Electro-Harmonix 2880 Assembly instructions

User Reference Manual

TABLE OF CONTENTS
PRECAUTIONS FOR SAFE USE 2
ALITTLE HISTORY AND INTRODUCTION 3
QUICK STARTGUIDE 4
THE RECORD TRANSPORT7
TRACKS, TRACK SELECTION AND TRANSPORT 9
ANALOG CONTROL AND I/O 11
DIGITAL I/O AND POWER 12
MEMORY CARD AND USB 12
IN-DEPTH LOOK AT RECORDING TRACKS 14
IN-DEPTH LOOK AT OVERDUBBING TRACKS 17
IN-DEPTH LOOK ATMIXDOWN 19
MIDI AND MIDI SYNC 21
USER NOTES & TIPS 22
SIGNAL PATH DIAGRAM 27
Copyright
2005 Electro-Harmonix. All rights reserved. 2880 and
Electro-Harmonix and logo are trademarks of New
Sensor/Electro Harmonix. Product and company names
used within the manual are trademarks of their
respective companies.
2880 Manual Version 1.1
T
Th ha an nk ky yo ou uf fo or rp pu ur rc ch ha as si in ng gt th he eE El le ec ct tr ro o- -
H
Ha ar rm mo on ni ix x2 28 88 80 0S Su up pe er rM Mu ul lt ti i- -t tr ra ac ck k
L
Lo oo op pe er r. .P Pl le ea as se er re ea ad dt th hi is sm ma an nu ua al li in no or rd de er r
t
to of fa am mi il li ia ar ri iz ze ey yo ou ur rs se el lf fw wi it th ht th hi is su un ni iq qu ue e
i
in ns st tr ru um me en nt t’ ’s sl la ay yo ou ut t. .I It tw wa as sw wr ri it tt te en nt to ob be e
a
ar re ef fe er re en nc ce eg gu ui id de et th ha at ty yo ou uc ca an nk ke ee ep p
c
cl lo os se eb by y. .T Th he es so ou un nd di is sw wo on nd de er rf fu ul lb bu ut tt th he e
k
ke ey yi is sy yo ou ur rc cr re ea at ti iv vi it ty y. .T Th he e2 28 88 80 0w wi il ll lt ta ak ke e
y
yo ou ur rm mu us si ic ct to on ne ew wc cr re ea at ti iv ve eh he ei ig gh ht ts s. .

2
Precautions For Safe Use
Please read the manual carefully, as it was written to help you understand the capabilities and system requirements
of your new instrument. Carefully review the safety precautions as they not only ensure long and trouble-free life of
your 2880, but also ensure your own long and trouble-free life. Instead of neatly tossing it to the side once it comes
out of the box, keep your manual in a convenient place for quick reference.
The following instructions, on this page, are WARNINGS that must be followed:
1. Fluids and moisture: Do not operate this or any electrical instrument, in an area where it could be exposed to
moisture. This is an instrument, do not place drinks or fluids on top of it.
2. Placement and ventilation: The 2880 is a tabletop or floor instrument and thus may be placed on the stage or
tabletop setup. Placement must be balanced and even, while still leaving an unobstructed space for proper ventilation.
Proper ventilation ensures long life and far less stress on the instrument. Again, keep all fluids away from the storage
location. All bracket mountings must be able to bear the weight of the 2880 as its minimum rating.
3. Cleaning: Extreme care must be taken when cleaning the exterior. The exterior may be wiped down with a damp
sponge and an extremely mild detergent. Damp means slightly moist and not wet or saturated. Keep away from
ALL critical components as if you were dusting priceless china. UNPLUG THE INSTRUMENT before any cleaning.
4. Heat: The unit should be situated away from heat sources, or other equipment that produces significant heat.
5. Power Sources: When the unit will be unused for extended periods, disconnect the AC Adapter power supply
from the outlet. Be careful that the power cord is out of the way and specifically away from traveled areas. When
connecting or disconnecting the cable, grasp the plug firmly and push or pull. Do not pull from the cable. Make
sure that your hands are dry.
6. Service Situations: Situations that must be immediately addressed if encountered:
a. Damage to the AC Adapter or power cord. Immediately shutdown and disconnect the power cable.
b. Water, any fluids or material (any amount) has fallen into the interior of the 2880.
c. Exposure to natural elements such as rain.
d. Sudden impact of the instrument, such as dropping or a hard external impact.
e. Sudden and noticeable differences in performance and consistency.
f. Functional change where a marked difference in operation is noticed.
Note: All electrical failures must be handled by an authorized service technician. Do not attempt user service.
A qualified technician will handle it swiftly, accurately and correctly.
For your safety and proper repair, call: Electro-Harmonix: 718-937-8300.
Ask to speak with a service representative and you will be instructed on how to proceed.
You must call in order to receive service.
WARNING: Use only the 9VDC/500mA AC adapter supplied with the 2880. Do not use any other AC adapters. Using
other AC adapters, even those made by Electro-Harmonix, could cause harm to the unit, the adapter or you. The 2880
does not use batteries.

