Eizo S1933H-GY User manual

Important
Please read PRECAUTIONS, this User’s Manual, and the Setup Guide
(separate volume) carefully to familiarize yourself with safe and effective
usage.
• Please refer to the Setup Guide for basic information ranging from
connection of the monitor to a PC to using the monitor.
• The latest User’s Manual is available for download from our web site:
http://www.eizoglobal.com
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Eizo FlexScan
S1933H-GY o cerca il tuo prodotto tra le migliori offerte di Monitor

2
[Location of the Caution Statements]
S1703 (Ex.Tilt Stand)
S1903 / S1933 (Ex.Tilt Stand)

3
This product has been adjusted specically for use in the region to which it was originally shipped. If operated outside
this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless prior
arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been
made to ensure that this manual provides up-to-date information, please note that EIZO monitor specications are
subject to change without notice.
Kensington and MicroSaver are trademarks of ACCO Brands Corporation.
VESA is a registered trademark of Video Electronics Standards Association.
Windows, Windows Media, Windows Vista, SQL Server, and Xbox 360 are registered trademarks of Microsoft Corporation in the United
States and other countries.
Apple, ColorSync, eMac, iBook, iMac, iPad, Mac, MacBook, Macintosh, Mac OS, PowerBook, and QuickTime are registered trademarks
of Apple Inc.
ENERGY STAR is a registered trademark of the United States Environmental Protection Agency in the United States and other
countries.
EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are
registered trademarks of EIZO Corporation in Japan and other countries.
ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO ScreenSlicer, i • Sound, Screen Administrator, and UniColor Pro are trademarks of
EIZO Corporation.
All other company and product names are trademarks or registered trademarks of their respective owners.

4
Notice for this monitor
This product is suited to general purposes like creating documents, viewing multimedia content.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is
used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
· Power cords provided with the product
· Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
As it takes about 30 minutes for the performance of electrical parts to stabilize, adjust the monitor 30 minutes or more
after the monitor power has been turned on.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and maintain a
stable display.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to
“Cleaning” (page 5)).
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on
the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994% or higher.
The backlight of the LCD panel has a xed lifetime. When the screen becomes dark or begins to icker, please contact
your local EIZO representative.
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference
patterns, etc. If pressure is continually applied to the panel, it may deteriorate or damage your panel. (If the pressure
marks remain on the panel, leave the monitor with a black or white screen. The symptom may disappear.)
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt
to brush with tissues as this may scratch the panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may
occur on the interior and exterior surfaces of the monitor. In that case, do not turn the monitor on. Instead wait until
the dew condensation disappears, otherwise it may cause some damage to the monitor.

5
Cleaning
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or
panel, and also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel.
NOTE
• The optional ScreenCleaner is recommended for cleaning the cabinet and panel surface.
The stains on the cabinet and panel surface can be removed by moistening part of a soft cloth with water.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to the
environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

