Eizo FlexScan EV3895 User manual

Important
Please read this “User’s Manual”, and “PRECAUTIONS” (separate
volume) carefully to familiarize yourself with safe and e󰀨ective
usage.
•Refer to the “Setup Guide” for information on the installation /
connection of the monitor.
•For the latest product information including the “User’s Manual”,
refer to our web site :
www.eizoglobal.com
Color LCD Monitor
User’s Manual

Location of Caution Statement
This product has been adjusted specically for use in the region to which it was originally shipped. If
operated outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless
prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every
e󰀨ort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.
2

Notice for this monitor
About the Usage of This Product
This product is suited to general purposes like creating documents, viewing multimedia content (Assuming
usage of approximately 12 hours per day).
If using this product for the following kinds of applications, where an extremely high degree of reliability and
safety is required, then measures should be in place to maintain safety while using this product.
• Transportation equipment (ships, aircraft, trains, and automobiles)
• Safety devices (Disaster prevention systems, security control systems, etc.)
• Life-critical devices (medical devices, such as life-support devices and operating room devices)
• Nuclear energy control devices (Nuclear energy control systems, security control systems of nuclear facilities, etc.)
• Major system communication devices (operation control systems of transportation systems, air tra󰀩c control systems, etc.)
This product has been adjusted specically for use in the region to which it was originally shipped. If the
product is used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
• Power cords provided with the product
• Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
About the LCD Panel
It takes about 30 minutes (under our measurement conditions) for the monitor display to stabilize. Please
wait 30 minutes or more after the monitor power has been turned on, and then adjust the monitor.
Monitors should be set to a lower brightness to prevent a loss in the screen quality caused by long-term use
and to maintain stable use.
When the screen image is changed after displaying the same image for extended periods of time, an
afterimage may appear. Use the screen saver or power save function to avoid displaying the same image for
extended periods of time. Depending on the image, an afterimage may appear even if it was displayed for
a short period of time. To remove such a phenomenon, change the image or keep the power turned o󰀨 for
several hours.
If the monitor displays continuously over a long period of time, dark smudges or burn-in may appear. To
maximize the life of the monitor, we recommend the monitor be turned o󰀨 periodically.
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may
appear on the LCD panel, this is not a malfunction. Percentage of e󰀨ective dots: 99.9994 % or higher.
The backlight of the LCD panel has a xed lifetime. Depending on the usage pattern, such as usage for
long continuous periods, the lifespan of the backlight may run out sooner, requiring replacement. When the
screen becomes dark or begins to icker, please contact your local EIZO representative.
Do not press on the LCD panel or edge of the frame strongly, as this may result in display malfunctions, such
as interference patterns, etc. If pressure is continuously applied to the LCD panel surface, the liquid crystal
may deteriorate or the LCD panel may be damaged. (If the pressure marks remain on the panel, leave the
monitor with a black or white screen. The symptom may disappear.)
Do not scratch or press on the LCD panel with any sharp objects, at this may result in damage to the LCD
panel. Do not attempt to brush with tissues as this may scratch the panel.
3
Notice for this monitor

About the Installation
If you place this product on a lacquer-coated desk, the color may adhere to the bottom of the stand due to
the composition of the rubber. Check the desk surface before use.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew
condensation may occur on the interior and exterior surfaces of the monitor. In that case, do not turn the
monitor on. Instead wait until the dew condensation disappears, otherwise it may cause some damage to the
monitor.
About the Maintenance
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer
to “Cleaning” (page 4)).
Cleaning
The stains on the cabinet and LCD panel surface can be removed by moistening part of a soft cloth with
water or by using ScreenCleaner (available as an option).
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet
or LCD panel, and also quality deterioration of the image.
• Never use thinner, benzine, wax, or abrasive cleaner as they may damage the cabinet or LCD panel surface.
To use the monitor comfortably
• An excessively dark or bright screen may a󰀨ect your eyes. Adjust the brightness of the monitor
according to the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.
4Notice for this monitor

