Eizo coloredge prominence CG3145 User manual

Important
Please read this “User’s Manual”, and “PRECAUTIONS” (separate
volume) carefully to familiarize yourself with safe and effective usage.
•Refer to the “Setup Guide” for information on the installation /
connection of the monitor.
•For the latest product information including the “User’s Manual”,
refer to our web site :
http://www.eizoglobal.com
HDR Reference Monitor
User’s Manual
Thank you for purchasing our HDR reference monitor.

2
Location of Caution Statement
This product has been adjusted specically for use in the region to which it was originally shipped. If
operated outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless
prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every
effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.

3
Notice for This Monitor
Notice for This Monitor
About the Usage of This Product
This product is suited for producing videos, where accurate color reproduction is a priority.
This product has been adjusted specically for use in the region to which it was originally shipped. If the
product is used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
• Power cords provided with the product
• Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
About the LCD Panel
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may
appear on the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994 % or higher.
It takes about 30 minutes (under our measurement conditions) for the monitor display to stabilize. Please
wait 30 minutes or more after the monitor power has been turned on, and then adjust the monitor.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and
maintain a stable display.
When the screen image is changed after displaying the same image for extended periods of time, an
afterimage may appear. Use the screen saver or power save function to avoid displaying the same image for
extended periods of time. Depending on the image, an afterimage may appear even if it was displayed for
a short period of time. To remove such a phenomenon, change the image or keep the power turned off for
several hours.
If the monitor displays continuously over a long period of time, smudges or burn-in may appear. To maximize
the life of the monitor, we recommend the monitor be turned off periodically. Use the power button on the
front of the monitor to turn it off.
The backlight of the LCD panel has a xed lifetime. Depending on the usage pattern, such as usage for
long continuous periods, the lifespan of the backlight may run out sooner, requiring replacement. When the
screen becomes dark or begins to icker, please contact your local EIZO representative.
Do not press on the LCD panel or edge of the frame strongly, as this may result in display malfunctions, such
as interference patterns, etc. If pressure is continuously applied to the LCD panel surface, the liquid crystal
may deteriorate or the LCD panel may be damaged. (If the pressure marks remain on the panel, leave the
monitor with a black or white screen. The symptom may disappear.)
Do not scratch or press on the LCD panel with any sharp objects, as this may result in damage to the LCD
panel. Do not attempt to brush with tissues as this may scratch the panel.

4Notice for This Monitor
About the Installation
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew
condensation may occur on the interior and exterior surfaces of the monitor. In that case, do not turn the
monitor on. Instead wait until the dew condensation disappears, otherwise it may cause some damage to the
monitor.
If you place this product on a lacquer-coated desk, the color may adhere to the bottom of the stand due to
the composition of the rubber. Check the desk surface before use.
About the Maintenance
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer
to “Cleaning” (page 4)).
Cleaning
The stains on the cabinet and LCD panel surface can be removed by using the provided ScreenCleaner.
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet
or LCD panel, and also quality deterioration of the image.
• Never use thinner, benzine, wax, or abrasive cleaner as they may damage the cabinet or LCD panel surface.
To Use the Monitor Comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor
according to the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