3
A Little History
In 1983, Electro-Harmonix released what would become
a legendary and more importantly, revolutionary, musical
instrument…The 16 Second Delay. Aside from being
the first looper ever invented, it helped change the way music
was created while presenting individual musicians with a way to
manipulate their creations instantly. The concept of looping, as
we know it today, was an entirely new dimension in musical
expression in 1983 and the 16 Second Delay was an
instant hit.
In 2004, the music public demanded the 16 Second’s re-release, and it once again became an all-time classic.
Electro-Harmonix is now proud to present the 2880 Super Multi-track Looper. The new definition
in complex expression for performance and the studio. This powerful and interactive instrument follows a traditional
recording layout, so it will feel instantly familiar. However, there are significant differences that go well beyond the
recording world. In fact, at the very least it is a multitrack recorder. When viewed as a whole, it is a multifaceted per-
formance instrument with significant advantages in both live performance and as a personal recording instrument.
Introduction
The uniqueness of the 2880 is the ability to layer multiple
tracks and manipulate them. A special mix down track allows
you to create a spatial stereo pair while freeing up previous
tracks to add more instruments. Very complex interactive tracks
can be completed quickly with the ability to sound unique and
totally original. This is a very spontaneous instrument.
The Electro-Harmonix 2880 records at the industry
CD standard of 44.1 kHz /16 bit uncompressed digital audio.
What you record is what you get, without the degradation or
artifacts that compressed audio usually presents.
Building upon the original concept of the 16 Second Delay, while taking into consideration the demand for
more complex possibilities, the 2880 is more of everything. True world standard audio fidelity, as much
creative time as any musician would need, and an ease of use that is instantly familiar.
The 2880 uses world-class audio converters, while offering uniformity in syncing and integration with any user’s current
equipment. The storage is on flash cards that range from 128 megabyte to 2 gigabyte. All files may be downloaded
to your computer and retrieved when needed.
2880 Super Multi-Track Looper

How to Record a Multi-Track Loop:
1. Plug your instrument into either the LEFT or RIGHT Inputs and adjust the corresponding Input Knob so
that the Clip LED (Light Emitting Diode) barely lights up on your loudest notes.
2. Connect the LEFT and/or RIGHT Outputs to an amplifier or mixer.
3. Raise the DRY OUT Fader so that you can hear your instrument.
4. If you are using Headphones, turn up the HEADPHONE knob.
5. Make sure the QUANTIZE LED is off.
6. If you do not want to hear the CLIX metronome, turn the CLIX LEVEL knob down to zero.
7. Set the TEMPO slider to 50%.
8. Press the NEW LOOP button to put the 2880 into Record-Ready mode. You should see the RECORD LED
blink rapidly.
9. Press the RECORD button to immediately start recording. Play your instrument. The 2880 will record onto
TRACK 1.
10. When you are finished playing, hit either the RECORD or PLAY button to stop recording. Pressing RECORD
will stop recording and stop the 2880. Hitting PLAY will loop the 2880 back to the beginning, put the 2880
into OVERDUB mode and automatically continue recording onto TRACK 2. To exit OVERDUB mode, press
the RECORD button.
11. Raise the TRACK 1 Fader to hear the track you just recorded.
12. To record on another track, hit the TRACK SELECT button, you will cycle through the 4 tracks. Whichever
track LED is lit, is the track you will record on.
4
Quick Start Guide

How to Overdub onto a Track:
1. You can continuously overdub onto any one of the tracks.
2. Record a New Loop onto TRACK 1, as done above in the How to Record a Multi-Track Loop section.
3. Press the TRACK SELECT button until TRACK 1 is lit.
4. Move the TRACK 1 Fader to 100%. When in Overdub mode, the track's volume slider acts like a Feedback
control on a delay pedal. For example, if the TRACK 1 slider is set to 50%, each time the loop cycles, the volume
of the previously recorded audio on TRACK 1 will be halved.
5. Hit the RECORD button, both the RECORD and PLAY LEDs will light up. This means you are in Overdub mode.
Since the TRACK 1 LED is lit, you are overdubbing onto TRACK 1.
How to Record 2 Tracks Simultaneously (aka Stereo):
1. Press the STEREO MODE button. Its LED will light and you will notice that a pair of TRACK LEDS will light, either
1 & 2 or 3 & 4.
2. After inserting your instrument(s) into the LEFT and RIGHT Input jacks, adjust the INPUT Level knobs so that the
CLIP LEDs barely light.
3. Press the NEW LOOP button to put the 2880 into Record Ready mode. The RECORD LED will blink rapidly.
4. Press the RECORD button to begin recording immediately.
5. To stop recording, hit either the RECORD or PLAY buttons. Hitting RECORD will stop record and playback.
Hitting PLAY will cycle the loop to its beginning and begin Overdubbing onto Tracks 3 & 4 automatically, the
loop continues playing.
How to Record a Quantized Loop:
1. Press the QUANTIZE button to turn on Quantize mode. Its corresponding LED will light up.
2. Turn the CLIX LEVEL knob up so that you will be able to hear the metronome Clix.
3. Press the NEW LOOP Button. The RECORD LED will blink rapidly.
4. At this point you will hear the metronome beating at the tempo set by the TEMPO Slider. You can adjust the
tempo by moving the tempo slider up or down. Up will give you a faster tempo; down will be a slower tempo.
5. Hit the RECORD button. The 2880 will not immediately begin recording but instead will give you a 4-Beat count-
in. On the 5th beat, after the count-in, the 2880 will begin recording. This is beat 1 of the loop. Upon hitting the
RECORD button, the Clix metronome will reset to beat 1.
6. For a Mono recording, TRACK 1 LED will blink rapidly during the 4-Beat count-in. When making a Stereo
recording, both the TRACK 1 and 2 LEDs will blink rapidly during the 4-Beat counting.
7. Once the TRACK 1 LED goes solid, the 2880 is recording.
8. To stop recording, hit either the RECORD or PLAY buttons. Press RECORD or PLAY within the first 2 beats of the
current bar and the 2880 will truncate the loop length to the end of the previous bar. Press RECORD or PLAY
during the 3rd or 4th beats of the current bar and the 2880 will finish recording the current bar then stop
recording. For example if you want to record a 2 bar loop, you can press the PLAY button during the 3rd and
4th beat of the second bar or within the first 2 beats of the third bar. The QUANTIZE LED will blink rapidly until
it finishes recording the loop.
How to Mixdown Your Tracks:
1. At anytime, you can mix your 4-Tracks down to one stereo Mixdown track. For now let's start with the 2880 in
Idle (stopped) mode. If the 2880 is Playing or Overdubbing a loop, hit the PLAY button to stop it.
5

