Eizo ColorEdge CG248-4K User manual

Important
Please read PRECAUTIONS, this User’s Manual, and the Setup Guide (separate volume) carefully to familiarize yourself
with safe and effective usage.
• Please refer to the Setup Guide for basic information ranging from connection of the monitor to a PC or external
device to using the monitor.
• The latest User’s Manual is available for download from our web site:
http://www.eizoglobal.com
Color Management LCD Monitor
User’s Manual

- 2 -
Location of Caution Statement
(Ex.CG318-4K)
AVERTISSEMENT
WARNING
WARNUNG
This product has been adjusted specically for use in the region to which it was originally shipped. If operated outside this region, the product may not perform as
stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without
the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless prior arrangements are made pursuant to EIZO
Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.

- 3 -
Notice for this monitor
Notice for this monitor
Aside from general purposes like creating documents, viewing multimedia content, this product is also suited to applications such as creations of images and
graphics, and digital photo processing, where accurate color reproduction is a priority.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as
specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
· Power cords provided with the product
· Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
If you place this product on a lacquer-coated desk, the color may adhere to the bottom of the stand due to the composition of the rubber. Check the desk surface
before use.
It takes about 3 minutes (under our measurement conditions) for the monitor display to stabilize. Please wait 3 minutes or more after the monitor power has been
turned on, and then adjust the monitor.
It is necessary to wait at least 30 minutes after turning on the power, in order to obtain correct measurement results.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and maintain a stable display.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may appear. Use the screen saver or power save
function to avoid displaying the same image for extended periods of time.
If the monitor displays continuously over a long period of time, dark smudges or burn-in may appear. To maximize the life of the monitor, we recommend the monitor
be turned off periodically.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to “Cleaning” (page 4)).

- 4 -
Notice for this monitor
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on the LCD panel, this is not a malfunction.
Percentage of effective dots: 99.9994% or higher.
The backlight of the LCD panel has a xed lifetime. When the screen becomes dark or begins to icker, please contact your local EIZO representative.
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc. If pressure is continually
applied to the panel, it may deteriorate or damage your panel. (If the pressure marks remain on the panel, leave the monitor with a black or white screen. The
symptom may disappear.)
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt to brush with tissues as this may scratch the
panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may occur on the interior and exterior surfaces of the
monitor. In that case, do not turn the monitor on. Instead wait until the dew condensation disappears, otherwise it may cause some damage to the monitor.
Cleaning
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel.
The stains on the cabinet and panel surface can be removed by using the provided ScreenCleaner.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

- 5 -
Contents
Contents
Notice for this monitor.................................................................................3
Cleaning.................................................................................................................4
To use the monitor comfortably ..........................................................................4
Contents........................................................................................................5
Chapter 1 Introduction ................................................................................7
1-1. Features......................................................................................................7
1-2. Controls and Functions ............................................................................9
●Front ............................................................................................................9
●Rear...........................................................................................................10
1-3. EIZO LCD Utility Disk ..............................................................................11
●Disk contents and software overview ........................................................11
●To use ColorNavigator...............................................................................11
1-4. Supported Resolutions...........................................................................12
●When using PC signal input ......................................................................12
●When using Video signal input ..................................................................14
1-5. Setting the Resolution ............................................................................15
●Windows 10...............................................................................................15
●Windows 8.1 / Windows 7 .........................................................................15
●OS X Mountain Lion (10.8) and later.........................................................16
●Mac OS X 10.7 ..........................................................................................16
Chapter 2 Basic Adjustments/Settings....................................................17
2-1. Switch Operation Method .......................................................................17
2-2. Switching Input Signals..........................................................................18
2-3. Switching the display mode (color mode) ............................................19
●Display Modes...........................................................................................19
2-4. Enlarging Images.....................................................................................20
2-5. Setting the display method for colors outside the REC709 standard
color gamut..............................................................................................21
Chapter 3 Advanced Adjustments/Settings ............................................22
3-1. Basic Operation of the Setting menu ....................................................22
3-2. Setting Menu Functions..........................................................................23
●Color..........................................................................................................23
●SelfCalibration ...........................................................................................29
●Signal Settings...........................................................................................32
●Preferences ...............................................................................................38
●Languages.................................................................................................41
●Information.................................................................................................41
Chapter 4 Administrator Settings ............................................................42
4-1. Basic Operation of the “Administrator Settings” menu ......................42
4-2. “Administrator Settings” Menu Functions............................................43
Chapter 5 Troubleshooting.......................................................................46
5-1. No picture.................................................................................................46
5-2. Imaging problems....................................................................................47
5-3. Other problems........................................................................................48
5-4. Built-in calibration sensor and SelfCalibration problems ...................49
Chapter 6 Reference..................................................................................51