5
Contents
Contents
Notice for This Monitor......................................... 3
Cleaning .................................................................... 4
To Use the Monitor Comfortably ............................ 4
Contents................................................................. 5
Chapter 1 Introduction....................................... 6
1-1. Features ......................................................... 6
●Large built-in high resolution 4K LCD
that is advantageous for video production ...... 6
●Support for HDR (High Dynamic Range)
video................................................................ 6
●Various functions that support color
grading work.................................................... 7
●Equipped with a USB Hub function................. 7
1-2. Controls and Functions ............................... 8
●Front ................................................................ 8
●Rear................................................................. 9
Chapter 2 Basic Adjustments/Settings.......... 10
2-1. Button Operation Method ...........................10
●Operation Guide Icons ...................................10
2-2. Switching Input Signals ..............................11
2-3.
Switching the Display Mode (color mode) ...11
●Display Modes................................................11
●Color Mode Setting Values ............................12
Chapter 3 Advanced Adjustments/Settings ... 13
3-1. Basic Operation of the Setting Menu ........13
3-2. Setting Menu Functions ..............................14
●Signal .............................................................14
●Color...............................................................16
●Screen ........................................................... 20
●Preferences....................................................24
●Languages .................................................... 26
●Information .................................................... 26
Chapter 4 Custom Key Settings...................... 27
4-1. Basic Operation of the Custom Keys ....... 27
4-2. Assigning a Function to a Custom Key.... 27
●Functions that can be Assigned to
Custom Keys ................................................. 29
Chapter 5 Administrator Settings................... 30
5-1. Basic Operation of the "Administrator
Settings" Menu............................................ 30
5-2.
"Administrator Settings" Menu Functions ...31
Chapter 6 Calibration ....................................... 33
Chapter 7 Troubleshooting.............................. 34
7-1. No Picture .................................................... 34
7-2. Imaging Problems....................................... 35
7-3. Other Problems........................................... 36
Chapter 8 Reference ........................................ 37
8-1. Connecting Multiple External Devices......37
8-2. Making Use of the USB Hub Function ...... 38
●Required System Environment ..................... 38
●Connection Procedure
(Setup of USB Function)................................ 39
8-3. Specications ............................................. 40
●Accessories....................................................41
Appendix.............................................................. 42
Trademark ............................................................... 42
License .................................................................... 42
FCC Declaration of Conformity ............................ 43

6Chapter 1 Introduction
Chapter 1 Introduction
This chapter describes the features of the monitor and the name of each control.
1-1. Features
●Large built-in high resolution 4K LCD that is advantageous for
video production
• 31.1-inch widescreen monitor with support for DCI 4K resolution (4096 × 2160)
Supports the digital cinema standard for DCI 4K resolution of 4096 × 2160. In addition to 4K videos,
which have a high resolution that is more than 4x greater than full HD, multiple full HD videos can
be displayed at the same time.
• Faithful reproduction of video colors with a wide color gamut display
99 % of DCI is covered, for a highly accurate color management environment.
• Achieves a contrast ratio of 1,000,000:1*1
A high contrast ratio allows black to be displayed in a rmer tone.
*1 Standard value. Not a guaranteed value.
• Built-in IPS LCD panel with 178° horizontal and vertical wide viewing angles
●Support for HDR (High Dynamic Range) video
• Complies with the international HDR standards for movies and broadcasts
Supports both the HDR "PQ format" for streaming and movie production, and the HDR "Hybrid Log
Gamma format" for broadcasts. The "PQ format" complies with the ITU-R BT.2100*2 and SMPTE
ST2084*3 international HDR standards, and the "Hybrid Log Gamma format" complies with the
ITU-R BT.2100 international HDR standard. This makes it possible to use the monitor for the color
grading of a wide range of HDR content, such as movies and broadcasts.
*2 ITU-R is the International Telecommunication Union-Radio communication Sector.
*3 SMPTE is the Society of Motion Picture and Television Engineers.
• High brightness and high contrast ratio
High brightness and a high contrast ratio are achieved by installing a dedicated IPS LCD panel and
a dedicated backlight unit with a high level of brightness.
• Built-in color mode function
Reproduces a color temperature, gamma, and color gamut compliant with ITU-R BT.2100 and other
standards.
See “Color Mode” (page 16).

7
Chapter 1 Introduction
●Various functions that support color grading work
• Dedicated video production functions, such as a Gamut Warning function and a Luminance
Warning function
See “Chapter 3 Advanced Adjustments/Settings” (page 13).
• 4K Zoom function
When a 4K2K signal (a signal with a resolution of 4096 × 2160 or 3840 × 2160) is displayed on the
monitor, the specied area can be doubled in size. This is convenient for checking details in an
image.
See “Zoom” (page 21).
• User-dened custom key function
Work efciency can be improved by assigning frequently used functions to the buttons on the front
of the monitor.
See “Chapter 4 Custom Key Settings” (page 27).
• Supports the "ColorNavigator NX" color management software
Use ColorNavigator NX to adjust the display according to various video production standards. Since
adjustment results are assigned to each color mode in the monitor, the display can be switched with
the buttons on the front of the monitor for easy color management.
See “Chapter 6 Calibration” (page 33).
• Displays HDCP (High Bandwidth Digital Protection) protected content
• Monitor hood included as standard
Includes a monitor hood that effectively prevents reections from external light, such as the
reected glare of a light. The monitor hood uses magnets for easy attachment and removal.
●Equipped with a USB Hub function
• Supports USB 3.0
Achieves high-speed data transfers of up to 5 Gbps, which enables transfers of large amounts of
data to and from USB memory devices in a short amount time.
Also, the USB downstream port supports quick charging, so you can recharge your
smartphone or tablet in a short period of time.
See “8-2. Making Use of the USB Hub Function” (page 38) and “USB CHARGE Port” (page 24).

