Electro-Voice SxA100+ User manual

KeyFeatures:
• Compact, Ergonomic Size
• Integral Monitor Stand
• Mic and Line Inputs with Mix Capability
• 350 W Dynamic LF Power
• 80 W Dynamic HF Power
• LF and HF Equalization
• Line Output for Additional Speakers
• 65° x 65° Constant Coverage Horn
• High Sensitivity, 124 dB Maximum SPL
• Dynamic Filters Provide Overload Protection
and Linear Response
• Molded-in Pole Mount, Easily Suspended
SxA100+
Compact Powered Sound
Reiforcement Speaker for
Live Sound, Speech, Playback, DJ,
A/V, Institutional Venues
GeneralDescription:
The Electro-Voice ® SxA100+ sets a new standard for
powered speakers. Its design provides the user multiple
inputs with mix capability, an easy to use EQ section, and
plenty of power in very compact, attractive package.
This is a full range loudspeaker ideal for most applications
requiringhigh-quality sound.Careful attentionto thedynamic
requirements of music guided the amplifier design to provide
highSPLwithoutexcessiveheat.Thehighqualitymicrophone
preamplifier provides great sounding vocals or speech. A
master level control sets the desired SPL, and the line input
can be mixed and balanced with a microphone with its level
control. Its linear response is easily optimized for speech or
music with the on board multiband equalization.
Built-in suspension points and pole mount make it easy to
position for your application without expensive accessories.
Thehigh-frequencysection oftheSxA100+ utilizesamolded-
in, 65° x 65° constant-directivity horn. This unique pattern
contributes to high intelligibility, vocals sound natural yet “cut
through” in reverberant, noisy rooms. Coverage pattern is
uniform, sound quality off-axis is very well maintained, even
at 45° off axis (a 90° total coverage angle). The SxA100+’s
high-frequency horn is driven by the DH2010A, a one-inch-
throat, wide-bandwidth, titanium-diaphragm driver using a
unique,convex-driveTimePathTM phasing plugstructure(U.S.
Patent #4,525,604) for smooth and extended high-frequency
response.
Technical Specifications:
:)Bd01-(esnopseR.qerFzHk02-zH05
:LPSxaMBd421
:egarevoClatnoziroH°56
:egarevoClacitreV°56
:rewoPreifilpmAFLsuounitnoCW051,tsrubsm01W053
:rewoPreifilpmAFHsuounitnoCW05,tsrubsm01W08
:LPSxaMBd421
:ytivitisneStupnIciMtuptuollufrofuBd0otuBd53-
:ytivitisneStupnIeniLtuptuollufrofuBd0otuBd21-
:recudsnarTFL)mm003("21
:recudsnarTFHrevirD.pmoCA0102HDtixe)mm52("1
:srotcennoC :stupnIeniL,ciMdecnalaB :tuptuOdecnalaB noitanibmoCenohp"¼dnaRLX,RLX RLX
:noitazilauqEzH041@Bd6±FL;gnivlehS zHk5@Bd4±FH
:tnemeriuqeRrewoP042-022ro,zH06-05,CAV031-011 sttaW006zH06-05,CAV
:lairetaMerusolcnEremylopoC
:ellirGhtolChtiwleetSdetaoCredwoP
:)DxWxH(miD3.21x"9.61x"1.32 )mm213x924x685"(
:)hcae(thgieWteN)gk5.91(sbl34
:thgieWgnippihS)gk3.12(sbl74

Frequency Response & Impedance:
Beamwidth:
PerformanceMatch:
• SxA180 Subwoofer
• SbA760 Subwoofer
IncludedAccessories:
• F200 Monitor Feet (Qty. 2)
AvailibleAccessories:
• TSS-1 Tripod Stand
• MB100 Eyebolt Suspension Kit
• MB200 Bracket Suspension Kit
• MB300 Bracket Suspension Kit
SxA100+PartNumbers:
• SxA100+ (120V) -- 301360-001
• SxA100+ (230V) -- 301360-003
12000 Portland Avenue South, Burnsville, MN 55337
Phone:[phone], Fax:[phone]
www.electrovoice.com
© Telex Communications, Inc. 7/2006
PartNumber 38110-193 RevC
U.S.A. and Canada only. For customer orders, contact Customer Service at:
800/392-3497 Fax: [phone]
Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:
+ 49 9421-706 0 Fax: + 49 9421-706 265
Other International locations. For customer orders, contact Customer Service at:
+ 1 952 884-4051 Fax: + 1 952 736-4212
For warranty repair or service information, contact the Service Repair department at:
800/685-2606
For technical assistance, contact Technical Support at: 866/78AUDIO
Specifications subject to change without notice.