- 6 -
Contents
6-1. Attaching the Optional Arm....................................................................51
6-2. Attaching/Detaching Cable Holder ........................................................52
6-3. Connecting Multiple External Devices ..................................................54
6-4. Making Use of USB (Universal Serial Bus) ...........................................55
●Required System Environment..................................................................55
●Connection Procedure (Setup of USB Function).......................................55
6-5. Specications ..........................................................................................56
●Dimensions................................................................................................60
●Main Default Settings ................................................................................64
●Accessories ...............................................................................................65
Chapter 7 Glossary....................................................................................66
Appendix .....................................................................................................69
Trademark............................................................................................................69
License / Copyright ............................................................................................70
FCC Declaration of Conformity .........................................................................71
Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor..........73
Hinweis zur Ergonomie :....................................................................................73
LIMITED WARRANTY..........................................................................................74
Recycling Information ........................................................................................83

- 7 -
Chapter 1 Introduction
Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
• CG248-4K: 23.8″ widescreen/ CG318-4K: 31.1″ widescreen
• Wide color gamut display
CG248-4K: Adobe® RGB coverage: 99%, DCI-P3 coverage: 93% / CG318-4K: Adobe® RGB coverage: 99%, DCI-P3 coverage: 98%
• Achieves contrast ratio of 1000:1 (CG248-4K) / 1500:1 (CG318-4K)*1
A high contrast ratio allows display of crisper black with reduced whiteness.
*1 (typical) When “DUE Priority” is set to “Brightness”
• Resolution
CG248-4K: Supports a resolution of 3840 × 2160 / CG318-4K: Supports a resolution of 4096 × 2160
Can display 4K (3840 x 2160 / 4096 x 2160) resolution as is.
• Pixel density
CG248-4K: 185 ppi / CG318-4K: 149 ppi
Can display text and images in high denition.
• IPS panel with 89˚ horizontal and vertical wide viewing angles
• The time from switching on the monitor until the display is stable has been shortened to approximately 3 minutes *2
*2 According to EIZO measurement conditions. However, if performing SelfCalibration (page 29), it is necessary to wait at least 30 minutes after turning on the power, in
order to obtain correct measurement results.
• Frame synchronization mode supported (23.75 – 30.25 Hz, 47.5 – 60.5 Hz)
• Support for four digital signal inputs (DisplayPort (HDCP) × 2, HDMI (HDCP, Deep Color) × 2)
- DisplayPort (supports 8 bit and 10 bit)*3,*4
- HDMI (supports 8 bit, 10 bit, and 12 bit)*3, *4
*3 Audio signals not supported.
*4 The maximum screen display is 10 bits.
• Color mode function
Reproduces a color temperature, gamma, and gamut compliant with the following standards.
- Broadcasting standards “EBU/REC709/REC1886/REC2020/SMPTE-C”
- Digital cinema standard “DCI”
- Adobe® RGB / sRGB
See “Chapter 3 Advanced Adjustments/Settings” (page 22)

