Elan EL-4KM-V88 User manual

EL-4KM-V88
User Manual
TCP/IP RS-232
HDMI Input HDMI Output
IR Input
HDBT Output
IR Ext. EDID
Power12V
On/Off
0
1
1 2 3 4 5 6 7 8
3 4 5 6 7 8
IR Output
1 2 3 4 5 6
3 4
1 2 5 6 7 8
EL-4KM-V88
7 8
POH 24V6A
5A
1
Lock 2 3 4 5 6 7 8 PTP
1Power
IR 2 3 4 5 6 7 8 All
In
Out
Menu Up Esc
Select Down Enter
EDID
VideoMatrix
TCP/IP RS-232
HDMI Input HDMI Output
IR Input
HDBT Output
IR Ext. EDID
Power12V
On/Off
0
1
1 2 3 4 5 6 7 8
3 4 5 6 7 8
IR Output
1 2 3 4 5 6
3 4
1 2 5 6 7 8
EL-4KM-V88
7 8
POH 24V6A
5A
1
Lock 2 3 4 5 6 7 8 PTP
1Power
IR 2 3 4 5 6 7 8 All
In
Out
Menu Up Esc
Select Down Enter
EDID
VideoMatrix

02
www.elanhomesystems.com
EL-4KM-V88 USER MANUAL
Surge protection device
recommended
This product contains sensitive electrical
components that may be damaged by
electrical spikes, surges, electric shock,
lightning strikes, etc. Use of surge protection
systems is highly recommended in order
to protect and extend the life of your
equipment.
Safety And
Performance Notice
The transmission distances of HDMI
over UTP cables are measured using
TE CONNECTIVITY 1427071-6
EIA/TIA-568-B termination (T568B)
of cables is recommended for optimal
performance.
To minimize interference of the unshielded
twisted pairs in the CAT5e/6 cable do not
run the HDBaseT/Cat5e/6/6a cabling with
or in close parallel proximity to mains power
cables.
Do not substitute or use any other power
supply other than the enclosed unit, or a
ELAN approved replacement.
Do not disassemble either the Transmitter or
Receiver units for any reason. Doing so will
void the manufacturer’s warranty.
Introduction 03
Features 03
Panel Descriptions 04
Control Ports 05
HDBaseT Receiver Options 06
Matrix Front Panel Controls 07
Terminating HDBaseT CAT Cables 08
Understanding Matrix/Receiver Status Lights 08
Infrared Distribution 09
Infrared Remote Control 10
EDID Control 11
Application Diagram 12
Specifications 13
Package Contents 13
Maintenance 13
RS-232 and Telnet Commands 14-15
Infrared Commands 16-18
Web Browser Interface 19
Certifications 19
Contents
Thank you for purchasing
this product.
For optimum performance and safety, please
read these instructions carefully before con-
necting, operating or adjusting this product.
Please keep this manual for future reference.

EL-4KM-V88 USER MANUAL
03
contact [e-mail]
The ELAN 8x8 HDBaseT™ Matrix offers unprecedented performance and value for
the custom installation market. The EL-4KM-V88 is a 4K HDCP 2.2 8x8 matrix with a
combination of 6 x HDBaseT™ and 2 x HDMI outputs. This allows for cost-effective
integration of local displays or AV receivers within an installation. The Matrix delivers
HDMI, Bi-directional IR and PoH (PoE) up to lengths of 40m at 4K (70m @1080p)
over a single CAT cable. The EL-4KM-V88 Matrix features a web browser interface
for control and configuration and is seamlessly integrated into ELAN control systems.
Introduction
Features:
• Features 8x HDMI inputs which can be independently routed to 6x HDBaseT™ outputs and 2x independent HDMI outputs
• Extends HDMI up to a distance of 70m 1080P over single CAT cable
• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports 3D signal display
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus
and DTS-HD Master Audio transmission
• Supports bi-directional IR on all HDBaseT outputs
• Web browser interface for control and configuration of Matrix
• Control via front panel, IR, RS-232, and TCP/IP
• Supports PoH (Power over HDBaseT™) to power compatible HDBaseT™ receivers
• Advanced EDID management
• HDCP 2.2 compliant
• 1U Design for 19” rack mount integration - mounting kit included

