ELECTOR Clarimax User manual

User Guide
Water-Filter-System for Treatment of Heating-System Make-Up Water
Water-Treatment

Page 1 www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water
1 General Information / Safety Instructions
1.1 General information......................................................................................................... 2
1.1.1 Field of use .................................................................................................................. 2
1.1.2 Operator obligations..................................................................................................... 3
1.2 Safety instructions .......................................................................................................... 3
1.2.1 Safety regulations ........................................................................................................ 3
1.2.2 Disclaimer.................................................................................................................... 3
1.2.3 Specific security instructions........................................................................................ 4
1.2.4 Safety work instructions............................................................................................... 4
1.3 Technical description
1.3.1 Electrical data .............................................................................................................. 5
1.3.2 Physical data ............................................................................................................... 5
1.4 Capacity filter-cartridge CLARIMAX 1200 DM pH+.......................................................... 5
2 Assembly / Commissioning
2.1 System overview............................................................................................................. 6
2.2 Scope of delivery ............................................................................................................ 7
2.3 Assembly of pressure container and container head......................................................... 7
2.4 Assembly of inlet and outlet............................................................................................. 7
3 Operation / Handling
3.1 General note ................................................................................................................... 8
3.2 Comissioning.................................................................................................................. 8
3.3 Filling of heating systems ................................................................................................ 8
3.4 In-line water correction.................................................................................................... 8
3.5 Capacity control.............................................................................................................. 8
3.5.1 Integrated conductivity measurement............................................................................ 9
3.5.1.1 Battery and mains operation...................................................................................... 9
3.5.1.2 Description LED-display ............................................................................................ 10
3.5.1.3 Standby-mode .......................................................................................................... 10
3.5.1.4 Interval measurement................................................................................................ 11
3.5.1.5 Continuous measurement.......................................................................................... 11
3.5.1.6 Battery capacity ........................................................................................................ 11
3.5.1.7 Acoustic signal ......................................................................................................... 11
3.5.1.8 Technical data conductivity meter.............................................................................. 12
3.6 Recycling / Disposal........................................................................................................ 12
3.7 Warranty......................................................................................................................... 12
As from: June 2017

1.1 General Information
CLARIMAX 1200 DM pH+ LED is a water treatment system for deionization of make-up water for heating
systems according to different European guidelines, such as VDI 2035, ÖNORM H 5195, SWKI BT 102-01,
and protects heating systems agains limescale deposits that might cause different malfuctions or damages.
CLARIMAX water is a special deionized water with low conductivity and slightly alkaline pH within the range
of the salt-free operation of heating system according to the guidelines mentioned above. Note: Dissimilar
materials need different ranges of the pH and the pH of the treated water fluctuates in a small range as well. The
average pH of the treated water is within the average range for these dissimilar materials.
All functional parts of the CLARIMAX cartridge are made of high-quality plastics. The body und all inner
plastics parts are made of impact resistant thermoplastic material, all rubber parts are made of age-resistant
elastomers. The used materials comply with the state of the art.
The information in this user guide allow a secure, proper and economic use of the device. The basic information
for installation, operation und maintenance shall be considered in particular.
Anyone working with this device must read this manual completely and follow the instructions.
In addition to the operating instructions, the locally applicable regulations for accident prevention and for safe
and professional work must be considered.
The manufacturer of the water treatment systems recommends to run a written documentation at the side of
use. The user should record the date of filling, the water volume, the method of water treatment, if necessary
the blend, the pH, the total hardness and the system pressure.
This manual must be available at the place of use at all times.
Observe Safety Instructions!
1.1.1 Field of use
This unit is used for preparation of tap water as boiler feed water or heating-system make-up water according
to European guidelines, such as VDI 2035, ÖNORM H5195 and SWKI 97-1. The use of untreated tap water for
feeding heating systems is very limited. Untreated tap water can cause malfunctions. These malfunctions can
be corrosion in the boiler or in the pipeline network, formation of sludge, limescale and loss of heat transfer. The
guidelines describe actions against these problems. Please take always the instructions of boiler manufacturers
or those of other system parts into consideration.
Chapter 1 - General Information / Safety Instructions
Page 2
www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water