6CONTENTS
CONTENTS
Notice for this monitor.............................................. 4
CONTENTS............................................................. 6
Chapter 1 Features and Overview ..................... 7
1-1 Features ............................................................... 7
1-2 Buttons and Indicators ....................................... 8
1-3 Functions and Basic Operation ....................... 10
Chapter 2 Settings and Adjustments .............. 12
2-1 Set a Sync-on-Green Signal ............................. 12
2-2 Setting Screen Resolution................................ 12
Compatible Resolutions/Frequencies ............... 12
Setting Resolution............................................... 13
2-3 Utility Disk.......................................................... 14
●Disk contents and software overview................ 14
●To use ScreenManager Pro for LCD (DDC/CI)/
EIZO ScreenSlicer............................................ 14
2-4 Screen Adjustment............................................ 15
Digital Input.......................................................... 15
Analog Input ........................................................ 15
2-5 Color Adjustment .............................................. 18
●
To select the display mode (FineContrast mode) ... 18
●To perform advanced adjustments .................... 18
●Adjustment items in each mode ........................ 18
●To set/adjust color ............................................. 19
2-6 Turning off the monitor automatically
[Eco Timer] ..................................................... 20
2-7 Setting Adjustment Menu Position
[Menu Position].............................................. 20
2-8 Setting Power Indicator ON/OFF
[Power Indicator] ........................................... 20
2-9
Displaying Monitor Information [Information] ... 20
2-10 Setting Language [Language]........................ 21
2-11 Setting On/Off for the automatic brightness
adjustment function
[Auto EcoView] .............................................. 21
2-12 Displaying the level of power saving by
EcoView Index................................................ 21
2-13 Locking Buttons.............................................. 21
●To lock adjustments/settings in the Adjustment
menu ................................................................ 21
2-14
Enabling/Disabling DDC/CI communication ... 22
2-15 Setting EIZO logo display ON/OFF ................ 22
2-16 Resuming the Default Setting [Reset]........... 22
●To reset color adjustment values....................... 22
●To reset all adjustments to the factory default
settings............................................................. 22
Chapter 3 Connecting Cables .......................... 23
3-1 Connecting Multiple PCs to the Monitor ........ 23
●To switch the input signal .................................. 23
●To set input signal selection [Input Signal] ........ 23
Chapter 4 Troubleshooting............................... 24
Chapter 5 Reference ......................................... 26
5-1 How to Attach the Optional Arm ...................... 26
5-2 Power Saving Mode .......................................... 27
5-3 Specications.................................................... 28
5-4 Glossary............................................................. 36
5-5 Preset Timing..................................................... 38
Appendix .................................................................. 39
FCC Declaration of Conformity.......................... 41
LIMITED WARRANTY .......................................... 42
Recycling Information......................................... 43

7
Chapter 1 Features and Overview
Chapter 1 Features and Overview
Thank you very much for choosing an EIZO color LCD monitor.
1-1 Features
• Applicable to the resolution of 1280 × 1024
• Stereo speakers
• Power saving function
Suppressing the power consumption* reduces the carbon dioxide emissions.
This product is equipped with various power saving functions.
– Auto EcoView function
The sensor on the front side of the monitor detects the environmental brightness to
adjust the screen brightness automatically and comfortably.
Excessively high brightness may lead a damage to the natural environment as well
as to your eyes. Suppressing the excessively high brightness will be helpful to
reduce the power consumption and the damage to your eyes.
“2-11 Setting On/Off for the automatic brightness adjustment function
[Auto EcoView]” (page 21)
– EcoView Index function
This indicator shows the power saving ratio, power reduction and CO2reduction as
a result of the brightness
of the monitor. You can realize the power consumption reduction by taking
consideration in the ratio of power saving.
“2-12 Displaying the level of power saving by EcoView Index” (page 21)
• FineContrast function to allow the best mode for screen display
– Features Paper mode showing a view when printed onto paper
“● To select the display mode (FineContrast mode)” (page 18)
• Supports portrait and landscape formats (For height adjustable stand)
• The software “ScreenManager Pro for LCD (DDC/CI)” to adjust the screen
using the mouse and keyboard is included
“2-3 Utility Disk” (page 14)
Note
• When using the monitor screen in
a portrait position, the graphics
board supporting portrait display is
required. When placing the monitor
in a portrait position, the settings
of your graphics board need to be
changed. Refer to the User’s Manual
of the graphics board for details.
* Reference values:
-S1703
Maximum power consumption:
25W (Luminance Max., at default
settings)
Standard power consumption: 9W
(Luminance 120cd/m2, at default
settings)
-S1903
Maximum power consumption:
23W (Luminance Max., at default
settings)
Standard power consumption: 11W
(Luminance 120cd/m2, at default
settings)
-S1933
Maximum power consumption:
24W (Luminance Max., at default
settings)
Standard power consumption: 12W
(Luminance 120cd/m2, at default
settings)