CONTENTS
Notice for this monitor ......................................... 3
Cleaning .................................................................... 4
To use the monitor comfortably ............................. 4
CONTENTS............................................................. 5
Chapter 1 Introduction....................................... 6
1-1. Features ......................................................... 6
●Curved Monitor ................................................ 6
●Free Layout ..................................................... 6
●Linking the Input Signal and USB Port ........... 6
●Docking Station Function ................................ 6
●Support for DisplayPort Alt Mode / USB
Power Delivery ................................................ 7
●Reduction of Power Consumption .................. 7
●Realizing More Convenient Operations
Using Screen InStyle ...................................... 8
1-2. Controls and Functions ............................... 8
●Front ................................................................ 8
●Rear ................................................................. 9
1-3. Supported Resolutions...............................10
●DisplayPort .....................................................10
●HDMI ..............................................................11
●USB-C ............................................................12
1-4. Changing the Computer Display Settings...13
●Windows 10 ....................................................13
●Windows 8.1 ...................................................13
●macOS ...........................................................13
Chapter 2 Basic Adjustment / Setting ............ 14
2-1. Switch Operation Method ...........................14
2-2. Switching Input Signals ..............................15
2-3. Switching Display Modes (Color Modes)...15
●Display Modes ................................................15
2-4. Adjusting Brightness ..................................16
2-5. Adjusting Volume.........................................16
Chapter 3 Advanced Adjustment / Setting .... 17
3-1. Basic Operation of the Setting Menu ........17
3-2. Setting Menu Functions ..............................18
●Color Adjustment ............................................18
●Signal Settings ...............................................21
●Preference Settings ...................................... 23
●EcoView Settings .......................................... 25
●Language ...................................................... 26
●Information .................................................... 26
Chapter 4 Connecting Multiple PCs ............... 27
4-1. Connecting Multiple PCs ........................... 27
●Connection examples ................................... 27
4-2. Using PbyP Display .................................... 28
●PbyP Settings ................................................ 28
●Swapping the Main Window of Three
Window Display ............................................. 30
4-3. Linking the Input Signal and USB Port .....31
●Connection Example ......................................31
Chapter 5 Administrator Settings................... 33
5-1. Basic Operation of the “Administrator
Settings” Menu............................................ 33
5-2. Functions of the “Administrator
Settings” Menu............................................ 34
Chapter 6 Troubleshooting.............................. 36
6-1. No Picture .................................................... 36
6-2. Imaging Problems....................................... 38
6-3. Other Problems........................................... 39
Chapter 7 Attaching/Removing the Stand ..... 41
7-1. Removing the Stand ....................................41
7-2. Attaching the Optional Arm....................... 42
7-3. Attaching the original stand...................... 43
Chapter 8 Reference ........................................ 44
8-1. Using the Docking Station Function ........ 44
●Connection Procedure .................................. 44
8-2. Specications ............................................. 46
●Accessories ....................................................47
Appendix.............................................................. 48
Trademark ............................................................... 48
License .................................................................... 48
5
CONTENTS

Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
●Curved Monitor
This monitor comes equipped with a curved LCD panel with a resolution of 3840 x 1600. Two
windows can be aligned side-by-side for seamless display.
●Free Layout
This monitor comes equipped with a PbyP (Picture by Picture) function that can display multiple input
signals at the same time. Three window Picture by Picture (3 PbyP) display and two window Picture
by Picture (2 PbyP) display are possible.
When using three window Picture by Picture (3 PbyP) display, you can swap the main window by
selecting the operation switch ( ) on the front of the monitor. (page 30)
●Linking the Input Signal and USB Port
When two or three PCs are connected to one monitor, you can link the input signals with the USB
upstream ports. This allows you to use a USB device connected to the monitor from multiple PCs by
switching between them.
Select the operation switch ( ) on the front of the monitor to swap to an enabled USB upstream port.
(page 32)
●Docking Station Function
This product is equipped with a LAN port and USB hub so that it can be used as a docking station.
By connecting a USB Type-C® (hereinafter USB-C®) cable, you can create a stable network
environment even on notebook PCs or tablet devices that are not equipped with LAN ports. You can
also use USB-compatible peripheral devices and charge smartphones. (page 44)
6Chapter 1 Introduction

