Please read this “User’s Manual”, and “PRECAUTIONS” (separate
volume) carefully to familiarize yourself with safe and effective usage.
•Refer to the “Setup Guide” for information on the installation /
connection of the monitor.
•For the latest product information including the “User’s Manual”,
refer to our web site :
http://www.eizoglobal.com
Color LCD Monitor
User’s Manual

2
Location of Caution Statement
This product has been adjusted specically for use in the region to which it was originally shipped. If
operated outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless
prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every
effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.

3
Notice for this monitor
Notice for this monitor
Aside from creating documents, viewing multimedia content, and other general purposes, this product is also
suited to applications such as creating CAD data and other drawings (Assuming usage of approximately 12
hours per day).
If using this product for the following kinds of applications, where an extremely high degree of reliability and
safety is required, then measures should be in place to maintain safety while using this product.
• Transportation equipment (ships, aircraft, trains, and automobiles)
• Safety devices (Disaster prevention systems, security control systems, etc.)
• Life-critical devices (medical devices, such as life-support devices and operating room devices)
• Nuclear energy control devices (Nuclear energy control systems, security control systems of nuclear facilities, etc.)
• Major system communication devices (operation control systems of transportation systems, air trafc control systems, etc.)
This product has been adjusted specically for use in the region to which it was originally shipped. If the
product is used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
• Power cords provided with the product
• Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
If you place this product on a lacquer-coated desk, the color may adhere to the bottom of the stand due to
the composition of the rubber. Check the desk surface before use.
It takes about 30 minutes (under our measurement conditions) for the monitor display to stabilize. Please
wait 30 minutes or more after the monitor power has been turned on, and then adjust the monitor.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and
maintain a stable display.
When the screen image is changed after displaying the same image for extended periods of time, an
afterimage may appear. Use the screen saver or power save function to avoid displaying the same image for
extended periods of time. Depending on the image, an afterimage may appear even if it was displayed for
a short period of time. To remove such a phenomenon, change the image or keep the power turned off for
several hours.
If the monitor displays continuously over a long period of time, dark smudges or burn-in may appear. To
maximize the life of the monitor, we recommend the monitor be turned off periodically.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer
to “Cleaning” (page 4)).
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may
appear on the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994 % or higher.
The backlight of the LCD panel has a xed lifetime. Depending on the usage pattern, such as usage for
long continuous periods, the lifespan of the backlight may run out sooner, requiring replacement. When the
screen becomes dark or begins to icker, please contact your local EIZO representative.
Do not press on the LCD panel or edge of the frame strongly, as this may result in display malfunctions, such
as interference patterns, etc. If pressure is continuously applied to the LCD panel surface, the liquid crystal
may deteriorate or the LCD panel may be damaged. (If the pressure marks remain on the panel, leave the
monitor with a black or white screen. The symptom may disappear.)

4Notice for this monitor
Do not scratch or press on the LCD panel with any sharp objects, at this may result in damage to the LCD
panel. Do not attempt to brush with tissues as this may scratch the panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew
condensation may occur on the interior and exterior surfaces of the monitor. In that case, do not turn the
monitor on. Instead wait until the dew condensation disappears, otherwise it may cause some damage to the
monitor.
Cleaning
The stains on the cabinet and LCD panel surface can be removed by moistening part of a soft cloth with water.
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet
or LCD panel, and also quality deterioration of the image.
• Never use thinner, benzine, wax, or abrasive cleaner as they may damage the cabinet or LCD panel surface.
Note
• It is recommended that ScreenCleaner (available as an option) be used to clean the cabinet and LCD panel surface.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor
according to the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