8Chapter 1 Features and Overview
1-2 Buttons and Indicators
Front
Adjustment menu (ScreenManager*1)
1 87654321 8765432
Tilt Stand Height adjustable Stand
Adjustment menu (ScreenManager*1)
1 Sensor The sensor detects ambient brightness. Auto EcoView function (page 21)
2 EcoView button Displays the setting menu of Auto EcoView and EcoView Index (page 21).
3 Volume control button Displays the volume adjustment menu (page 10).
4
Input Signal Selection button Switches input signals for display.
5 Control buttons (Left, Right) • Displays the brightness adjustment window (page 10).
• Chooses an adjustment item or increases/decreases adjusted values for
advanced adjustments using the Adjustment menu (page 11).
6 Enter button Displays the Adjustment menu, determines an item on the menu screen, and
saves values adjusted.
7 Power button Turns the power on or off.
8 Power indicator Indicates monitor’s operation status.
Blue: Operating Orange: Power saving Off: Power off
*1 ScreenManager is an EIZO’s nickname of the Adjustment menu. See “Basic operation of Adjustment menu” (page 11) for how to use.

9
Chapter 1 Features and Overview
Rear
9
16
14
15 16
14
1211 13
1211 13
10 10
15
9
Tilt Stand Height adjustable Stand
9 Security lock slot Complies with Kensington’s MicroSaver security system.
10 Stand*2Tilt Stand : Used to adjust the angle (tilt) of the monitor screen.
Height adjustable Stand : Adjusts the height and angle (tilt and swivel) of the monitor.
11
Power connector Connects the power cord.
12
Input signal connectors Left: DVI-D connector/Right: D-Sub mini 15-pin connector
13 Stereo mini jack Connects the stereo mini jack cable.
14 Cable holder Covers the monitor cables.
15 Speaker Outputs audio source.
16 Headphone jack Connects the headphones.
*2 An optional arm (or an optional stand) can be attached by removing the stand section. (Refer to “5-1 How to Attach the Optional Arm” (page 26))

10 Chapter 1 Features and Overview
1-3 Functions and Basic Operation
To adjust the screen and color
• The Adjustment menu and the EcoView menu
cannot be displayed at the same time.
●Setting On/Off for the automatic brightness
adjustment function
[Auto EcoView]………………………… see page 21
1 Press .
2 Change “On” and “Off” with or .
●Displaying the level of power saving by EcoView
Index …………………………………… see page 21
Press to display the level of power saving mode.
EcoView menu
Color Adjustment
●To select the display mode (FineContrast mode)
……………………………………… see page 18
●“Brightness,” “Contrast,” “Temperature,” and
“Gain” can be set for each mode (Custom/
EyeCare/Paper/Text/sRGB (S1703/S1903),
Custom/EyeCare/Paper/sRGB/DICOM (S1933)).
Settable functions vary with the display mode.
Resumption of Default Setting
●To reset color adjustment values
[Reset] ……………………………… see page 22
Main menu (Refer to page 11 for operation)
1Screen Adjustment
(Automatic Adjustment)
●To adjust flickering and position
[Screen]…………………………… see page 15
●To adjust color gradation automatically
[Range] …………………………… see page 17
(for analog signal input only)
2Screen Adjustment
(Advanced Adjustment)
[Adjustment menu]
[At analog signal input] [At digital signal input]
●To eliminate vertical bars [Clock*] … see page 16
●To remove flickering or blurring
[Phase*]……………………………… see page 16
●To correct screen position
[Hor. Position*] ……………………… see page 17
[Ver. Position*] ……………………… see page 17
●To modify blurred characters/lines
[Smoothing] ………………………… see page 17
*
Items marked with * can be adjusted with analog
input.
Brightness Adjustment
Press or to adjust brightness.
Volume Adjustment
1Press .
2Press or to adjust volume.
page 15
page 16
page 18

