Elation Design LED 108IP User manual

Design LED 108IP
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free [phone]
TECHNICAL SPECIFICATIONS
• DMX Channels: 3, 4 & 6 CH DMX control modes
• Control: USITT DMX-512, 3 pin or 5 pin XLR
data input & output
• Dimmer: Selectable dim options (Standard & Linear)
0 - 100% dimming
• Strobe: Strobe effect (1-18 ashes per second)
• IP Rating: IP 65
• Power Supply: Multi-voltage 100-240VAC, 50/60Hz
• Power Consumption: 150W
• Lamp: 36 x 3W K2 LEDs - (12 each R, G, B) Long-life L.E.D.s
• Lamp Life: 100,000 hrs. life
• Dimensions: ( L x W x H - not including hanging bracket)
8.8” x 8” x 10.8” / 223.52 x 203.20 x 274.32mm
• Weight: 15.2 lbs / 6 kg
• Rigging: Mounting bracket designed for oor,
wall or truss mount and molded eye hole for safety cable
FEATURES
• Linear RGB color mixing allows for innite
color possibilities
• 6 Luxeon K2 LED’s - 12 RED, 12 BLUE and 12 GREEN
running at 3W power each
• 15º standard beam angle
(25º & 45º optional lens kits available)
• IP65 outdoor rated, compact design, die cast case
• Silent operation, convection cooled (No fans)
• Built-in, auto switching power supply
• AC Power input & output
• LED display with easy to use function keys
• DMX controllable via 3, 4 & 6 channel DMX modes
• 6 built-in programs with Speed control
• Master/ Slave auto program and sound trigger
The Design LED 108IP (DLED 108IP) by Elation Professional is a high output, compact L.E.D. color changer
featuring full RGB color mixing using 36 Luxeon K2 LED’s - 12 RED, 12 BLUE and 12 GREEN running at 3W power
each. The unit is made of a high quality die cast metal case and is convection cooled with design of the fixture
optimized providing up to 100,000 hours estimated LED life. The DLED 108IP is rated at IP 65 ideal for indoor
or outdoor applications and includes outdoor rated power and data cables along with a/c power 120v input
cable but unit can operate from 90 – 240v AC via the internal auto sensing electronic power supply. Control
data input is via 3 pin or 5pin DMX data first in and out cables. The DLED 108IP includes a dual yoke mounting
bracket for fixed installation or can be used as a split bracket for floor standing. The unit also features an on
board weather protected 4 button control menu with 4 digit LED display for setting control address, modes,
manual or auto programs. The unit comes fitted standard with a 15° lens kit which produces a 44° field angle
effect. Optional wide and narrow lens kits are available.
7.7” (195mm)
10.23” (260mm)
7.28” (185mm)
8.60” (218.5mm)
8.05” (204.5mm)
4.25” (108mm)
1.57” (40mm)
9.13” (232mm)
8.27” (210mm)
7.7” (195mm)
10.23” (260mm)
7.28” (185mm)
8.60” (218.5mm)
8.05” (204.5mm)
4.25” (108mm)
1.57” (40mm)
9.13” (232mm)
8.27” (210mm)
Design LED 108IP Dimensions

Design LED 108IP
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free [phone]
COLORS
• 36 x 3W K2 LEDs - (12 each R, G, B)
• Long Life L.E.D. (rated at 100,000 Hours)
• Linear RGB color mixing allows for innite color possibilities
PHOTOMETRICS
OUTDOOR RATED
I P 6 5
Design LED 108IP
Photometric Beam Angle Data
Standard 15° Lens: 44° Beam Angle
LUX x0.0929 = FC
44°
Beam Angle
0 m
0 ft
1 m
3.28 ft
3 m
9.84 ft
2 m
6.56 ft
Ø 2.4 m
Ø 7.9 ft
Beam Diameter
Ø 0.8 m
Ø 2.6 ft
Ø 1.6 m
Ø 5.2 ft
Ø1.6m / Ø 5.2ft
Ø 2.4m / Ø 7.9ft
Ø 0.8m / Ø 2.6ft
R (12)
G (12)
B(12)
RGB (36)
440 FC / 4,729 LUX
664 FC / 7,152 LUX
41 FC / 443 LUX
1,199 FC / 12,900 LUX
118 FC / 1,272 LUX
180 FC / 1,940 LUX
12 FC / 127 LUX
342 FC / 3,680 LUX
53 FC / 570 LUX
77 FC / 831 LUX
5 FC / 55 LUX
136 FC / 1,465 LUX
47°
Beam Angle
0 m
0 ft
1.5 m
4.9 ft
3 m
9.84 ft
Ø 2.80 m
Ø 9.2 ft
Beam Diameter
Ø 1.40 m
Ø 4.6 ft
Ø 2.80 m / Ø 9.2 ft
Ø 1.40 m / Ø 4.6 ft
RGB (36) 64 FC / 690 LUX 16 FC / 168 LUX
Optional 25° lens: 47° Beam Angle (not included)
LUX x0.0929 = FC
56°
Beam Angle
0 m
0 ft
1.5 m
4.9 ft
3 m
9.84 ft
Ø 3.20 m
Ø 10.50 ft
Beam Diameter
Ø 1.60 m
Ø 5.24 ft
Ø 3.20 m / Ø 10.50 ft
Ø 1.60 m / Ø 5.24 ft
RGB (36) 52 FC / 549 LUX 14 FC / 146 LUX
Optional 45° lens: 56° Beam Angle (not included)
LUX x0.0929 = FC

Design LED 108IP
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free [phone]
DMX TRAITS
3 Channel Mode:
Channel Value Function
1 0 - 255 Red ( 0 - black, 255 - 100% red
)
2 0 - 255 Green ( 0 - black, 255 - 100% green
)
3 0 - 255 Blue (0 - black, 255 - 100% blue )
4 Channel Mode:
Channel Value Function
1 0 - 255 Red ( 0 - black, 255 - 100% red
)
2 0 - 255 Green ( 0 - black, 255 - 100% green
)
3 0 - 255 Blue (0 - black, 255 - 100% blue )
4 0 - 255 Dimming (
0 - 100%
) ~ normal operation
0 - 255 Speed (
min to max
) ~ when running
built-in programs on channel 4
6 Channel Mode:
Channel Value Function
1 0 - 255 Red ( 0 - black, 255 - 100% red
)
2 0 - 255 Green ( 0 - black, 255 - 100% green
)
3 0 - 255 Blue (0 - black, 255 - 100% blue )
4 0 - 255 Internal programs
5 0 - 255 Strobe
6 0 - 255 Dimming (
0 - 100%
) ~ normal operation
0 - 255 Speed (
min to max
) ~ when running
built-in programs on channel 4
Product Order Code Description
DLED 108 IP Black DLED 108
DLED 108 IPS Silver DLED 108
Accessories Order Code Description
PRO CLAMP Mounting Clamp
DLED-LK25 25° Lens Kit
DLED-LK45 45° Lens Kit
80409030066 DLED DMX In 3P Male XLR/5P Female IP 3M
80409030065 DLED DMX Out 3P Female XLR/5P Male IP 3M
80409030054 DLED 120V Power In 3P IP Cable 1.8M
80409030011 DLED Data Link Cable 5P IP 3M
DLED Power Link Cable 3P IP 3M
