Eizo FlexScan S2133 User manual

Important
Please read PRECAUTIONS, this User’s Manual, and the Setup Guide
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• Please refer to the Setup Guide for basic information ranging from
connection of the monitor to a PC to using the monitor.
• The latest User’s Manual is available for download from our web site:
http://www.eizo.com
Cover

2
Location of Caution Statement
This product has been adjusted specically for use in the region to which it was originally shipped. If operated
outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless prior
arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been
made to ensure that this manual provides up-to-date information, please note that EIZO monitor specications are
subject to change without notice.

3
Noticeforthismonitor
Notice for this monitor
This product is suited to general purposes like creating documents, viewing multimedia content.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is
used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
· Power cords provided with the product
· Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the
monitor power has been turned on, and then adjust the monitor.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and maintain a
stable display.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to
“Cleaning” (page 4)).
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on
the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994% or higher.
The backlight of the LCD panel has a xed lifetime. When the screen becomes dark or begins to icker, please contact
your local EIZO representative.
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference
patterns, etc. If pressure is continually applied to the panel, it may deteriorate or damage your panel. (If the pressure
marks remain on the panel, leave the monitor with a black or white screen. The symptom may disappear.)
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt
to brush with tissues as this may scratch the panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may
occur on the interior and exterior surfaces of the monitor. In that case, do not turn the monitor on. Instead wait until
the dew condensation disappears, otherwise it may cause some damage to the monitor.

4Noticeforthismonitor
Cleaning
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel,
and also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel.
Note
• The optional ScreenCleaner is recommended for cleaning the cabinet and panel surface.
The stains on the cabinet and panel surface can be removed by moistening part of a soft cloth with water.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to
the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

5
CONTENTS
CONTENTS
Cover ...................................................................... 1
Notice for this monitor ......................................... 3
Cleaning .................................................................... 4
To use the monitor comfortably ............................. 4
CONTENTS ............................................................. 5
Chapter 1 Introduction ....................................... 7
1-1. Features ......................................................... 7
1-2. Controls and Functions ............................... 8
●Front................................................................ 8
●Rear................................................................. 9
1-3. EIZO LCD Utility Disk.................................... 9
●Diskcontentsandsoftwareoverview............. 9
●Touse“ScreenManagerProforLCD
(DDC/CI)/EIZOScreenSlicer”....................... 9
1-4. Basic Operations and Functions ...............10
●BasicoperationoftheSettingmenu..............10
●Functions........................................................11
Chapter 2 Adjusting Screens .......................... 12
2-1. Compatible Resolutions .............................12
●AnalogInput(D-Sub).....................................12
●DigitalInput(DVI-D).......................................12
●DigitalInput(DisplayPort)..............................12
2-2. Setting the Resolution ................................13
●Windows8/Windows7.................................13
●WindowsVista................................................13
●WindowsXP...................................................13
●MacOSX.......................................................13
2-3. Adjusting Color ............................................14
●Toselectthedisplaymode
(FineContrastMode)......................................14
●Toperformadvancedadjustments................15
●Adjustablesettingsineachmode..................15
●Toadjustbrightness.......................................15
●Toadjustcontrast...........................................16
●Toadjustcolortemperature...........................16
●Toadjustgamma...........................................17
●Toadjustthecolorsaturation.........................17
●Toadjusthue..................................................18
●Tosetoverdriveintensity................................18
●Toadjustgain.................................................19
2-4. Screen Adjustment ..................................... 20
●DigitalSignalInput........................................ 20
●AnalogSignalInput....................................... 20
2-5. Screen Size Changing ................................ 24
●ScreenSizeChanging...................................24
●Toadjustbrightnessofnon-displayarea.......24
Chapter 3 Setting Monitor ............................... 25
3-1. Enabling / Disabling DDC/CI
communication .......................................... 25
3-2. Locking Operation Buttons ....................... 25
3-3. Setting Orientation ..................................... 26
3-4. Showing and hiding the EIZO logo ........... 26
3-5. Changing Setting Menu Display Position 26
3-6. Setting Language ........................................ 27
3-7. Resetting the Monitor to the Default
Settings ........................................................ 27
●Toresetthecoloradjustments...................... 27
●Toresetalladjustmentstothedefault
settings.......................................................... 27
Chapter 4 Power Saving Functions ................ 28
4-1. Setting Power Saving ................................. 28
4-2. Setting Power Indicator .............................. 29
4-3. Enabling / Disabling Automatic
Brightness Adjustment ............................. 29
●AutoEcoView................................................ 29
●EcoViewOptimizer2..................................... 29
4-4. Checking the power saving level .............. 30
4-5. Enabling / Disabling Auto Power-OFF ...... 30
Chapter 5 Troubleshooting .............................. 31
5-1. No picture .....................................................31
5-2. Imaging problems (for both digital and
analog) .......................................................... 32
5-3. Imaging problems (for digital only) .......... 33
5-4. Imaging problems (for analog only) ......... 33
5-5. Other problems ........................................... 34
Chapter 6 Reference ........................................ 35
6-1. Attaching the Optional Arm ....................... 35
6-2. Connecting Multiple PCs ........................... 36
●Toswitchamonginputsignals...................... 36
●Tosetinputsignalselection...........................37
6-3. Making Use of USB (Universal Serial
Bus) ................................................................37
●RequiredSystemEnvironment......................37
●ConnectionProcedure(SetupofUSB
Function)........................................................ 38
6-4. Displaying Monitor Information ................ 38
6-5. Specications ............................................. 39
●MainDefaultSettings.................................... 40
●OutsideDimensions...................................... 40
●Accessories....................................................41
6-6. Preset Timing ...............................................41
Chapter 7 Glossary .......................................... 42
Appendix .............................................................. 44

