IBM 9008-22L User manual

Removing and replacing external
cables
IBM

ii Removing and replacing external cables

Contents
Removing and replacing the external HMC cable in the 9008-22L, 9009-22A, or 9223-22H 1
Preparing the system to remove and replace the external HMC cable ................ 1
Removing the external HMC cable from the 9008-22L, 9009-22A, or 9223-22H ............. 1
Replacing the external HMC cable in the 9008-22L, 9009-22A, or 9223-22H............... 2
Preparing the system for operation after removing and replacing the external HMC cable ......... 2
Removing and replacing the external serial cable in the 9008-22L, 9009-22A, or
9223-22H ................................... 3
Preparing the system to remove and replace the external serial cable ................ 3
Removing the external serial cable from the 9008-22L, 9009-22A, or 9223-22H.............. 3
Replacing the external serial cable in the 9008-22L, 9009-22A, or 9223-22H ............... 4
Preparing the system for operation after removing and replacing the external serial cable ......... 4
Removing and replacing the external USB cable in the 9008-22L, 9009-22A, or 9223-22H 5
Preparing the system to remove and replace the external USB cable ................. 5
Removing the external USB cable from the 9008-22L, 9009-22A, or 9223-22H .............. 5
Replacing the external USB cable in the 9008-22L, 9009-22A, or 9223-22H ............... 6
Preparing the system for operation after removing and replacing the external USB cable .......... 6
iii

iv Removing and replacing external cables

Removing and replacing the external HMC cable in the
9008-22L, 9009-22A, or 9223-22H
Find information about removing and replacing the external HMC cable in the 9008-22L, 9009-22A, or
9223-22H.
Preparing the system to remove and replace the external HMC cable
To prepare the system to remove and replace the external HMC cable, complete the steps in this
procedure.
Procedure
Removing the external HMC cable from the 9008-22L, 9009-22A, or
9223-22H
To remove the external HMC cable, complete the steps in this procedure.
Procedure
1. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an
unpainted metal surface until the service procedure is completed, and if applicable, until the service
access cover is replaced.
Attention:
vAttach an electrostatic discharge (ESD) wrist strap to the front ESD jack, to the rear ESD jack, or to
an unpainted metal surface of your hardware to prevent the electrostatic discharge from damaging
your hardware.
vWhen you use an ESD wrist strap, follow all electrical safety procedures. An ESD wrist strap is
used for static control. It does not increase or decrease your risk of receiving electric shock when
using or working on electrical equipment.
vIf you do not have an ESD wrist strap, just prior to removing the product from ESD packaging and
installing or replacing hardware, touch an unpainted metal surface of the system for a minimum of
5 seconds. If at any point in this service process you move away from the system, it is important to
again discharge yourself by touching an unpainted metal surface for at least 5 seconds before you
continue with the service process.
2. Disconnect the HMC cable indicated in the FRU Location field in the upper left of this page. See
Figure 1.
Figure 1. Removing an HMC cable
1

Replacing the external HMC cable in the 9008-22L, 9009-22A, or
9223-22H
To replace the external HMC cable, complete the steps in this procedure.
Procedure
1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged
into a ground jack or connected to an unpainted metal surface. If not, do so now.
2. Connect the HMC cable indicated in the FRU Location field in the upper left of this page. See
Figure 2.
Preparing the system for operation after removing and replacing the
external HMC cable
To prepare the system for operation after removing and replacing the external HMC cable, complete the
steps in this procedure.
Procedure
Figure 2. Replacing an HMC cable
2Removing and replacing external cables

Removing and replacing the external serial cable in the
9008-22L, 9009-22A, or 9223-22H
Find information about removing and replacing the external serial cable in the 9008-22L, 9009-22A, or
9223-22H.
Preparing the system to remove and replace the external serial cable
To prepare the system to remove and replace the external serial cable, complete the steps in this
procedure.
Procedure
Removing the external serial cable from the 9008-22L, 9009-22A, or
9223-22H
To remove the external serial cable, complete the steps in this procedure.
Procedure
1. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an
unpainted metal surface until the service procedure is completed, and if applicable, until the service
access cover is replaced.
Attention:
vAttach an electrostatic discharge (ESD) wrist strap to the front ESD jack, to the rear ESD jack, or to
an unpainted metal surface of your hardware to prevent the electrostatic discharge from damaging
your hardware.
vWhen you use an ESD wrist strap, follow all electrical safety procedures. An ESD wrist strap is
used for static control. It does not increase or decrease your risk of receiving electric shock when
using or working on electrical equipment.
vIf you do not have an ESD wrist strap, just prior to removing the product from ESD packaging and
installing or replacing hardware, touch an unpainted metal surface of the system for a minimum of
5 seconds. If at any point in this service process you move away from the system, it is important to
again discharge yourself by touching an unpainted metal surface for at least 5 seconds before you
continue with the service process.
2. Disconnect the serial cable indicated in the FRU Location field in the upper left of this page. See
Figure 3.
Figure 3. Removing the serial cable
3

Replacing the external serial cable in the 9008-22L, 9009-22A, or
9223-22H
To replace the external serial cable, complete the steps in this procedure.
Procedure
1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged
into a ground jack or connected to an unpainted metal surface. If not, do so now.
2. Connect the serial cable indicated in the FRU Location field in the upper left of this page. See
Figure 4.
Preparing the system for operation after removing and replacing the
external serial cable
To prepare the system for operation after removing and replacing the external serial cable, complete the
steps in this procedure.
Procedure
Figure 4. Replacing the serial cable
4Removing and replacing external cables

Removing and replacing the external USB cable in the
9008-22L, 9009-22A, or 9223-22H
Find information about removing and replacing the external USB cable in the 9008-22L, 9009-22A, or
9223-22H.
Preparing the system to remove and replace the external USB cable
To prepare the system to remove and replace the external USB cable, complete the steps in this
procedure.
Procedure
Removing the external USB cable from the 9008-22L, 9009-22A, or
9223-22H
To remove the external USB cable, complete the steps in this procedure.
Procedure
1. Attach the electrostatic discharge (ESD) wrist strap. The ESD wrist strap must be connected to an
unpainted metal surface until the service procedure is completed, and if applicable, until the service
access cover is replaced.
Attention:
vAttach an electrostatic discharge (ESD) wrist strap to the front ESD jack, to the rear ESD jack, or to
an unpainted metal surface of your hardware to prevent the electrostatic discharge from damaging
your hardware.
vWhen you use an ESD wrist strap, follow all electrical safety procedures. An ESD wrist strap is
used for static control. It does not increase or decrease your risk of receiving electric shock when
using or working on electrical equipment.
vIf you do not have an ESD wrist strap, just prior to removing the product from ESD packaging and
installing or replacing hardware, touch an unpainted metal surface of the system for a minimum of
5 seconds. If at any point in this service process you move away from the system, it is important to
again discharge yourself by touching an unpainted metal surface for at least 5 seconds before you
continue with the service process.
2. Disconnect the USB cable indicated in the FRU Location field in the upper left of this page. See
Figure 5.
Figure 5. Removing a USB cable
5

Replacing the external USB cable in the 9008-22L, 9009-22A, or
9223-22H
To replace the external USB cable, complete the steps in this procedure.
Procedure
1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged
into a ground jack or connected to an unpainted metal surface. If not, do so now.
2. Connect the USB cable indicated in the FRU Location field in the upper left of this page. See Figure 6.
Preparing the system for operation after removing and replacing the
external USB cable
To prepare the system for operation after removing and replacing the external USB cable, complete the
steps in this procedure.
Procedure
Figure 6. Replacing a USB cable