CONTENTS
Notice for this monitor ......................................... 3
Cleaning .................................................................... 4
To use the monitor comfortably ............................. 4
CONTENTS............................................................. 5
Chapter 1 Introduction....................................... 6
1-1. Features ......................................................... 6
●Support for DisplayPort over USB
Type-C (DP Alt Mode) / USB Power Delivery ... 6
●High Degree of Flexibility for Installation ........ 7
●Reduction of Power Consumption .................. 7
●Realizing More Convenient Operations
Using Screen InStyle ...................................... 7
1-2. Controls and Functions ............................... 8
●Front ................................................................ 8
●Rear ................................................................. 9
1-3. Supported Resolutions...............................10
●For DisplayPort ..............................................10
●For HDMI ........................................................11
●For USB-C ......................................................12
1-4. Changing the Computer Display Settings ...13
●Windows 10 ....................................................13
●Windows 8.1 / Windows 7 ..............................13
●macOS ...........................................................13
Chapter 2 Basic Adjustment / Setting ............ 14
2-1. Switch Operation Method ...........................14
2-2. Switching Input Signals ..............................15
●PbyP display ...................................................15
●PinP display ....................................................17
2-3. Switching Display Modes (Color Modes) ...18
●Display Modes ................................................18
2-4. Conserving Energy......................................19
2-5. Adjusting Brightness ..................................21
2-6. Adjusting Volume.........................................21
Chapter 3 Advanced Adjustment / Setting .... 22
3-1. Basic Operation of the Setting Menu ....... 22
3-2. Setting Menu Functions ............................. 23
●Color Adjustment ........................................... 23
●Signal Settings .............................................. 26
●Preference Settings ...................................... 28
●Language ...................................................... 29
●Information .................................................... 30
Chapter 4 Administrator Settings................... 31
4-1. Basic Operation of the “Administrator
Settings” Menu.............................................31
4-2. Functions of the “Administrator
Settings” Menu............................................ 32
Chapter 5 Troubleshooting.............................. 34
5-1. No Picture .................................................... 34
5-2. Imaging Problems....................................... 35
5-3. Other Problems........................................... 36
Chapter 6 Reference ........................................ 37
6-1. Attaching the Optional Arm........................37
●Attaching the optional arm (or optional
stand) ............................................................ 38
●Attaching the original stand .......................... 38
6-2. Detaching/Attaching the Cable Holder..... 39
●Detaching the cable holder ........................... 39
●Attaching the cable holder ............................ 39
6-3. Detaching / Attaching the Cable Cover .... 40
●Attaching the cable cover .............................. 40
●Detaching the cable cover .............................41
6-4. Connecting Multiple PCs ........................... 42
●Connection examples ....................................42
6-5. Using the USB Hub Function..................... 43
●Connection procedure................................... 43
6-6. Specications ............................................. 44
●Accessories ................................................... 45
Appendix.............................................................. 46
Trademark ............................................................... 46
License .................................................................... 46
ENERGY STAR ........................................................ 46
FCC Declaration of Conformity .............................47
5
CONTENTS

Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
●
Support for DisplayPort over USB Type-C (DP Alt Mode) / USB Power
Delivery
This product is equipped with a USB Type-C (USB-C) connector compatible with DP Alt Mode and
USB Power Delivery.
• While being used as an external monitor of a notebook PC, this product can supply power to the
PC.
Video Signals
Power Supply
• While displaying photos and motion pictures from a smartphone or tablet, this product can charge
the device.
100%
Video Signals
Power Supply
Note
• Devices to be connected must be equipped with a USB-C connector, and support the charging function
based on USB-C or USB Power Delivery.
• The device connected to the monitor can be charged even when the monitor is in power saving mode.
6Chapter 1 Introduction

●High Degree of Flexibility for Installation
• This product can be used as an external monitor of a notebook computer.
• This product can be used in a multi-monitor conguration in which multiple monitors are connected
to a single PC.
●Reduction of Power Consumption
This product provides a function that automatically adjusts the screen brightness to reduce power
consumption *1. Power Reduction, CO2 Reduction, and Eco Performance Level can be checked on
the "EcoView Settings" menu. (page 19)
• Auto EcoView
The ambient light sensor on the front of the monitor detects the ambient brightness to automatically
adjust the screen brightness to a comfortable level.
• EcoView Optimizer 2
The monitor automatically adjusts the screen brightness according to the white level of the input
signal. This function can reduce power consumption while maintaining the brightness specied by
the input signal.
*1 Reference values
Maximum power consumption: 163 W (when a USB device is connected and the speakers are working),
standard power consumption: 32 W (brightness 120 cd/m2, when no USB device is connected and the
speakers are not working, at default settings)
●Realizing More Convenient Operations Using Screen InStyle
The "Screen InStyle" monitor control utility enables you to use the monitor more conveniently.
• The monitor color mode can be switched automatically to suit the software to be used.
• When multiple monitors are installed, you can turn the power on and off or change the color mode
of all monitors at the same time.
Note
• Screen InStyle can be downloaded from our web site (http://www.eizoglobal.com).
• The Windows operating systems are only supported.
7
Chapter 1 Introduction