6CONTENTS
Trademark ............................................................... 44
License / Copyright ................................................ 44
ENERGY STAR ........................................................ 45
TCO .......................................................................... 45
FCC Declaration of Conformity ............................ 46
Hinweise zur Auswahl des richtigen
Schwenkarms für Ihren Monitor ............................47
Hinweis zur Ergonomie : ........................................47
LIMITED WARRANTY ............................................. 48
Recycling Information ........................................... 57
China Measures for RoHS Compliance in
ChinaRoHS ...............................................................61

7
Chapter1Introduction
Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
• Supports a resolution of 1600 × 1200
• IPS panel with 89˚ horizontal and vertical viewing angles
• Applicable to DisplayPort (applicable to 8 bit)
• The FineContrast function allows the user to select the display mode optimum to the displayed image.
- The Paper mode reproduces a printed paper effect on the monitor.
See “To select the display mode (FineContrast Mode)” (page 14).
• The software “ScreenManager Pro for LCD (DDC/CI)” to adjust the screen using the mouse and keyboard is
included.
See “1-3. EIZO LCD Utility Disk” (page 9).
- EyeCare Filter
Texture of the paper is reproduced by displaying a translucent image in the foreground of the desktop.
By using this function with the Paper mode, the screen looks more like paper.
See “To select the display mode (FineContrast Mode)” (page 14).
• Supports the power management software “EIZO EcoView NET”
For more information, refer to our web site (http://www.eizo.com).
• Power saving function
Suppressing the power consumption*1 reduces the carbon dioxide emissions. This product is equipped with power saving
function.
- Auto EcoView
The ambient light sensor on the front side of the monitor detects the environmental brightness to adjust the screen
brightness automatically and comfortably. Excessively high brightness may increase power consumption and cause
unwanted environmental effects. It may also lead to fatigue of your eyes. Use the Auto EcoView to reduce the
brightness.
See “Auto EcoView” (page 29).
- EcoView Optimizer 2
The monitor automatically adjusts the screen brightness according to the white level of the input signal. This
function can reduce the power consumption while maintaining the brightness specied by the input signal.
See “EcoView Optimizer 2” (page 29).
*1 Reference values:
Maximum power consumption: 45 W (Brightness Max., when a USB device is connected, at default settings)
Standard power consumption: 12 W (100VAC, Brightness 120 cd/m2, when no USB device is connected, at default
settings)
Standard power consumption: 13 W (200VAC, Brightness 120 cd/m2, when no USB device is connected, at default
settings)
• Supports portrait and landscape formats
• Displays HDCP (High-bandwidth Digital Protection) protected contents.
Note
• This monitor supports the portrait display. This function allows you to change the orientation of the Setting menu when
using the monitor screen in vertical display position (see “3-3. Setting Orientation” (page 26)).
• When using the monitor screen in a portrait position, the graphics board supporting portrait display is required. When
placing the monitor in a portrait position, the settings of your graphics board need to be changed. Refer to the User’s
Manual of the graphics board for details.