●Support for DisplayPort Alt Mode / USB Power Delivery
This product is equipped with a USB-C connector and supports the transmission of video signals
(DisplayPort Alt Mode) as well as the charging of USB devices (USB Power Delivery).
It supplies a maximum of 85 W of power to a connected notebook PC when used as an external
monitor.
Video signals
Power supply
Note
• To use the charging function, the connected device must support device charging by using USB Power
Delivery. Charging may not be possible depending on the connected external device.
• Only when one of the following USB-C cables is used, a maximum power of 85 W can be supplied.
-CC200SS-5A or CC200SSW-5A (Included)
- CC100 (Separately sold accessory)
• To display video signals, the connected device must support DisplayPort over USB Type-C (DisplayPort Alt
Mode).
• Connected devices can be charged even when the monitor is in power saving mode.
• When “Compatibility Mode” is set to “On” in the “Administrator Settings” menu, connected devices can be
charged even when the power of the monitor is turned o󰀨.
●Reduction of Power Consumption
This product provides a function that automatically adjusts the screen brightness to reduce power
consumption *1. Power Reduction, CO2 Reduction, and Eco Performance Level can be checked on
the "EcoView Settings" menu. (page 25)
• Auto EcoView
The ambient light sensor on the front of the monitor detects the ambient brightness to automatically
adjust the screen brightness to a comfortable level.
• EcoView Optimizer 2
The monitor automatically adjusts the screen brightness according to the white level of the input
signal. This function can reduce power consumption while maintaining the brightness specied by
the input signal.
*1 Reference values
Maximum power consumption: 194 W (when a USB device is connected and the speakers are working),
standard power consumption: 28 W (brightness 120 cd/m2, when no USB device is connected and the
speakers are not working, at default settings)
7
Chapter 1 Introduction

●Realizing More Convenient Operations Using Screen InStyle
The "Screen InStyle" monitor control utility enables you to use the monitor more conveniently.
• The monitor color mode can be switched automatically to suit the software to be used.
• You can switch input signals using the shortcut keys on the keyboard.
• When multiple monitors are installed, you can turn the power on and o󰀨 or change the color mode
of all monitors at the same time.
Note
• Screen InStyle can be downloaded from our web site (www.eizoglobal.com).
• The Windows operating systems are only supported.
1-2. Controls and Functions
●Front
3
54
1 1
2
1. Speakers Outputs audio.
2. Ambient light sensor Detects ambient brightness. If you use Auto EcoView, the screen brightness is
automatically adjusted according to the ambient brightness (page 25).
3. Power indicator Indicates the monitor’s operation status.
White: Normal operation mode
Orange: Power saving mode
OFF: Main power / power o󰀨
4. Operation switches Displays menus. Operate the switches according to the operation guide (page 17).
5. Power switch Turns the power on or o󰀨.
8Chapter 1 Introduction

●Rear
12
11
10
9
14
13
8
7
6
16
17
19
15
18
6
6. Handle This handle is used for transportation.
7. Security lock slot Complies with Kensington’s MicroSaver security system.
8. Lock button Use this button to remove the monitor from the stand.
9. Cable holder Stores the cables.
10. Stand*1 Adjusts the height and angle (tilt and swivel) of the monitor.
11. Power connector Connects the power cord.
12. Main power switch Turns the main power on or o󰀨. : On, : O󰀨
13. USB-A connector (downstream) Connects to a peripheral USB device (page 44).
14. Headphone jack Connects to headphones.
15. HDMI connector Connects to a PC with HDMI output.
16. DisplayPort connector Connects to a PC with DisplayPort output.
17. USB-C connector (upstream) Connects to a PC with USB-C output. This also transmits the
USB signal that is necessary for using software that requires USB
connection or when using the docking station function (page 44).
18. USB-B connector (upstream) Connect the USB cable when using software that requires USB
connection. This makes it possible to connect USB devices such as a
mouse or keyboard to the monitor and use them from multiple PCs.
19. LAN port (RJ-45) When using a network connection with the docking station function
(page 44), this connects to a network hub or router with a LAN
cable.
*1 By removing the stand from the monitor, it is possible to attach the monitor to a di󰀨erent stand or arm.
9
Chapter 1 Introduction