2. Hit the Mixdown button once and its LED will light solid. You are now in Mixdown mode.
3. Assuming the Mixdown Track has not been previously recorded, move its volume slider to its top position.
You can continually Overdub any of the 4 tracks onto the Mixdown track; the Mixdown Fader acts like a
Feedback control.
4. Hit the PLAY button. Your loop will play back. Move the Volume and Pan controls of the 4 tracks to your
preferred settings. You can adjust the Volume and Pan controls as much as you like when recording the
Mixdown track.
5. When you are ready to record the Mixdown track, hit the RECORD button. You will immediately begin recording
your mix onto the Mixdown track.
6. To stop recording the Mixdown track, hit either the PLAY or RECORD buttons.
7. The Dry Input signal will not be recorded to the Mixdown track, only audio that was previously recorded on the
4 tracks.
How to Backup your Audio Files to a Computer:
1. Make sure both your computer and the 2880 are powered up.
2. Connect the 2880 to your computer with a standard USB cable.
3. As long as your computer is running Windows XP, ME, MAC OS X or 9.2, the computer will automatically
recognize the Compact Flash card inside the 2880 and treat it like a Removable Disk.
4. Open up the Compact Flash card's window, you will see 6 files: TEMPO.TXT, TRACK1.WAV,
TRACK2.WAV…TRACKM.WAV. You can copy any or all of these files to your hard drive. It is recommended that
you copy all 6 files and store them together in a folder on your hard drive.
5. To disconnect the 2880 from the computer, follow the proper ejection procedure for the computer you are using:
a. For Windows, go to the “Safely Remove Hardware” icon down in the lower right corner of the screen.
Select the USB Mass Storage Device and hit the STOP button. Alternatively in XP, setup the 2880’s CF Card
for “Optimize For Quick Removal.”
b. For MAC OS, go to the Finder, drag the Compact Flash Card icon to the Trash.
How to Restore your Audio Files from a Computer:
1. Make sure both your computer and the 2880 are powered up.
2. Connect the 2880 to your computer with a standard USB cable.
3. As long as your computer is running Windows XP, ME, Mac OS X or 9.2, the computer will automatically
recognize the Compact Flash card inside the 2880 and treat it like a Removable Disk.
4. Locate the 6 files you want to restore to the 2880 on your hard drive.
5. Copy the files to the 2880’s Compact Flash card, directly to its root folder (meaning do not place the files into a
folder on the Compact Flash card if you want the 2880 to play them).
6. Play the 2880, the audio files should be restored.
7
.To disconnect the 2880 from the computer, follow the proper ejection procedure for the computer you are using:
a. For Windows, go to the “Safely Remove Hardware” icon down in the lower right corner of the screen.
Select the USB Mass Storage Device and hit the STOP button.
b. For MAC OS, go to the Finder, drag the Compact Flash Card icon to the Trash.
6

1. NEW LOOP Button: The NEW LOOP button will put the 2880 into Record-Ready Mode. When you press
the NEW LOOP button, the RECORD LED will blink rapidly, telling you the 2880 is ready to record. Press the
NEW LOOP button again to exit Record-Ready Mode. If you press the NEW LOOP button while recording a New
Loop it will end recording and put the 2880 into Playback mode. Below is a table displaying the results of press-
ing the NEW LOOP button depending on the current mode of the 2880:
Current Mode New Mode
Idle Record-Ready
Playback Record-Ready (Continues playing loop in memory)
Overdubbing Overdubbing (NEW LOOP Button is ignored)
Record-Ready Reverts to previous mode before Record-Ready
Recording New Loop Playback (End recording New Loop)
2. RECORD Button and LED: Depending on the 2880's current mode, the RECORD button serves a few
purposes, all of which cause the 2880 to enter/exit some kind of recording mode. The RECORD LED will light up
anytime the 2880 is Recording or Overdubbing audio. Below is a table displaying the results of pressing the
RECORD button depending on the current mode of the 2880:
Current Mode New Mode (RECORD LED State)
Idle (If Loop in Storage) Overdubbing (RECORD LED = ON)
Playback Overdubbing (RECORD LED = ON)
Overdubbing Playback (RECORD LED = OFF)
Record-Ready Begin Recording New Loop (RECORD LED = ON)
Recording New Loop Idle (RECORD LED = OFF)
The RECORD LED blinks rapidly when the 2880 is in Record-Ready mode.
+NEW LOOP =
}
+RECORD =
}
1
8
7
23
465
The Record Transport
7