1-2. Controls and Functions
●Front
4321
5 5
1. Ambient light sensor Detects ambient brightness. If you use Auto EcoView, the screen brightness is
automatically adjusted according to the ambient brightness (page 20).
2. Operation switches Displays menus. Operate the switches according to the operation guide (page 22).
3. Power switch Turns the power on or off.
4. Power indicator Indicates the monitor’s operation status.
White: Normal operation mode
Orange: Power saving mode
OFF: Main power / power off
5. Speakers Outputs audio.
8Chapter 1 Introduction

●Rear
16
15
12
13
14
11
10
8 9
7
6
6. Handle This handle is used for transportation.
7. Security lock slot Complies with Kensington’s MicroSaver security system.
8. Main power switch Turns the main power on or off. : On, : Off
9. Power connector Connects the power cord.
10. Input signal connectors The following connectors are available on the monitor rear in order of left to
right.
HDMI connector (1)
HDMI connector (2)
DisplayPort connector
USB-C connector (USB upstream port)
11. Lock button Use this button to remove the monitor from the stand.
12. USB downstream port
(support for boost charging)
Connects to a peripheral USB device. (page 28)
13. USB downstream port Connects to a peripheral USB device.
14. Headphone jack Connects to headphones.
15. Cable holder Holds the monitor cables.
16. Stand*1 Adjusts the height and angle (tilt and swivel) of the monitor.
*1 An optional arm (or optional stand) can be attached by removing the stand section (see “6-1. Attaching the
Optional Arm” (page 37)).
9
Chapter 1 Introduction

1-3. Supported Resolutions
The monitor supports the following resolutions.
●For DisplayPort
Resolution
Vertical scan
frequency (Hz)
Single screen and PinP
display *1 PbyP display
Version 1.2 Version 1.1 Dual screen
display
Quad screen
display
720 × 400 70.087 √ √ √ √
640 × 480 59.940 √ √ √ √
640 × 480 60.000 √ √ √ √
800 × 600 60.317 √ √ √ √
1024 × 768 60.004 √ √ √ √
1280 × 720 59.855 √ √ √ √
1280 × 720 59.979 √ √ √ √
1280 × 800 59.810 √ √ √ √
1280 × 800 59.910 √ √ √ √
1280 × 1024 60.020 √ √ √ √
1600 × 900 60.000 √ √ √ √
1600 × 1200 60.000 √ √ √ √
1680 × 1050 59.954 √ √ √ √
1680 × 1050 59.883 √ √ √ √
1920 × 1200 59.885 √ √ √ -
1920 × 1200 59.950 √ √ √ -
2560 × 1440 59.951 √ √ - -
1280 × 1600 59.910 - - √ -
3840 × 2160 59.997 √ *2 - - -
3840 × 2160 29.981 √ √ *2 - -
1920 × 2160 59.988 - - √ *2 -
1280 × 720 60.000 √ √ √ √
1280 × 720 59.940 √ √ √ √
1920 × 1080 60.000 √ √ √ √
1920 × 1080 59.940 √ √ √ √
1920 × 1080 30.000 √ √ √ √
1920 × 1080 29.970 √ √ √ √
720 × 480 60.000 √ √ √ √
720 × 480 59.940 √ √ √ √
720 × 480 60.000 √ √ √ √
720 × 480 59.940 √ √ √ √
*1 Supported signals differ depending on the settings in “Administrator Settings”. For information on how to
change the settings, see “4-2. Functions of the “Administrator Settings” Menu” (page 32).
*2 This is the recommended resolution.
10 Chapter 1 Introduction