8Chapter 1 Introduction
1-2. Controls and Functions
●Front
31 2
*1
1. Control buttons Displays menus. Operate the buttons according to the operation
guide.
2. Power button Turns the power on or off.
3. Power indicator The indicator is lit when you turn the power on.
The indicator color differs depending on the monitor's operation
status.
Blue : Operating
Orange : Power saving mode
OFF : Power off
*1 See “3-1. Basic Operation of the Setting Menu” (page 13) for more information about how to use the
Setting menu.

9
Chapter 1 Introduction
●Rear
7
8
13121110
6
5
4
9
4. Handle This handle is used for transportation.
Attention
• With help from one other person, rmly grasp and hold the monitor by
the bottom while grabbing the handle, and carefully convey the monitor
so as not to drop it.
5. USB downstream port
(supports quick charging)
Connects to a peripheral USB device (page 24).
6. USB downstream port Connects to a peripheral USB device.
7. Cable holder Covers the monitor cables.
8. Stand Adjusts the height and angle (swivel) of the monitor.
9. Security lock slot Complies with Kensington's MicroSaver security system.
10. Main power switch Turns the main power on or off.
: On : Off
Normally, it is not necessary to turn off the main power switch.
11. Power connector Connects the power cord.
12. Input signal connectors The following input connectors are located on the monitor rear in order
of left to right.
HDMI connector 1
HDMI connector 2
DisplayPort connector 1
DisplayPort connector 2
13. USB upstream port Connects to the USB cable when using software that requires a USB
connection, or when using the USB Hub function (page 38).

10 Chapter 2 Basic Adjustments/Settings
Chapter 2 Basic Adjustments/Settings
This chapter describes the basic functions that can be set by pressing the buttons on the front of the monitor.
For advanced adjustment and setting procedures using the Setting menu, see “Chapter 3 Advanced
Adjustments/Settings” (page 13).
2-1. Button Operation Method
1.
Displaying the operation guide
1. Press any of the buttons (except ).
The operation guide appears on the screen.
2.
Setting
1. Press the button for an item that you want to set.
The Setting menu appears.
2. Use the buttons to adjust/set the selected item, and then select to conrm.
3.
Exiting
1. Select to exit the menu.
2. When no menu is displayed, the operation guide will automatically disappear after a few seconds
if no buttons are operated.
Note
• The contents of the guide will differ depending on the selected menu or status.
●Operation Guide Icons
Icon Description
Switches the input signal.
Switches the color mode.
Executes the function assigned to Custom Key 1.
Executes the function assigned to Custom Key 2.
Displays the Setting menu.
Returns to the previous screen.
Moves the cursor.
Executes the selected operation.
Turns the monitor's power on or off.

11
Chapter 2 Basic Adjustments/Settings
2-2. Switching Input Signals
When a monitor has multiple signal inputs, the signal to display on-screen can be changed.
2-3. Switching the Display Mode (color mode)
This function allows easy selection of a display mode according to monitor application.
●Display Modes
Color Mode Purpose
Standard Mode Adjust color using the monitor's Setting menu.
REC2020 See “Color Mode Setting Values” (page 12) for detailed setting values
for each color mode.
REC709
DCI
PQ_REC2100
PQ_REC709
PQ_DCI
HLG_REC2100
Calibration Mode (CAL mode) This mode displays the screen according to the settings that you have
adjusted with the "ColorNavigator NX" color management software.
CAL1 Displays the screen adjusted by ColorNavigator NX.
CAL2
CAL3

