Architecture & Engineering Specs:
Theloudspeakershallbeatwo-waysystemconsistingoftwo4”(102mm)
low-frequency transducers, 1” (25mm) high-frequency transducer with
a Coherent Coverage Waveguide, and frequency-dividing network
installed in a vented, line array enclosure. The network shall include a
passivelimiterforboththelowfrequencyandhighfrequencytransducers.
The loudspeaker system shall meet the following performance criteria:
Power handling, 200 watts of EIA RS-426A continuous pink noise (6 dB
crest factor); Frequency response, 65 Hz – 20 kHz (-10 dB from rated
sensitivity); Pressure sensitivity, 89 dB at one watt, 200 Hz – 10 kHz at
one meter; Impedance, 8 ohms nominal, 6 ohms minimum. The high
frequency transducer shall drive a waveguide to evenly cover 120°
horizontally by 80° vertically. The enclosure shall be molded of acrylic
butylstyrene. Theenclosureshallbe12.2”(310mm)high,6.9”(175mm)
wide, 8.5” (216mm) deep. The finish shall be a paintable black or white.
The grille shall be zinc plated, powder coated for corrosion resistance,
and restrained with a safety leash. The loudspeaker shall be adjustable
over a range of 100° horizontally and 90° vertically. The support bracket
shall be low profile and integral with the enclosure. The system shall be
weatherresistanttoMILSpec810andIEC529IP34testconditions. The
surface mount loudspeaker shall be the Electro-Voice® EVID model
4.2.
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: 800/955-6831
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 887-9212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
12000 Portland Avenue South, Burnsville, MN 55337
Phone:952/884-4051,Fax:952/884-0043
www.electrovoice.com
© Telex Communications, Inc. 12/2005
Part Number 38109-982 Rev E
Beamwidth:
Frequency Response:
Directivity:
Block Diagram:
INPUT
LPF
HPF
Passive
Limiter
+
Side
Wall Plate
Front
Top
Performance Match:
• EVID12.1 Sub
Available Accessories:
• HS-3 Horizontal Mount Desk Stand for 3.2/4.2
• VS-4 Vertical Mount Desk Stand for 4.2
• AB-ZE Array Bracket Kit for 2 or 4 ZX1i or EVID Systems, Black
• TC-4B Black Weatherized Terminal Cover for 4.2
• TC-4W White Weatherized Terminal Cover for 4.2
EVID 4.2 Part Numbers:
301046-001 Black
301046-002 White
301046-003 Black, Transformer
301046-004 White, Transformer
Dimension Drawings:
