Electro-Harmonix LUMBERJACK User manual

LUMBERJACK
Congratulations on your purchase of the LUMBERJACK, the revolutionary new log
overdriver y ELECTRO-HARMONIX. The distortion character of the LUMBERJACK
changes depending on your playing dynamics, ranging from a powerful clean oost to
su tle torn-speaker overdrive to gritty distortion. The LUMBERJACK is housed in a
dura le, compact die-cast chassis, and includes true- ypass switching to keep your
ypassed tone intact.
- CONTROLS -
BOOST Knob – This kno controls the volume of your input signal. It can e used to
oost a quiet guitar, to achieve more distortion, or, when set to higher settings,
allows your natural guitar tone to lend with the overdriven signal.
LOG FACTOR Knob – This kno controls the amount of logarithmic distortion
created y the LUMBERJACK. As you turn LOG FACTOR clockwise, overdrive
distortion increases.
VOL Knob – Sets the output level of the LUMBERJACK.
FOOTSWITCH and LED – The Footswitch selects whether the LUMBERJACK is
engaged or in true ypass mode. When the effect is engaged, the LED is lit.
INPUT Jack – This ¼” jack is the audio input for the LUMBERJACK. The input
impedance is 1MΩ.
AMP Jack – This ¼” jack is the audio output from the LUMBERJACK. The output
impedance is 100Ω.
V Power Jack – Plug the output of the supplied AC adapter into the 9V power jack
located at the top of the LUMBERJACK. The LUMBERJACK requires 100mA at 9VDC
with a center negative plug. The LUMBERJACK accepts Boss/I anez style AC
Adapters.

- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete
and return the enclosed warranty card within 10 days of purchase. Electro-
Harmonix will repair or replace, at its discretion, a product that fails to operate
due to defects in materials or workmanship for a period of one year from date of
purchase. This applies only to original purchasers who have ought their product
from an authorized Electro-Harmonix retailer. Repaired or replaced units will then
e warranted for the unexpired portion of the original warranty term.
If you should need to return your unit for service within the warranty period,
please contact the appropriate office listed elow. Customers outside the regions
listed elow, please contact EHX Customer Service for information on warranty
repairs at [email protected] or [phone]. USA and Canadian customers:
please o tain a Return Authorization Number (RA#) from EHX Customer
Service efore returning your product. Include with your returned unit: a written
description of the pro lem as well as your name, address, telephone num er, e-
mail address, and RA#; and a copy of your receipt clearly showing the purchase
date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: [phone]
Email: [email protected]
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: [phone]
Email: [email protected]
This warranty gives a purchaser specific legal rights. A purchaser may have even
greater rights depending upon the laws of the jurisdiction within which the
product was purchased.
To hear demos on all EHX pedals visit us on the we at www.ehx.com
Email us at [email protected]
- FCC COMPLIANCE -
This device complies with part 15 of the FCC Rules. Operation is su ject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation. If the device is not installed and used in
accordance with the instructions, it may cause harmful interference to radio
communications and void the user's authority to guarantee the equipment.
Note: This equipment has een tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasona le protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can e determined y turning the equipment off and on, the
user is encouraged to try to correct the interference y one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation etween the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved y the manufacturer could void the user's
authority to operate the equipment under FCC rules.