1-3. Supported Resolutions
The monitor supports the following resolutions.
●DisplayPort
Two window display (2 PbyP)
Layout 1 Layout 2 Layout 3
PbyP-A PbyP-A PbyP-CPbyP-B PbyP-BPbyP-C
Three window display (3 PbyP)
Layout 1 Layout 2 Layout 3
PbyP-B
PbyP-D
PbyP-D PbyP-D
PbyP-D
PbyP-B PbyP-C PbyP-C PbyP-C
Resolution
Vertical Scan
Frequency
(Hz)
Scan Format
Single Window
Display*1 PbyP Display
Version
1.1
Version
1.2 PbyP-A PbyP-B PbyP-C PbyP-D
640 × 480 59.940 Progressive √ √ √ √ √ √
640 × 480 60.000 Progressive √ √ √ √ √ √
720 × 400 70.087 Progressive √ √ √ √ √ √
720 × 480 59.940 Progressive √ √ √ √ √ √
720 × 480 59.941 Progressive √ √ √ √ √ √
720 × 480 60.000 Progressive √ √ √ √ √ √
800 × 600 60.317 Progressive √ √ √ √ √ √
1024 × 768 60.004 Progressive √ √ √ √ √ √
1280 × 720 59.855 Progressive √ √ √ √ √ √
1280 × 720 59.940 Progressive √ √ √ √ √ √
1280 × 720 59.979 Progressive √ √ √ √ √ √
1280 × 720 60.000 Progressive √ √ √ √ √ √
1280 × 800 59.810 Progressive √ √ √ √ √ √*4
1280 × 800 59.910 Progressive √ √ √ √ √ √*4
1280 × 1024 60.020 Progressive √ √ √ √ √ √*3
1280 × 1600 59.910 Progressive - - - - √*2 -
1600 × 900 60.000 Progressive √ √ √ - - -
1600 × 1200 60.000 Progressive √ √ √ - - -
1680 × 1050 59.883 Progressive √ √ √ - - -
1680 × 1050 59.954 Progressive √ √ √ - - -
1920 × 1080 59.940 Progressive √ √ √ √ - √*3
1920 × 1080 60.000 Progressive √ √ √ √ - √*3
1920 × 1600 59.950 Progressive - - √*2 ---
2560 × 1600 59.972 Progressive √ √ - √*2 - √*2 *3
3840 × 1600 29.998 Progressive √*2 √ ----
3840 × 1600 59.994 Progressive - √*2 ----
*1 The applicable signal varies depending on the “Signal Format” settings (refer to “Signal Format” (page 35))
*2 Recommended resolution
*3 Displayed at reduced size
*4 Native resolution of the display area
10 Chapter 1 Introduction