12 Chapter 2 Basic Adjustments/Settings
●Color Mode Setting Values
-: Cannot be changed
Item
Color Mode
REC2020 REC709 DCI
PQ_
REC2100
PQ_
REC709
PQ_
DCI
HLG_
REC2100
CAL1 /
CAL2 /
CAL3
Brightness (cd/m2)100 100 48 1000 1000 1000 1000 -
Temperature
REC2020 REC709 DCI REC2020 REC709 DCI REC2020 -
Gamma
REC1886 REC1886 DCI PQ PQ PQ HLG -
PQ Clipping (cd/m2) - - - 1000 1000 1000 - -
HLG System Gamma - - - - - - 1.2 -
Color Gamut
REC2020 REC709 DCI REC2020 REC709 DCI REC2020 -
Advanced Settings
Hue 0000000-
Saturation 0000000-
Gamut Clipping On Off Off On Off Off On -
XYZ Format - - Off - - Off - -
Gain
Red Calculated from color temperature -
Green -
Blue -
Black Level
Red 0000000 -
Green 0000000 -
Blue 0000000 -
6 Colors Magenta
Hue 0000000-
Saturation 0000000-
Lightness 0000000 -
Red
Hue 0000000-
Saturation 0000000-
Lightness 0000000 -
Yellow
Hue 0000000-
Saturation 0000000-
Lightness 0000000 -
Green
Hue 0000000-
Saturation 0000000-
Lightness 0000000 -
Cyan
Hue 0000000-
Saturation 0000000-
Lightness 0000000 -
Blue
Hue 0000000-
Saturation 0000000-
Lightness 0000000 -
Note
• Use ColorNavigator NX to set CAL1 / CAL2 / CAL3. These settings cannot be changed in the Setting menu on the
monitor.
• A color mode can be set for each input signal.
• See “Color” (page 16) for details about each item.
• You can disable specic mode selections. For more information, see “Mode Skip” (page 25).

13
Chapter 3 Advanced Adjustments/Settings
Chapter 3 Advanced Adjustments/Settings
This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu.
For the basic setting functions using the buttons on the front of the monitor, see "Chapter 2 Basic
Adjustments/Settings" (page 10).
3-1. Basic Operation of the Setting Menu
1.
Menu display
1. Press any of the buttons (except ).
The operation guide appears.
2. Select .
The Setting menu appears.
2.
Adjusting/setting
1. Choose a menu to adjust/set with , and then select .
The Sub menu appears.

14 Chapter 3 Advanced Adjustments/Settings
2. Choose an item to adjust/set with , and then press .
The Adjustment/Setting menu appears.
3. Adjust/set the selected item with , and then select .
The Sub menu appears.
Selecting during adjustment/setting will cancel the adjustment/setting and restore the state prior to
making changes.
3.
Exiting
1. Select .
The Setting menu appears.
2. Select .
The Setting menu exits.
Note
• The contents of the guide will differ depending on the selected menu or status.
3-2. Setting Menu Functions
●Signal
The signal settings are used to congure advanced settings for input signals, such as the screen
display size and color format.
Function Adjustable Range Description
Input Color Format Auto
YUV 4:2:2*1
YUV 4:4:4*1
YUV*2
RGB
The color space of the input signal can be specied.
Try changing this setting if colors are not displayed correctly.
When inputting YUV 4:2:0, select "Auto".
*1 Only enabled during HDMI input
*2 Only enabled during DisplayPort input

15
Chapter 3 Advanced Adjustments/Settings
Function Adjustable
Range Description
Input Range Auto
Full
Limited (109
% white)
Limited
Depending on the external device, the black and white levels
in the video signal output to the monitor may be restricted. If
the signal is displayed on the monitor in its restricted form,
the blacks will be faint, the whites dull, and contrast will
be reduced. The brightness range of such signals can be
extended to match the actual contrast ratio of the monitor.
• "Auto"
The monitor automatically recognizes the brightness range of
input signals and displays images appropriately.
• "Full"
The input signal brightness range is not extended.
• "Limited (109 % white)"
The brightness range of the input signal is
extended from
16 - 254 (10 bits: 64 - 1019) to 0 - 255 (10 bits: 0 - 1023) for
display.
• "Limited"
The brightness range of the input signal is
extended from
16 - 235 (10 bits: 64 - 940) to 0 - 255 (10 bits: 0 - 1023) for
display.
HDMI
Settings
Noise
Reduction
On
Off
The small noises that occur in dark areas of an image are
reduced. Use this function to reduce noise and roughness in
images.
Note
• This can only be set when there is HDMI input.
• Using the Noise Reduction function may lead to deterioration
of ne images.
Film Detection On
Off
When displaying an interlaced signal, a display method can
be selected. For video, CG, animation, etc., the 24 fps or 30
fps signal is automatically detected, and the optimal image is
displayed.
Note
• This can only be set when there is HDMI input.
• If the video does not display normally when "Film Detection"
is set to "On", change the setting to "Off".
• "Film Detection" is enabled only when a 1080i signal is input.
Signal Information - You can check the information for the input signal.
The following information is displayed:
• Resolution
• Vertical scan frequency
• Input range
• Color format
• Color depth
• Colorimetry
• EOTF