04
www.elanhomesystems.com
EL-4KM-V88 USER MANUAL
Rear Panel
1 2 3 4 5 6 7 8
91110
1RJ45 – TCP/IP control (Connect to LAN)
2RS-232 port – Connect to this port
for the control of the matrix from a
computer or control processor.
3IR inputs – 3.5mm stereo jack.
Transmits IR to the zone HDBaseT
receiver (displays). When using the
IRCAB cable (supplied) ensure cable
direction is correct.
4IR outputs – 3.5mm mono jack –
Routed IR from HDBaseT extender
(zone output).
5IR input for matrix control – For hard
wired IR connection. Connect to ELAN
control processor.
6EDID DIP switch – Used for global EDID
settings
7POH power port – Use included 24V/6A
DC adaptor to power the remote
HDBaseT receivers.
8Power port – Use included 12V/5A DC
adaptor to power the matrix switcher.
9HDMI inputs 1 to 8 – Connect HDMI
sources.
qHDMI outputs 1 to 2 – Output for
displays.
wHDBT outputs 3 to 8 – Output for
displays.
Front Panel
1 2 4
11
5
12
6
13
7
14
8
15
9
16
3
10
1LCD display – Shows the status of input-
output selection, menu and EDID info.
2IR receiver window – Receives IR from a
hand held remote control or processor.
3Power LED indicator – Indicates the
power status of the matrix.
4Power button – Press to toggle the
power of the matrix on/off.
5HDMI output selection button 1 to 8 –
Press to select the output from
1 to 8.
6All button for HDMI outputs – Press to
select all of the outputs from 1 to 8.
7Menu button – Press to enter EDID
setup mode. Three EDID segments
will display on the LCD panel listed as:
INPUT, VIDEO and AUDIO, for example:
IN1 1080P 2.0CH, means to set 1080P
2.0CH EDID to INPUT1. The blinking
segment is the adjustable parameter.
8Up – Press to change up through the
adjustable values.
9ESC – Press to quit EDID setup menu.
qLock LED indicator – Indicate the status
of the key lock.
wLock button – Press to lock the buttons
on the front panel.
eHDMI input selection button 1 to
8 – Press to select the input from
1 to 8.
rPTP – Press to mirror all inputs and
outputs (e.g. output 1 to input 1, output
2 to input 2 and so on).
tSelect – Press to select an EDID
parameter to change. Selected segment
will blink.
yDown – Press to change down through
the adjustable values.
uEnter – Press to set EDID to specified
INPUT or copy EDID from specified
OUTPUT to specified INPUT.
TCP/IP RS-232
HDMI Input HDMI Output
IR Input
HDBT Output
IR Ext. EDID
Power12V
On/Off
0
1
1 2 3 4 5 6 7 8
3 4 5 6 7 8
IR Output
1 2 3 4 5 6
3 4
1 2 5 6 7 8
EL-4KM-V88
7 8
POH 24V6A
5A
1
Lock 2 3 4 5 6 7 8 PTP
1Power
IR 2 3 4 5 6 7 8 All
In
Out
Menu Up Esc
Select Down Enter
EDID
VideoMatrix
TCP/IP RS-232
HDMI Input HDMI Output
IR Input
HDBT Output
IR Ext. EDID
Power12V
On/Off
0
1
1 2 3 4 5 6 7 8
3 4 5 6 7 8
IR Output
1 2 3 4 5 6
3 4
1 2 5 6 7 8
EL-4KM-V88
7 8
POH 24V6A
5A
1
Lock 2 3 4 5 6 7 8 PTP
1Power
IR 2 3 4 5 6 7 8 All
In
Out
Menu Up Esc
Select Down Enter
EDID
VideoMatrix