●HDMI
Two window display (2 PbyP)
Layout 1 Layout 2 Layout 3
PbyP-A PbyP-A PbyP-CPbyP-B PbyP-BPbyP-C
Three window display (3 PbyP)
Layout 1 Layout 2 Layout 3
PbyP-B
PbyP-D
PbyP-D PbyP-D
PbyP-D
PbyP-B PbyP-C PbyP-C PbyP-C
Resolution
Vertical Scan
Frequency
(Hz)
Scan Format
Single Window
Display*1 PbyP Display
WQHD+
60Hz
WQHD+
30H
z
PbyP-A PbyP-B PbyP-C PbyP-D
640 × 480 59.940 Progressive √ √ √ √ √ √
640 × 480 60.000 Progressive √ √ √ √ √ √
720 × 400 70.087 Progressive √ √ √ √ √ √
720 × 480 59.940 Progressive √ √ √ √ √ √
720 × 480 59.941 Progressive √ √ √ √ √ √
720 × 480 60.000 Progressive √ √ √ √ √ √
720 × 576 50.000 Progressive √ √ √ √ √ √
800 × 600 60.317 Progressive √ √ √ √ √ √
1024 × 768 60.004 Progressive √ √ √ √ √ √
1280 × 720 50.000 Progressive √ √ √ √ √ √
1280 × 720 59.855 Progressive √ √ √ √ √ √
1280 × 720 59.940 Progressive √ √ √ √ √ √
1280 × 720 59.979 Progressive √ √ √ √ √ √
1280 × 720 60.000 Progressive √ √ √ √ √ √
1280 × 800 59.810 Progressive √ √ √ √ √ √*4
1280 × 800 59.910 Progressive √ √ √ √ √ √*4
1280 × 1024 60.020 Progressive √ √ √ √ √ √*3
1280 × 1600 59.910 Progressive - - - - √*2 -
1600 × 900 60.000 Progressive √ √ √ - - -
1600 × 1200 60.000 Progressive √ √ √ - - -
1680 × 1050 59.883 Progressive √ √ √ - - -
1680 × 1050 59.954 Progressive √ √ √ - - -
1920 × 1080 50.000 Progressive √ √ √ √ - √*3
1920 × 1080 59.940 Progressive √ √ √ √ - √*3
1920 × 1080 59.940 Interlace √ √ √ √ - √*3
1920 × 1080 60.000 Progressive √ √ √ √ - √*3
1920 × 1080 60.000 Interlace √ √ √ √ - √*3
1920 × 1600 59.950 Progressive - - √*2 ---
2560 × 1600 59.972 Progressive √ √ - √*2 - √*2 *3
3840 × 1600 29.998 Progressive √ √*2 ----
3840 × 1600 59.994 Progressive √*2 - ----
*1 The applicable signal varies depending on the “Signal Format” settings (refer to “Signal Format” (page 35))
*2 Recommended resolution
*3 Displayed at reduced size
*4 Native resolution of the display area
11
Chapter 1 Introduction

●USB-C
Two window display (2 PbyP)
Layout 1 Layout 2 Layout 3
PbyP-A PbyP-A PbyP-CPbyP-B PbyP-BPbyP-C
Three window display (3 PbyP)
Layout 1 Layout 2 Layout 3
PbyP-B
PbyP-D
PbyP-D PbyP-D
PbyP-D
PbyP-B PbyP-C PbyP-C PbyP-C
Resolution
Vertical Scan
Frequency
(Hz)
Scan Format
Single Window
Display*1 PbyP Display
WQHD+
60Hz /
USB2.0
WQHD+
30Hz /
USB3.1
PbyP-A PbyP-B PbyP-C PbyP-D
640 × 480 59.940 Progressive √ √ √ √ √ √
640 × 480 60.000 Progressive √ √ √ √ √ √
720 × 400 70.087 Progressive √ √ √ √ √ √
720 × 480 59.940 Progressive √ √ √ √ √ √
720 × 480 59.941 Progressive √ √ √ √ √ √
720 × 480 60.000 Progressive √ √ √ √ √ √
800 × 600 60.317 Progressive √ √ √ √ √ √
1024 × 768 60.004 Progressive √ √ √ √ √ √
1280 × 720 59.855 Progressive √ √ √ √ √ √
1280 × 720 59.940 Progressive √ √ √ √ √ √
1280 × 720 59.979 Progressive √ √ √ √ √ √
1280 × 720 60.000 Progressive √ √ √ √ √ √
1280 × 800 59.810 Progressive √ √ √ √ √ √*4
1280 × 800 59.910 Progressive √ √ √ √ √ √*4
1280 × 1024 60.020 Progressive √ √ √ √ √ √*3
1280 × 1600 59.910 Progressive - - - - √*2 -
1600 × 900 60.000 Progressive √ √ √ - - -
1600 × 1200 60.000 Progressive √ √ √ - - -
1680 × 1050 59.883 Progressive √ √ √ - - -
1680 × 1050 59.954 Progressive √ √ √ - - -
1920 × 1080 59.940 Progressive √ √ √ √ - √*3
1920 × 1080 60.000 Progressive √ √ √ √ - √*3
1920 × 1600 59.950 Progressive - - √*2 ---
2560 × 1600 59.972 Progressive √ √ - √*2 - √*2 *3
3840 × 1600 29.998 Progressive √ √*2 ----
3840 × 1600 59.994 Progressive √*2 - ----
*1 The applicable signal varies depending on the “Signal Format” settings (refer to “Signal Format” (page 35))
*2 Recommended resolution
*3 Displayed at reduced size
*4 Native resolution of the display area
12 Chapter 1 Introduction