Page 3 www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water
1.1.2 Operator obligations
The operator of the unit is responsible for:
- The instruction of the user
- Regular maintenance
1.2 Safety instructions
-> Please read this guide carefully before comissioning and follow the instructions. Keep this guide accessible
at all times.
-> Personal injury, caused by non-observance of this guide, are not covered by the product liability law.
-> The manufacturer takes no liability for any other damages caused by non-observance of this guide.
Please note:
Safety instructions warn against dangers and help to prevent personal injury and damage to property. Comply
with the safety instructions for your own safety. The applicable national and international safety regulations
must be observed. Every operator is responsible for compliance with the regulations applicable to him and must
make every effort to comply with the latest regulations.
1.2.1 Safety regulations
• The CLARIMAX water filter system shall only be used by trained service technicians.
• The manufacturer‘s specifications must be complied with for maintenance and / or replacement of spare
parts.
• In case of unauthorized modifications at the device, the CE declaration of the manufacturer expires.
• The manufacturer takes no liability for damage caused by improper use. Furthermore, the warranty expires.
• CLARIAMX must not be operated in potentially explosive atmospheres.
• CLARIMAX must only be used in perfect condition.
• CLARIMAX must only be used for treatment of tap water with a quality according to the local tap water law.
Treatment of acids, alkalis, etc. is not permitted.
• Check the system for possible damage prior use.
• The intended use within the performance limits must be ensured.
• Release water pressure from the unit and / or disconnect it from the mains supply before any repairs.
• Damaged equipment must be put out of service.
• Repairs should only be done by qualified personel.
• Observe relevant and binding standards, such as DIN EN 1717; DIN 1988 etc.
1.2.2 Disclaimer
The use must be carried out exactly as desribed in this manual. The manufacturer is not liable for any damage
including consequential damage that may result from improper installation or misuse of the product.

1.2.3 Specific security instructions
Feed water used for CLARIMAX 1200 pH+ LED water treatment system should only be untreated tap water.
CLARIMAX is only to be used with cold water within the water inlet temperature range specified in the technical
data. Microbiologically contaminated water or water of unknown quality must not be used without appropriate
desinfection.
The filter system is not resistant to highly concentrated cleaning agents (eg bleaching agents, chlorinated
solvents, strong oxidizing agents) and should not come into contact with them.
Do not open the system during operation.
The filter cartridge must not be opened.
The pressure housing and the filter head of the system are designed for a service life of 10 years (from
installation date).
1.2.4 Safety work instructions
Protect the water filter system from direct sunshine and mechanical damage. Do not use near sources of heat
and open fire. Installed a safetly armature category 4 according to the European standard DIN EN 1717 at the
inlet of CLARIMAX.
If the water pressure is higher than 6.9 bar, a pressure limiter should be installed at the inlet of the water
treatment system. It is generally recommended to use a pressure limiter when filling heating systems. At the
water inlet of the filter head, a DVGW model-tested backflow preventer according to DIN EIN 13959 is factory
installed. The installation of all parts must be carried out according to the country specific guidelines. The
CLARIMAX filter system must be operated within the specified ambient temperature.
Caution in case of frost:
Once filled with water the filter should not be stored at temperatures below 4°C. Frost may destroy the water
filter system.
New filters, that are not filled with water, can be stored and transported at temperatures below 0°C. These filters
need to be stored at temperature of the side of installation for at least 24 hours prior use.
Please observe the technical data, the operating and maintenance instructions as well as the safetiy instructions
in this manual before comissioning.
Page 4
www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water

Page 5 www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water
1.3 Technical description
1.3.1 Electrical data
CLARIMAX 1200 pH+ LED is equipped with an integrated electrical conductivity meter. An external power
supply is necessary for its operation.
Power supply: Power adapter DC 12V
1.3.2 Physical data
Operation pressure................................................2 bar - max. 6,9 bar
Operation- / Water temperature..............................4°C to 60°C
Ambient temperature.............................................10°C to 50°C
Ambient temperature for storage and transport
commissioned filter system...................................4°C to 50°C
Ambient temperature for storage and transport
dry new filter system ............................................-20°C to 50°C
Nominal flow rate filter cartridge DM pH+.............approx. 300 l/h at a pressure drop of ~1.2 bar
Weight (dry/wet)...................................................18 kg/24 kg
Capacity ...............................................................744 L at 500 µS/cm (conductivity of untreated tap water)
Dimensions (Width/Depth/Height)..........................288/255/550 mm (Total system)
Operating position.................................................vertical
Inlet connection.....................................................G 3/4“
Outlet connection..................................................G 3/4“
Noise....................................................................<70 dB(A)
1.4 Capacity filter-cartridge CLARIMAX 1200 DM pH+
CLARIMAX 1200DM pH+ (Conductivity untreated water in µS/cm / Capacity in Liter)
µS/cm Capacity µS/cm Capacity
200 1860 1200 310
300 1240 1300 286
400 930 1400 265
500 744 1500 248
600 620 1600 232
700 531 1700 218
800 465 1800 206
900 413 1900 195
1000 372 2000 186
1100 338