- 8 -
Chapter 1 Introduction
• This product is equipped with a built-in calibration sensor, and supports SelfCalibration in which the monitor executes calibration independently.
See “SelfCalibration” (page 29)
• The provided Color Management Software “ColorNavigator 6” enables you to calibrate monitor characteristics and generate color proles
See “1-3. EIZO LCD Utility Disk” (page 11)
• Equipped with 4K zoom function
If a 4K2K signal (signals with a resolution of 4096 × 2160 or 3840 × 2160) is displayed on the screen, the specied area can be expanded by 2x in the display.
This is convenient when checking the ne detail of photos. This is convenient when checking the ne detail of images.
See “2-4. Enlarging Images” (page 20)
• Equipped with a USB Hub function that supports USB 3.0
Achieves high-speed data transfers of up to 5 Gbps, which enables transfers of large amounts of data to and from USB-connected devices in a short amount time.
Also, the “CHARGE” USB downstream port supports quick charging, so you can recharge your smartphone or tablet in a short period of time.
See “6-4. Making Use of USB (Universal Serial Bus)” (page 55) and “USB CHARGE Port” (page 39)
• Monitor hood is included
Includes a monitor hood that can effectively shield the monitor from the reection of external lighting, such as the reected glare of a uorescent light.
• Displays HDCP (High Bandwidth Digital Protection) *5 protected contents.
*5 Supports HDCP Version 1.2
Attention
Be careful of the following points when using the built-in calibration sensor.
Do not touch the built-in calibration sensor.
It may reduce the measurement accuracy of the built-in calibration sensor, or result in injury or equipment damage.
Attention
• A high temperature or high humidity environment may affect the measurement accuracy of the built-in calibration sensor. We suggest storing and using the monitor under the
following conditions.
- Temperature 30 ºC or less
- Humidity 70% or less
Avoid storing or using the sensor where it may be exposed to direct sunlight.
• Since the measurement result for the built-in sensor may be affected, ensure that the level of ambient light that enters the receiver part of the built-in sensor does not change
signicantly during measuring.
- The use of the monitor hood is recommended.
- While measuring, do not bring your face or any objects close to the monitor, do not look into the sensor.
- Set the monitor in the environment so that external light does not enter the sensor directly.

- 9 -
Chapter 1 Introduction
1-2. Controls and Functions
●Front
(Ex.CG318-4K)
4
3
2
1
Setting menu *1
1. Built-in calibration sensor Executes calibration for an independent monitor. SelfCalibration function (page 29))
2. Ambient light sensor Measures ambient light.
3. Operation switches Displays menus. Operate the switches according to the operation guide.
The switch indicator is lit white when you turn the power on.
4. Power switch Turns the power on or off.
The switch indicator is lit when you turn the power on. The indicator color differs depending on the monitor's operation status.
White: Operating
Flashing white (quickly twice): Indicates that recalibration is required if the SelfCalibration schedule (page 30) is set.
Orange: Power saving mode
OFF: Main power/Power off
*1 See “3-1. Basic Operation of the Setting menu” (page 22) for how to use.

- 10 -
Chapter 1 Introduction
●Rear
(Ex.CG318-4K)
12
10
11
13
9
6 85 7
5. Main power switch Turns the main power on or off.
6. Power connector Connects the power cord.
7. Input signal connectors On the monitor rear in order of left to right: HDMI connector × 2, DisplayPort connector × 2
8. USB upstream port Connects to the USB cable when using software that requires a USB connection, or when using the USB Hub function.
9. USB downstream port Connects to a peripheral USB device.
The “CHARGE” port supports quick recharging (page 39).
10. Handle This handle is used for transportation.
Attention
• Firmly grasp and hold the monitor by the bottom while grabbing the handle, and carefully convey the monitor so as not to drop it.
Do not hold the sensor section on the front side of the monitor.
11. Security lock slot Complies with Kensington’s MicroSaver security system.
12. Stand *2 Adjusts the height and angle (tilt and swivel) of the monitor.
13. Cable holder *3 Covers the monitor cables.
*2 An optional arm (or an optional stand) can be attached by removing the stand section (see “6-1. Attaching the Optional Arm” (page 51)).
*3 For details on mounting the cable holder, see “6-2. Attaching/Detaching Cable Holder” (page 52).