EL-4KM-V88 USER MANUAL
05
contact [e-mail]
The EL-4KM-V88 main communication ports are located on the rear panel and includes the following connections:-
Connections:
A. TCP/IP – For control of the Matrix (RJ45 Connector).
B. RS-232 – For control of the Matrix (9 pin serial connection).
C. IR Input (3.5mm stereo jack) for IR pass-through to associated output
HDBaseT Receiver*.
D. IR Output (3.5mm mono jack) for routed IR control of source equipment*.
E. Global IR Input 3.5mm stereo jack - For controlling the Matrix Switcher*.
There is no IR routing for outputs 1 & 2 on the EL-4KM-V88 Matrix as these are HDMI
outputs only and designed for connection to local displays/hardware.
TCP/IP
The ELAN EL-4KM-V88 can be controlled via TCP/IP.
For full list of protocols please see ‘RS-232 & Telenet Commands’ located at the rear of
this manual.
The EL-4KM-V88 features a built-in web browser user interface allowing control and
configuration of the matrix. For further details please see page 19 ‘Web Browser User
Inter face’.
A ‘Straight-through’ RJ45 patch lead should be used.
RS-232 2-Way
The ELAN EL-4KM-V88 can be controlled via a 9-pin serial cable.
For full list of protocols please see ‘RS-232 & Telenet Commands’ located at the rear of
this manual.
Details of RS-232 pin assignment and communication are adjacent. Please note that
depending on your control device serial port pin configuration you may require either a
‘Straight’ RS-232 cable or ‘Null-modem’ type.
EL-4KM-V88 Control Ports
ELAN RS-232 REMOTE CONTROL
CONSOLE
PIN Assignment PIN Assignment
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 57600 bps
Data Bit: 8-bit
Parity: None
Stop Bit: 1-bit
Flow Control: None
AB
E
TCP/IP RS-232
HDMI Input
HDMI Output
IR Input
HDBT Output
IR Ext. EDID
Power12V
On/Off
0
1
1 2 3 4 5 6 7 8
3 4
5 6 7 8
IR Output
1 2 3 4 5 6
3 4
1 2 5 6 7 8
EL-4KM-V88
7 8
POH 24V6A
5A
1
Lock 2 3 4 5 6 7 8 PTP
1Power
IR 2 3 4 5 6 7 8 All
In
Out
Menu Up Esc
Select Down Enter
EDID
VideoMatrix
TCP/IP RS-232
HDMI Input
HDMI Output
IR Input
HDBT Output
IR Ext. EDID
Power12V
On/Off
0
1
1 2 3 4 5 6 7
8
3 4 5 6 7 8
IR Output
1 2 3 4 5 6
3 4
1 2 5 6 7
8
EL-4KM-V88
7 8
POH 24V6A
5A
1
Lock 2 3 4 5 6 7 8 PTP
1Power
IR 2 3 4 5 6 7 8 All
In
Out
Menu Up Esc
Select Down Enter
EDID
VideoMatrix
C D

06
www.elanhomesystems.com
EL-4KM-V88 USER MANUAL
There are two HDBaseT receiver options that are recommended to be used with the HDBaseT outputs on the EL-4KM-V88:-
EL-4KHDBT-RX-40-IR
Basic HDBaseT Receiver with 2-way IR pass-through. Supports display distances up to 70m @ 1080P and 40M 4K (30Hz 4:4:4 & 60Hz 4:2:0).
EL-4KM-V88 HDBaseT Receiver Options
* Note - Other HDBaseT receivers will work with the HDBaseT outputs of the ELAN EL-4KM-V88 but some features of these receivers may not
be supported by the Matrix.
• HDBaseT input/HDMI output
• IR Output 3.5mm mono jack
• IR Input 3.5mm stereo jack
HDMI Out
LINK POWER
IR RXIR TX12V
2A
EL-4KHDBT-RX-40-IR
HDBT In
LINK
HDMI Out
LINK POWER
IR RXIR TX12V
2A
EL-4KHDBT-RX-40-IR
HDBT In
LINK
EL-4KHDBT-RX-40-IRS
Mid-Level HDBaseT receiver which has the same features as the EL-4KHDBT-RX-70-ARC receiver but with added 2-way RS-232 control.
• HDBaseT input/HDMI output
• 2-way RS-232 (9-pin serial) -
• IR Output 3.5mm mono jack
• IR Input 3.5mm stereo jack
EL-4KHDBT-RX-40-IRS
HDBT In
Standard
Upgrade
LINK POWER
12V
2A
HDMI Out
HDMI
LINK
RS-232 IR RX IR TX
EL-4KHDBT-RX-40-IRS
HDBT In
Standard
Upgrade
LINK POWER
12V
2A
HDMI Out
HDMI
LINK
RS-232 IR RX IR TX
NOTE: EL-4KM-V88 does not support RS-232