1-4. Changing the Computer Display Settings
If the image is not displayed properly after connecting the monitor to a PC, follow the procedure below to
change the display settings on the computer.
●Windows 10
1. Right-click the mouse anywhere on the desktop except on icons. A menu is displayed.
2. From the displayed menu, click “Display Settings”. The “Settings” screen is displayed.
3. If multiple monitors, including notebook PC screens, are connected to the computer, select “Extend
these displays” in the “Multiple displays” menu, and then click “Keep changes” on the conrmation
screen. After changing the settings, select a monitor in the “Select and rearrange displays” menu.
4. Select the “Make this my main display” option in the “Multiple displays” menu. This enables the
monitor to display images properly.
5. Conrm that the recommended resolution for the monitor is set in the “Resolution” menu.
(“(Recommended)” is displayed after the resolution.)
6. To change the size of text and icons, select a magnication in the menu of zoom percentages
according to personal preference.
7. If a message prompting you to sign out is displayed after changing the settings, sign out and then
sign in again.
●Windows 8.1
1. Click the “Desktop” tile on the Start Screen to display the desktop.
2. Right-click the mouse anywhere on the desktop except on icons. A menu is displayed.
3. From the displayed menu, click “Screen resolution”. The settings screen is displayed.
4. If multiple monitors, including notebook PC screens, are connected to the computer, select “Extend
these displays” in the “Multiple displays” menu, and then click “Apply”. Click “Keep changes” on
the conrmation screen.
5. Select a monitor in the “Display” menu, and then select the “Make this my main display” option
and click “Apply”. This enables the monitor to display images properly.
6. Conrm that the recommended resolution for the monitor is set in the “Resolution” menu.
(“(recommended)” is displayed after the resolution.)
7. To change the size of text and icons, click “Make text and other items larger or smaller”, select a
size according to personal preference on the settings screen, and then click “Apply”.
8. If a message prompting you to sign out/log o󰀨 is displayed after changing the settings, sign out/
log o󰀨 and then sign in/log in again.
●macOS
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” panel is displayed, click “Displays”.
3. If multiple monitors, including notebook PC screens, are connected to the computer, make sure
that “Mirror Displays” is not selected on the “Arrangement” tab. If it is selected, remove the check
mark.
4. Select the “Display” tab, and make sure that “Default for display” is selected for “Resolution”. If
it is not selected, add a check mark. The correct resolution has now been set for your display.
Close the “System Preferences” panel. If multiple monitors, including notebook PC screens, are
connected to the computer, congure these settings in “Display” on each monitor.
5. To select a resolution according to personal preference, select “Scaled” and then select a
resolution (either from a list or icons), and then close the panel.
13
Chapter 1 Introduction

