EKSMA OPTICS HVS-100 Parts list manual

HVS-100
HighVoltage Power Supply
Technical Description
2022
Lithuania

HIGH VOLTAGE POWER SUPPLY HVS-100
2
EKSMA OPTICS • Tel.: [phone] • Fax: [phone] • [e-mail] • www.eksmaoptics.com
CONTENTS
Chapter 1. DEVICE LAYOUT 3
1.1. SYMBOLS AND ABBREVIATIONS 3
Chapter 2. QUICKSTARTGUIDE 4
2.1. INSTALLATION AND CONNECTING 4
2.2. OPERATION 4
2.2.1. Precise High Voltage (HV) Adjustment 4
2.2.2. Turning On and Off of HV Output 4
2.2.3. OledDisplay 4
2.3. DISCONNECTING 4
Chapter 3. SPECIFICATIONS 5
3.1. GENERAL INFORMATION 5
3.1.1. Model 5
3.1.2. MainComponents 5
3.2. TECHNICAL SPECIFICATIONS 5
Chapter 4. WARRANTY 6
4.1. WARRANTY STATEMENT 6
4.2. SAFETY 6
4.3. SERVICE CONTACT INFORMATION 6
LIST OF FIGURES
Figure 1.
OUTLINE DRAWING AND DIMENSIONS
OF THE HV SUPPLY
3
Figure 2.
FRONT VIEW OF THE HV SUPPLY
3
Figure 3.
BACK VIEW OF THE HV SUPPLY
3
LIST OF TABLES
Table 1.
CONTROLS AND CONNECTIONS OF THE HV SUPPLY
3
Table 2.
MAIN COMPONENTS
5
Table 3.
TECHNICAL SPECIFICATIONS
5

HIGH VOLTAGE POWER SUPPLY HVS-100
3
Visit www.eksmaoptics.com for new products and prices • Rev. 20220211
1
2
3
4
7
5
6
8 9 10
DEVICE LAYOUT
Figure 1. Outline drawing and dimensions of the HV supply
Table 1. CONTROLS AND CONNECTIONS OF THE HV SUPPLY
NO.
DESCRIPTION
1
ON/OFF power button: It has priority over all operations for
safety.
2
OLED screen interface: Used to display voltage of HV output.
Indicates the current consumed from HV output.
3
HV output tuning encoder with button: Used for voltage tuning
of HV output. Press to set the tuned value.
4
HV output ON/OFF button with LED: Used to turn ON/OFF the
HV output. LED indicates if HV output is active.
5
AC power input connector.
6
GND terminal.
7
USB connector. Used to control the device via “CAN Browser”
application.
8, 9
24V output connectors.
10
HV output connector. -HV output is only available for HVS100-
2x60 model.
Figure 2. Front view of the HV supply Figure 3. Back view of the HV supply
1.1. SYMBOLS AND ABBREVIATIONS
Symbolfordevicepowerswitch
Symbol for chassis earth, potential safety earth.
HV – highvoltage.
GND –ground.
AC –alternating current.
DC –direct current.
LED –light-emitting diode.
OLED –organic light-emitting diode.
Chapter 1

HIGH VOLTAGE POWER SUPPLY HVS-100
4
EKSMA OPTICS • Tel.: [phone] • Fax: [phone] • [e-mail] • www.eksmaoptics.com
QUICK START GUIDE
2.1. INSTALLATION AND CONNECTING
❯Ground the HV supply.
❯Connect the device to the AC power source.
❯Connect the load.
2.2. OPERATION
2.2.1 PRECISE HIGH VOLTAGE (HV) ADJUSTMENT
2.2.3. OLED DISPLAY
Turn knob till the required voltage value is achieved. Push knob
until buzzer sound is heard to set the required voltage value.
2.2.2. TURNING ON AND OFF OF HV OUTPUT
Push ON/OFF button until buzzer sound is heard to turn high
voltage output ON or OFF.
1
Current of HV output: HV output current meter value.
2
Voltagedisplay:
❯With underline and overline: HV tuned value is
displayed;
❯No underline and overline: HV output value is
displayed (measured with reference to ground).
In the case of HVS100-2x60 potential difference
between +HV and - HV is doubled.
2.3. DISCONNECTING
❯Push the On/Off button to off. The On/Off LED (4 in Figure 2)
should turn off.
❯Turn off the Power button (1 in Figure 2).
❯Disconnect the load.
ATTENTION
Take care not to apply HV of a higher value than your load is
certified to handle.
ATTENTION
For safety reasons, do not connect/disconnect the load
when the supply is powered and switched on.
ADJUSTMENT
SET
Chapter 2