3. PLAY Button and LED: The PLAY button is used to enter/exit Playback mode depending on the current
mode it is in. The PLAY LED will light anytime the 2880 is Playing or Overdubbing audio. Below is a table
displaying the Record/Playback modes and the resultant mode the 2880 enters after pressing the PLAY button:
Current Mode New Mode (PLAY LED State)
Idle (If Loop in Storage) Playback (PLAY LED = ON)
Playback Idle (PLAY LED = OFF)
Overdubbing Idle (PLAY LED = OFF)
Record-Ready Playback of Loop in Storage (PLAY LED = ON)
Recording New Loop Overdubbing (PLAY LED = ON)
When a loop cycles back to the beginning, the PLAY LED blinks once, signifying the start of the loop.
4. REVERSE Button and LED: Press the REVERSE button and the loop will reverse its Playback/Record
direction. The REVERSE button can be used at all times except when recording a New Loop. The REVERSE LED
will light up when the Reverse function is active.
5. OCTAVE Button and LED: The OCTAVE button will lower the pitch and tempo of the loop by exactly
one octave. The OCTAVE button can be used at all times except when recording a New Loop. The OCTAVE LED
will light up when the Octave function is active.
6. PUNCH IN Button and LED: When the PUNCH IN function is activated, Overdubbing Mode will
change into Punch In Mode. When recording with Punch In active, whatever was previously recorded on the
active track will be erased, no matter where the volume fader is set to for that track. The Punch In function is
useful for fixing bad notes or mistakes. When Punch In is active its LED will light up.
7. QUANTIZE Button and LED: The QUANTIZE button toggles between Non-Quantize (NQ) and
Quantize modes. When the QUANTIZE LED is lit, the 2880 is in Quantize mode. When you record a New Loop
in Quantize mode, the 2880 will give you a 4 beat count-in and extend the loop length to the nearest full bar;
the loop is quantized to the nearest bar. This means the 2880 will continue recording a New Loop (after
pressing the RECORD or PLAY buttons to end the loop) until it reaches the end of the current bar. All bars are 4
beats long. In Non-Quantize mode, the length of the loop is defined by the time between pressing the RECORD
button (to begin recording) and then the RECORD or PLAY buttons (to end the loop).
8. EXT. CLOCK Button and LED: Pressing the EXT. CLOCK button will enable the 2880 to follow the
external MIDI Sync it receives at its MIDI IN jack. The EXT. CLOCK LED will light up when in Ext. Clock mode.
While in Ext. Clock mode, the 2880 will wait for the MIDI Sync signal. If no MIDI Sync is available when you
press the PLAY button, the PLAY and EXT. CLOCK LEDs will blink rapidly telling you there is no sync. You will see
the same blinking if you try to Overdub or record a New Loop with no MIDI Sync present. The one exception is
when recording a New Loop, if you press the RECORD button twice, the 2880 will look to its internal tempo
setting and record the loop, ignoring the fact that there is no MIDI Sync signal.
+PLAY =
}
8

11
12
9 10
16
15
13 14
9. DRY OUT Fader and Pan Pot: The DRY OUT Fader and Pan Pot give you the ability to monitor your
instrument when recording or to play along with a loop you have already recorded. Adjust the output volume of your
instrument using the DRY OUT Fader. Use the Pan Pot to direct the Left and Right Inputs to the Left and Right Outputs.
When Pan is set to the CCW position, the Left Input is monitored at the Left Output and the Right Input is monitored at
the Right Output. When Pan is set to the CW position, the Left Input is monitored at the Right Output and the Right
Input is monitored at the Left Output. When Pan is set to the middle, both Inputs are mixed to both Outputs. The
setting of the DRY OUT Fader and the Pan Pot have no influence on the signal that is recorded.
10. RECORD Tracks: There are 4 tracks available for you to record your instruments onto. You can record at most
2 tracks simultaneously. Each of the 4 tracks contain a pan pot and a level fader. This allows you to balance your
volumes as well as locate your tracks within the stereo spectrum. Each track also contains an activation LED above the
track number. When the LED is lit, that particular track is activated for recording. When you hit the RECORD button
from the Idle state, the active track will be recorded or overdubbed onto.
The tracks are available in mono or stereo pairs (1 & 2 or 3 & 4). The recording levels are set with the INPUT knobs.
TRACK Faders: The 4 track faders serve a dual purpose: during Playback they are the volume control for each
track, during Overdubbing they act like a Feedback control from a delay effect. So when you are Overdubbing, the
level of the previously recorded audio on the active track is multiplied by the position of the track's fader. If the fader
is set to 100%, the previously recorded audio will remain at the volume it was recorded at. If the fader is set anywhere
below 100%, with each pass of the loop, the volume of the previously recorded audio will attenuate according to the
setting of the fader. Using this function, it is possible to use the 2880 as a very long delay pedal.
11. TRACK SELECT Button: This button is used to select the active track. Pressing the TRACK SELECT button will
cycle through the 4 tracks.
12. STEREO MODE Button and LED: This button toggles the 2880 in/out of Stereo Mode. When the STEREO
MODE LED is lit, you are in Stereo Mode, when it is off, you are in Mono Mode. When Stereo Mode is activated, the
stereo pairs (1 & 2 or 3 & 4) will be recorded simultaneously. The LEFT Input will always be sent to Tracks 1 or 3. The
RIGHT Input goes to Tracks 2 or 4.
Tracks, Track Selection and Mixdown
9