EL-4KM-V88 USER MANUAL
07
contact [e-mail]
Matrix Front Panel Control
Front Panel Display - Input/Output selection
The following display shows current source input selection per zone output.
1. To change input selection first press ‘OUTPUT’ button (1-8)
2. Press desired ‘INPUT’ button (1-8)
3. An ‘X’ indicates that the zone output has been turned off.
Zones can be turned on/off using RS-232/TCP/IP commands.
Zone outputs can be forced back on by powering OFF/ON the matrix. All outputs will be turned on when powered up.
Zone outputs can be forced back on by pressing and holding ‘OUTPUT 1’ button on the front panel for 10 seconds.
The matrix will reset and all outputs will be turned back on.
OUT 1 2 x 4 5 x 7 8
IN 1 2 3 4 5 6 7 8
EDID: IN ALL
HDMI: 1080P 2CH
EDID Management - Global or individual input settings
The following characters show adjusting the EDID for ‘All’ inputs (Global). Current EDID value is set to 1080P & 2ch audio.
To change the input signal type using the Matrix front panel buttons press the following:-
Using Matrix Front Panel Buttons
a. Press MENU button
b. Panel will display ‘EDID settings’. Press SELECT button
c. Select the input you wish to fix the EDID on (1-8) or select ‘All’. Use UP/DOWN buttons to toggle selection and SELECT button to confirm
d. Select video resolution required (4K, 1080p, 3D etc). Use UP/DOWN buttons to toggle selection and SELECT button to confirm
e. Select audio resolution required (2CH, 5.1 or 7.1). Use UP/DOWN buttons to toggle selection and SELECT button to confirm
f. Press the ESC button to exit
2
1
TCP/IP RS-232
HDMI Input HDMI Output
IR Input
HDBT Output
IR Ext. EDID
Power12V
On/Off
0
1
1 2 3 4 5 6 7 8
3 4 5 6 7 8
IR Output
1 2 3 4 5 6
3 4
1 2 5 6 7 8
EL-4KM-V88
7 8
POH 24V6A
5A
1
Lock 2 3 4 5 6 7
8 PTP
1Power
IR 2 3 4 5 6 7
8 All
In
Out
Menu Up Esc
Select Down Enter
EDID
VideoMatrix
3

08
www.elanhomesystems.com
EL-4KM-V88 USER MANUAL
Terminating HDBaseT CAT cable
It is important that the interconnecting CAT cable between the ELAN HDBaseT products is terminated using the correct RJ45 pin configuration. The
link CAT cable MUST be a ‘straight’ (pin-to-pin) CAT cable and it is advised that this is wired to the T568B wiring standard as this format is less
prone to EMI (Electro-Magnetic Interference).
When installing CAT cables it is advised that you use the best possible CAT cable quality possible. HDMI disitrbution products will only work if used
with CAT5e standard cable or above. ELAN recommends using a CAT6 cable for your installations, especially when running over longer distances,
in areas of high EMI, or with 4K signal distribution.
RJ45 Pin-Out
T568B
12345678
Understanding the Matrix/Receiver HDBaseT status lights
The ELAN Matrix and HDBaseT extender solutions include status LED indicators on both the Matrix and Receiver products to show all connections
are active and to help diagnose possible problems.
Understanding the status lights:-
ELAN Matrix:
• The Yellow HDBaseT status link light will be off when the zone output has been turned off or there is a problem with the specific Matrix output.
• The Yellow HDBaseT status link light will blink when the zone output is on and working
• The Green HDBaseT link light will blink if there is an unstable connection between the ELAN Matrix and HDBaseT Receiver
• The Green HDBaseT link light will be lit when a there is an active HDBaseT Receiver connected to the Matrix
• The Green HDBaseT link light will be off when a there is no connection with a HDBaseT receiver
ELAN HDBaseT Receiver:
• The HDMI link light will be off when there is no connection with a display
• The HDMI link light will be on when there is an active connection with a display (NOTE - Not all HDBaseT RX feature a HDMI status LED)
• The HDBaseT link light will be off when there is no CAT cable/active HDBaseT connection on the RJ45 HDBaseT input
• The HDBaseT link light will blink if there is an unstable connection between the ELAN Matrx and HDBaseT receiver
• The HDBaseT link light will be lit when a CAT cable is connected to the HDBaseT RJ45 output on the Matrix and an active connection is
achieved with the ELAN HDBaseT Receiver.