- 11 -
Chapter 1 Introduction
1-3. EIZO LCD Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and an overview of the software programs.
●Disk contents and software overview
The disk includes application software programs for calibration, and the User's Manual. Refer to “Readme.txt” or the “read me” le on the disk for software
startup procedures or le reference procedures.
Contents Overview
A “Readme.txt” or “read me” le
ColorNavigator 6 An application software for measuring and calibrating monitor characteristics and generating ICC proles (for Windows) and
Apple ColorSync proles (for Macintosh).
(The monitor and PC must be connected using the USB cable.)
User’s Manual of this monitor (PDF le)
●To use ColorNavigator
Refer to the User’s Manual on the CD-ROM disk in order to install and use the software. When using this software, you will need to connect a PC to the
monitor with the supplied USB cable. For details of the USB cable connection, see “6-4. Making Use of USB (Universal Serial Bus)” (page 55).
Attention
• While using ColorNavigator, do not operate the power switch or operation switches on the front side on the monitor.

- 12 -
Chapter 1 Introduction
1-4. Supported Resolutions
The monitor supports the following resolutions.
●When using PC signal input
CG248-4K
Resolution Vertical scan frequency Scan Type
DisplayPort
HDMISignal Format *1
Ver.1.2 Ver.1.1 Extra
640 × 480 59.94 Hz Progressive √ √ √ √
720 × 400 70.09 Hz Progressive √ √ √ √
800 × 600 60.32 Hz Progressive √ √ √ √
1024 × 768 60.00 Hz Progressive √ √ √ √
1280 × 960 60.00 Hz Progressive √ √ √ √
1280 × 1024 60.02 Hz Progressive √ √ √ √
1600 × 1200 60.00 Hz Progressive √ √ √ √
1920 × 1080 59.96 Hz Progressive √ √ √ √
1920 × 1200 59.89 Hz Progressive √ √ √ -
1920 × 1200 59.95 Hz Progressive ---√
2048 × 1080 24.00 Hz / 48.00 Hz Progressive ---√
2560 × 1440 59.95 Hz Progressive ---√
3840 × 2160 *2 60.00 Hz Progressive √ -√-
3840 × 2160 *2 24.0 Hz / 29.98 Hz Progressive √ √ √ √
3840 × 2160 *2 24.99Hz Progressive √ √ √ -
3840 × 2160 *2 24.00 Hz / 25.00 Hz / 30.00 Hz Progressive ---√
4096 × 2160 *3 59.98 Hz Progressive √ -√-
4096 × 2160 *3 23.98 Hz / 29.97 Hz Progressive √ √ √ -
4096 × 2160 *3 24.00 Hz / 25.00 Hz / 30.00 Hz Progressive ---√
*1 The supported signal differs depending on “Signal Format” (page 45) in the “Administrator Settings” menu.
*2 Recommended resolution
*3 Select a setting other than “Dot by Dot” for “Picture Expansion” (page 33) in the Setting menu. Due to this resolution exceeding the highest resolution that can be dis-
played by the LCD panel, when “Dot by Dot” is used, the left and right edges of images are not displayed.

- 13 -
Chapter 1 Introduction
CG318-4K
Resolution Vertical scan frequency Scan Type
DisplayPort
HDMISignal Format *1
Ver.1.2 Ver.1.1 Extra
640 × 480 59.94 Hz Progressive √ √ √ √
720 × 400 70.09 Hz Progressive √ √ √ √
800 × 600 60.32 Hz Progressive √ √ √ √
1024 × 768 60.00 Hz Progressive √ √ √ √
1280 × 960 60.00 Hz Progressive √ √ √ √
1280 × 1024 60.02 Hz Progressive √ √ √ √
1600 × 1200 60.00 Hz Progressive √ √ √ √
1920 × 1080 59.96 Hz Progressive √ √ √ √
1920 × 1200 59.89 Hz Progressive √ ---
1920 × 1200 59.95 Hz Progressive ---√
2048 × 1080 24.00 Hz / 48.00 Hz Progressive ---√
2560 × 1440 59.95 Hz Progressive ---√
3840 × 2160 60.00 Hz Progressive √ -√-
3840 × 2160 24.0 Hz / 30.48 Hz Progressive √ √ √ -
3840 × 2160 24.00 Hz / 25.00 Hz / 30.00 Hz Progressive ---√
4096 × 2160 *2 59.98 Hz Progressive √ -√-
4096 × 2160 *2 23.98 Hz / 29.97 Hz Progressive √ √ √ -
4096 × 2160 *2 24.99 Hz Progressive √ √ - -
4096 × 2160 *2 48.00 Hz / 58.00 Hz Progressive - - √-
4096 × 2160 *2 24.00 Hz / 25.00 Hz / 30.00 Hz Progressive ---√
*1 The supported signal differs depending on “Signal Format” (page 45) in the “Administrator Settings” menu.
*2 Recommended resolution