13. MIXDOWN Track: The Mixdown Track is a stereo track that records the audio from the 4 Recording tracks
through their Pan Pots and Faders. There are two different modes of Mixdown: Normal Mixdown and Constant Tempo
Mixdown.
MIXDOWN Button and LED: If the 2880 is idle, press the MIXDOWN button once and the MIXDOWN LED
will light up solid. You are in the normal Mixdown mode. Normal Mixdown is the mode to use when you want to
make a stereo mix of the 4 tracks. Press the MIXDOWN button again and the MIXDOWN LED will blink. You are in the
Constant Tempo Mixdown mode. Constant Tempo is a special mode that you can use to put flanging, pitch-bending
effects onto your Mixdown track, see below for more information on both modes. To exit either Mixdown mode, press
the Mixdown button while in idle mode, until the Mixdown LED turns off.
NORMAL MIXDOWN Mode: MIXDOWN LED lit solid. In this mode the 2880 is set up to produce a clean mix
of the 4 tracks. Press the RECORD button to begin mixdown. You can move the track faders and pan pots during the
mixdown and the audio will be recorded onto the Mixdown track just as you hear it when recording the Mixdown
track. The Mixdown Fader will act like a Feedback control during Overdubbing, just like the track faders. You can
record onto the Mixdown track as many times as you like, keeping what was previously recorded.
CONSTANT TEMPO Mode: MIXDOWN LED blinks rapidly. In this mode the Mixdown track is recorded at a
constant speed or tempo but the TEMPO Slider will allow you to vary the speed of the 4 Recorded tracks. As the
Mixdown track is recorded, speed variations you perform with the TEMPO Slider will be recorded onto the Mixdown
track. This allows you to make subtle effects such as flanging or more drastic effects like radically bending the pitch of
an instrument. You can also engage the Reverse function to reverse a track that was recorded forwards. In some cases
of drastic TEMPO Slider use, the tracks you are mixing will become delayed with respect to their original timing.
14. TEMPO Slider and LED: The TEMPO Slider sets the tempo for the 2880 at all times except when the
EXT.CLOCK is activated (then the 2880 looks to the MIDI IN jack for its tempo). The TEMPO normally ranges from 60
BPM to 240 BPM. If the OCTAVE LED is lit, the tempo will range from 30 BPM to 120 BPM. The tempo gets faster as
the slider is pushed up. The total range of the Tempo slider is +/- 1 Octave + 1 step. When moving the TEMPO Slider,
it will increment the Pitch and Tempo in semitone (1/2) steps. After recording a New Loop, the TEMPO LED lights up
solid when the TEMPO Slider is set to the original tempo the loop was recorded at.
Pitch Changing and Bending with the Tempo Slider: After you have recorded a New Loop, on subsequent tracks you
record, you can move the TEMPO Slider and/or press the OCTAVE button to record notes at different pitches when
played back at the loop's original speed. For example, record Track 1 with some guitar chords. Move the TEMPO Slider
up one octave and record some single low notes with the same guitar. When you play both tracks back at normal
speed you will have guitar and bass tracks. While recording, try moving the TEMPO Slider, when you play the loop
back at a set tempo, the notes will bend according to how you moved the TEMPO Slider when recording.
15. CLIX LEDs: The CLIX LEDs blink on the beat, at the same tempo the 2880 is set to. The left LED lights briefly on
every beat, the right LED blinks only on beat 1. When the 2880 is using its internal tempo, the TEMPO Slider will set
the tempo the LEDs blink at. When the EXT. CLOCK is activated, the CLIX LEDs will blink at the MIDI Sync tempo.
16. CLIX LEVEL Knob: The CLIX LEVEL knob adjusts the volume of the Clix metronome. When you are recording a
New Loop, this knob will vary the volume for the metronome from 0 to 100%. After you record a New Loop and you
are either Playing back or Overdubbing, the CLIX LEVEL knob acts more like a switch for the metronome. If you have
the CLIX LEVEL knob set to above 75%, you will hear the metronome, otherwise it is silent. When the 2880 is idle, the
metronome is off. The metronome beat is output through the Headphone jack and the Left/Right Output jacks but will
not be recorded.
10

LEFT and RIGHT INPUT Jacks: Plug your instruments into these Hi-Impedance audio input jacks. In
mono mode, either input can be recorded onto any of the 4 tracks. In Stereo Mode, the Left Input will record to
either Tracks 1 or 3, the Right Input will record to either Tracks 2 or 4. The Input Impedance presented at each of the
INPUT Jacks is 470 kOhms.
INPUT L and RKnobs: These knobs adjust the amplitude of the signal before it goes into the A/D Converter.
The L knob adjusts the signal level of the LEFT Input and the R knob adjusts the level of the RIGHT Input. The INPUT
knobs should be adjusted to the point where maximum level causes the CLIP LEDs to barely blink or not light up at
all. The trick to achieving the best quality digital audio is to record the hottest possible signal without clipping the
A/D converter. You do not want to record a signal that is too low in volume or a signal that clips very often (unless
that is the sound you are going for). When recording in mono, both the Left and Right Inputs are summed together
and recorded onto the active track. To minimize hiss when recording in mono mode, it is best to turn down the
unused Input knob.
CLIP L and R LEDs: These LEDs light up when the audio signal clips the A/D Converter. In other words, the
signal’s amplitude is greater than what the A/D Converter can properly handle. The L LED lights when the LEFT
Input clips, the R LED when the RIGHT Input clips.
AUX IN Jack: This stereo input is mixed with the stereo output of the D/A Converter in the analog domain and
is output through all three output jacks. You could use this input to connect a CD Player, iPod, Mixer, Drum Machine
or Sampler. The 2880 does not record audio from the AUX IN Jack. The Input Impedance presented at the AUX IN
Jack is 6.8 kOhms, so it is best suited for Line Inputs. You will need to use the output volume of your device to mix it
properly with the 2880 output.
LEFT and RIGHT OUTPUT Jacks: Your main output from the 2880. Plug these outputs into your amplifier,
A. Analog Control and I/O
A
C
B
11