EL-4KM-V88 USER MANUAL
09
contact [e-mail]
The ELAN range of HDMI matrix products include multiple options for control and routing of IR.
IMPORTANT: The ELAN HDMI Platinum, Matrix, & HDBaseT product lines utilize 5 volts to power an IR Receiver on the IR Input and
include an EL-4KACC-IR-CAB, 3.5mm Mono to 3.5mm Stereo 5v to 12v IR converter cable. This cable is required when using 12v IR
products from Xantech, Niles, and SpeakerCraft.
Each ELAN Matrix and HDBaseT receiver is supplied with all necessary IR hardware required and includes:
Infrared (IR) Distribution
IR Control Cable - EL-4KACC-IR-CAB
ELAN IR Control cable 3.5mm Mono to 3.5mm Stereo for linking
third party IR Receivers to ELAN Platinum, Matrix, and HDBaseT
HDMI Series products.
Compatible with 12v IR third party products.
Note: Cable is directional as indicated
IR Receiver - Stereo 3.5mm
Signal
Power
Ground
Infrared 3.5mm Pin-Out
IR Emitter - Mono 3.5mm
Signal
Ground

10
www.elanhomesystems.com
EL-4KM-V88 USER MANUAL
Infrared (IR) Control
Remote Control Description
The ELAN EL-4KM-V88 Matrix is supplied with one IR Remote Control for source selection and general setup.
As well as controlling matrix solutions using the original ELAN remote the ELAN products can be controlled using the original Infrared codes shown
at the rear of this manual.
OUTPUT AND INPUT SELECTION
ASelect the zone OUTPUT you wish to change the source on
(Numbers 1-8 correspond to the zone outputs 1-8).
BSelect the source INPUT you wish to change on the selected zone to
(Numbers 1-8 corresponds to the source inputs 1-8)
CPress PTP button If you wish to instantly mirror all inputs and outputs
(Example - Input 1 to output 1, input 2 to output 2 etc).
EDID Configuration
Fixed EDID to INPUT / ALL INPUTS:
To select video resolution - Press 1080I/1080P/3D/4K
To select Audio resolution - Press 2.0CH/5.1CH/7.1CH
To assign settings to individual input/all inputs – Press INPUT /ALL button in
‘ZONE INPUT’ area of remote control
Copy EDID of any specific OUTPUT to any assigned INPUT or ALL INPUTS:
Press COPY button
Press OUTPUT zone button you wish to copy EDID from
Press INPUT zone button /ALL button to copy EDID to
User defined EDID to any INPUT or ALL INPUTS:
Press USER1/USER2 button
Press selected INPUT or ALL button to assign EDID
NOTE: THE BUTTON PRESS SEQUENCE SHOULD BE FINISHED IN 5 SECONDS,
OTHERWISE THE OPERATION IS DISCARDED
POWER
1
ALL PTP
OUTPUT
2 3 4
1
ALL
INPUT
2 3 4
POWER
1
ALL PTP
OUTPUT
2 3 4
5 6 7 8
1
ALL
INPUT
2 3 4
5 6 7 8
1080i 1080p 3D 4K
USER1 USER2 FN1
EDID
FN2
2.0CH 5.1CH 7.1CH COPY
1080i 1080p 3D 4K
USER1 USER2 FN1
EDID
FN2
2.0CH 5.1CH 7.1CH COPY
B
C
A

