Electro-Harmonix THE ANALOGIZER User manual

FCC COMPLIANCE
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the CC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the
user's authority to operate the equipment under CC rules.
THE ANALOGIZER
Congratulations on your purchase of the Electro-Harmonix
ANALOGIZER…an effect for warming up the harshness of your digitally
processed guitar or for thickening up your already warm sound.
— POWER —
— OPERATING INSTRUCTIONS and CONTROLS —
Connect your guitar or the output of another effects pedal to the INPUT jack
of the ANALOGIZER. Connect the AMP jack to your amplifier or the input of
another effects pedal. The ANALOGIZER can be used in combination with
other effects devices. Experiment with any combination to develop your own
unique sound. The footswitch toggles between effect and true bypass
modes.
GAIN – Controls the input gain of your ANALOGIZER. The available gain
ranges from 0 dB to +"+26dB. As you turn the GAIN knob clockwise, the
GAIN increases.
SPREAD – Controls the delay time of the ANALOGIZER. The delay time
range is from 3.5 mS to 65 mS. As you turn the SPREAD knob clockwise, the
delay time increases. Adjusting the SPREAD knob in the lower half of its
range will produce tonal variations in the effect; adjustment in the upper half
of the SPREAD knob’s range can be used to thicken up your sound.
BLEND – Varies the mix of direct and effected signals from 100% dry when
set to counter-clockwise to 100% wet at full clockwise.
VOLUME – Controls the output level of the ANALOGIZER. As you turn the
VOLUME knob clockwise the volume at the output jack increases. The
VOLUME control is after the BLEND knob in the circuit.
Your
ANALOGIZER
comes supplied with a 9
V
olt battery.
The ANALOGIZER can also be
powered from a 9VDC AC Adapter capable of delivering at least 20mA. The power supply
must have a barrel connector with a center negative plug. The optional 9V power supply
from Electro-Harmonix is 9.6DC-200BI (same as used by Boss ® & Ibanez ® ).

INPUT JACK – Connect the output of your instrument or another effects
pedal to this jack. The input impedance presented at the INPUT jack is 1
MΩ.
AMP JACK – Connect the AMP jack to your amplifier input or the input of
another effects pedal. This is the output of the ANALOGIZER
STATUS LED and FOOTSWITCH – When the STATUS LED is lit, the
ANALOGIZER is in effect mode. When the LED is off, the ANALOGIZER is in
true bypass mode. Use the OOTSWITCH to toggle between the two modes.
- WARRANT INFORMATION -
Please register online at http://www.ehx.com/product-registration or
complete and return the enclosed warranty card within 10 days of purchase.
Electro-Harmonix will repair or replace, at its discretion, a product that fails
to operate due to defects in materials or workmanship for a period of one
year from date of purchase. This applies only to original purchasers who
have bought their product from an authorized Electro-Harmonix retailer.
Repaired or replaced units will then be warranted for the unexpired portion
of the original warranty term.
If you should need to return your unit for service within the warranty period,
please contact the appropriate office listed below. Customers outside the
regions listed below, please contact EHX Customer Service for information on
warranty repairs at [email protected] or [phone]. USA and Canadian
customers: please obtain a Return Authorization Number (RA#) from
EHX Customer Service before returning your product. Include with your
returned unit: a written description of the problem as well as your name,
address, telephone number, e-mail address, and RA#; and a copy of your
receipt clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: [phone]
Email: [e-mail]
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: [phone]
Email: [e-mail]
This warranty gives a purchaser specific legal rights. A purchaser may have
even greater rights depending upon the laws of the jurisdiction within which
the product was purchased.
To hear demos on all EHX pedals visit us on the web at www.ehx.com
Email us at [email protected]