16 Chapter 3 Advanced Adjustments/Settings
●Color
The setting details differ depending on the color mode selected.
When the color mode is Standard Mode (REC2020 / REC709 / DCI / PQ_REC2100 /
PQ_REC709 / PQ_DCI / HLG_REC2100)
Each color mode setting status can be adjusted according to personal preference.
Attention
• The same image may be seen in different colors on multiple monitors due to differences between individual
monitors. Make ne color adjustment visually when matching colors on multiple monitors.
Note
• Use the values shown in "cd/m2", "K", and "%" as a guide only.
Function Adjustable
Range Description
Color Mode REC2020
REC709
DCI
PQ_REC2100
PQ_REC709
PQ_DCI
HLG_REC2100
CAL1
CAL2
CAL3
Switch to the desired mode according to the monitor application.
Note
• For more information on how to switch modes, see "2-3. Switching
the Display Mode (color mode)" (page 11).
• Regarding "CAL1 / CAL2 / CAL3" see page 19.
Brightness
48 cd/m2to
1000 cd/m2
The screen brightness is adjusted by changing the brightness of the
backlight (light source from the LCD back panel).
Note
• If a value that cannot be set is selected, the value will appear in
magenta. In such a case, change the value.
• 48 cd/m2 to 300 cd/m2 can be set in increments of 1, and 300 cd/m2
to 1000 cd/m2 can be set in increments of 100.

17
Chapter 3 Advanced Adjustments/Settings
Function Adjustable
Range Description
Temperature Native
4000 K to
10000 K
D50
D65
Adobe®RGB
sRGB
EBU
REC709
REC1886
REC2020
SMPTE-C
DCI
User
The color temperature can be adjusted.
The color temperature is used to express the chromaticity of "White".
The value is expressed in degrees "K" (Kelvin).
The screen becomes reddish at a low color temperature, and bluish
at a high color temperature, like the temperature of a ame.
Specify a color temperature in units of 100 K, or select a standard
name.
Note
• When you select "Native", the original color of the monitor (Gain:
100 % for each RGB) is displayed.
• "Gain" allows you to perform more advanced adjustment. When
gain is changed, the color temperature is changed to "User".
• The gain preset values are set for each color temperature setting
value
.
Gamma 1.6 to 2.7
Adobe®RGB
sRGB
EBU
REC709
REC1886
REC2020
SMPTE-C
DCI
PQ
HLG
Adjust the gamma.
The brightness of the monitor varies depending on the input signal,
however, the variation rate is not simply proportional to the input
signal. The control performed to keep the balance between the
input signal and the brightness of the monitor is called "Gamma
correction".
Set the gamma, or select a standard name.
Note
• If you select "HLG", you must set "HLG System Gamma".
PQ Clipping 300 cd/m2
500 cd/m2
1000 cd/m2
4000 cd/m2
Off
Areas with brightness equal to or greater than the value set here are
displayed as clipping at this setting value for the PQ signal that is
input to the monitor.
Note
• This can be set when "PQ" is specied for gamma.
• You can check the areas where clipping occurs. For more
information, see "Luminance Warning" (page 22).
HLG System Gamma 1.0 to 1.5 Adjust the system gamma value for the HLG signal that is input to the
monitor.
Note
• This can be set when "HLG" is specied for gamma.
Color Gamut Native
Adobe®RGB
sRGB
EBU
REC709
REC1886
REC2020
SMPTE-C
DCI
Set the color reproduction area (color gamut).
"Color Gamut" is the range of colors that can be represented. Multiple
standards are dened.
Note
• Select "Native", to display the original color gamut of the monitor.
• The method of displaying colors outside the monitor's displayable
range within the dened color gamut can be set. For more
information, see "Gamut Clipping" (page 18).