EL-4KM-V88 USER MANUAL
11
contact [e-mail]
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source. This data is used by the source to find
out what audio and video resolutions are supported by the display then from this information the source will discover what the best audio and video
resolutions need to be outputted.
While the objective of EDID is to make connecting a digital display to a source a simple plug and play procedure issues do arise when multiple
displays or video matrix switching is introduced because of the increased number of variables.
By pre-determining the video resolution and audio format of the source and display device you can reduce the time need for EDID hand shaking
thus making switching quicker and more reliable.
Configuration of the EDID settings can be achieved in one of four ways:
1Via the Web GUI
2Using Matrix Front Panel Buttons (For further details see page 7)
3Using Supplied ELAN Matrix IR Remote Control (For further details see page 10)
4Using dip-switches on the rear panel of the EL-4KM-V88 Matrix. Please see below table for global EDID settings.
*Note - Once dip-switch settings have been made the EL-4KM-V88 must be power cycled
for settings to be applied.
EDID Control
Global EDID settings DIP ON /OFF SWITCHING POSITIONS
EDID TYPE3 2 1 0
OFF OFF OFF OFF 1080p/2.0
OFF OFF ON OFF 1080i/2.0
OFF ON OFF OFF 4K60Hz 4:2:0 2.0
OFF ON ON OFF 4K30Hz 4:4:4 2.0
ON OFF OFF OFF 4K30Hz 4:4:4 5.1
ON OFF ON OFF 4K30Hz 4:4:4 7.1
ON ON OFF OFF DVI 1280x1024
Dip-switch position ‘0’ = Off
Dip-switch position ‘1’ = On
TCP/IP RS-232
HDMI Input HDMI Output
IR Input
HDBT Output
IR Ext. EDID
Power12V
On/Off
0
1
1 2 3 4 5 6 7 8
3 4 5 6 7 8
IR Output
1 2 3 4 5 6
3 4
1 2 5
6
7 8
EL-4KM-V88
7 8
POH 24V6A
5A
1
Lock 2 3 4 5 6 7 8 PTP
1Power
IR 2 3 4 5 6 7 8 All
In
Out
Menu Up Esc
Select Down Enter
EDID
VideoMatrix
Note - When setting EDID values using the dip-switches there are limited EDID types available. It is advised that EDID values are adjusted using
the EL-4KM-V88 front panel. For full details please see page 7 ‘Matrix Front Panel Control’.

12
www.elanhomesystems.com
EL-4KM-V88 USER MANUAL
Example Schematic EL-4KM-V88
Cat 5/5e/6 Network Connection RS232 HDMI IR Cable
5678
4
3
2
1DISPLAY 1
DISPLAY 2
DISPLAY 3
HD BT RECEIVER
ZONE 03
ZONE 04
ZONE 05
ZONE 06
ZONE 07
ZONE 08
SOURCE 01
SOURCE 02
SOURCE 03
SOURCE 04
SOURCE 05
SOURCE 06
SOURCE 07
SOURCE 08
ZONE
01
ZONE
02
ZONE
03
ZONE
04
ZONE
05
ZONE
06
ZONE
07
ZONE
08
in
out
70m max
POH
IR Emitter
Link to source
HDMI RS232 IR
EL-4KHBT-RX-40-IR
ABCD
A
B
IR Receiver
Link to control device
MAXIMUM OF 8 SOURCES
Control Processor
C
D
EL-4KM-V88
Receiver
CONNECTION DIAGRAM
Application Diagram

EL-4KM-V88 USER MANUAL
13
contact [e-mail]
Video Input Connections: 8x HDMI Type A, 19-pin, female
Video Output Connections: 6x HDBaseT RJ45 connector, 2x HDMI Type A, 19-pin, female
RS-232 serial port: DB-9, female
TCP/IP Control: RJ45, female
IR Input ports: 9x 5v 3.5mm stereo jack
IR Output ports: 8x 5v 3.5mm mono jack
Rack-Mountable: 1U rack height, rack ears included
Casing Dimensions (W x H x D): 440mm x 300mm x 43mm, without feet
Dimensions (W x D x H): 440mm x 305mm x 43mm, with feet
Shipping Weight: 2.7kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature: -4°F to 140°F (-20°C to 60°C)
Power Supply: 12V/5A DC (main) & 24V/6A DC (POH)
NOTE: Specifications are subject to change without notice.
Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
Specifications:
Package Contents:
• 1 x EL-4KM-V88
• 1 x Rack mounting kit
• 1 x 24V/6A power supply
• 1 x 12V/5A power supply
• 1 x Remote control
Remote Includes CR2025 battery
• 8 x 5v-to-12v IR converter cables
• 1 x User manual
• 8 x Power cables (2x Type A, C, G & I)