8Chapter1Introduction
1-2. Controls and Functions
●Front
7 81 965221 33 44
Settingmenu*1
1. Ambient light sensor Detectsambientbrightness(AutoEcoViewfunction(page29)).
2. button Displaysthesettingmenuofthepowersavingfunction(AutoEcoView(page29)and
EcoViewOptimizer2(page29)).
3. button Switchesinputsignalsfordisplay(page36).
4. button ChangestheFineContrastmode(page14).
5. , button Adjuststhebrightness(page15).
6. button DisplaystheSettingmenu,determinesanitemonthemenuscreen,andsavesvalues
adjusted(page10).
7. , button Providesthemenuselectionaswellastheadjustmentandsettingofafunction.
8. button Turnsthepoweronoroff.
9. Power indicator
Indicatesthemonitor’soperationstatus.
Blue: Operating
Orange: Powersavingmode
OFF: Poweroff
*1 See “1-4. Basic Operations and Functions” (page 10) for how to use.

9
Chapter1Introduction
●Rear
14
1210 11
13
16
15
10. Power connector Connectsthepowercord.
11. Input signal connector Left:DisplayPortconnector/Center:DVI-Dconnector/Right:D-Submini15-pin
connector
12. USB port (UP) ConnectstheUSBcableforusingtheUSBHubfunction(page37).
13. Security lock slot ComplieswithKensington’sMicroSaversecuritysystem.
14. Stand*2 Adjuststheheightandangle(tiltandswivel)ofthemonitor.
15. USB port (DOWN) ConnectsaperipheralUSBdevice.
16. Cable holder Coversthemonitorcables.
*2 An optional arm (or an optional stand) can be attached by removing the stand (see “6-1. Attaching the Optional Arm” (page 35)).
1-3. EIZO LCD Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents
and the overview of the software programs.
●Disk contents and software overview
The disk includes software programs for adjustment, and User’s Manual. Refer to Readme.txt le on the disk
for software startup procedures or le access procedures.
Item Overview Windows Macintosh
Screenadjustmentpatternles Usedwhenadjustingtheimageofanalog
signalinputmanually. √ √
ScreenManagerProforLCD
(DDC/CI)
Softwareforadjustingthescreenusingthe
mouseandkeyboard. √ -
EIZOScreenSlicer Softwarethatdividesascreenandlaysout
multiplewindowsefciently. √ -
User’sManualofthismonitor(PDFle) √ √
Readme.txtle √ √
●To use “ScreenManager Pro for LCD (DDC/CI) / EIZO ScreenSlicer”
For the installation and use of “ScreenManager Pro for LCD (DDC/CI) / EIZO SceenSlicer”, refer to the
respective User’s Manual on the disk.

10 Chapter1Introduction
1-4. Basic Operations and Functions
●Basic operation of the Setting menu
1. Displaying the Setting menu
1. Press . The Setting menu appears.
2.
Adjusting / Setting
1. Choose a menu to adjust / set with , , and then press . The Sub menu appears.
2. Choose an item to adjust / set with , , and then press . The adjustment / setting menu appears.
3. Adjust / set the selected item with , , and then press .
3.
Exiting
1. Choose “Return” from the Sub menu and press . The Setting menu appears.
2. Choose “Exit” from the Main menu and press . The Setting menu quits.
Note
• The Setting menu can also be exited by pressing twice quickly.

11
Chapter1Introduction
●Functions
The following table shows the Setting menu and setting items of each menu.
Main menu Setting Reference
Color*1 Brightness “2-3.AdjustingColor”(page14)
Contrast
Temperature
Gamma
AdvancedSettings Saturation
Hue
Overdrive
Gain
ColorReset “Toresetthecoloradjustments”(page27)
Screen ScreenSize “ScreenSizeChanging”(page24)
Smoothing “2-4.ScreenAdjustment”(page20)
AnalogAdjustment*2 AutoScreenAdjust
AutoRangeAdjust
Clock
Phase
Hor.Position
Ver.Position
PowerManager PowerSave “4-1.SettingPowerSaving”(page28)
EcoTimer “4-5.Enabling/DisablingAutoPower-
OFF”(page30)
MonitorSettings InputSignal “Tosetinputsignalselection”(page37)
PowerIndicator “4-2.SettingPowerIndicator”(page29)
Language “3-6.SettingLanguage”(page27)
DDC/CI “3-1.Enabling/DisablingDDC/CI
communication”(page25)
BorderIntensity “Toadjustbrightnessofnon-displayarea”
(page24)
MenuSettings Orientation “3-3.SettingOrientation”(page26)
Logo “3-4.ShowingandhidingtheEIZOlogo”
(page26)
MenuPosition “3-5.ChangingSettingMenuDisplay
Position”(page26)
Reset “Toresetalladjustmentstothedefault
settings”(page27)
Information “6-4.DisplayingMonitorInformation”
(page38)
*1 The adjustment / settings available on the “Color” menu depend on the selected Color mode. The above table shows
the sub menus when the User1 or User2 mode is selected.
*2 These functions can be adjusted with analog input.