18 Chapter 3 Advanced Adjustments/Settings
Function Adjustable
Range Description
Advanced
Settings
Hue -100 to 100 The hue can be adjusted.
Note
• Using this function may make some color gradations unavailable
for display.
Saturation -100 to 100 The saturation can be adjusted.
Note
• Using this function may make some color gradations unavailable
for display.
• The minimum value (-100) changes the screen to monochrome.
Gamut
Clipping
On
Off
The method of displaying colors outside the monitor's displayable
range within the color gamut specied in accordance with "Color
Gamut" (page 17) can be set.
• "On"
The range of colors that are
displayable on the monitor will be
accurately displayed in accordance
with the standard. Colors outside
the displayable range will be
saturated.
• "Off"
Displays colors with priority on
the color gradation rather than
the color accuracy. The vertices
of the color gamut dened in the
standard move to a range that
can be displayed by the monitor.
This allows the closest colors
displayable by the monitor to be
displayed.
Color gamut displayable by
the monitor
Color gamut defined by
standard
Color gamut displayed on
screen
Note
• The diagrams shown above are conceptual diagrams, and they do not
display the actual color gamut of the monitor.
• This setting will be disabled if "Native" is selected at "Color Gamut"
(page 17)
.
XYZ Format On
Off
If this function is set to "On", the XYZ signal for digital cinema can be
displayed on the monitor.
Note
• This can be set only when "Color Gamut" (page 17) is set to
"DCI".
• If you select "On", you cannot set "Color Gamut".

19
Chapter 3 Advanced Adjustments/Settings
Function Adjustable
Range Description
Advanced
Settings
Gain 0 % to 100 % The brightness of each color component red, green, and blue is
called Gain. The chromaticity of "white" can be changed by adjusting
the gain.
Note
• Using this function may make some color gradations unavailable for
display.
• The gain value changes according to the color temperature.
• When gain is changed, the color temperature is changed to "User".
Black Level 0 % to 100 % You can adjust the brightness and chromaticity of black by adjusting
the black level for red, green, and blue. Display the black test pattern
or the background and adjust the black level.
6 Colors -100 to 100 The hue, saturation and lightness (brightness) can each be adjusted
for the colors Magenta, Red, Yellow, Green, Cyan, and Blue.
Reset -
Resets any color adjustment values for the currently selected color
mode back to the default settings.
When the color mode is Calibration Mode (CAL mode: CAL1 / CAL2 / CAL3)
You can switch the Color Mode.
Function Adjustable
Range Description
Color Mode REC2020
REC709
DCI
PQ_REC2100
PQ_REC709
PQ_DCI
HLG_REC2100
CAL1
CAL2
CAL3
Switch to the desired mode according to the monitor application.
Note
• For more information on how to switch modes, see "2-3.
Switching the Display Mode (color mode)" (page 11).
• Regarding "REC2020 / REC709 / DCI / PQ_REC2100 / PQ_
REC709 / PQ_DCI / HLG_REC2100", see page 16.
Reset - Resets any calibration targets for the currently selected color mode
back to the default settings.

20 Chapter 3 Advanced Adjustments/Settings
●Screen
The signal settings are used to congure advanced settings for input signals, such as the screen
display size and color format.
Function Adjustable
Range Description
Picture Expansion Auto
Full Screen
Aspect Ratio
Dot by Dot
The screen size of the monitor display can be changed.
• "Auto"
The monitor automatically changes the screen size according
to the resolution information and aspect ratio information from
the input signal.
• "Full Screen"
Displays an image in full screen. Images are distorted in some
cases because the vertical rate is not equal to the horizontal
rate.
• "Aspect Ratio"
Displays an image in full screen. However, since aspect
ratios are maintained, part of an image may not be visible in
horizontal or vertical direction.
• "Dot by Dot"
Displays the image at the set resolution or at the size specied
by the input signal.
Note
• Example settings
- Full Screen
- Aspect Ratio
- Dot by Dot (Input
Signal)