11
Chapter 1 Features and Overview
To make useful settings/adjustments
Setting Input Signal Selection
●To set input signal selection
[Input Signal] ……………………… see page 23
Enabling / Disabling Auto Power-OFF
●Turning off the monitor automatically
[Eco Timer] ………………………… see page 20
Setting Adjustment Menu Position
●Setting Adjustment Menu Position
[Menu Position] …………………… see page 20
Power Indicator Setting
●Setting Power Indicator ON/OFF
[Power Indicator] …………………… see page 20
Resumption of Default Setting
●To reset all adjustments to the factory default
settings [Reset] …………………… see page 22
Basic operation of Adjustment menu
[Displaying Adjustment menu and selecting function]
(1) Press . The main menu appears.
(2) Select a function with or , and press . The sub menu appears.
(3) Select a function with or , and press . The adjustment/setting menu appears.
(4) Adjust the selected item with or , and press . The setting is saved.
[Exiting Adjustment menu]
(1) Choose <Return> from the sub menu and press .
(2) Choose <Exit> from the main menu and press .
NOTE
• The Adjustment menu can also be exited by pressing twice quickly.
●Set a Sync-on-Green Signal [SoG]
…………………………………… see page 12
●Locking Buttons [Adjustment Lock]
…………………………………… see page 21
●Enabling/Disabling DDC/CI communication
[DDC/CI] ………………………… see page 22
●Setting EIZO logo display ON/OFF
…………………………………… see page 22
Adjustment menu (Refer to below for operation)
Language
●Setting Language [Language]
page 21
Information
●Displaying monitor information [Information]
page 20

12 Chapter 2 Settings and Adjustments
2-1 Set a Sync-on-Green Signal
When inputting a sync-on-green signal, the [SoG] setting for the monitor must be changed in advance according to the
procedure below (for analog signal).
(1) Press to turn off the monitor.
(2) Press holding down to turn on the monitor.
(3) Select “On” with or , and press .
2-2 Setting Screen Resolution
Compatible Resolutions/Frequencies
The monitor supports the following resolutions.
Analog Input
Resolution Frequency Dot Clock
640 × 480 (VGA, VESA) ~75 Hz
135 MHz (Max.)
720 × 400 (VGA TEXT)70 Hz
800 × 600 (VESA) ~75 Hz
1024 × 768 (VESA) ~75 Hz
1152 × 864 (VESA) 75 Hz
1280 × 960 (VESA) 60 Hz
1280 × 1024 (VESA)*~75 Hz
Digital Input
Resolution Frequency Dot Clock
640 × 480 (VGA) 60 Hz
108 MHz (Max.)
720 × 400 (VGA TEXT)70 Hz
800 × 600 (VESA) 60 Hz
1024 × 768 (VESA) 60 Hz
1280 × 1024 (VESA)*60 Hz
* Recommended resolution (Set this resolution)
Chapter 2 Settings and Adjustments

13
Chapter 2 Settings and Adjustments
Setting Resolution
When you connect the monitor to the PC and nd that the resolution is improper, or when you want to change the
resolution, follow the procedure below.
●Windows 8 / Windows 7
1. For Windows 8, click the “Desktop” tile on the Start Screen to display the desktop.
2. Right-click the mouse anywhere on the desktop except for icons.
3. From the displayed menu, click “Screen resolution”.
4. On the “Screen Resolution” dialog box, select the monitor.
5. Click “Resolution” to select the desired resolution.
6. Click the “OK” button.
7. When a conrmation dialog box is displayed, click “Keep changes”.
●Windows Vista
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Personalize”.
3. On the “Personalization” window, click “Display Settings”.
4. On the “Display Settings” dialog box, select the “Monitor” tab and select desired resolution in the
“Resolution” eld.
5. Click the “OK” button.
6. When a conrmation dialog box is displayed, click “Yes”.
●Windows XP
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Properties”.
3. When the “Display Properties” dialog box is displayed, click the “Settings” tab and select desired
resolution for “Screen resolution” under “Display”.
4. Click the “OK” button to close the dialog box.
●Mac OS X
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” dialog box is displayed, click “Displays” for “Hardware”.
3. On the displayed dialog box, select the “Display” tab and select desired resolution in the “Resolutions”
eld.
4. Your selection will be reected immediately. When you are satised with the selected resolution, close
the window.