12 Chapter2AdjustingScreens
Chapter 2 Adjusting Screens
2-1. Compatible Resolutions
The monitor supports the following resolutions.
●Analog Input (D-Sub)
Resolution Applicable Signals Vertical Scan
Frequency Dot Clock
640×400 PC-9801,PC-9821AP2 ~70Hz
162MHz
(Max.)
640×480 VGA,VESA,MAC ~75Hz
720×400 VGATEXT 70Hz
800×600 VESA ~75Hz
832×624 MAC 75Hz
1024×768 VESA ~75Hz
1152×864 VESA 75Hz
1152×870 MAC 75Hz
1280×960 VESA,MAC ~75Hz
1280×1024 VESA ~75Hz
1600×1200*1 VESA 60Hz
●Digital Input (DVI-D)
Resolution Applicable Signals Vertical Scan
Frequency Dot Clock
640×480 VGA 60Hz
162MHz
(Max.)
720×400 VGATEXT 70Hz
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1600×1200*1 VESA 60Hz
●Digital Input (DisplayPort)
Resolution Applicable Signals Vertical Scan
Frequency Dot Clock
640×480 VGA 60Hz
162MHz
(Max.)
720×400 VGATEXT 70Hz
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1600×1200*1 VESA 60Hz
ThegraphicsboardshouldcomplywiththeVESAstandard.
*1 Recommended resolution

13
Chapter2AdjustingScreens
2-2. Setting the Resolution
When you connect the monitor to the PC and nd that the resolution is improper, or when you want to change the
resolution, follow the procedure below.
●Windows 8 / Windows 7
1. For Windows 8, click the “Desktop” tile on the Start Screen to display the desktop.
2. Right-click the mouse anywhere on the desktop except for icons.
3. From the displayed menu, click “Screen resolution”.
4. On the “Screen Resolution” dialog box, select the monitor.
5. Click “Resolution” to select the desired resolution.
6. Click the “OK” button.
7. When a conrmation dialog box is displayed, click “Keep changes”.
●Windows Vista
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Personalize”.
3. On the “Personalization” window, click “Display Settings”.
4. On the “Display Settings” dialog box, select the “Monitor” tab and select desired resolution in the
“Resolution” eld.
5. Click the “OK” button.
6. When a conrmation dialog box is displayed, click “Yes”.
●Windows XP
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Properties”.
3. When the “Display Properties” dialog box is displayed, click the “Settings” tab and select desired resolution
for “Screen resolution” under “Display”.
4. Click the “OK” button to close the dialog box.
●Mac OS X
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” dialog box is displayed, click “Displays” for “Hardware”.
3. On the displayed dialog box, select the “Display” tab and select desired resolution in the “Resolutions” eld.
4. Your selection will be reected immediately. When you are satised with the selected resolution, close the
window.

14 Chapter2AdjustingScreens
2-3. Adjusting Color
●To select the display mode (FineContrast Mode)
This function allows easy selection of a desired mode according to monitor application.
Display Modes
Mode Purpose
User1 Selectthistodeneadesiredsetofparametersettings.
User2
sRGB SuitableforcolormatchingwithsRGBcompatibleperipherals.
Paper Producesaprintedpapereffect.Suitablefordisplayingimagesfrommediasuchasbooks
anddocuments.
Movie Suitableforplayingbackanimatedimages.
Themodemenu
appears.
Procedure
1. Press .
The mode menu appears at the bottom left of the screen.
2. The mode among the list is highlighted in turn each time is pressed.
You can switch the mode with or while the mode menu is displayed.
→User1←→User2←→sRGB←→Paper←→Movie←
Note
• The Setting menu and the Mode menu cannot be displayed at the same time.
• “ScreenManager Pro for LCD (DDC/CI)” allows you to select the FineContrast mode automatically according to the
application used (see “Chapter 3 Auto FineContrast” in the “ScreenManager Pro for LCD (DDC/CI)” User’s Manual).