- 14 -
Chapter 1 Introduction
●When using Video signal input
CG248-4K
Resolution Vertical scan frequency Scan Type HDMI
720 × 480 (480p) 60.00 Hz Progressive √
720 × 480 (480i) 60.00 Hz Interlace √
720 × 576 (576p) 50.00 Hz Progressive √
720 × 576 (576i) 50.00 Hz Interlace √
1280 × 720 (720p) 50.00 Hz / 60.00 Hz Progressive √
1920 × 1080 (1080p) 24.00 Hz / 25.00 Hz / 30.00 Hz / 50.00 Hz / 60.00 Hz Progressive √
1920 × 1080 (1080i) 50.00 Hz / 60.00 Hz Interlace √
3840 × 2160 *1 24.00 Hz / 25.00 Hz / 30.00 Hz Progressive √
4096 × 2160 *2 24.00 Hz / 25.00 Hz / 30.00 Hz Progressive √
*1 Recommended resolution
*2 Select a setting other than “Dot by Dot” for “Picture Expansion” (page 33) in the Setting menu. Due to this resolution exceeding the highest resolution that can be dis-
played by the LCD panel, when “Dot by Dot” is used, the left and right edges of images are not displayed.
CG318-4K
Resolution Vertical scan frequency Scan Type HDMI
720 × 480 (480p) 60.00 Hz Progressive √
720 × 480 (480i) 60.00 Hz Interlace √
720 × 576 (576p) 50.00 Hz Progressive √
720 × 576 (576i) 50.00 Hz Interlace √
1280 × 720 (720p) 50.00 Hz / 60.00 Hz Progressive √
1920 × 1080 (1080p) 24.00 Hz / 25.00 Hz / 30.00 Hz / 50.00 Hz / 60.00 Hz Progressive √
1920 × 1080 (1080i) 50.00 Hz / 60.00 Hz Interlace √
3840 × 2160 24.00 Hz / 25.00 Hz / 30.00 Hz Progressive √
4096 × 2160 *1 24.00 Hz / 25.00 Hz / 30.00 Hz Progressive √
*1 Recommended resolution

- 15 -
Chapter 1 Introduction
1-5. Setting the Resolution
If the resolution is incorrect after connecting the monitor to a PC or if you want to change the resolution, follow the procedure below.
●Windows 10
1. Right-click the mouse anywhere on the desktop except on icons.
2. From the displayed menu, click “Display Settings”.
3. On the “Customize your display” dialog box, click “Advanced display settings”.
4. Select a monitor, then choose a resolution from the “Resolution” pull-down menu.
5. Click the “Apply” button.
6. When a conrmation dialog box is displayed, click “Keep changes”.
●Windows 8.1 / Windows 7
1. For Windows 8.1, click the “Desktop” tile on the Start Screen to display the desktop.
2. Right-click the mouse anywhere on the desktop except for icons.
3. From the displayed menu, click “Screen resolution”.
4. On the “Screen Resolution” dialog box, select the monitor.
5. Click “Resolution” to select the desired resolution.
6. Click the “OK” button.
7. When a conrmation dialog box is displayed, click “Keep changes”.
Note
• When changing the size of the characters or other items that are displayed, select “Display” from the control panel and change the scaling level.

- 16 -
Chapter 1 Introduction
●OS X Mountain Lion (10.8) and later
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” dialog box is displayed, click “Displays”.
(For Mac OS X Mountain Lion (10.8), click “Displays” for “Hardware”.)
3. On the displayed dialog box, select the “Display” tab, then choose “Change” for “Resolutions”.
4. The list of selectable resolutions is displayed. Select the desired resolution.
If the desired resolution is not displayed in the list, hold down the Option key and select “Change”.
5. Your selection will be reected immediately. When you are satised with the selected resolution, close the window.
●Mac OS X 10.7
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” dialog box is displayed, click “Displays” for “Hardware”.
3. On the displayed dialog box, select the “Display” tab and select desired resolution in the “Resolutions” eld.
4. Your selection will be reected immediately. When you are satised with the selected resolution, close the window.
Note
• If a suitable resolution is not displayed even after changing the resolution in the operating system, try changing the “Signal Format” (page 45) setting in the “Administrator Set-
tings” menu.

