ELAN Lighting CABLED-150-BEAM User manual

CABLED-150-BEAM
Thank you for purchasing a product from our CABLED-150-BEAM Every suit has been
thoroughly tested and shipped in perfect condition. Carefully check the shipping carton
for damage that may have occurred during shipping. If the carton appears to be damaged,
carefully inspect your unit for any damage and be sure all accessories necessary to operate
the unit has arrived intactly. In the case damage has been found or parts are missing,
please contact Acson Comercial or your local supplier for further instructions. Do not return
this unit without any warning.
USER’S MANUAL

2
Contents
FOR YOUR OWN SAFETY, PLEASE READ
THIS USER MANUAL CAREFULLY BEFORE
POWERING OR INSTALLING. SAVE IT FOR
FUTURE REFERENCE
1. Safety Instructions............................................................................................... 3
2. Unpacking .......................................................................................................... 3
3. Features & Specications ................................................................................... 4
4. Photometric Data ............................................................................................... 5
5. Operation Instructions ........................................................................................ 5
6. Installation .......................................................................................................... 6
7. DMX-512 Control Connections .......................................................................... 7
8. Menu Operations ................................................................................................ 7
9. DMX Channels .................................................................................................... 8
10. Maintenance And Cleaning .............................................................................. 10

3
1. Safety Instructions
2. Unpacking
Caution!
Be careful when operating this xture. Dangerous
voltage can cause serious electric shock.
!
This device has left the factory in perfect condition. In order to maintain this condition and to ensure a safe
operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written
in this user manual.
• If the device has been exposed to temperature changes due to environmental changes, do not switch
it on immediately. The arising condensation could damage the device.
• Leave the device switched o until it has reached room temperature.
• This device falls under protection-class I. Therefore it is essential that the device be earthed.
• The electric connection must carry out by qualied person.
• The device shall only be used with rate voltage and frequency.
• Make sure that the available voltage is not higher than stated at the end of this manual.
• Make sure the power cord is never crimped or damaged by sharp edges. If this would be the case,
replacement of the cable must be done by an authorized dealer.
• Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
• During initial start-up some smoke or smell or smell may arise. This is a normal process and does not
necessary mean that the device is defective, it should decrease gradually.
• Please don’t project the beam onto combustible substances.
• Fixtures cannot be installed on combustible substances, keep more than 50cm distance with wall for
smooth air ow, so there should be no shelter for fans and ventilation for heat radiation.
• If the external exible cable or cord of this luminaire is damaged, it shall be exclusively replaced by
the manufacturer of his service agent or a similar qualied person in order to avoid a hazard.
Thank you for choosing our LED 150W moving head light. For your own safety, please read this manual
before installing the device. This manual covers the important information on installation and applications.
Please install and operate the xture with following instructions. Meanwhile, please keep this manual well
for future needs.
The LED 150W is made of a new type of high temperature strength of engineering plastic and cast alumi-
num casing with nice outlook. The xture is designed and manufactured strictly following CE standards,
complying with international standard DMX512 protocol. It’s available independently controlled and linka-
ble with each other for operation. And it is applicable for large-scale live performances, theater, studio,
nightclubs and discos.
The 150W Moving head light which features high brightness and stability. Please carefully unpack it when
you receive the xture and check whether it is damaged during the transportation.

4
2.1 Included in the box:
3. Features & Specications
1
1Moving Head
2Signal Cable
3Power Clamp
4Omega Clamp
5User Manual
• 150W High Output White LED
• 50,000 hours lifespan and low power consump-
tion
• Beam Angle 6°, Outstanding sharp BEAM eect
and remarkable wash eect with pure color
mixing and focus Function
• High light output, 14020LUX@5M at White light
• Temperature protect function, when the internal
temperature is up to 40° and then the fans be-
gin to work, when the internal temperature is up
to 70° and the brightness reduce half.
• Color Wheel: 7 colors +white, rotation with va-
riable direction and speed
• 1 static Gobo Wheel: 8 gobos +white, wheel
rotation and shake
• 1 Rotate Gobo Wheel: 6 gobos +white, wheel
rotation and shake
• Prism: 8-facet Prism, bi-directionally rotatable at
variable speeds
• High speed strobe eect with 1-25 ashers per
second
• Internal program available
• 16/14/12/10 DMX Channels USITT DMX-512
• DMX 512, master-slave and sound activated
controllable or auto operation
• Specic computer control software as optional
• Colorful LCD display
• Ecient low noise fan cooling system
• POWERCON IN/OUT
• 3-pin XLR connectors IN/OUT
• Two 1/4 turn fastening Omega Clamps
• IP 20 protection rating
3.1 Features
3.2 Specications
• Input Voltage: AC90-260V 50/60Hz
• Light Source: 150W High Output White LED
• Control Signal: DMX 512, master-slave and
sound activated or auto operation
• Control Channel: 16/14/12/10 DMX Channels
USITT DMX-512
• Power Consumption: 250W
• Dimensions: 270(D) x 270(W) x 470(H)mm
• Packing Dimensions: 305(D) x 305(W) x 500(H)
mm
• Net Weight: 10.6kg, Gross Weight: 12.6kg