Chapter 2 Basic Adjustment / Setting
The input signals and display modes of this monitor can be switched according to your usage environment
and preferences.
This chapter describes the basic functions that can be adjusted and set using the switches on the front of the
monitor.
For advanced adjustment and setting procedures using the Setting menu, see “Chapter 3 Advanced
Adjustment / Setting” (page 17).
2-1. Switch Operation Method
1.
Displaying the operation guide
1. Touch any switch (except ).
The operation guide appears on the screen.
Note
• Do not directly touch the operation guide that appears on the screen. There are switches below the operation
guide that can be touched to perform adjustment / setting.
2.
Adjusting / setting
1. Touch a switch for adjustment / setting.
The Adjustment / Setting menu appears.
(A submenu may also be displayed. In this case, select the item for adjustment / setting using and
select .)
2. Perform adjustment / setting with the switches and select to accept the changes.
3.
Exiting
1. Select to exit the menu.
14 Chapter 2 Basic Adjustment / Setting

2-2. Switching Input Signals
When a monitor has multiple signal inputs, the signal to display on-screen can be changed.
For details on PbyP, see “4-2. Using PbyP Display” (page 28).
Note
• "Screen InStyle" allows you to switch input signals using the shortcut keys on the keyboard.
2-3. Switching Display Modes (Color Modes)
This product is preinstalled with color modes for various display purposes.
By switching the mode according to the purpose and contents of the display, you can display images in
an appropriate manner.
●Display Modes
Color Mode Purpose
User1
User2
Select either of these modes to set a user-dened display mode.
sRGB This mode is suitable for matching color reproduction with peripheral devices that
support sRGB, such as when printing photos taken using a digital camera.
Paper This mode uses color tones and contrast similar to that of paper to produce a printed
paper e󰀨ect. It is suitable for displaying images from media such as books and
documents.
Movie This mode displays moving images brightly and with a clear-cut three-dimensional
appearance. It is suitable for playing back video content.
DICOM Select this mode to simply display medical purpose digital images based on DICOM®
Part 14.
Attention
• This is not intended to be used for diagnostic purposes.
Note
• "Screen InStyle" allows you to select the color mode automatically according to the software in use.
• In Paper mode, the amount of blue light emitted from the screen is reduced by changing the color tone and
controlling the brightness.
15
Chapter 2 Basic Adjustment / Setting

2-4. Adjusting Brightness
The brightness of the screen can be adjusted to suit the installation environment or personal preference.
The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD
back panel).
Setting Value
0 to 100
2-5. Adjusting Volume
The volume of the speakers and headphones can be set individually.
Setting Value
0 to 30
Speaker volume
Headphone volume (when the
headphones are connected)
16 Chapter 2 Basic Adjustment / Setting

Chapter 3 Advanced Adjustment / Setting
This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu.
For basic functions, see “Chapter 2 Basic Adjustment / Setting” (page 14).
3-1. Basic Operation of the Setting Menu
1.
Menu display
1. Touch any switch (except ).
The operation guide appears.
2. Select .
The Setting menu appears.
2.
Adjusting / setting
1. Select a menu to adjust / set with and select .
The Sub menu appears.
2. Select an item to adjust / set with and select .
The Adjustment / Setting menu appears.
3. Perform adjustment / setting with or and select to accept the changes.
The Sub menu appears.
Selecting during adjustment / setting will cancel the adjustment / setting and restore the state prior to
making changes.
3.
Exiting
1. Selecting several times will terminate the Setting menu.
17
Chapter 3 Advanced Adjustment / Setting

3-2. Setting Menu Functions
●Color Adjustment
The color mode settings can be adjusted according to personal preference.
Functions that can be adjusted di󰀨er depending on the color mode.
√: Adjustable -: Not adjustable
Function
Color Mode
User1
User2 sRGB Paper Movie DICOM
Brightness √√√√-
Contrast √- - √-
Temperature √-√ √ -
Gamma √----
Super Resolution √-√ √ -
Advanced
Settings
Overdrive √----
Hue √- - √-
Saturation √- - √-
Gain √----
Reset √√√√-
Attention
• It takes about 30 minutes for the monitor display to stabilize. Please wait 30 minutes or more after power to
the monitor has been turned on before adjusting the monitor.
• The same image may be observed in di󰀨erent colors on multiple monitors due to monitor-specic
characteristics. Make ne color adjustments visually when matching colors across multiple monitors. Follow
the procedure below to adjust and match colors across multiple monitors.
1. Display a white screen on each monitor.
2. Use one of the monitors as a visual reference point to make adjustments to the “Brightness”,
“Temperature”, and “Gain” of the other monitors.
• When Auto EcoView is set to “On”, the same brightness setting is shared by all of the color modes and cannot
be set individually for each color mode.
18 Chapter 3 Advanced Adjustment / Setting