HIGH VOLTAGE POWER SUPPLY HVS-100
5
Visit www.eksmaoptics.com for new products and prices • Rev. 20220211
SPECIFICATIONS
3.1. GENERAL INFORMATION
3.1.1. MODEL
The model number can be found on a label on the bottom side
of the high voltage power supply.
3.2. TECHNICAL SPECIFICATIONS
3.1.2. MAIN COMPONENTS
Table 2. MAIN COMPONENTS
COMPONENT
QUANTITY
High voltage power supply HVS-100
1
AC power cable / External power supply with AC
power cable
1
HV cable of 1.5 m length
1
24V banana jack connector with cable
2
Technical description
1
Table 3. TECHNICAL SPECIFICATIONS
MODEL
HVS100-2X60
HVS100-120
HVS100-5
HVS100-40
HVS100-80
HVS100-150
Maximal high voltage output options
±1.4kV
±2.5kV
1.8kV
2.6kV
3.1kV
3.6kV
1.8kV
2.8kV
4.0kV
4.4kV
5.0kV
1.3kV
1.8kV
2.5kV
3.6kV
4.0kV
1.8kV
2.6kV
3.1kV
3.6kV
4.0kV
4.4kV
1.8kV
2.6kV
3.1kV
3.6kV
4.0kV
4.4kV
Maximal output power at maximal output voltage
2 × 60 W
120 W
5 W
40 W
80 W
150 W
Voltage control limits
40% Umax to Umax
Remaining power at the output of 24 V DC for external
needs
55 W
55 W
190 W
150 W
100 W
Not available
Mains voltage
90 to 264 V AC, 47 – 63 Hz
24 V DC
Dimensions (W × L × H)
230 × 245 × 53.5 mm
Weight
2.5 kg
Maximal power is proportionally lower by tuning to lower HV output.
Output ripple is 0.5% typically at maximal power for all models of HV power supplies.
Chapter 3

HIGH VOLTAGE POWER SUPPLY HVS-100
6
EKSMA OPTICS • Tel.: [phone] • Fax: [phone] • [e-mail] • www.eksmaoptics.com
WARNING
ThesafetyofthesystemincorporatingHVpowersupplyis the
responsibilityoftheassemblerofthesystem.
WARNING
Direct contact with the exposed inner parts of the system
when it is powered may cause human injuries or death.
WARRANTY
4.1. WARRANTY STATEMENT
This HV power supply HVS-100 is protected by one-year warranty
covering labor and parts. The warranty enters into validity since
the shipment date. Any evidence of improper use or
unauthorized attempts at repair leads to warranty cancellation.
4.2. SAFETY
Operating the power supply is allowed to persons acquainted
with the operation manual and having permission to deal with
voltages over 1000 V.
In order to ensure the safe operation of the product, please
follow these warnings and cautions in addition to the other
information contained elsewhere in this document.
❯Ensure that nothing, and nobody, will be endangered by this
High Voltage before putting the unit into operation!
❯The full dielectric strength of the high voltage connectors is
only realized when fully mated together.
❯If possible, familiarize yourself with the equipment being used
and the location of its high-voltage points.
❯Make sure that instruments are properly grounded.
❯Before supplying the power to the instrument, make sure that
the correct voltage of the AC power source is used.
❯After the power off please wait few seconds before making
any connections, in order for capacitors to discharge.
❯The units may only be operated in a clean, dry environment.
Please make sure that no objects or liquids can enter the casing
through the ventilating aperture. Because of the risk of sparks,
the unit should not be operated in the vicinity of flammable
gases or fumes.
❯To ensure a adequate cooling, the ambient temperature
should not exceed 40 °C. This unit is air cooled. Ensure that
nothing is placed near the back of unit which may impede the
air-flow. Do not expose the unit directly to solar radiation.
❯Use an insulated floor material or a large, insulated floor mat
to stand on, and an insulated work surface on which to place
equipment. Make certain such surfaces are not damp or wet.
❯Use the time-proven “one hand in the pocket” technique
while handling an instrument probe. Be particularly careful to
avoid contact with metal objects that could provide a good
ground return path.
4.3. SERVICE CONTACT INFORMATION
In case of service required or any questions on warranty, please
notify:
EKSMA Optics, UAB
Dvarcioniu st. 2B
LT-10233 Vilnius, Lithuania
Phone: [phone]
Fax.: [phone]
E-mail: [email protected]
Website: www.eksmaoptics.com
Chapter 4