5
4. Photometric Data
5. Operation Instructions
• The moving head is for beam eect for on-site
decoration purpose.
• Don’t turn on the xture if it’s been through
severe temperature dierence like after trans-
portation because it might damage the light due
to the environment changes. So make sure to
operate the xture until it is in normal tempera-
ture.
• This light should be keep away from strong sha-
king during any transportation or movement.
• Don’t pull up the light by only the head, or it
might cause damages to the mechanical parts.
• Don’t expose the xture in overheat, moisture
or environment with too much dust when insta-
lling it. And don’t lay any power cables on the
oor. Or it might cause electronics shock to the
people.
• Make sure the installation place is in good safe-
ty condition before installing the xture.
• Make sure to put the safety chain and check
whether the screws are screwed properly when
installing the xture.
• Make sure the lens are in good condition. It’s
recommended to replace the units if there are
any damages or severe scratch.
• Make sure the xture is operated by qualied
personnel who know the xture before using.
• Keep the original packages if any second ship-
ments is needed.
• Don’t try to change the xtures without any ins-
truction by the manufacturer or the appointed
repairing agencies.
• It is not in warranty range if there are any mal-
functions from not following the user manual to
operate or any illegal operation, like shock short
circuit, electronic shock, lamp broke, etc.

6
6. Installation
Caution!
For added protection mount the xtures in areas outside walking paths, seating areas,
or in areas were the xture might be reached by unauthorized personnel.
!
• Before mounting the xture to any surface, make sure that the installation area can hold a minimum
point load of 10 items the device’s weight.
• Fixture installation must always be secured with a secondary safety attachment, such as an appropria-
te safety cable.
• Never stand directly below the device when mounting, removing, or servicing the xture.
• From a ceiling, or set on a at level surface (see illustration below). Be sure this xture is kept at least
0.5m (1.5ft) away from any ammable materials (decoration etc.).
• Always use and install the supplied safety cable as a safety measure to prevent accidental damage
and/or injury in the event the clamp fails.
6.1 Mounting Points
6.2 Mounting Points
Overhead mounting requires extensive experience, including amongst others calculating working load
limits, a ne knowledge of the installation material being used, and periodic safety inspection of all installa-
tion material and the xture. If you lack these qualications, do not attempt the installation yourself. Impro-
per installation can result in bodily injury.
Be sure to complete all rigging and installation procedures before connecting the main power cord to the
appropriate wall outlet.
The LED Moving Head provides a unique mounting bracket assembly that integrates the bottom of the
base, and the safety cable rigging point in one unit (see the illustration below). When mounting this xture
to truss be sure to secure an appropriately rated clamp to the included omega bracket using a M10 screw
tted through the center hole of the “omega bracket”. As an added safety measure be sure to attached at
least one properly rated safety cable to the xture using on of the safety cable rigging point integrated in
the base assembly.
Regardless of the rigging option you choose for
your LED Moving Head, always be sure to secure
your xture with a safety cable. The xture provi-
ders a built-in rigging point for a safety cable on
the hanging bracket as illustrated above. Be sure
to only use the designated rigging point for the
safety cable and never secure a safety cable to a
carrying handle.

7
7. DMX-512 Control Connections
8. Menu Operations
8.2 Menu
Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to
the male 3-pin XLR input of the moving head. You can chain multiple moving head together through serial
linking. The cable needed should be two core, screened cable with XLR input and output connectors.
Please refer to the diagram below.
For installations where the DMX cable has to run a long distance or is in an electrically noisy environment,
such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corrup-
tion of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120
Ω resistor connected between pins 2 and 3, which is then plugged into the output XLR socket of the last
xture in the chain. Please see illustrations above.
DMX Connection DMX Terminator Connection
Address Set [Set Address Numbers]
Run Mode
DMX
AUTO Auto 1 - Auto 2
SOUND
MANUAL Manual Test Function and Operation
Setup Advanced Setting
Pan Reverse
Tilt Reverse
Display
Screen Reverse
Channel (16/14/12/10CH-Select)
Sensitivity (01-100)
Motor Zero
Reset
Factory Set
8.1 Digital Display