mixer, computer, tape recorder or any other suitable device. The Output Impedance at each OUTPUT Jack is 400 Ohms.
HEADPHONE OUTPUT Jack: Plug your preferred headphones into the Stereo Headphone jack,
labeled . Each channel of the HEADPHONE Output jack can deliver 0.1W into 16 ohms.
HEADPHONES VOLUME Knob: The knob labeled adjusts the output volume for the Headphones.
The Headphones Volume knob is an analog knob after the D/A Converter, it has no bearing on the level of the
recorded or played back audio that is saved on the card.
B. Digital I/O and Power
FOOTSWITCH Jack: Using a standard 1/4" guitar cable, connect this jack to the 2880’s remote Foot Controller
(sold separately). The Foot Controller allows foot access to the following functions: NEW LOOP, RECORD, PLAY,
TRACK SELECT, REVERSE and OCTAVE. With the Foot Controller, the 2880 becomes a live/solo looper where you can
make loops on the fly, in time with your band, while playing your instrument.
MIDI IN Jack: Standard 5-pin DIN MIDI cables connect to this jack. When the EXT. CLOCK function is on, the
2880 can sync to MIDI Clock through the MIDI IN jack. You can use a drum machine, sequencer, beat box or any
device that outputs MIDI Clock as the MIDI Clock master; the 2880 will slave to the external device.
MIDI OUT Jack: Standard 5-pin DIN MIDI cables connect to this jack. When the EXT.CLOCK function is off, the
2880 constantly generates MIDI Clock and outputs it through the MIDI OUT jack. Using the MIDI OUT Jack, the 2880
is the MIDI Clock master; you can slave another device, such as a drum machine, sequencer or beat box, to the 2880.
The 2880 also uses the MIDI OUT jack as a MIDI Thru, passing whatever commands the MIDI IN jack receives back
out to the MIDI OUT jack. When EXT. CLOCK Mode is activated, the MIDI OUT jack will pass the MIDI Clock signal it
receives through the MIDI IN jack back out of the MIDI OUT jack.
9VDC/500mA Power Jack: Plug the supplied 9VDC/500mA AC Adapter into this jack. The barrel connector
dimensions required for the Power Jack are 5.5 x 2.5 mm. Use only the supplied AC Adapter or you may damage the
unit, injure yourself or a band mate.
C. Memory Card and USB
The 2880 records 16 bit audio at a sampling rate of 44.1 kHz. One significant advantage is that all audio is uncompressed
and is not processed into a less professional format. What you hear is what you recorded and it is presented at CD quality.
Compact Flash Memory Card
All recorded audio is stored on removable Compact Flash (CF) memory cards. The CF Card slot is located on the
right side of the 2880.
The 2880 comes supplied with a 1GB card which allows for a maximum loop length of 31 minutes. Just as the
original 16 Second Delay stood for the maximum amount of storage, the name 2880 stands for the number of
seconds that can be recorded with a 256MB card, 2880 seconds or 48 track-minutes of full bandwidth recording.
Using a 2GB flash memory card, you can record over 372 track-minutes of full bandwidth audio. The real name
could be the 22,670.
The CF card can easily be removed when you record a loop, song or project that you do not want to overwrite
immediately. You may then reinsert a new CF card and continue working.
12

Please Note: Only one loop, song or project can be on a CF card at a time, even if it is only 1 second in length.
When you begin recording a New Loop, it erases the previous loop that you had on the card; you cannot retrieve
old loops once overwritten.
2880 Requirements for the Compact Flash Card:
Minimum Card Size = 128MB
Maximum Card Size = 2GB
Card Speed = 40x or greater is recommended
Approximate Maximum Loop Length for each standard Compact Flash card size:
128MB = 4 minutes
256MB = 8 minutes
512MB = 16 minutes
1GB = 31 minutes
2GB = 62 minutes
Cards will have to be formatted to the FAT16 file system. Most store bought cards are formatted for FAT16. If you
need to format a CF Card, attach the 2880 to a Windows PC via the USB port, and choose “FAT,” under the File
System pull-down menu.
The 2880 will not Record or Playback without a proper CF Card inserted into the 2880’s card slot.
USB Port
The 2880 is fitted with a USB Port, which allows you to move your files to and from your computer using a standard
USB cable. The USB Port is located on the right side of the 2880, next to the CF card slot.
When you connect your 2880 to a computer, through the USB connector, it will display the Compact Flash card
inside the 2880 as an external hard drive. You may then copy files to and from the CF card. The 2880 is automatically
recognized by PCs running Windows XP or ME or Macs running OS X or OS 9.2.
The 2880 records all audio files as wave files (.wav), which can then be read by most if not all computers. Any
audio program that accepts wave files as a viable format can play or edit the 2880 audio files. Every PC and most
Macs can play wave files. The biggest plus is the ability to insert your manipulated file into your favorite software
program. A sound designer’s dream.
Your computer can backup and restore loops, songs and projects to the CF card inside the 2880. When backing up
the contents of the CF card, it is recommended you copy all 6 files from the CF card and place them together into
their own folder. When restoring the loop, copy all 6 files back to the root directory of the CF Card (not into a folder
on the CF card).
When copying files to the CF Card, it is important to include the Tempo.txt file. This file gives the 2880 information
on the original tempo setting of the audio files.
Please refer to the “How to Backup...” and “...Restore your Audio Files from a Computer” sections of the Quick Start
guide, earlier in this manual, for more information on connecting the 2880 to a computer through USB.
13

