than 90 %
Dimension/ Weight 521.1 mm (W) × 327.3 mm (H) × 1.0 mm (D) / approx. 210 g
Accessories Lever (for Panel Protector) x 1, Stoppers 2 types x 4, User’s Manual
Stopper
User’s Manual
Panel Protector for EIZO 61 cm (24.1 inch) class LCD Monitors

(U.M-FP-2401W-AL)
00N0L767D1
Printed in Japan.4th Edition - August, 2021
Copyright © 2012 - 2021 EIZO Corporation All rights reserved.