8
System
Information
Ver V1
DMX Address
Temperature
9. DMX Channels
CH10 CH12 14CH 16CH Function Channel Value Description
CH1 CH1 CH1 CH1 Pan 0-255 0-540°
CH2 CH2 Pan ne 0-255 Pan Fine
CH2 CH2 CH3 CH3 Tilt 0-255 0-270°
CH4 CH4 Tilt Fine 0-255 Tilt Fine
CH3 CH3 CH5 CH5 X, Y speed 0-255 From fast to slow
CH4 CH4 CH6 CH6 LED Dimmer 0-255 From dark to bright
CH5 CH5 CH7 CH7 LED Strobe
0-7 Turn on
8-250 Strobe from slow to fast
251-255 Turn on
CH6 CH6 CH8 CH8 7 color + White
0-15 White Light
16-31 Color 1
32-47 Color 2
48-63 Color 3
64-79 Color 4
80-95 Color 5
96-111 Color 6
112-127 Color 7
128-191 CW from slow to fast
192-255 CCW from slow to fast
CH7 CH7 CH9 CH9 8 Static Gobos
+White
0-6 Open
7-13 Gobo 1
14-20 Gobo 2
21-27 Gobo 3
28-34 Gobo 4
35-41 Gobo 5
42-48 Gobo 6
49-55 Gobo 7
56-63 Gobo 8
64-70 Gobo 8 shake speed from slow to
fast
71-77 Gobo 7 shake speed from slow to
fast
78-84 Gobo 6 shake speed from slow to
fast

9
CH10 CH12 14CH 16CH Function Channel Value Description
CH7 CH7 CH9 CH9 8 Static Gobos
+White
85-91 Gobo 5 shake speed from slow to
fast
92-98 Gobo 4 shake speed from slow to
fast
99-105 Gobo 3 shake speed from slow to
fast
106-112 Gobo 2 shake speed from slow to
fast
113-119 Gobo 1 shake speed from slow to
fast
120-127 Open
128-191 Gobo Rotate CCW slow to fast
192-255 Gobo Rotate CW slow to fast
CH8 CH10 6 rotation gobos
+White
0-15 open
16-31 Gobo1
32-47 Gobo2
48-63 Gobo3
64-79 Gobo4
80-95 Gobo5
96-127 Gobo6
128-191 Gobo Rotate CW slow to fast
192-255 Gobo Rotate CCW slow to fast
CH9 CH11 Gobo Rotation
0-15 open
16-95 Gobo Fine 0-360
96-135 Gobo Rotating 0-90
CH9 CH11 Gobo Rotation
136-155 Gobo Rotating 0-180
156-175 Gobo Rotating 0-720
176-215 Gobo self-rotating CW from slow
to fast
216-255 Gobo self-rotating CCW rotating
from slow to fast
CH8 CH10 CH10 CH12 Focus 0-255 Gobo hazy to clear
CH9 CH11 CH11 CH13 Prism 0-63 Open
64-255 Prism In
CH10 CH12 CH12 CH14 Prism Rotation
0-15 Stop
16-135 Rotate CW slow > fast
136-255 Rotate CCW slow > fast
CH13 CH15 self-setting Program
0-7 No action
8-131 Auto mode
132-255 Sound mode
CH14 CH16 Reset 250-253 Reset

10
10. Maintenance And Cleaning
The following points have to be considered during the inspection:
1. All screws for installing the devices or parts of the device have to be tightly connected and must not
be corroded.
2. There must not be any deformations on the housing, color lenses, xations and installation spots (cei-
ling, suspension, trussing).
3. Mechanically moved parts must not show any traces of wearing and must not rotate with unbalances.
4. The electric power supply cables must not show any damage, material fatigue or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a skilled installer
and any safety problems have to be removed.
In order to make the lights in good condition and extend the life time, we suggest a regular cleaning to the
lights.
1. Clean the inside and outside lens each week to avoid the weakness of the lights due to accumulation
of dust.
2. Clean the fan each week.
3. A detailed electric check by approved electrical engineer each three month, make sure that the circuit
contacts are in good condition, prevent the poor contact of circuit from overheating.
10.1 Maintenance
10.2 Cleaning
We recommend a frequent cleaning of the device. Please use a moist, lint-free cloth. Never use alcohol
solvents.
There are no serviceable parts inside the device. Please refer to the instructions under “Installation instruc-
tions”.
Should you need any spare parts, please order genuine parts from your local dealer.

Note: All information is subject to change without prior notice.
IMPORTANT INFORMATION!
In order to optimize the recovery and recycling of the materials that old appliances contain
and reduce the impact on human health and the environment, please make sure that this
product is recycled at the end of its life.
Importer:
ACSON COMERCIAL
C/Pallars, 405
08019 Barcelona
www.acson.com
[email protected]