Readying the 2880 to Record a NEW LOOP:
Plug your instrument into either the LEFT or RIGHT INPUT jacks, or both if recording two separate instruments or if
recording in stereo.
To monitor your recording, connect the LEFT and/or RIGHT OUTPUT jacks to a mixer or amp or plug headphones
into the HEADPHONE jack.
Play your instrument(s) and adjust the INPUT Level knobs so that the CLIP LED does not light or just barely lights
on your loudest notes. The trick to achieving the best quality digital audio is to record the hottest possible signal
without clipping the A/D converter. You do not want to record a signal that is too low in volume or a signal that clips
very often (unless that is the sound you are going for).
If recording only one input, turn the Input knob down fully for the unused channel, this reduces hiss.
Use the DRY OUT slider and PAN knob to adjust what you hear when monitoring.
The DRY OUT Pan Pot can be used to mix the Left and Right Inputs to both outputs or to separate the Inputs to
monitor on different outputs. In the CCW position, the Left Input is sent out the Left Output jack, the Right Input is
sent out the Right Output jack. In the CW position, output monitoring is reversed: Left In goes to Right Out and Right
In goes to Left Out. When the DRY OUT Pan Pot is set to the center, the Left & Right Inputs will be mixed together in
both Outputs.
If using Headphones, you also have a separate volume control just for the Headphones.
The setting of the DRY OUT Fader and PAN Pot will not effect what is actually recorded. Only the INPUT Level knobs
have any bearing on what is recorded.
In-Depth Look at Recording Tracks
14

NON-QUANTIZE vs. QUANTIZE Loop Recording:
In Non-Quantize Mode: the loop length is set by the user. The time between pressing the RECORD and PLAY
buttons determines the length of the loop for all of the tracks. You could also press RECORD or NEW LOOP to end
the loop. The 2880 will begin recording the loop immediately upon hitting the RECORD button.
In Quantize Mode: the loop length is determined by the number of bars you wish to record and the setting of the
TEMPO slider. Upon pressing the RECORD button, the 2880 will reset its Clix metronome to beat 1; then you will
hear a 4-Beat count-in. The 2880 will start recording after the 4-beat count-in; on the 5th beat you hear. Pressing the
PLAY, RECORD or NEW LOOP buttons will end the loop. The 2880 will truncate the loop’s length to the end of the
previous bar if the aforementioned buttons are pressed within the first 2 beats of the current bar. When the
aforementioned buttons are pressed after the 2nd beat, the 2880 will continue recording to the end of the current
bar and then end the loop. You can record as many bars as the Compact Flash card will allow or as few as 1 bar.
A bar is 4-beats long.
The metronome’s tempo can be adjusted using the TEMPO Slider. It is best to adjust the tempo while in Record-
Ready mode, before pressing the RECORD button.
You can change from Non-Quantize to Quantize mode at any time by pressing the QUANTIZE button. When the
QUANTIZE LED is lit, you are in Quantize mode.
The most appropriate times to press the QUANTIZE button are either just before pressing the NEW LOOP button or
while the 2880 is in Record Ready mode.
Pressing the QUANTIZE button while in the process of recording a new loop will enable you to end the loop according
to the rules of the Quantize mode you just entered. For example, you start a loop in Quantize mode so that you can
have the 4-beat count-in but you want to end the loop in the middle of a bar. You can press the QUANTIZE button
while recording the loop; when you hit the PLAY button to end the loop, it will end immediately, without finishing
out the bar you are recording or truncating the bar.
The QUANTIZE button will have no effect once you have recorded a New Loop and established the loop length.
Stereo Mode:
Press the STEREO MODE button to Toggle between Mono and Stereo modes. Stereo mode is active when the
STEREO MODE LED is lit.
In Mono mode, one Track Select LED is lit at a time. In Stereo Mode, the tracks will be selected in pairs, so either
the LEDs for TRACKS 1 & 2 will be lit or TRACKS 3 & 4.
You may press the STEREO MODE button at any time. It is most appropriate to hit the STEREO MODE button just
before recording, either a New Loop or tracks for an already established loop.
You can start a loop by recording mono instruments onto the tracks and then at any time, switch to stereo mode
and begin recording stereo instruments onto the track pairs or vice versa.
15

Recording a New Loop:
When you are ready to record a loop, press the NEW LOOP button. This will put the 2880 into Record Ready mode.
You will see the RECORD LED blinking rapidly.
To exit out of Record-Ready mode, press the NEW LOOP button again.
Choose between Quantize or Non-Quantize mode.
Press the RECORD button to commence recording.
While in the process of recording a new loop, the following buttons will be inactive: REVERSE, OCTAVE, EXT. CLOCK
and MIXDOWN.
Moving the TEMPO slider while in the process of recording a New Loop will not change the pitch of the recording,
although it does change the pitch after you have recorded the initial loop.
Ending a New Loop:
To end a New Loop press either the PLAY, RECORD or NEW LOOP buttons. Each of the three buttons will put the
2880 into a different mode upon completing the loop.
By pressing the PLAY button: the 2880 will automatically enter OVERDUB mode, the loop will cycle back to its
beginning and you will hear what you just recorded on Track 1. Both the RECORD and PLAY LEDs light up. When
pressing PLAY, the active track will jump to Track 2, so that you can immediately start recording onto Track 2.
By pressing the RECORD button: the 2880 will go into idle mode and stop Record and Playback. Track 1 will remain
the active track. The audio you recorded on Track 1 is in memory; you need to press PLAY to hear it.
By pressing the NEW LOOP button: the 2880 will automatically enter Play mode, the loop will cycle back to its beginning
and you will hear what you just recorded on Track 1. The PLAY LED lights up. The active track will jump to Track 2.
Notes on Loop Length and Compact Flash Card:
The loop length is set automatically for all tracks when you record a New Loop on Track 1. This means the loop
length for the entire 2880 is set when you record your New Loop. It also means the loop length for all 5 tracks are
always identical to Track 1’s length. For example, if you are recording a New Loop and it turns out to be 10 seconds
long, the length of all 5 tracks will be 10 seconds. You cannot record a longer or shorter loop on say Track 3 as
compared to Track 1.
Approximate Maximum Loop Length vs. Compact Flash card size:
128MB = 4 minutes
256MB = 8 minutes
512MB = 16 minutes
1GB = 31 minutes
2GB = 62 minutes
Only one loop can be on the Compact Flash card at a time.
Once you begin recording a New Loop, all of the files for the previous loop will be overwritten and you cannot
retrieve them.
16