●For HDMI
Resolution
Vertical scan
frequency (Hz)
Single screen and PinP
display *1 PbyP display
4K UHD 60Hz 4K UHD 30Hz Dual screen
display
Quad screen
display
720 × 400 70.087 √ √ √ √
640 × 480 59.940 √ √ √ √
640 × 480 60.000 √ √ √ √
800 × 600 60.317 √ √ √ √
1024 × 768 60.004 √ √ √ √
1280 × 720 59.855 √ √ √ √
1280 × 720 59.979 √ √ √ √
1280 × 800 59.810 √ √ √ √
1280 × 800 59.910 √ √ √ √
1280 × 1024 60.020 √ √ √ √
1600 × 900 60.000 √ √ √ √
1600 × 1200 60.000 √ √ √ √
1680 × 1050 59.954 √ √ √ √
1680 × 1050 59.883 √ √ √ √
1920 × 1200 59.885 √ √ √ -
1920 × 1200 59.950 √ √ √ -
2560 × 1440 59.951 √ √ - -
1280 × 1600 59.910 - - √ -
3840 × 2160 59.997 √ - - -
3840 × 2160 29.981 √ √ - -
1920 × 2160 59.988 - - √ *2 -
1920 × 2160 29.952 - - √ -
1280 × 720 60.000 √ √ √ √
1280 × 720 59.940 √ √ √ √
1280 × 720 50.000 √ √ √ √
1920 × 1080 60.000 √ √ √ √
1920 × 1080 59.940 √ √ √ √
1920 × 1080 50.000 √ √ √ √
1920 × 1080 30.000 √ √ √ √
1920 × 1080 29.970 √ √ √ √
720 × 480 60.000 √ √ √ √
720 × 480 59.940 √ √ √ √
720 × 480 60.000 √ √ √ √
720 × 480 59.940 √ √ √ √
720 × 576 50.000 √ √ √ √
720 × 576 50.000 √ √ √ √
3840 × 2160 60.000 √ *2 - - -
3840 × 2160 59.940 √ *2 - - -
3840 × 2160 50.000 √ - - -
3840 × 2160 30.000 √ √ *2 - -
3840 × 2160 29.970 √ √ *2 - -
*1 Supported signals differ depending on the settings in “Administrator Settings”. For information on how to
change the settings, see “4-2. Functions of the “Administrator Settings” Menu” (page 32).
*2 This is the recommended resolution.
11
Chapter 1 Introduction

●For USB-C
Resolution
Vertical scan
frequency (Hz)
Single screen and PinP
display *1 PbyP display
4K UHD 60Hz
/ USB2.0
4K UHD 30Hz
/ USB3.1
Dual screen
display
Quad screen
display
720 × 400 70.087 √ √ √ √
640 × 480 59.940 √ √ √ √
640 × 480 60.000 √ √ √ √
800 × 600 60.317 √ √ √ √
1024 × 768 60.004 √ √ √ √
1280 × 720 59.855 √ √ √ √
1280 × 720 59.979 √ √ √ √
1280 × 800 59.810 √ √ √ √
1280 × 800 59.910 √ √ √ √
1280 × 1024 60.020 √ √ √ √
1600 × 900 60.000 √ √ √ √
1600 × 1200 60.000 √ √ √ √
1680 × 1050 59.954 √ √ √ √
1680 × 1050 59.883 √ √ √ √
1920 × 1200 59.885 √ √ √ -
1920 × 1200 59.950 √ √ √ -
2560 × 1440 59.951 √ √ - -
1280 × 1600 59.910 - - √ -
3840 × 2160 59.997 √ *2 - - -
3840 × 2160 29.981 √ √ *2 - -
1920 × 2160 59.988 - - √ *2 -
1280 × 720 60.000 √ √ √ √
1280 × 720 59.940 √ √ √ √
1920 × 1080 60.000 √ √ √ √
1920 × 1080 59.940 √ √ √ √
1920 × 1080 30.000 √ √ √ √
1920 × 1080 29.970 √ √ √ √
720 × 480 60.000 √ √ √ √
720 × 480 59.940 √ √ √ √
720 × 480 60.000 √ √ √ √
720 × 480 59.940 √ √ √ √
*1 Supported signals differ depending on the settings in “Administrator Settings”. For information on how to
change the settings, see “4-2. Functions of the “Administrator Settings” Menu” (page 32).
*2 This is the recommended resolution.
Note
• Only the progressive scan type is supported.
12 Chapter 1 Introduction