14 Chapter 2 Settings and Adjustments
2-3 Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and
the overview of the application software programs.
● Disk contents and software overview
The disk includes software programs for adjustment, and User’s Manual. Refer to “Readme.txt” le on the disk for
software startup procedures or le access procedures.
Item Overview Windows Macintosh
Screen adjustment pattern les Used when adjusting the image of analog signal
input manually. √ √
ScreenManager Pro for LCD
(DDC/CI)
Software for adjusting the screen using the mouse
and keyboard. √-
EIZO ScreenSlicer Software that divides a screen and lays out
multiple windows efciently. √-
User’s Manual of this monitor (PDF le) √ √
Readme.txt le √ √
● To use ScreenManager Pro for LCD (DDC/CI)/EIZO ScreenSlicer
For the installation and use of ScreenManager Pro for LCD (DDC/CI)/EIZO SceenSlicer, refer to the respective User’s
Manual on the disc.

15
Chapter 2 Settings and Adjustments
2-4 Screen Adjustment
Digital Input
When digital signals are input, images are displayed correctly based on the
preset data of the monitor, but if characters and/or lines appear blurred, go to
step 6 “● To modify blurred characters/lines [Smoothing]” (page 17). When
performing more advanced adjustment, see “2-5 Color Adjustment” (page 18) and
subsequent pages.
Analog Input
The monitor screen adjustment is used to suppress ickering of the screen or
adjust screen position and screen size correctly according to the PC to be used.
To use the monitor comfortably, adjust the screen when the monitor is set up for
the rst time or when the settings of the PC in use are updated.
The Self Adjust function works when all of the following conditions are
satised.
• Whenasignalisinputintothemonitorforthersttimeorwhenthe
resolution or Vertical/Horizontal Frequency not displayed before is
set
• When signals with the vertical resolution over 480 are input
If the screen is not displayed correctly even after performing the Self Adjust
operation, adjust the screen according to the procedures on the following pages
to use the monitor comfortably.
[Adjustment Procedure]
1Perform the auto adjustment.
● To adjust ickering, screen position, and screen size
automatically [Screen]
(1) Choose <Screen> from the <Auto Adjustment> menu, and press
.
The <Auto Adjustment> menu appears.
(2) Select “Execute” with or , and press .
Flickering, screen position, and screen size are corrected by the auto-
adjustment function.
If the screen is not displayed correctly even after adjusting in
step 1 above, perform the adjustments according to the
proceduresonthefollowingpages.Whenthescreenis
displayed correctly, go to step 5 “● To adjust color gradation
automatically [Range]” (page 17).
2Prepare the display pattern for the analog display adjustment.
Load the “EIZO LCD Utility Disk” to your PC, and then open the “Screen
adjustment pattern les”.
Attention
• Wait 30 minutes or more from
monitor power on before starting
adjustments. (Allow the monitor
to warm up for at least 30 minutes
before making adjustments.)
• The self adjustment (or automatic
screen adjustment) function works
correctly when an image is fully
displayed over the Windows or
Macintosh display area. They do not
work properly in the cases below:
- When an image is displayed only
on a part of the screen (command
prompt window, for example)
- When a black background
(wallpaper, etc.) is in use
Also, these functions cannot work
properly in some graphic boards.
NOTE
• For details and instructions on opening
the “Screen adjustment pattern les”,
refer to the “Readme.txt” le.

16 Chapter 2 Settings and Adjustments
3Perform the auto adjustment again with the analog screen
adjustment pattern displayed.
● To adjust ickering, screen position, and screen size
automatically [Screen]
(1) Display Pattern 1 of the “Screen adjustment pattern les” in full
screen on the monitor.
(2) Choose <Screen> from the <Auto Adjustment> menu, and press
.
The <Auto Adjustment> menu appears.
(3) Select “Execute” with or , and press .
Flickering, screen position, and screen size are corrected by the auto-
adjustment function.
If the screen is not displayed correctly even after adjusting in
step 3 above, perform the adjustments according to the
proceduresonthefollowingpages.Whenthescreenis
displayed correctly, go to step 5 “● To adjust color gradation
automatically [Range]” (page 17).
4Perform advanced adjustments for the following using the
<Screen> menu of the Adjustment menu.
Adjust the clock, phase and position, in this order.
●To eliminate vertical bars [Clock]
(1) Choose <Clock> from the <Screen> menu, and press .
The <Clock> menu appears.
(2) Adjust the clock with or , and press .
The adjustment is completed.
● To remove ickering or blurring [Phase]
Adjustable range: 0 to 63
(1) Choose <Phase> from the <Screen> menu, and press .
The <Phase> menu appears.
(2) Adjust the phase with or , and press .
The adjustment is completed.
NOTE
• Press the control button slowly so as
not to miss the adjustment point.
• When blurring, ickering or bars
appear on the screen after adjustment,
proceed to “● To remove ickering or
blurring [Phase]” (page 16) to remove
ickering or blurring.
Attention
• Flickering or blurring may not be
eliminated depending on your PC or
graphics board.
NOTE
• When vertical bars appear on the
screen after adjustment, go back to
“● To eliminate vertical bars [Clock]”
(page 16). (Clock → Phase → Position)