Our Definition of Overdubbing:
Overdubbing is the recording of any track after the initial recording of a New Loop. Overdubbing can mean:
¥Recording a new instrument for the first time on a track that has not been previously recorded.
¥Layering notes or instruments on top of each other on one track. Using the track’s fader as a feedback control.
¥When Overdubbing with the 2880, both the RECORD and PLAY LEDs will be lit solid.
Choosing a Track to Overdub:
After recording a New Loop, the 2880 may have automatically advanced to Track 2. If so, you may be already over-
dubbing onto Track 2, are both the RECORD and PLAY LEDs lit?
To choose a track to Overdub onto, press the TRACK SELECT button. Pressing the TRACK SELECT button will cycle
you through the 4 tracks.
As you press the TRACK SELECT button, the LEDs above the Track numbers will consecutively light up. The track that
is lit is the active track. Meaning you will or are currently Overdubbing onto the active track.
To Overdub in stereo, press the STEREO MODE button so that its LED lights up. You will now be able to Overdub
onto Tracks 1 & 2 or 3 & 4. Pressing the TRACK SELECT button will toggle you between these two track pairs.
In-Depth Look at Overdubbing Tracks
17

Overdubbing:
Begin Overdubbing by pressing the RECORD button. Immediately you will see both the RECORD and PLAY LEDs
light up.
If the loop is playing back, pressing the RECORD button will put you into Overdub mode while in the middle of the
loop cycle.
Again you will be Overdubbing on the track that is currently active; the track(s) with its LED lit up.
Moving the active track’s fader to anything below 100% will attenuate the previously recorded audio on that track
each time the loop cycles. The track fader will act like a Feedback control on a delay effect. If you do not want to
attenuate or lose the audio already on the track, make sure the fader is set to 100%.
While Overdubbing you can move the TEMPO Slider to achieve slowed down or sped up sounding instruments. You
can also press the OCTAVE button, which will automatically drop the pitch and tempo of the loop exactly 1 octave.
The TEMPO slider changes the speed of the loop in semitone (1/2) step increments.
You can press the REVERSE button at anytime to reverse the playback direction of the loop. By doing this you can
easily record a backwards guitar line.
When using the OCTAVE and REVERSE buttons, activating either function will act on all 5 tracks of the loop, not just
the active track.
The TEMPO LED lights up when the TEMPO Slider is set to the same tempo that the original loop was recorded at. If
you move the TEMPO Slider you will see the TEMPO LED light up only when the TEMPO Slider is set to its original
setting. This is an easy way to get back to the original pitch and tempo of the loop.
Punch-In:
If the Punch-In function is activated while Overdubbing, whatever was recorded previously on the active track will
be erased.
Punch-In is useful for situations where you want to fix a bad note or simply erase one section of the loop.
While playing back you can push the active track’s fader up so that you can properly hear the track. Once you press
RECORD, the track will go silent. It is erasing and recording as the loop plays.
Steps for a common Punch-In:
1. Select the track you want to Punch-In.
2. Press the Punch-In button so that it is active.
3. Press the Play button to playback the loop.
4. When the punch-in section arrives, press the RECORD button.
The 2880 immediately begins erasing and recording onto the active track.
5. When the Punch-In section is finished, press RECORD or PLAY to stop recording.
18

What is Mixdown:
Looking at the 2880’s top panel, you can see it has a simple mixer that combines the 4 recorded tracks, the DRY
input signal and the Mixdown track, which are then sent to the stereo outputs. You can independently adjust the
volume of any of the 4 tracks, the DRY OUT and the Mixdown track. You can also adjust the stereo positioning of the
4 tracks and the DRY OUT.
During Mixdown, the 4 Record tracks are mixed internally, inside the 2880’s DSP. The output of the 4 Record tracks’
internal mixer is sent to the input of the Mixdown track as well as the OUTPUT jacks. The Mixdown track is a stereo
track so it records both the Left and Right sides of the stereo spectrum.
Since the Mixdown track is recording audio, any adjustments you make to the track faders or pan pots will be
recorded as audio onto the Mixdown track. What is getting recorded is not the fader movements but the change in
volume that the fader produces.
The Mixdown track works like any of the other 4 recording tracks. The differences are that the Mixdown track is
stereo not mono and therefore does not have a Pan Pot to turn. You cannot record audio from the Input jacks
directly to the Mixdown track. Only audio that is recorded on any of the 4 tracks will go to the Mixdown track.
While Overdubbing, if the MIXDOWN track is active, its fader will act like a Feedback control on a delay effect.
In-Depth Look at Mixdown
19
