ElectricSA Trotinette User manual

Owner's Guide
ElectricSA Trotinette
(*Picture for refernce only)
Read this guide completely before assembling and riding your
ElectricSA Trotinette
ElectricSA International
580, Avenue Lépine
Dorval, Québec, Canada, H9P 1G2
[email protected]
www.electricsa.com

Table of Contents
Technical Information-----------------------------------1
Warning Statement--------------------------------------2
List of Parts-----------------------------------------------5
Handle Bar------------------------------------------------7
Tool Kits In The Tool Bag------------------------------8
Assembling The Trotinette ---
-------------------------
9
Charging The Batteries--------------------------------12
Riding The Trotinette ---------------------------------13
Folding The Trotinette -
--------------------------------15
Wiring Diagram------------------------------------------17
Trouble Shooting Guide------------------------------18
Warranty---------------------------------------------------20
--
ElectricSA International
580, Avenue Lépine
Dorval, Québec, Canada, H9P 1G2
[email protected]
www.electricsa.com

1
Technical Information
Tri
nf
fo
or
r m
ma
at
i
on
nZAPPY3
Model No.
Packing size
30.3L x 18.1W x 25.6 H inch
(770 L x 460 W x 650 H mm)
Type of motor Permanent-magnet
brushless DC Motor
Motor power 350 wgeared motor, 36 V
Battery type sealed lead acid battery
Battery capacity 36 Vo , 12Ah
Charger 110V/240V(optional)
Charging time 6-8 hours
Rated speed Up to 30km/h
Single charge Up to 40km
Max capacity 154 LBS (70 KG)
Gross weight 77 LBS (35 kg)
2
ESA-Trotinette
IMPORTANT !
BEFORE YOU OPERATE YOUR ELECTRIC TROTINETTE
PLEASE READ CAREFULLY:
Your existing insurance policy may not provide coverage
for electrical vehicles. You should contact your insurance
agent to determine if coverage is provided.
Do not ride this trotinette until you read and thoroughly
understand the owner's guide. It contains information
critical to your safety. If you have questions about the
operation of this trotinette, you should contact ElectricSA
at [email protected]
It is extremely important that you follow the safety
guidelines contained in this guide in order to in-
sure maximum safety.
Faiure to comply to the standards outlined in this
guide could result in fire or/ serious injuries.
ElectricSA is not liable for any damage or injuries
caused by unsafe or faulty repairs. Any repairs made
to this product by unauthorized service technicians
are the sole responsability of the owner.
Warning Statement
Tri
nf
fo
or
rm
ma
at
i
on
nZAPPY3

3
4
WARNING
CHECK IF ALL THE TIRES ARE PROPERLY INFLATED
BEFORE RIDING THE TROTINETTE.
ALWAYS WEAR A HELMET WHEN RIDING THE
TROTINETTE. WEAR REFLECTIVE CLOTHING.
NEVER TRY STUNTS. ALWAYS MAINTAIN A SAFE
SPEED.
FOLLOW ALL STATE&CITY LAWS REGARDING USE
OF ELECTRIC TROTINETTE ON ROADS.
Our products are designed to be ecologically
conscious,please dispose of used batteries in compli-
ance with local laws.
WARNING
THE ELECTRIC TROTINETTE IS NOT A TOY AND
SHOULD NOT BE OPERATED BY ANYONE UNDER 12
YEARS OLD.
Safty Instruction(please take note of the followings
before each ride)
󱕰
󱕰 Only one person at a time should reide.
󱕰 Always wear protective gear including knee and elbow pads
and an approved safety helmet when riding the trotinette.
󱕰 Before riding be sure to check that all pivot points, locking
buttons, quick release, and latches are secured properly.
󱕰 The power switch lock must be in the “off” position when the
trotinette is being charged.
󱕰 Do not use the trotinette when it is raining.
󱕰 Do not place the battery near heat or fire.
󱕰 Do not expose the charger near water.
󱕰 Check if the battery is properly charged and installed.
󱕰 Charge the battery after each use.
󱕰 Always ride on dry paved surfaces. Wet and uneven surfaces
are a hazard.
󱕰Sand and loose impediments are your enemy, avoid them.
󱕰Never operate too fast for your skills or condition.
Warning Statement
Tri
nf
fo
or
rm
ma
at
i
on
nZAPPY3
Warning Statement
Tri
nf
fo
or
rm
ma
at
i
on
nZAPPY3
The maximum load capacity is 154 lbs

5
List of parts
Bef
fo
or
re
e
R
di
n
ng
g
6
List of parts
ead
d
re
Rig
g
1Handlebar
2Quick release
3Handlebar tube
4Handlebar tube clamp
5Connecting tube
6Rear fender
7 Battery & controller compartment
8 Balancing wheel
9 Footboard
10 Rear wheel
11 Power connecting plug
12 Connecting tube clamp
13 Key ignition
14 Front fender
15 Front fork
16 Drum brake
17 Motor
18 Front wheel