- 17 -
Chapter 2 Basic Adjustments/Settings
Chapter 2 Basic Adjustments/Settings
This chapter describes the basic functions that can be adjusted and set by touching the switches on the front of the monitor.
For advanced adjustment and setting procedures using the Setting menu, see “Chapter 3 Advanced Adjustments/Settings” (page 22).
2-1. Switch Operation Method
1. Displaying the operation guide
1. Touch any switch (except ).
The operation guide appears on the screen.
2. Adjusting/setting
1. Touch a switch for adjustment/setting.
The Adjustment/Setting menu appears.
(A submenu may also be displayed. In that case, select an item to adjust/set with , and then select .)
2. Use the switches to adjust/set the selected item, and then select to conrm.
3. Exiting
1. Select or to exit the menu.
2. When no menu is displayed, the operation guide will automatically disappear after a few seconds if no switches are operated.
Note
• The contents of the guide will differ depending on the selected menu or status.

- 18 -
Chapter 2 Basic Adjustments/Settings
2-2. Switching Input Signals
When a monitor has multiple signal inputs, the signal to display on-screen can be changed.
When the input signal is switched, the connector name of the displayed signal appears at the bottom right of the screen.
The combination of input signals that you can select differs depending on “Picture Setup” (page 44) in the “Administrator Settings” menu.
Picture Setup Input Signal
DisplayPort HDMI
Single Single
DP
1
DP
2
HDMI
1
HDMI
2
→→→
→
Dual Single
DP
1
DP
2
HDMI
1
HDMI
2
→ →
→
Single Dual
DP
1
DP
2
→HDMI
1
HDMI
2
→
→
Dual Dual
DP
1
DP
2
DP
1
HDMI
2
HDMI
1
HDMI
1
HDMI
2
→ →→
→
DP
2

- 19 -
Chapter 2 Basic Adjustments/Settings
2-3. Switching the display mode (color mode)
This function allows easy selection of a display mode according to monitor application.
●Display Modes
Color Mode Purpose
Standard Mode Adjust color using the monitor's Setting menu.
Custom Select for conguring color settings according to your preference.
Adobe®RGB Suitable for color matching with Adobe®RGB compatible peripherals.
sRGB Suitable for color matching with sRGB compatible peripherals.
EBU Suitable for reproducing the color gamut and gamma as dened in the EBU (European Broadcasting Union)
standards.
REC709 Suitable for reproducing the color gamut and gamma as dened in the ITU-R Rec. 709 standard.
SMPTE-C Suitable for reproducing the color gamut and gamma as dened in the SMPTE-C standards.
DCI Suitable for reproducing the color gamut and gamma as dened in the DCI standards.
REC2020 Suitable for reproducing the color gamut and gamma as dened in the ITU-R Rec. 2020 standard.
Calibration Mode (CAL mode) Adjusts the monitor’s color using the monitor’s SelfCalibration function or the “ColorNavigator 6” color management
software.
CAL1 Displays the screen adjusted by ColorNavigator and SelfCalibration.
CAL2
Note
• The Setting menu and the Mode names cannot be displayed at the same time.
• You can disable specic mode selections. For more information, see “Mode Skip” (page 40).

- 20 -
Chapter 2 Basic Adjustments/Settings
2-4. Enlarging Images
If a 4K2K signal (signals with a resolution of 4096 × 2160 or 3840 × 2160) is displayed on the screen, the specied area can be expanded by 2x in the display.
This is convenient when checking the ne detail of images.
Attention
• This function cannot be used when “Picture Setup” (page 44) is set to “Dual” in the “Administrator Settings” menu.
Adjustable Range
Center, Lower Left, Upper Left, Upper Right, Lower Right, Off
Center
Lower Left
Upper Left
Lower Right
Upper
Right
Example: Expand “Upper Right”