14
www.elanhomesystems.com
EL-4KM-V88 USER MANUAL
RS-232 and Telnet Commands
The ELAN EL-4KM-V88 can be controlled via serial and TCP/IP. The following pages list all available serial commands for the EL-4KM-V88 Matrix.
Details of RS-232 pin assignment can be found on page 05.
Commonly used Serial commands:
There are several commands that are commonly used for control and testing:-
STATUS Status will give feedback on Matrix such as zones on, type of connection etc
PON Power on
POFF Power off
OUTxxON (xx is the zone number you wish to turn on)
Example:- OUT01ON (This would turn output one back on)
OUTxxFRyy (xx is the zone out, yy is the input)
Example:- OUT01FR04 (This would switch output 1 to source input 4)
Common Mistakes
• Carriagereturn–Someprogramsdonotrequirethecarriagereturnwhereasotherwillnotworkunlesssentdirectlyafterthestring.Inthecase
of some Terminal software the token <CR> is used to execute a carriage return. Depending on the program you are using this token maybe
different. Some other examples that other control systems deploy include \r or 0D (in hex)
• Spaces–ELANcommandsdonotrequirespacebetweencommandsunlessspecied.
There may be some programs that require spacing in order to work.
- How the string should look is as follows OUT01ON
- How the string may look if spaces are required: OUT{Space}01{Space}ON
• Baudrateorotherserialprotocolsettingsnotcorrect-PleaseseePage5forMatrixsettings
RS-232 COMMAND DESCRIPTION
?Print Help Information
HELP Print Help Information
STATUS Print System Status And Port Status
PON Power On, System Run On Normal State
POFF Power Off, System Run On Power Save State
IR ON/OFF Set System IR Control On Or Off
KEY ON/OFF Set System KEY Control On Or Off
DBG ON/OFF Set Debug Mode On Or Off
BEEP ON/OFF Set Onboard Beep On Or Off
RESET
RESET ALL
Reset System To Default Setting (Should Type “Yes” To Confirm, “No” To Discard)
Reset System And Network To Default Setting
OUT xxON/OFF Set OUTPUT:xx On Or Off
OUT xx FR yy Set OUTPUT:xx From INPUT:yy
EDID xx CP yy Copy EDID from output (yy) to input (xx)
Both yy&xx can be set individually (01-08) or as ALL (00)

EL-4KM-V88 USER MANUAL
15
contact [e-mail]
RS-232 and Telnet Commands (Continued)
RS-232 COMMAND DESCRIPTION
EDID xx DF zz
Set Input:xx EDID To Default EDID:zz
xx=00: Select All INPUT Port
xx=[01...08]: Select One INPUT Port
yy=[01...08]: Select One OUTPUT Port
zz=00: HDMI 1080p@60Hz, Audio 2CH PCM
zz=01: HDMI 1080p@60Hz, Audio 5.1CH DTS/DOLBY
zz=02: HDMI 1080p@60Hz, Audio 7.1CH DTS/DOLBY/HD
zz=03: HDMI 1080i@60Hz, Audio 2CH PCM
zz=04: HDMI 1080i@60Hz, Audio 5.1CH DTS/DOLBY
zz=05: HDMI 1080i@60Hz, Audio 7.1CH DTS/DOLBY/HD
zz=06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
zz=07: HDMI 1080p@60Hz/3D, Audio 5.1CH DTS/DOLBY
zz=08: HDMI 1080p@60Hz/3D, Audio 7.1CH DTS/DOLBY/HD
zz=09: HDMI 4K@30Hz 4:4:4, Audio 2CH PCM
zz=10: HDMI 4K@30Hz 4:4:4, Audio 5.1CH DTS/DOLBY
zz=11: HDMI 4K@30Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
zz=12: DVI 1280x1024@60Hz, Audio None
zz=13: DVI 1920x1080@60Hz, Audio None
zz=14: DVI 1920x1200@60Hz, Audio None
zz=15: User EDID 1
zz=16: User EDID 2
zz=17: GUI Download EDID
zz=18: HDMI 4K@60Hz 4:2:0, Audio 2CH PCM
zz=19: HDMI 4K@60Hz 4:2:0, Audio 5.1CH DTS/DOLBY
zz=20: HDMI 4K@60Hz 4:2:0, Audio 7.1CH DTS/DOLBY/HD
RESETDEF Restore factory settings
MXIR xx FR yy
Set HDBT RX:xx IR Out From Local IR In:yy
xx=[00]: All HDBT RX IR Out,[03...08]: HDBT RX IR Out
yy=[03...08]: Local IR In
NET DHCP ON/OFF : Set Auto IP(DHCP) ON Or OFF
NET IP xxx.xxx.xxx.xxx : Set IP Address
NET GW xxx.xxx.xxx.xxx : Set Gateway Address
NET SM xxx.xxx.xxx.xxx : Set Subnet Mask Address
NET RB : Set Network Reboot and Apply New Config!!!
NET TN xxxx : Set Telnet Port