1-4. Changing the Computer Display Settings
If the image is not displayed properly after connecting the monitor to a PC, follow the procedure below to
change the display settings on the computer.
●Windows 10
1. Right-click the mouse anywhere on the desktop except on icons. A menu is displayed.
2. From the displayed menu, click “Display Settings”. The “Settings” screen is displayed.
3. If multiple monitors, including notebook PC screens, are connected to the computer, select “Extend
these displays” in the “Multiple displays” menu, and then click “Keep changes” on the conrmation
screen. After changing the settings, select a monitor in the “Select and rearrange displays” menu.
4. Select the “Make this my main display” option in the “Multiple displays” menu. This enables the
monitor to display images properly.
5. Conrm that the recommended resolution for the monitor is set in the “Resolution” menu.
(“(Recommended)” is displayed after the resolution.)
6. To change the size of text and icons, select a magnication in the menu of zoom percentages
according to personal preference.
7. If a message prompting you to sign out is displayed after changing the settings, sign out and then
sign in again.
●Windows 8.1 / Windows 7
1. For Windows 8.1, click the "Desktop" tile on the Start Screen to display the desktop.
2. Right-click the mouse anywhere on the desktop except on icons. A menu is displayed.
3. From the displayed menu, click “Screen resolution”. The settings screen is displayed.
4. If multiple monitors, including notebook PC screens, are connected to the computer, select “Extend
these displays” in the “Multiple displays” menu, and then click “Apply”. Click “Keep changes” on
the conrmation screen.
5. Select a monitor in the “Display” menu, and then select the “Make this my main display” option
and click “Apply”. This enables the monitor to display images properly.
6. Conrm that the recommended resolution for the monitor is set in the “Resolution” menu.
(“(recommended)” is displayed after the resolution.)
7. To change the size of text and icons, click “Make text and other items larger or smaller”, select a
size according to personal preference on the settings screen, and then click “Apply”.
8. If a message prompting you to sign out/log off is displayed after changing the settings, sign out/
log off and then sign in/log in again.
●macOS
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” panel is displayed, click “Displays”.
3. If multiple monitors, including notebook PC screens, are connected to the computer, make sure
that “Mirror Displays” is not selected on the “Arrangement” tab. If it is selected, remove the check
mark.
4. Select the “Display” tab, and make sure that “Default for display” is selected for “Resolution”. If
it is not selected, add a check mark. The correct resolution has now been set for your display.
Close the “System Preferences” panel. If multiple monitors, including notebook PC screens, are
connected to the computer, congure these settings in “Display” on each monitor.
5. To select a resolution according to personal preference, select “Scaled” and then select a
resolution (either from a list or icons), and then close the panel.
13
Chapter 1 Introduction

Function Setting
Value Description
PbyP
Settings
Input Left USB-C
DisplayPort
HDMI 1
HDMI 2
Select an input signal to be displayed on the left screen of
the PbyP display (dual screen).
Right USB-C
DisplayPort
HDMI 1
HDMI 2
Select an input signal to be displayed on the right screen
of the PbyP display (dual screen).
Upper Left USB-C
DisplayPort
HDMI 1
HDMI 2
Select an input signal to be displayed on the upper left
screen of the PbyP display (quad screen).
Lower Left USB-C
DisplayPort
HDMI 1
HDMI 2
Select an input signal to be displayed on the lower left
screen of the PbyP display (quad screen).
Upper Right USB-C
DisplayPort
HDMI 1
HDMI 2
Select an input signal to be displayed on the upper right
screen of the PbyP display (quad screen).
Lower Right USB-C
DisplayPort
HDMI 1
HDMI 2
Select an input signal to be displayed on the lower right
screen of the PbyP display (quad screen).
Note
• You cannot set the same input signal for multiple screens. Therefore, when changing the input signal for a
screen, if you select an input signal that has already been set for another screen, the signals are switched
automatically.
16 Chapter 2 Basic Adjustment / Setting

Function Setting
Value Description
Auto EcoView On
Off
The ambient light sensor on the front of the monitor
detects the ambient brightness to automatically adjust
the screen brightness to a comfortable level using Auto
EcoView. The power consumption of the backlight can
be curtailed by adjusting the brightness to an appropriate
level.
This function can also mitigate eye strain and tiredness
caused by a screen that is too bright or too dark.
Note
• Be careful not to block the ambient light sensor on the
lower side of the monitor when using Auto EcoView.
• Even when the Auto EcoView setting is “On”, the
operation switch on the front of the monitor or color
adjustment can be used to change the “Brightness”
to suit your personal preference. Moreover, the
manner in which the Auto EcoView function changes
brightness also differs according to the changed
value.
• When “DICOM” is selected for the color mode, the
Auto EcoView setting is turned “Off”.
EcoView Optimizer 2 On
Off
The monitor automatically adjusts the screen brightness
according to the white level of the input signal.
This function can reduce power consumption while
maintaining the brightness specied by the input signal.
Note
• The setting is turned “Off” in the following cases:
- When “Movie” or “DICOM” is selected for the color
mode
- During PbyP/PinP display
• When set to “On”, the appearance of pale colors may
change. If this bothers you, set this function to “Off”.
20 Chapter 2 Basic Adjustment / Setting
