Eizo FlexScan T965 User manual

55 cm (21") CLASS
COLOR CRT MONITOR
FINE CONTRAST
The front-button-operated Fine Contrast function, exclu-
sive to EIZO, provides advanced image customization in just
about any application. It features five user-selectable modes: Text,
Browser, Picture, Graphic and Movie, each with unique color
temperature, brightness and contrast settings. Additionally, an
sRGB mode, accessible through the OSD, offers color matching
with software and other peripheral devices that also support the
sRGB color space.
COLOR RESTORATION
This function detects the slight changes of color tonality
and brightness that occur with all CRT monitors, and restores the
settings to their original, factory-installed values. As a result, the
monitor delivers much longer service life at the highest levels of
accuracy.
GOOD CONNECTIONS
The front button allows switching between two video
inputs (D-Sub and BNC). Either can be prioritized when two
computers are connected. There is also a built-in USB hub with
one upstream and four downstream ports for easy connection of
peripherals. One downstream port is accessed by a convenient
drop-down lid at the front of the monitor.
Advanced
Control
Designed and built to handle
complex imaging tasks, the
FlexScan T965 employs a com-
pletely flat tension mask CRT to
produce stable, high-brightness
images, low reflection, true-to-life
colors and a sharp focus over the
whole screen. In addition, its
extensive image control features
allow the user to set or adjust a
wide range of display parameters to
achieve the precision and detail
required for complex DIP, DTP and
CAD/CAM applications. Versatile
low-to-high resolution handling,
multiple connectivity and compli-
ance with key environmental and
ergonomic standards make the
FlexScan T965 ideal for high-end
graphics professionals.

55 cm (21") CLASS
COLOR CRT MONITOR
Additional Features
SUPER ERGOCOAT
®
EIZO-developed coating to reduce reflection, glare, dust and
static electricity.
SCREENMANAGER PRO
FOR USB
This software enables precise, individual adjustment of
several key display parameters.
WINDOW MOVIE MODE
Independently adjustable brightness levels for foreground/
background windows.
AUTO-SIZING
One touch on the Auto button automatically sizes and
centers the displayed image in relation to the screen frame.
SIGNAL FILTERS
These filters correct smearing and ghosting of the image
caused by defective signals from a graphics card.
AUTOMATIC COLOR CORRECTION
Compensates for uneven video signal levels and unifies color
temperature when two computers are connected.
UNIFORMITY ADJUSTMENT
Reduces geomagnetic-induced color uniformity errors at the
edges of the screen.
RAPID WARM-UP
Full operational mode with stable brightness is attained in
about 10 minutes compared with 40 minutes for conven-
tional CRTs.
REGULATORY STANDARDS
Accessories
SOUND UNIT
Powered from the monitor, this unit attaches directly to the
bezel.
Specifications
1Maximum refresh rate for this resolution.
2Only valid when computer supports all Plug & Play functions (personal
computer, graphics board, Windows®95/98/2000). For more details, please refer
to the Windows 95/98/2000, personal computer, and graphics board manuals or
contact the manufacturers.
55 cm (21") class 90°deflection Tension Mask
Gray
0.24 mm
Super ErgoCoat
®
H: 30 - 130 kHz V: 50 - 160 Hz
340 MHz
RGB Analog
D-Sub mini 15 pin and BNC ×5 (switchable)
400 mm ×298 mm
498 mm (diagonal)
1600 ×1200 / 104 Hz
1
2048 ×1536 / 80 Hz
1
DDC 2B
ScreenManager
®
, Auto-Sizing,
ScreenManager Pro for USB
AC 100-120V/220-240V, 50-60 Hz
VESA DPMS
160 watts
Less than 3 watts
English, German, French, Spanish, Italian, Swedish
494 mm ×486 mm ×520 mm
36.0 kg
10º Up, 4º Down / 45º Right, 45º Left
TCO‘99, TÜV ECO Circle 2000, TÜV/GS, c-Tick
CE, CB, UL 1950, CSA C22.2 No.950, FCC-B,
Canadian ICES-003-B, TÜV/S, VCCI-B, EPA
ENERGY STAR
®
, Energy 2000
USB Standard Rev. 1.1
1 upstream, 4 downstream
AC power cord, user's manual, signal cable (D-Sub
mini 15 pin), EIZO USB Cable, EIZO CRT Utility
Disk (ScreenManager for USB, ICC profile),
warranty registration card
CRT Size and Type
Cabinet Color
Phosphor Pitch
CRT Surface Treatment
Scanning Frequency
Dot Clock
Input Signals
Input Terminal
Active Display Size (H ×V)
Viewable Image Size
Recommended Resolution
Maximum Resolution
Plug & Play
2
Screen Control
Power Requirements
Power Management
Power Consumption
Power Save Mode
OSD Languages
Dimensions (W ×H ×D)
Net Weight
Tilt/Swivel
Certifications and Standards
USB Standard
USB Ports
Supplied Accessories
EIZO NANAO CORPORATION
153 Shimokashiwano, Matto, Ishikawa 924-8566 Japan
Phone [phone] Fax: [phone]
Web: www.eizo.com
Specifications are subject to change without notice.