2.1 System overview
1....... Pressure housing
2....... Filter cartridge
3....... Filter head
4....... Floor brackets
5....... Housing handles
Note
There is an integrated electrical device in the filter head of CLARIMAX 1200 DM pH+ LED for capacity control.
You need an external power adapter for operation of this device.
Attention
Please pay attention to the technical data and to the operation and security instructions prior assembly and
comissioning. After storage below 0°C (Note: Store only new dry cartridges below 0°C) the product need to be
stored at room temperature for at least 24 hours.
Chapter 2 - Assembly / Comissioning
4
5
Page 6
www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water

Page 7 www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water
2.2 Scope of delivery
For installation of an CLARIMAX 1200 DM pH+ LED you need the pressure housing (incl. filter cartridge) and
the filter head.
Please check the scope of delivery prior use:
• Pressure housing
• Filter head with integrated measurement device
• Filter cartridge
• Power adapter
Please contact your supplier if parts are missing.
2.3 Assembly of the Pressure housing and the filter head
Place both feet on the floor brackets #4. Lift pressure housing #1 and turn clockwise so that the handles #5
are in one line with the floor brackets. At one handle you can finde a security lock at the side. Press it and turn
the filter head #3 counter-clockwise, lift it to the top to remove it from the housing.
Remove the red transport cap from the filter cartridge #2 and check the o-ring-seals for correct installation,
integrity and cleanliness. Place cartridge #2 in pressure housing #1.
Place both feet on the floor brackets #4. Place filter head #3 in position „INSERT“ at pressure housing #1.
Turn the filter head clockwise until it snaps back to the security lock.
2.4 Assembly of inlet and outlet
Note: Inlet and outlet hoses are not included in the delivery.
Caution: The maximum tightening torque at the connections must not exceed 15 Nm! Only connections with flat
gaskets may be used. Conical Connections will damage the connections of the filter head and will lead to the
extinguishing of warranty claims. The direction of flow indicated on the filter head by arrows must be observed.
Operate the system only vertically. Please observe the relevant regulations, such as DIN EN 1717 or DIN 1988.

Chapter 3 - Operation / Handling
3.1 General note
The guideline DIN EN 1717 will replace the DIN 1988-100. The „short-term connection“ of the heating system
with mains water supply by a hose connection is then not longer state of the art.
According to DIN EN 1717 chapter 5.3.2 : „All connections to the tap water installation are regarded as
permanent connections“.
Therefore we recommend to install a safety armature with fluid class 4 when filling a heating system with
CLARIMAX 1200 DM pH+ LED.
3.2 Comissioning
Starting with a new filter cartridge you always should displace air out of the water filter system and flush the
filter system.
Please proceed as follows:
1. Install filter cartridge in system, close system with filter-head and connect with hoses.
2. Position filter system horizontally and let water run into connection „IN“. Rinse the filter with 10 liters water.
3. Position the filter vertically and rinse with additional 10 liters of water.
4. Dispose the rinsing water.
The filter-system is ready for operation after this procedure.
Repeat this process after any cartridge change.
3.3 Filling of heating systems
As soon as the system is ready for operation you can fill the heating system as usual. The filter treats the water
in a single flow through principle. The inlet of CLARIMAX is to be connected to the mains tap water supply
and the outlet of CLARIMAX with the heating system. Once the water has passed CLARIMAX it has the quality
according to the guidelines. We recommend to install a system separator or a compact filling armature at the
inlet of the CLARIMAX filter system.
3.4 In-line water correction
You even can treat existing heating water with the CLARIMAX filter system. Simply install CLARIMAX in a
bypass and pump the heating water via CLARIMAX and back into the system, where the treated water will
dillute the circulating system water. As a temporary limited but continuous process all the heating water will be
corrected after a while. Please observe the maximum operation pressure and that the heating water should be
in a quality of natural water without chemicals. The water must not contain strong oxidants. Particles should be
removed by additional filtration at the inlet of CLARIMAX.
3.5 Capacity control
There is a conductivity meter installed in the filter head. This device controls the filter capacity and gives a
signal, as soon as the cartridge is exhausted and needs to be replaced.
The end of capacity is indicated by an electrical conductivity of the treated water at a level of 90 - 100 µS/cm.
Page 8
www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water

Page 9 www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water
3.5.1 Integrated conductivity measurement
There is an electrical conductivity measurement device installed in the filters head.
The device has an optical LED unit, an acoustic signal and needs an external 12 V power adapter for operation
and charging of the battery pack.
3.5.1.1 Battery and mains operation
All functions are independently from the power supply.
The batteries are not charged in the state as delivered and therefore should be charged for at least 24 hours.
You can operate CLARIMAX either in mains supply mode with the power adapter or in battery mode.
A fully charged battery allows 48 hours operation.
You can find the connection for the power adapter on the backside of the filter head.
Anzeigeeinheit
Display Unit
Status Indicator
F-Key
LED Display
Acoustic signal
on the circuit board