Function Setting Value Description
Color Mode User1
User2
sRGB
Paper
Movie
DICOM
Select the desired mode according to the monitor application.
The color mode settings can also be adjusted according to
personal preference. Select the mode for adjustment and perform
adjustment using the relevant functions.
Note
• For details on the adjustment status of each mode, see “2-3.
Switching Display Modes (Color Modes)” (page 15).
Brightness 0 to 100 The screen brightness is adjusted by changing the brightness of
the backlight (light source from the LCD back panel).
Note
• If the image is too dark even when the brightness is set to 100,
adjust the contrast.
Contrast 0 to 100 The brightness of the screen is adjusted by varying the video
signal level.
Note
• A contrast of 50 displays every color gradation.
• When adjusting the monitor, it is recommended to perform
brightness adjustment, which does not lose gradation
characteristics, prior to contrast adjustment.
• Perform contrast adjustment in the following cases.
- If the image is too dark even when the brightness is set to
100 (Set the contrast to higher than 50.)
Temperature O󰀨
4000 K to 10000
K
(in increments
of 500 K. 9300 K
is included.)
Adjust the color temperature.
The color temperature is normally used to express the hue of
“White” and/or “Black” with a numerical value. The value is
expressed in degrees “K” (Kelvin).
The screen becomes reddish at low color temperatures and bluish
at high color temperatures, similar to the temperatures of a ame.
A gain preset value is set for each color temperature setting value.
Note
• The value shown in “K” is available only as a reference.
• “Gain” allows you to perform more advanced adjustment.
• If set to “O󰀨”, the image is displayed in the preset color of the
LCD panel (Gain: 100 for each RGB channel).
• When the gain is changed, the color temperature setting
changes to “O󰀨”.
Gamma 1.8
2.0
2.2
2.4
Adjust the gamma.
While the brightness of the monitor varies depending on the
video level of the input signal, the variation rate is not directly
proportional to the input signal. Maintaining the balance between
the input signal and brightness of the monitor is referred to as
“Gamma correction”.
Note
• If “sRGB” is selected for the color mode, “sRGB” is displayed
for the gamma value.
• If “Paper” is selected for the color mode, “Paper” is displayed
for the gamma value.
• If “DICOM” is selected for the color mode, “DICOM” is
displayed for the gamma value.
Super Resolution O󰀨
1
2
Image blur can be reduced by enhancing its outline.
Select “1” or “2” (outlines are more enhanced than “1”) according
to personal preference.
19
Chapter 3 Advanced Adjustment / Setting

Function Setting Value Description
Advanced
Settings
Overdrive O󰀨
On
This function allows you to set the overdrive based on the use of
the monitor.
Image lag can be reduced by using the “On” setting when
displaying moving images.
Note
• Depending on the display resolution and the setting of “Picture
Expansion” (page 21), overdrive may be set to “O󰀨”.
Hue -50 to 50 Adjust the hue.
Note
• Using this function may prevent some color gradations from
being able to be displayed.
Saturation -50 to 50 Adjust the color saturation.
Note
• Using this function may prevent some color gradations from
being able to be displayed.
• The minimum value (-50) changes the screen to monochrome.
Gain 0 to 100 The brightness of each red, green, and blue color component
is referred to as “Gain”. The hue of “white” can be changed by
adjusting the gain.
Note
• Using this function may prevent some color gradations from
being able to be displayed.
• The gain value changes according to the color temperature.
• When the gain is changed, the color temperature setting
changes to “O󰀨”.
Reset - Reset any color adjustments for the currently selected color mode
back to the default settings.
20 Chapter 3 Advanced Adjustment / Setting