17
Chapter 2 Settings and Adjustments
●To correct screen position [Hor. Position], [Ver. Position]
(1) Choose <Hor. Position> and or <Ver. Position> from the <Screen>
menu, and press .
The <Hor. Position> or <Ver. Position> menu appears.
(2) Adjust the position with or to display the image properly
in the display area of the monitor.
The adjustment is completed.
5Adjust the color gradation.
●To adjust color gradation automatically [Range]
Every color gradation (0 to 255) can be displayed by adjusting the
signal output level.
(1) Display Pattern 2 in full screen on the monitor using the “Screen
adjustment pattern les”.
(2) Choose <Range> from the <Auto Adjustment> menu, and press
.
(3) Select “Execute” with or , and press .
The output range is adjusted automatically.
(4) Close the Pattern 2.
6Modify blurred characters or lines.
●To modify blurred characters/lines [Smoothing]
When a image is displayed with a resolution other than the
recommendation, the characters or lines of the displayed image may
be blurred.
Adjustable range: 1 to 5
(1) Choose <Smoothing> from the <Screen> menu, and press .
The <Smoothing> menu appears.
(2) Adjust the characters/lines with or , and press .
The adjustment is completed.
NOTE
• Since the number of pixels and the
pixel positions are xed on the LCD
monitor, only one position is provided
to display images correctly. The
position adjustment is made to shiftn
an image to the correct position.

18 Chapter 2 Settings and Adjustments
2-5 Color Adjustment
● To select the display mode (FineContrast mode)
This function allows you to select the best display mode for monitor brightness,
etc.
FineContrast mode
Mode Purpose
Custom Available for making desired setting.
EyeCare Allows the brightness to be set lower than possible with
other modes.
Paper Produces a printed paper effect. Suitable for displaying
images from media such as books and documents.
Text (S1703/S1903) Suitable for displaying texts for word processing or
spreadsheets.
sRGB Suitable for color matching with sRGB compatible
peripherals.
DICOM (S1933) Selected for the display in the DICOM mode.
(1) Choose <Color> from the Adjustment menu, and press .
(2) Choose <Color Mode> from the <Color> menu, and press .
The <Color Mode> menu appears.
(3) Select the mode with or , and press .
The setting completes.
● To perform advanced adjustments
Independent setting and saving of color adjustment are available for each
FineContrast mode.
● Adjustment items in each mode
According to the FineContrast mode selected, the adjustable function differs.
√: Adjustment available −: Invalid for adjustment
Icon Function
FineContrast mode
Custom EyeCare Paper
Text
(S1703/
S1903)
sRGB DICOM
(S1933)
Brightness √ √ √ √ √ −
Contrast √− − √ − −
Temperature √ √ − √ − −
Gain √ √ − − − −
Reset √ √ √ √ √ −
NOTE
• “ScreenManager Pro for LCD
(DDC/CI)” allows you to select the
FineContrast mode automatically
according to the application used.
(Refer to “Chapter 3 Auto
FineContrast” on the User’s Manual
for “ScreenManager Pro for LCD
(DDC/CI)”.)
Attention
• Wait 30 minutes or more from
monitor power on before starting
adjustments.
• Perform the range adjustment rst
when adjusting color for analog input
signals.
(Refer to “● To adjust color gradation
automatically [Range]” (page 17).)
• The same image may be seen in
different colors on multiple monitors
due to their monitor-specic
characteristics. Make ne color
adjustment visually when matching
colors on multiple monitors.