15
Chapter2AdjustingScreens
●To perform advanced adjustments
The “Color” menu of the Setting menu allows you to set and save the independent color adjustment for each
mode.
Attention
• It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the
monitor power has been turned on, and then adjust the monitor.
• Perform the range adjustment rst when adjusting color for analog signals (see “To adjust color gradation automatically”
(page 23)).
• The same image may be seen in different colors on multiple monitors due to their monitor-specic characteristics. Make
ne color adjustment visually when matching colors on multiple monitors.
Note
• Using the “ScreenManager Pro for LCD (DDC/CI)” allows you to perform the color adjustment by using the mouse and
keyboard of your PC. (Refer to “Chapter 4 Color Adjustment” in the User’s Manual for “ScreenManager Pro for LCD
(DDC/CI)”.)
●Adjustable settings in each mode
The adjustable settings depend on the mode. (Non-adjustable or non-settable function cannot be selected.)
√: Adjustable -: Not adjustable
Function FineContrast Mode
User1 User2 sRGB Paper Movie
Brightness √ √ √ √ √
Contrast √ √ - - √
Temperature √ √ - √ √
Gamma √ √ - - -
AdvancedSettings Saturation √ √ - - √
Hue √ √ - - √
Overdrive √ √ - - -
Gain √ √ - - -
ColorReset √ √ √ √ √
●To adjust brightness
The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back
panel).
Adjustable range
0 to 100
Procedure
1. Press or .
The Brightness menu appears.
2. Use or for adjustment.
3. Press to exit.
Note
• If you feel that the image is too dark even if the brightness is set to 100, adjust the contrast.
• Alternatively, you can use “Brightness” under “Color” in the Adjustment menu to adjust it.
• To adjust the screen brightness automatically and comfortably, see “4-3. Enabling / Disabling Automatic Brightness
Adjustment” (page 29).

16 Chapter2AdjustingScreens
●To adjust contrast
The brightness of the screen is adjusted by varying the video signal level.
Adjustable range
0 to 100
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Contrast” in the “Color” menu, and press .
The “Contrast” menu appears.
3. Use or for adjustment.
4. Press to exit.
Note
• In the contrast of 50, every color gradation is displayed.
• When adjusting the monitor, it is recommended to perform the brightness adjustment which may not lose the gradation
characteristics, prior to the contrast adjustment.
• Perform the contrast adjustment in the following cases.
- When you feel the image is too dark even if the brightness is set to 100 (Set the contrast to higher than 50.)
●To adjust color temperature
Color temperature can be adjusted.
The color temperature is normally used to express the hue of “White” and / or “Black” by a numerical value.
The value is expressed in degrees “K” (Kelvin).
The screen becomes reddish at a low color temperature, and bluish at a high color temperature, like the ame
temperature. A gain preset value is set for each color temperature setting value.
Adjustable range
Off, 4000 K-10000 K (specied by every 500 K unit, including 9300 K)
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Temperature” in the “Color” menu, and press .
The “Temperature” menu appears.
3. Use or for adjustment.
4. Press to exit.
Note
• The value shown in “K” is available only as reference.
• “Gain” allows you to perform more advanced adjustment (see “To adjust gain” (page 19)).
• If you set to “Off”, the image is displayed in the preset color of the monitor (Gain: 100 for each RGB).
• When gain is changed, the color temperature is changed to “Off”.

17
Chapter2AdjustingScreens
●To adjust gamma
Gamma can be adjusted. The brightness of the monitor varies depending on the input signal, however, the
variation rate is not proportional to the input signal. To keep the balance between the input signal and the
brightness of the monitor is called as “Gamma correction”.
Adjustable range
1.8, 2.0, 2.2
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Gamma” in the “Color” menu, and press .
The “Gamma” menu appears.
3. Use or for adjustment.
4. Press to exit.
Note
• If “Paper” is selected in the FineContrast mode, the gamma value is displayed for “Paper”. The setting “Paper” is
specially meant to get the displayed image look like it is printed on paper.
●To adjust the color saturation
This function allows you to adjust color saturation.
Adjustable range
-50 to 50
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Advanced Settings” in the “Color” menu, and press .
3. Choose “Saturation” in the “Advanced Settings” menu, and press .
The “Saturation” menu appears.
4. Use or for adjustment.
5. Press to exit.
Attention
• Using this function may make some color gradations unavailable for display.
Note
• The minimum value (-50) changes the screen to monochrome.

