Electro-Harmonix XO STEREO CLONE THEORY User manual

- FCC COMPLIANCE -
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: 1) This device may not cause harmful interference,
and 2) this device must accept any interference received, including interference
that may cause undesired operation. If the device is not installed and used in
accordance with the instructions, it may cause harmful interference to radio
communications and void the user's authority to guarantee the equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the user's
authority to operate the equipment under FCC rules.
STEREO CLONE THEORY
Congratulations! You have just purchased the CLONE THEORY, one of the
most lush, deep and warm CHORUS/VIBRATO ever made, now in stereo.
The CLONE THEORY’s depth and rate controls swing from one extreme to
the other, giving the user an entire realm of possibility for tone. Use both
stereo outputs and completely surround yourself with sweet warm Electro-
Harmonix tone.
-CONTROLS-
MODE SWITCH – The CLONE THEORY has two CHORUS modes and one
VIBRATO made. IN CHR 1 mode, you can control the rate of modulation
using the RATE control, but the DEPTH is preset to what we consider the
perfect chorus. This means the DEPTH control is inactive. IN CHR 2 mode
you have full control of your chorus tone. The RATE control adjusts the rate
of modulation and the DEPTH control adjusts the depth of modulation. In
VIBR mode, the dry voice is taken away, changing the effect from CHORUS
to VIBRATO. In VIBR mode you have full control. The RATE control adjusts
the VIBRATO’s rate of modulation and the DEPTH control adjusts the
VIBRATO’s modulation depth.
RATE CONTROL– Adjusts the RATE of modulation.
DEPTH CONTROL– Adjusts the modulation depth. Inactive preset) in CHR
1 mode.
FOOTSWITCH – Selects whether the CLONE THEORY is engaged or in True
BYPASS. The corresponding LED will be lit when the pedal is engaged, and
dark when True Bypassed. In True Bypass, the input signal is connected
directly to both the MAIN and STEREO output jacks.
INPUT JACK – This ¼” jack is the audio input to the CLONE THEORY.
MAIN OUTPUT JACK – This ¼” jack is the main audio output from the
CLONE THEORY. Use this jack from mono operation. When the CLONE
THEORY is in True Bypass mode, the MAIN OUTPUT jack is connected
directly to the INPUT jack.

STEREO OUTPUT JACK – This ¼” jack is the second audio output from the
CLONE THEORY. When the CLONE THEORY is in True Bypass mode, the
STEREO OUTPUT jack is also connected directly to the INPUT jack.
A NOTE ABOUT STEREO OPERATION: The STEREO OUTPUT is 180o out
of phase from the MAIN OUTPUT. This means that the extremes of the
modulation will be heard at opposite moments at each output. Try plugging
the CLONE THEORY in to two amplifiers one from each output) and notice
the panning effect between the two amplifiers. Control the panning using
RATE and DEPTH.
-OPERATION AND WARNINGS-
Power, from the internal 9-volt battery or external battery eliminator, is
activated by plugging into the input. The input cable should be removed
when the unit is not in use to avoid running down the battery. The input
impedance presented at the Input Jack is 480 kohms. The output impedance
at both the Main and Stereo Output Jacks is 300 ohms.
The barrel connector on the front of the CLONE THEORY is for a 9-volt
battery eliminator capable of delivering 100 mA of current. The inner ring of
the 9-volt battery eliminator must be negative, the outer ring positive. The
unit’s battery may be left in or taken out when the eliminator is in use.
To change the 9-volt battery, you must remove the 4 screws on the bottom
of the CLONE THEORY. Once the screws are removed, you can take off the
bottom plate and change the battery. Please do not touch the circuit board
while the bottom plate is off or you may damage a component.
The optional 9V power supply from Electro-Harmonix is US96DC-200BI
same as used by Boss ™ & Ibanez™) 9.6 v lts/DC 200ma. The barrel
connector on the front of the CLONE THEORY is for the 9-volt battery
eliminator capable of delivering 100 mA of current. The inner ring of the 9-
volt battery eliminator must be negative, the outer ring positive. The unit’s
battery may be left in or taken out when the eliminator is in use.
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete
and return the enclosed warranty card within 10 days of purchase. Electro-
Harmonix will repair or replace, at its discretion, a product that fails to operate
due to defects in materials or workmanship for a period of one year from date of
purchase. This applies only to original purchasers who have bought their product
from an authorized Electro-Harmonix retailer. Repaired or replaced units will then
be warranted for the unexpired portion of the original warranty term.
If you should need to return your unit for service within the warranty period,
please contact the appropriate office listed below. Customers outside the regions
listed below, please contact EHX Customer Service for information on warranty
repairs at [email protected] or [phone]. USA and Canadian customers:
please obtain a Return Auth rizati n Number RA#) from EHX Customer
Service before returning your product. Include with your returned unit: a written
description of the problem as well as your name, address, telephone number, e-
mail address, and RA#; and a copy of your receipt clearly showing the purchase
date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: [phone]
Email: [email protected]
Eur pe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: [phone]
Email: [email protected]
This warranty gives a purchaser specific legal rights. A purchaser may have even
greater rights depending upon the laws of the jurisdiction within which the
product was purchased.