3.5.1.2 Description LED display
The optical LED display is divide into three areas, which are modeled after the traffic light system.
The LED lights change their color and the illuminated area with increased cartridge exhaustion.
The first area is divided into 4 gree LED lights. The LEDs turn on
consecutively until all 4 LEDs are active. This signals an increasing
cartridge exhaustion. The water quality is within the recommeded
range of VDI 2035.
The second area is divided into 3 yellow LEDs. All LEDs turn on
together and the green LEDs turn off. This signals that the cartridge
is soon to be exhausted and that a replacement of the cartridge will
soon be necessary. The quality of the treated water is still within the
range of VDI 2035.
The third area is divided into 3 red LEDs. All LEDs start flashing
accompanied by an acoustic signal. The yellow LEDs turn of. The
filter cartridge is exhausted and need to be replaced. The quality of the
water does not comply with VDI 2035 anymore.
3.5.1.3 Standby-Mode
The conductivity measurement is deacitivated as long as the device
is in the standby-mode. The LED display is not active.
There will neither be an acoustical nor an optical signal in case of
cartridge exhaustion when the device is operated in the standy-
mode.
Page 10
www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water

Page 11 www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water
3.5.1.4 Interval measurement (Short-term-mode)
The interval measurement is activated by a single press of the
F-key. The status indicator flashes as long as the device is active.
In this mode the measurement and the display stays on for 30
seconds. Afterwards the device is deactivated automatically. This
is a power-saving mode and therefore recommended for battery
operation.
3.5.1.5 Continuous measurement
The continuous measurement mode is activated by pressing
the F-buttom for approximately 3 seconds. The activation is
confirmed by 3 successive acoustic signals. The status indicator
stays on until the measurement mode is deactivated. In this
mode the measurement and the display stay on constantly. For
deactivation the F-key need to be pressed again for a longer time.
The deactivation is also confirmed acoustically. The continuous
measurement is only recommended in mains operation.
3.5.1.6 Battery capacity
The remaining battery capacity indicates the charge statues of
the integrated rechargeable battery. As the number of highlighted
LEDS decreases, the charge level decreases. (From green to red).
The 3 red LEDS always stay on and represent a critical state of
charge. The mains power adapter should be connected for further
operation.
The display of the remaining battery capacity is activated by
pressing the F key 5 times.
The status indicator flashes as follows: 3x flashing -> 2 seconds pause -> 3x flashing.....
This mode stays on constantly. The conductivity measurement is switched off during thise mode. For
deacitivation the F-key need to be pressed one time. The display returns to the previous mode.
3.5.1.7 Acoustic signal
As soon as the measurement enters the red area, an acoustic
signal will sound. This remains active until the water quality is
improved or it is deactivated manually.
The acoustic signla sounds in the following cycle: 5x tone -> 30
sec pause -> 5x tone
To deactivate, press the F-key once.
1x
3 sec
5x
1x

3.5.1.8 Technical data conductivity meter
Power supply: 12 V DC with included power adapter. Only the original power adapter must be used.
Max. current consumption during operation with power supply: 35 mA
Standby current consumption: <1mA
Rechargeable Battery: 1,2 V 750mAh
Operation with battery (fully charged): min 48h
Charging time with empty battery: 24h
3.6 Recycling / Disposal
The packing material of this product is suitable for recycling and can be reused. Please dispose all materials
according to local regulations. Exhausted filter cartridges are taken back at the expenses of the sender or can be
disposed in accordance with local regulations.
3.7 Warranty
The CLARIMAX 1200 DM pH+ LED filter system is subject to the statutory warranty of 2 years.
A warranty claim can only be asserted if all instructions in this manual are followed and observed.
Damage caused by improper changes, use or grossly negligent damage to the product are not covered by the
warranty.
Malfunctions due to incorrect of faulty handling are not covered by this warranty.
Manufacturer of the cartridge filter
BRITA GmbH, Heinrich-Hertz-Straße 4, 65232 Taunusstein, Germany
Manufacturer and sales of the water filter system
elector GmbH, Düsseldorfer Straße 287, 42327 Wuppertal, Germany
Page 12
www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water

Page 13 www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water

Page 14
www.elector-water-treatment.com
CLARIMAX 1200 DM pH+ LED – Water-filter-system for treatment of heating-system make-up water

elector GmbH
Düsseldorfer Straße 287
42327 Wuppertal · Germany
Phone: [phone]
Fax: [phone]
E-Mail: [e-mail]
Internet: www.elector-water-treatment.com
Water-Treatment