16
www.elanhomesystems.com
EL-4KM-V88 USER MANUAL
Infrared Commands
8X8 MATRIX PRODUCTS NEC IR: CUSTOMER CODE 1898 HEX IR
POWER 14
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016
0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
OUTPUT 1 09
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F
0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
OUTPUT 2 1D
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016
003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
OUTPUT 3 1F
0AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016
0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016
0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016
0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 003F 0016 0689
OUTPUT 4 0D
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016
0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
OUTPUT 5 19
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016
003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
Output 6 1B
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016
003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
OUTPUT 7 11
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016
0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
OUTPUT 8 15
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016
0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
OUTPUT ALL 17
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016
0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
OUTPUT PTP 12
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016
0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
INPUT 1 50
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016
0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F
0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689

EL-4KM-V88 USER MANUAL
17
contact [e-mail]
Infrared Commands
INPUT 2 55
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016
0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016
0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689
INPUT 3 48
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016
003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F
0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
INPUT 4 4A
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016
003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F
0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
INPUT 5 5E
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016
003F 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016
0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689
INPUT 6 06
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016
0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016
0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
INPUT 7 05
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016
0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016
0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
INPUT 8 03
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016
0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
INPUT ALL 47
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016
0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
INPUT BACK 07
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016
0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
INPUT UP 40
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016
0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F
0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
1080i18
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016
003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689

18
www.elanhomesystems.com
EL-4KM-V88 USER MANUAL
Infrared Commands
1080P 44
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016
0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 0016
0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
3D 0F
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
4K 51
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016
0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F
0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689
2.0CH 0A
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F
0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
5.1CH 1E
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016
003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
7.1C H 0E
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016
0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
COPY 1A
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016
003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
USER 1 53
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016
0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689
USER 2 52
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016
0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F
0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689
USER 3 01
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016
0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F
0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
USER 4 45
0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016
003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016
0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016
0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689

EL-4KM-V88 USER MANUAL
19
contact [e-mail]
ELAN Web Browser Interface
The ELAN EL-4KM-V88 matrix unit can be both controlled and configured using the in-built web-server.
The EL-4KM-V88 Matrix must be connected to an active network router/switch and it is advised that the Matrix is given a static IP address. You
can configure the network settings of the Matrix using the Web Browser Interface (ELAN Matrix products are shipped with the network set to
DHCP)
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION - changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
CANADA, INDUSTRY CANADA (IC) NOTICES
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
CANADA, AVIS D’INDUSTRY CANADA (IC)
Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d’interférence et (2) cet appareil doit accepter
toute interférence, notamment les interférences qui peuvent affecter son fonctionnement.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household wastes. To prevent possible harm to
the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmentally safe recycling.
Certifications

10014816 Rev-C0, 04/2017
main:
1 [phone] - US
1 [phone] - International
1 [phone] - Fax
tech support:
[email protected]
web:
elanhomesystems.com
© 2017 ELAN®is a registered trademark of Core Brands, LLC.