19
Chapter 2 Settings and Adjustments
Menu Description Adjustment range
Brightness
To adjust the full screen
brightness as desired
0 to 100%
NOTE
• Values shown in percentage are available only as reference.
• You can also adjust the brightness by pressing or
button while the adjustment menu is not displayed. Press
after adjustment.
• If you feel that the image is too dark even if the brightness is
set to 100%, adjust the contrast.
Contrast To adjust the contrast of the
0 to 100%
NOTE
• Values shown in percentage are available only as reference.
• In the contrast of 50%, every color gradation is displayed.
• When adjusting the monitor, it is recommended to perform
the brightness adjustment which may not lose the gradation
characteristics, prior to the contrast adjustment.
• Perform the contrast adjustment in the following cases.
– When you feel the image is too dark even if the brightness
is set to 100% (Set the contrast to higher than 50%.)
Temperature To select a color
temperature
Off, 5000K, 6500K, 9300K
NOTE
• Setting the value to “Off” presents the natural color of the
panel.
• The values shown in the Kelvin (K) are available only as
reference.
Gain To adjust red, green, and
blue to a desired color tone
respectively
0 to 100%
Adjust the respective brightness of
red/green/blue to make a desired
color tone. Display an image with
white or gray background for
adjustment.
Attention
• This function does not enable to display every color gradation.
NOTE
• Values shown in percentage are available only as reference.
• When using the <Gain> setting, the <Temperature> setting is
set to “Off”.
• The gain value may change depending on the value of the
color temperature.
Reset To reset the color settings of the selected FineContrast mode to
the default settings
● To set/adjust color
(1) Choose <Color> from the Adjustment menu, and press .
(2) Select a desired function from the <Color> menu, and press .
The selected function menu appears.
(3) Adjust the selected item with or , and press .
The adjustment is completed.
NOTE
• Using the “ScreenManager Pro
for LCD (DDC/CI)” allows you to
perform the color adjustment by using
the mouse and keyboard of your PC.
The adjusted status can be registered
as a color data and restore the data
later. (Refer to “Chapter 4 Color
Adjustment” on the User’s Manual
for “ScreenManager Pro for LCD
(DDC/CI)”.)

20 Chapter 2 Settings and Adjustments
2-6 Turning off the monitor automatically
[Eco Timer]
This function allows you to specify whether to turn on / off the monitor
automatically after a specied time has elapsed in the power saving mode.
Adjustable range: Disable, Enable (0, 1, 2, 3, 5, 10, 15, 20, 25, 30, 45 min,
1-5h)
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Eco Timer> from the <Others> menu, and press .
The <Eco Timer> menu appears.
(3) Select “Enable” or “Disable” with or .
When selecting “Enable”, set a monitor Off time with or .
(4) Press .
The setting is completed.
2-7 Setting Adjustment Menu Position
[Menu Position]
Adjust the menu position using the following procedure.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Menu Position> from the <Others> menu, and press .
The <Menu Position> menu appears.
(3) Select a menu position with or , and press .
The setting is completed.
2-8 Setting Power Indicator ON/OFF
[Power Indicator]
This function allows you to set the power indicator (blue) ON/OFF in the
monitor ON condition.
(1) Choose <Others> from the Adjustment menu, and press .
(2) Choose <Power Indicator> from the <Others> menu, and press .
The <Power Indicator> menu appears.
(3) Select “Enable” or “Disable” with or , and press .
The setting is completed.
2-9 Displaying Monitor Information
[Information]
This function allows you to display the input signal status, current resolution
and model name.
Information 1/3 : Input signal status, resolution and H/V frequency
Information 2/3 : Enable/Disable setting for DDC/CI, On/Off setting for
SoG (Sync-on-Green)
Information 3/3 : Model name, serial number and usage time
(1) Choose <Information> from the Adjustment menu, and press .
The <Information> menu appears.
(2) Then, press to check settings, etc.
NOTE
• The usage time is not always “0”
when you purchase the monitor due
to factory inspection.