18 Chapter2AdjustingScreens
●To adjust hue
This function allows you to adjust hue.
Adjustable range
-50 to 50
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Advanced Settings” in the “Color” menu, and press .
3. Choose “Hue” in the “Advanced Settings” menu, and press .
The “Hue” menu appears.
4. Use or for adjustment.
5. Press to exit.
Attention
• Using this function may make some color gradations unavailable for display.
●To set overdrive intensity
This function allows you to set overdrive intensity based on the use of the monitor. You can reduce Image lags
by setting it to “Enhanced” when displaying animated images.
Adjustable range
Enhanced, Standard, Off
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Advanced Settings” in the “Color” menu, and press .
3. Choose “Overdrive” in the “Advanced Settings” menu, and press .
The “Overdrive” menu appears.
4. Use or for adjustment.
5. Press to exit.
Note
• The setting of the overdrive function can be changed in any of the following cases. The function is turned “Off” in all
other cases.
- When the display resolution is 1600 x 1200
- When “Full Screen” or “Enlarged” is selected for “Screen Size” and the vertical scan frequency of the input signal is
60 Hz (except when the resolution is 640 x 480)

19
Chapter2AdjustingScreens
●To adjust gain
The brightness of each color component red, green, and blue is called “Gain”. You can change the hue of
“white” by adjusting gain.
Adjustable range
0 to 100
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Advanced Settings” in the “Color” menu, and press .
3. Choose “Gain” in the “Advanced Settings” menu, and press .
The “Gain” menu appears.
4. Adjust gain with or for each of red, green, and blue.
5. Press to exit.
Attention
• Using this function may make some color gradations unavailable for display.
Note
• The value of gain changes with that of color temperature.
• When gain is changed, the color temperature is changed to “Off”.

20 Chapter2AdjustingScreens
2-4. Screen Adjustment
●Digital Signal Input
When digital signals are input, images are displayed correctly based on the preset data of the monitor, but if
characters and / or lines appear blurred, go to “To modify blurred characters / lines” (page 23).
When performing more advanced adjustment, see “2-3. Adjusting Color” (page 14) and subsequent pages.
●Analog Signal Input
Attention
• It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the
monitor power has been turned on, and then adjust the monitor.
• The Self Adjust (automatic screen adjustment) function does not work for the images under the resolution of 800 × 600
(SVGA).
• The self adjustment (or automatic screen adjustment) function works correctly when an image is fully displayed over the
Windows or Macintosh display area. They do not work properly in the cases below:
- When an image is displayed only on a part of the screen (command prompt window, for example)
- When a black background (wallpaper, etc.) is in use
Also, these functions cannot work properly in some graphic boards.
The monitor screen adjustment is used to suppress ickering of the screen or adjust screen position and screen
size correctly according to the PC to be used.
Note
• The Self Adjust function works when all of the following conditions are satised:
- When a signal is input into the monitor for the rst time or when a resolution or vertical / horizontal scan frequency
not used before is set
If the screen is not displayed correctly even after performing the Self Adjust operation, adjust the screen
according to the procedures on the following pages to use the monitor comfortably.
Setting Procedures
1. Perform the auto adjustment.
● To adjust ickering, screen position, and screen size automatically
Procedure
1. Choose “Screen” in the Setting menu, and press .
2. Choose “Analog Adjustment” in the “Screen” menu, and press .
3. Choose “Auto Screen Adjust” in the “Analog Adjustment” menu, and press .
4. Select “Yes” with or , and press .
Flickering, screen position, and screen size are corrected by the auto-adjustment function.
Ifthescreenisnotdisplayedcorrectlyevenafterperformingtheautoadjustment,performadjustments
accordingtothefollowingprocedure.Ifthescreenisdisplayedcorrectly,goto“5.Adjustingcolorgradation.”
(page23).