7
Handlebar
ist
t
f
Par
rt
ts
sZAPPY3
8
1 Brake lever
2 Horn switch
3 Multi-function Instrument
4 Key switch
5 Throttle
1 Allen wrench (8 x 10mm)
2 Allen wrench (14 x 17mm)
3 Allen wrench (14 x 17mm)
4 Screwdriver
5 Wrench (3mm)
6 Wrench (6mm)
7 charger
is
tt
T
To oo ol lK Ki it ts sI In nT Th he eT To oo ol lB Ba ag g

9
A
As ss se em mb bl li in ng g the Trotinette
3
1. Unpack the Trotinette carefully so that you
do not misplace any of the parts.
2. Place the Trotinette on a flat, level surface.
Using any household item, raise the front base
of the trotinette up at least 4 inch, so you can
3. Remove the bolts and nuts from the connecting
tube clamp (B). Place the connecting tube into
the top opening (A). After aligning the holes,
place two bolts through the connecting tube and
neck assembly. Twist and tighten the bolts.
4. Tighten the bolts and nuts using the 2 allen
wrenches 14 x 17mm in the tools kit.
5. Extend the handle bar tube to full upright
position and slide it into connecting with the
front fork.
6. Ensure that the handlebar is facing front, the
brake on the left side and the throttle on the
right, then tighten the handlebar tube collar
clamp using the enclosed 6mm wrench.
A
As ss se em mb bl li in ng g the Trotinette
10
easily connect the frame/front wheel to
the base

11
A
As ss se em mb bl li in ng gT Th he
e Trotinette
12
Charging The Batteries
7. Plug in the two power connecting plugs into
the sockets. The design of each plug and
socket is different. Connect the ones which
best fit each other to finish the assembly.
8. Match pins of plugs to the holes of the
sockets. Note the alignment notches.
NOTE : Handlebar height adjustment. Handlebar
height can be easily adjusted by opening the
quick release on the handlebar tube to preferred
height, then firmly closing quick release.
Before you ride the Trotinette for the first time
it is advised that the unit is fully charged (4-6
hours) and fully discharged(ride until the battery
gauge indicates low battery) for at least 3 cycles
to maximize the efficiency of the battery. After
that, you should continue to charge the battery
frequently, at least once every 30 days to prolong
the battery lifespan.
Important:DO NOT leave the battery uncharged
for more than 3 months,otherwise it will greatly
reduce the battery lifespan.
To charge the batteries, plug the charger into
the charger socket located on the rear side of the
battery/ controller compartment. Then plug the
charger into a wall outlet.

13
R
R
i
id di in ng gT Th he
e Trotinette
Once you have completed the initial charge you
are readyb to ride. Remember, this is not atoy.
The Trotinette can reach speeds up to 30 Km / h
depending on the terrain and the weight of the
rider.You must wear ahelmet and protective
pads. You must also be aware of all local laws
and ordinances that govern and/or restrict the use
of powered scooters. The laws and ordinances
vary greatly from municipality to municipality. It is
your responsibility to know and abide by your local
restrictions.
To ride, plug the key into the key switch and
turn the key to the “ON” position. The battery gauge
will be illuminated indicating that the battery is in
operation.
R
R
i
id di in ng gT Th he
e Trotinette
Hold onto the front bar with both hands. Your left
fingers will control the brakes and your righthand
will control the thumb throttle. As you de-press
the throttle lever with your thumb the
speed will increase. Release the thumb throttle
and apply the brake to stop the Trotinette.You
will control the speed of the trotinette by us-
ing both the throttle and the brake. When the
brake handle is squeezed it cuts power to the
throttle.
NOTE 1: You may use the balancing wheel
(the smaller middle rear wheel) to balance the
Trotinette. WARNING: Never try stunts beyond
the control of your skills. Never ride too fast for
your skills or conditions.
NOTE 2: When trotinette is parked, please turn
off the power and take off the key, this will avoid
anyone from accidentally turning the throttle
causing the scooter to speed forward. Failure to
do this could lead to an accident.
14
13

15
F
Fo ol ld di in ng gT Th he
e Trotinette
1. Unplug the power connecting plugs.
2. Unscrew the bolts and nuts from the con-
necting tube clamp using the enclosed allen
wrenches .
3. Lift the connecting tube (which is also attached
to the handlebar tube).
4. Carefully place the handlebar tube on the
footrest frame.
5. Finger screw the bolts and nuts back to the
connecting tube clamp to avoid any mis-
placements.
F
Fo ol ld di in ng gT Th he e Trotinette
Battery: (for professional use only)
The E-Trotinette is powered by three 12 volt, re-
chargeable batteries secured in asingle compart-
ment. Other than recharging, these batteries need
no maintenance. To prolong battery life, you must
recharge the battery after each use. You must
also charge your Trotinette if it has not been
used for 30 days or more. If you must replace
the battery pack, it is located inside the battery
compartment on the footboard. To get to the
battery pack, remove the compartment cover by
loosening the screws. To remove the batteries
disconnect the wires from the battery terminals.
Replace the battery pack with a new one and
reconnect the wires. Follow the instructions on
charging batteries to charge the new batteries.
16
15 16

17
W
Wi ir ri in ng gD Di ia ag gr ra am mT Tr ro ou ub bl le eS Sh ho oo ot ti in ng gG Gu ui id de e
For professional use only For professional use only
Problem Cause Solution
The power light
on the
instrument
does not
illuminate when
the trotinette
is on.
1. Battery is
discharged.
2 . L o o s e
connection
inside the
.
3. Fuse is blown.
1. Recharge your
2. Remove the
screws that hold the
battery compartment
cover and raise the
cover. Visually
inspect all wire
connections making
sure there are no
loose wires, recon-
necting those that
are.
3. Replace the fuse.
The power in-
dicator on the
instrument
illuminates but
trotinette still
does not work.
1. The throttle
handle is not
operating
properly.
1. Replace the
throttle handle. Call
Customer Service to
order a new throttle
18
trotinette
trotinette

19
W
Wi ir ri in ng gD Di ia ag gr ra am m
20
Noise coming
from motor 1 The motor sensor is
defective.
1. Replace motor
sensor. Call
Customer Service to
order a new sensor
When the brake
lever is
squeezed the
does not stop.
1. The brakes
are not adjusted
properly.
1. Adjust the brake
by loosening the bolt
on the rear brake
wheel, pull the cable
and retighten the
bolt.
Trotinette is
losing speed. 1. Low battery 2. Battery is
defective
1. Recharge your
battery for 4~6 hours.
2. Replace battery.
Call Customer
Service to order a
new battery.
W
Wa ar rr ra an nt ty y
ElectricSA International warrants each new Electric
Trotinette product for six (6)months according to
the following terms. Batteries are also warranted
for three (3) months. This warranty extends to the
original retail purchaser only and commences on
the date of the original retail purchase. Any part
of the Electric Trotinette product manufactured
or supplied by ElectricSA International and found
in the reasonable judgment of ElectricSA Interna-
tional to be defective in material or workmanship
will be repaired or replaced by an authorized ser-
vice dealer without charge for parts or labor. The
product including any defective par must be re-
turned to an authorized service dealer within the
warranty period. The expense of delivering the
product to the factory or authorized service deal-
er for warranty work or the expense of returning it
back to the owner after repair or replacement will
be paid for by the owner. ElectricSA Internation-
al’s responsibility in respect to claims is limited to
making the required repairs or replacements and
no claim of breach of warranty shall be cause for
cancellation or rescission of the contract of sale
of any ElectricSA International product. Proof of
date of purchase will be required by the dealer to
substantiate any warranty claim. An authorized
service dealer must perform all warranty
trotinette

21 22
work. The warranty is limited to thirty (30) days
from the date of purchase for any ElectricSA
International product that is used for rental
demonstration or commercial purposesor any other
income producing purpose.This warranty does not
cover and ElectricSA International product that has
been subject to misuse, neglect, negligence or
accident, or has been operated in any way
contrary to the operating instructions as spe-
cified in the owner’s guide . This warranty
does not apply any damage to the ElectricSA
International product that is the result of improp-
er maintenance or to any ElectricSA Internation-
al product that has been altered or modified
so as to adversely affect the products operation,
performance or durability or that has been altered
or modified to change its intended use. This
warranty does not extend to repairs made
necessary by normal wear and or by use of parts
that are incompatible with ElectricSA Inter-
national products.In addition this warranty does
not cover items that experience normal wear and
tear. ElectricSA International reserves the right
to improve the design of the product without
assuming any obligations to modify any product
previously manufactured. All warranties are lim-
ited in duration to the six (6) months warranty
period. Any such implied warrantiesincluding pur-
pose or otherwise are disclaimed in their entirety
after the expiration of the appropriate thirty day
warranty period. ElectricSA International’s obliga-
tion under this warranty is strictly and exclusively
limited to the repair and replacement of defective
parts and ElectricSA International does not
assume for them any obligation. ElectricSA Inter-
national assumes no responsibility for incidental
consequential or other damages including but not
limited to expense of returning the ElectricSA In-
ternational product to an authorized service deal-
er and expense of delivering it back to the owner.
WHAT ELECTRICSA INTERNATIONAL WILL
DO:
ElectricSA International will, at its sole option,
either repair, replace or refund the purchase price
of any unit that does not conform to this limited
warranty. ElectricSA International may choose at
its option to use functionally equivalent recondi-
tioned, refurbished or new units or parts or any
units. You are responsible to get the unit back to
ElectricSA International .
W
Wa ar rr ra an nt ty yW Wa ar rr ra an nt ty y

23
W
Wa ar rr ra an nt ty y
HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call or fax to
the following telephone numbers from anywhere
in Canada:
Tel. [phone]
or Fax.[phone]
Correspondence may also be mailed to:
Email: i[email protected]
DO NOT RETURN YOUR PRODUCT TO THE
ABOVE ADDRESS.
Please call or write for thelocation of the ElectricSA
International authorized service center nearest
you and for the procedures for obtaining warranty
claims.
ElectricSA International
580, Avenue Lépine
Dorval, Québec, Canada, H9P 1G2
[email protected]
www.electricsa.com
ElectricSA International
580, Avenue Lépine
Dorval, Québec, Canada, H9P 1G2
[email protected]
www.electricsa.com
